Discount Car Stereo A2DIY-C5CD Instruction Manual

Courtesy of: DiscountCarStereo.com
Serving the internet community since 1995
A2DIY-C5CD (Newest Version)
QUICK START BLUETOOTH HANDS-FREE INSTALLATION GUIDE FOR SELECT 1997-04 CORVETTE WITH 12-DISC CD CHANGER
Created January 16, 2013
Revised April 22, 2021

PRODUCT SAFETY & DISCLAIMER
READ ALL INSTRUCTIONS CAREFULLY BEFORE INSTALLING, FAILURE TO DO SO MAY CAUSE
PERSONAL INJURY OR DAMAGE TO PRODUCT AND/OR PROPERTY
•This installation guide is provided as a GENERAL installation guide, some vehicles vary and
may require additional steps. We do not accept responsibility for third party labor charges
or modifications. Exercise due-diligence when installing this product.
•We do not accept any responsibility for vehicle damage or personal injury resulting from
the installation of this product.
•Careless installation and operation can result in equipment damage.
Click here to install older version (with push-to-talk button)
Introduction:
If looking to add Bluetooth features to your American classic with trunk/hatch
mounted 12-disc changer should consider the A2DIY-C5CD Kit. This revised
easy to install kit is essential to adding Bluetooth features to the C5 radio.
This module sounds great for mobile conversations, streaming Pandora, Sirius
radio, Apple music, audiobook, podcast and more. The included media button
(remote) can be mounted on dashboard or steering wheel to adjust volume,
track selection and more. In addition, an optional USB charging port is available
to keep devices charged while on the road. Thanks to the A2DIY-C5CD kit users
keep the radio and CD changer while enjoying Bluetooth features only
available on newer cars.
Trunk/hatch mounted 12-disc changer is required. If
vehicle does not have one or if malfunctions; this product will
not work. Purchase our A2DIY-C5 instead.
See Frequently Asked question at the end of this guide for more details.
Installation: (To radio)
Remove radio from dash to gain access to connectors. Click link below
https://www.youtube.com/watch?v=WTbWYNJTSDs
1. Locate and disconnect factory 20-pin plug from radio as seen in Fig. 1
Fig. 1
radio connector
2. Connect factory 20-pin plug to installation harness 20-pin connector
(white) See Fig. 2
Fig. 2
Fig. 3
installation harness
3. Connect installation harness 20-pin plug (black/gray) (See Fig. 3) to
radio 20-pin connector (See Fig. 1)

Trunk/hatch mounted 12-disc changer
Playback options explained
These options are available at checkout:
1. Retain changer playback (default)
2. Auxiliary input (instead of changer playback)
3. Auxiliary input + changer playback (both)
Retain Changer playback:
Default option that allows users to retain use of their 12-disc changer.
Proceed to installation step 4.
AUX input (instead of changer playback):
This option allows users to connect and play a portable audio device (e.g.
sat radio, Alexa, iPod, Mp3 etc.) instead of 12-disc changer)
WARNING: The required CD changer remains connected but will no
longer play. (At least one disc must be loaded to magazine)
1. Connect included 3.5mm audio cable (See Fig. 4) to module “AUX” jack
2. Route audio cable plug to where audio device will reside (within 3 ft.)
3. Proceed to installation step 4.
AUX Jack+ changer playback
With this option, AUX plus 12-disc changer playback are possible.
1. Route installation harness aux jack (See Fig. 5) to glove box, dash area
etc. (cable is 3 ft. long)
2. Drill a ¼” hole in dash or panel and secure jack with included nut or
leave freestanding.
3. To listen to audio device (e.g. Mp3 player) simply connects to jack. To
listen to the CD changer, disconnect audio device from jack (jack
must be empty during changer playback).
Proceed to installation step 4
Module
Fig. 4
3.5male to male audio cable
Fig. 5

4. Remove tape backing and attach microphone mounting bracket to
headliner, sun visor etc.; route cable down pillar, under dashboard
toward module location and connect to module “MIC” input. (See Fig.
6)
Wind noise (Convertibles) will negatively affect phone audio. Users are
advised to install microphone away from wind/ventilation ducts etc. or
opt for push button microphone seen in Fig. 7
Visor microphone
Fig. 6
Optional button-style microphone:
For added installation flexibility, we offer optional button-style microphone. (See
Fig. 7). Adding this option replaces standard visor microphone shown in Fig. 6).
To install, route 1/8” plug to module location behind the dash and connect to MIC
input jack on module. To secure button, clean area with alcohol, remove tape
backing and attach to dash (cable is 6ft. long). We recommend testing mic
audio from multiple dashboard locations prior to finalizing install.
Warning: This option includes microphone only. The button has no function.
Fig. 7

Optional USB “Fast Charge” Kit (not for thumb drives etc.)
Optional USB charger can be added to the A2DIY-C5CD Kit. Should you decide to
add it, we suggest one of 3 connecting options:
A. Flush to dash/panel requires drilling a ¾” hole
B. Flush with Support bracket (Mount USB terminal wherever your installation
demands without drilling)
C. USB port- (default)
A. Flush to Dash or Panel (drilling required)
1. Drill a ¾” hole in the dash or panel using a step drill bit or equivalent
(See Fig. 10)
Fig. 10
Step drill bit
2. Insert supplied 3ft. USB male terminal (See Fig. 11) through hole
created in step 1 and connect to module USB port (See Fig. 12)
Fig. 11
Flush mount 3 ft. USB cable
Fig. 12
USB port
3. Snap USB head (See Fig. 13) in place and flush with mounting surface
(See Fig. 14)
Fig. 13
USB head

Fig. 14
Flush mounted to dash
4. Tuck and secure any extra wire from moving parts and test operation
B. Bracket Mount (No drilling)
1. Locate a flat surface at location of choice within 3.2 ft. of module and
mount USB support bracket (See Fig. 15) to surface using
adhesive/tape or screws (included).
Fig. 15
USB mounting bracket
2. Insert male terminal through hole in bracket (See Fig. 16) and connect
to module USB port (See Fig. 12)
Fig. 16
3. Snap USB head (See Fig. 16) to bracket until flush (See Fig. 17)
Fig. 17
4. Tuck and secure any extra wire away from moving parts and test
operation ( See Bluetooth Pairing and Connection )

Bluetooth Media button
Pairing media button: Ensure Bluetooth is enabled on your device (e.g.,
Smartphone/Tablet etc.) scan/search for available devices and select BT009
from list. Media button can be paired with multiple devices but can only operate
one at a time.
Fig. 18
Installing media button:
Attach button to steering wheel (includes holder) or dashboard to safely and
conveniently control multi-media functions even when smartphone is out of
reach.
Charging Media Button:
Media button has a built-in rechargeable 200mAH battery which may last up to
10 days. Use supplied USB cable to connect media button to charging source.
Reaches full charge after 2 hours.
Media button Operation:
Once paired with smartphone/Tablet, users may perform the following functions
on iOS devices with Bluetooth 3.0 and later and Android 4.0 or later.
These functions do not apply to the Jaguar radio.

Bluetooth pairing and connection
This process must be carried out upon initial install after which the A2DIY-JAG97
will automatically reconnect with paired phone.
1. Go to smartphone settings and enable Bluetooth
2. Smartphone will automatically begin searching for devices.
3. Select Bluetooth name below, tap “Connect”
Note: Supports multiple phone pairings but connects to one phone at a time.
If for some reason phone fails to pair, ensure no other has paired to module in
such case you must unpair that device in other to pair another.
Caller ID and text are not shown on radio screen.
Operate Bluetooth device via wireless remote control, VR
(voice recognition) or deice built-in controls. Radio
buttons can be used to adjust playback level.
Test Operation:
1. Turn ignition and radio “ON”
2. Press AUX button on radio.
3. Launch smartphone music streaming application
4. Set audio device initial volume to 80% and raise radio volume knob to set
playback level. If distorted, lower audio device volume.
5. Use media button to change tracks, adjust device volume, pause etc.
6. Place test call or ask someone to call. Press Pause/Play to
answer/end call
7. To switch between CD or AUX playback and music stream press media
button Pause/Play
8. If correct operation is confirmed go ahead and reinstall radio.
Notes:
1. On incoming calls, ring tone also plays through car speakers
2. AUX has playback priority.
3. *Media button does not control aux device or radio. Use AUX device
built-in buttons for music selection and controls.

Feature comparison:
The following chart illustrates the requirements and features offered by our
exclusive C5 Bluetooth modules.
FYI: Our Bluetooth kits are defined as music streaming and/or hands-free.
Bluetooth music streaming modules do not support hands-free calls, but our
hands-free calling modules support music streaming.
Features/Requirements
A2D-C5
A2DIY-C5
BLU-C5
A2DIY-C5CD
C5CD-HF
C5-HF
Retains changer playback
YES
NO
NO
YES*
YES*
NO
Requires CD changer
YES
NO
NO
YES
YES
NO
Audio input jack (Aux in)
NO
YES
NO
*
*
YES
USB charging port
optional
optional
optional
Optional
YES
YES
Supports Hands-free calls
NO
YES
NO
YES
YES
YES
Connect to radio
YES
YES
YES
YES
YES
YES
Connects to changer
YES
NO
YES
NO
NO
NO
Supports voice activation
**
**
**
**
YES
YES
Wireless remote control
optional
YES
optional
YES
NO
NO
Push-to-talk button
NO
NO
NO
NO
YES
YES
Controls from radio
NO
NO
NO
NO
NO
NO
Aux input and/or CD changer playback retention
** Voice Activation possible from device buttons
Frequent asked questions
1. What is the difference between the C5CD-HF and A2DIY-C5CD?
The A2DIY-C5CD includes media button (remote) and optional push button
microphone. The C5CD-HF does not include media button and the push-to-
talk button with built-in mic is standard. See feature comparison table for
more details,
2. What is the difference between the A2D-C5 and A2DIY-C5CD?
The A2DiY-C5 both music streaming and Hand-free calls. The A2D-C5 does
not support hands-free calls.
3. Does the A2DIY-C5CD work on all C5 radios?
Works in 1997-04 C5 with Theftlock AM/FM/CD or AM/FM/Cassette with
functioning 12-disc changer in trunk/hatch. (will not work if changer
malfunctions). See our A2DIY-C5
4. Will radio display call number or song name?
NO. These features are not possible on this generation C5 radio.
5. Is it possible to control smartphone music from radio buttons?
NO; Use smartphone or audio device built-in controls, media button or
voice commands. Use radio volume button to set playback level.
6. I selected the option to retain CD changer playback but how do I listen
to CD’s?
Press AUX button on radio to enter Bluetooth mode (if not already), then
press Pause/Play on media button.
7. I selected option to retain changer playback plus AUX input; but how
do I listen to AUX device?
Press AUX button on radio to enter Bluetooth Mode (if not already), Connect
aux device to 3.5mm jack, press Play/Pause on media button. To stream
music, repeat aforementioned steps.
8. I selected option to retain changer playback plus AUX input; but how
do I listen to CD changer?
Press AUX button on radio to enter Bluetooth Mode (if not already), ensure
aux jack is empty, then press Play/Pause on media button
9. Will radio mute when call is made and/or received?
Muting is only possible when radio is in “AUX/Bluetooth mode. If in AM/FM
mode; radio will not mute. Radio must be switched to “AUX” to hear callers
voice on car speakers.

10. My second phone does not pair or find Bluetooth module. Why not?
Ensure no other phone is paired. Allow module to enter “discovery” mode
at which point it will be ready for pairing.
11. Will I be able to connect a flash drive to optional USB port?
NO; Optional USB port does not support thumb/flash drives. Charge only.
How do I remove radio from dashboard to install module?
The ADIY-C5CD connects to the radio. Click link for video instructions:
https://www.youtube.com/watch?v=WTbWYNJTSDs
12. Will radio CD player or Tape player work after installing this module?
YES! The CD player or Tape player built-into AM/FM radio or remote 12-disc
changer operation are not affected by this module.
13. Callers not able to hear my voice with top down (convertible).
Can you offer some guidance?
In convertibles, microphone mounted to visor is exposed to wind noise.
Notable, callers will have no issue while vehicle is standing. Our microphone
includes noise cancellation features, which is different than wind noise and
our recommendation is to install microphone in an area less susceptible to
wind noise (e.g., pillar, mirror etc.). This may not be an issue with optional
push button with built-in mic.
Disclaimer
• This product has no affiliation with GM or Apple
• When possible, professional installation is recommended
Email [e-mail]
© 1995-Apr-21 Discount Car Stereo, Inc. All rights reserved. Information in this document is
subject to change without notice. Other products and companies referred to herein are
trademarks or registered trademarks of their respective companies or mark holders.
