disperator 500A-GTS-E65 EXCELLENT SERIES User manual

FOOD WASTE PROCESSOR
500A-GTS-E65 EXCELLENT SERIES
Product Descripon Installaon Safety Operaon Service
USER MANUAL
User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se

User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se

User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
Statement of Compliance
DNV·GL
Folder: A1003885
Document N14240EG
no:






Regulation 4
Discharge of garbage outside special areas
 

 
 

Regulation 5
Special requiremen r discharge of garbage from jed or oating plaorms
 

 

Regulation 6
Discharge  garbage within special areas
 

 
 


® 
 



lf any person suffers loss or damage which is proven to have been caused by any negligent act or emission of the Society, then the Society shall pay compensation ta such person for his proven direct loss or damage. However, the
compensation shall not exceed an amount equal to ten times the fee charged for the service in question. The maximum compensation shall never exceed USD 2 million.
In this provision the “Society” shall mean DNV GLAS as well as all its direct and indirect owners, affiliates, subsidiaries, directors, officers, employees, agents and any other person or entity acting on behalf of DNV GLAS.
© DNV GL 2014. DNV GL AND THE HORIZON GRAPHIC ARE TRADEMARKS OF DNV GLAS.
Form No.: 40.91a lssue: 2014-07
w.dnvgl.com
Page 1 of 1

User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
Table of Contents
1. Safety Precauons _______________________________________________________ 7
1.1. Safety Signs __________________________________________________________ 7
1.2. Personnel Qualicaons and Training______________________________________ 8
2. Company Prole _________________________________________________________ 9
3. Product Descripon and Technical Specicaon _______________________________ 10
3.1. Food Waste Processor 500A-GTS-E65 EXCELLENT-Series for Free-standing
Installaon___________________________________________________________ 10
3.2. Technical Specicaon _________________________________________________ 11
4. Storage and Displacement _________________________________________________ 18
4.1. Storage of the Machine_________________________________________________ 18
4.2. Displacement of the Machine____________________________________________ 18
5. Included in Delivery ______________________________________________________ 19
5.1. Documentaon _______________________________________________________ 19
5.2. Kvarn med montage ___________________________________________________ 19
6. Installaon Descripon for the Machine _____________________________________ 20
6.1. Assembly of the Machine _______________________________________________ 20
6.1.1. Deployment of the Machine ___________________________________________ 20
6.1.2. Fixaon of the Machine _____________________________________________ 20
6.1.3. Mounng of the Splash Guard ________________________________________ 20
6.2. Flushing Water _______________________________________________________ 21
6.2.1. Water Pipe DN15___________________________________________________ 21
6.2.2. Line Strainer DN15 and Solenoid Valve DN15_____________________________ 21
6.2.3. Hose with Protecve Steel-Covered Stocking for Flushing Water,
Minimum Inner-Ø 9mm _____________________________________________ 21
6.3. Connecon of Pump Outlet to Drain Waste Pipe going to Tank__________________ 22
6.3.1. To Check before the Connecon is made ________________________________ 22
6.3.2. Specicaon and Connecon of Drain Waste Pipe_________________________ 22
6.4. Electrical Connecon___________________________________________________ 23
6.4.1. Supply Voltage_____________________________________________________ 23
6.4.2. Mains Fuses _______________________________________________________ 23
6.4.3. Wall/Bulkhead Mounted Electrical Security Breaker _______________________ 23
6.4.4. Cable Dimension ___________________________________________________ 23
6.4.5. Cable Protecon ___________________________________________________ 23
6.4.6. Earth Wire ________________________________________________________ 23
6.4.7. Direcon of Rotaon for the Disposer and the Pump ______________________ 24
6.4.8. Protecve Cover Connected to Safety Interlock Switch _____________________ 24
6.4.9. Sensor for Monitoring Pump Temperature_______________________________ 24

User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
6.5. Start Up and Final Tesng _______________________________________________ 25
6.5.1. Check before Start Up _______________________________________________ 25
6.5.2. Important Preparaons before Starng-up the Machine____________________ 25
6.5.3. Checks during Start-up ______________________________________________ 25
6.5.4. Seng the Monitoring of the Pump’s Temperature________________________ 25
6.5.5. Final Measures ____________________________________________________ 26
7. Installaon Instrucons for Level Sensors and Overll Protecon in the Tank ________ 27
8. Safety Instrucons _______________________________________________________ 31
9. Operang Instrucons ____________________________________________________ 32
9.1. Start and stop ________________________________________________________ 33
9.2. Daily cleaning of the disposer ____________________________________________ 33
9.4. Trouble Shoong ______________________________________________________ 34
9.4.1. Disposer Reduces Speed, Stops or does not Start _________________________ 34
9.4.2. Machine Starts but there is no Flushing Water ___________________________ 34
9.4.3. Machine does not Start and makes no Sound ____________________________ 34
10. Service Instrucons _____________________________________________________ 35
10.1. Authorizaon________________________________________________________ 35
10.2. Exploded View and Spare Parts List for the Disposer _________________________ 36
10.3. Overhaul of Protecon Cover with Switch, Assembly and Connecons __________ 41
10.4. Overhaul and Maintenance of the Pump __________________________________ 41
10.5. Dismantling of Disposer _______________________________________________ 42
10.6. Assembly of Disposer _________________________________________________ 45
10.7. Overhaul and Maintenance Intervals _____________________________________ 48

User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
7 / 48
This manual contains instrucons for installaon, operaon and maintenance of the food waste disposer
(below also called the machine). It is therefore essenal for the installer, union representaves and
users of the machine to read the manual thoroughly prior to installaon, commissioning, operaon and
overhaul & maintenance.
This manual must always be at hand where the machine is being used.
It is not only the general safety instrucons in this secon that need to be considered, but also the other
special safety instrucons given in this manual.
1. Safety Precautions
1.1. Safety Signs
The following safety signs are used in this manual and on the machine. Failure to comply with the safety
regulaons contained in this manual as well as on the machine may cause personal injury or damage the
machine.
Read this User Manual before use
Use protecve goggles
Use ear protecon
Warning for electric voltage
General personal danger
Warning for mechanically caused damage (rotang parts)
Warning plates located on or close to the machine must always be observed and kept legible.

User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
8 / 48
1.2. Personnel Qualications and Training
All personnel managing the below tasks for the machine as described in this manual, must have the
necessary qualicaons to carry out this work. Areas of responsibility, scope of authority and sta
supervision must be carefully dened by the machine owner. If the personnel do not have the necessary
qualicaons for this, they must receive training and instrucons. Such training can be provided by the
manufacturer / supplier. Moreover, it is the responsibility of the machine owner to make sure that all
users read and understand the content of this User Manual.
Moving the Machine
Sta responsible for moving the machine must have knowledge about the handling of the liing gear
and stopping devices and have knowledge of applicable safety regulaons for these. If they lack this
knowledge, they must receive the required training.
Installaon
Personnel responsible for the installaon of the machine must have knowledge equivalent to educaon
in industrial mechanics/technician. The electric connecon must be performed by trained and cered
electrician.
Commissioning and Maintenance
Personnel responsible for commissioning, overhaul and maintenance of the machine must be familiar
with all funcons, and how to operate these funcons. Furthermore, they must know of all safety
precauons in this manual, and which in other respects also are valid where the machine is used.
Operaon
All persons who operate and maintain the machine must be aware of the risks that may occur with its use
and as described in this manual.
Service and Repair
Responsible personnel for service and repair of the machine must have knowledge equivalent to
educaon in industrial and design mechanics, and also know and understand the technical data of the
machine described in this manual. Assisng personnel for these jobs must be trained and performed
repair work must be checked by the machine owner.

User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
9 / 48
8 / 48
2. Company Prole
Disperator’s business idea is to provide innovave and adapve equipment for kitchens on land as well
as galleys at sea, and for the food processing industry, which enables ecient collecon of communited
food leovers for anaerobic digeson or composng in subsequent stages, which is of benet to society.
With over 70 years of experience in the development and producon of such equipment, our devoon
to this has resulted in the unique operaonal reliability required for the extreme condions prevailing in
the marine industry. Furthermore, our innovaveness has provided commercial kitchens on land with an
alternave approach to handle food waste separaon at source, complying with modern demands and
being economically aordable.
Our product assortment is unique! Disperator can as the only manufacturer of such equipment oer
all types of installaon possibilies needed in a kitchen. Our basic range of ve dierent series of
water-based food waste disposers, consisng of three to six dierent sizes in each serie, which may be
combined with as many as 13 dierent mounng assemblies. Furthermore, the advantage of the basic
model’s design is that the waste disposers may easily be integrated into other kitchen manufacturer’s
mounng assembly or furniture. Thereby, each workplace in a kithen or galley can be designed to its
specic requirements regarding funcon, ergonomics and economy. To all this there is also the dierent
series of water-saving processor technology for collecon and storage of grinded food waste in a tank, as
well as disposers that grinds food waste without any ushing water at all.

User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
10 / 48
3. Product Description and Technical Specication
3.1. Food Waste Processor 500A-GTS-E65 EXCELLENT-Series for Free-standing
Installation
Immediately and eciently removing the heaviest part of kitchen waste – i.e. food leovers - is a
necessity in any commercial kitchen. In the event water-based food waste disposers connected to the
municipal sewer system is not permied in your community, a by Disperator developed unique and
patent pending technology can handle the task for you. When using a GTS-Series processor, food waste
can hygienically and without any heavy liing or manual transfer easily take care of and reduce the total
amount of refuse – by volume, but especially in the handling of the total weight in dierent transport
phases!
Regardless of the selected model, the disposal procedure is the same. Food waste is fed down the inlet
hopper of the machine and ground into small parcles in a disposer for further transport in a pipe using
a processor pump to a sealed and odorless tank. The tank is emped by a vacuum truck approximately
every four weeks or according to the driving schedule that applies in your municipality. Depending upon
preference, the tank may be placed outdoors buried in the ground, as well as placed indoors. One of the
unique benets of this processor technology is that the pumping of the ground food waste can be done
with minimal amount of ushing water, which gives a good operang economy as the tank does not
need to be emped as oen. The slurry is transported to an anaerobic digeson facility and converted
into valuable renewable energy resource (i.e. biogas), and oen the digested residue can also be used
as ferlizer on farmland. Biogas is one of our society’s most environmentally clean and desired energy
forms, as fuel for vehicles as well as to produce heat and electricity.
In its standard version the GTS-processor has a capacity of up to 15 l/min. With an average amount of
food waste of 0.15 l/served meal, the processor can take care of food waste generated by as many as
4,000 served guests/hour. And this even though the storage tank, if required, can be located over 100
meters away.
To suit exisng interior and logiscs within the kitchen, the E65-processor outlet may be posioned
either to the le or to the right of infeed opening, thus giving full exibility in planning your kitchen and
possibility to fully ulize valuable space. Disperator’s broad assortment of dierent technical soluons
for source separaon of food waste can be adapted to your specic kitchen and your specic working
environment, regardless of size or layout, and regardless of the specic municipal’s food waste handling
rules in your community!
Food waste disposers within the Disperator Excellent Series have the Declaraon of Compliance issued
by DNV, verifying compliance with applicable secons of MARPOL consolidated edion 2017 ANNEX V for
disposal of ground food waste into the open sea.

User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
11 / 48
10 / 48
3.2. Technical Specication







660
835
35 - 105
1046
~135
135
1400
903
784

















































User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
12 / 48







386
612
480
20 - 80
20 - 92
 


















36
50
6,5
50

User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
13 / 48
12 / 48







386
612
480
20 - 80
20 - 92












































User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
14 / 48







 






   
   
   
   
   
   
   
   
388
81
205

























User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
15 / 48
14 / 48

















¡


¡



¢

£

¡

£

£




¢



¢






¤
¤


¥
¢
¥



User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
16 / 48






¡





£




¢



¢






¤
¤


¥
¢
¥


£

¡

£




¡



¢





¡

User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
17 / 48
16 / 48








¦ 
§¢ 

¦ 
¢¨ 

¦ 
££

¥



¡
¦
¦©¢
¦¢
¦¢ 

¦ 

¢
¦¢
 ¡  
   ¡
¢   
£¤ ¤ ¤ ¤

¥¤ ¡¤ ¤ ¤
¥¤ ¡¤ ¤ ¤
 ¥ ¥ ¥
   
   
   
   

¦   
¦   
§¤§



User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
18 / 48
4. Storage and Displacement
4.1. Storage of the Machine
If the machine will be stocked before installaon and use the following applies:
• The machine should be stored in a dry and clean room where the relave humidity may not
exceed 60%.
• Recommended storage temperature of -20 °C to + 60 °C.
4.2. Displacement of the Machine
The machine should not be lied or moved by hand. During installaon, we recommend using a
pallet jack or forkli, and during service a liing trolley for component parts (like the disposer placed
inside the cabinet) in the machine.

User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
19 / 48
18 / 48
5. Included in Delivery
5.1. Documentation
• This User Manual
• Safety Instrucon (laminated)
• Operang Instrucon (laminated)
• The Operang and Maintenance Instrucon in original for the processor pump
• Electric documentaon (connecon and wiring diagram, component layout diagram)
5.2. Kvarn med montage
Food Waste Processor Inlet on 4pcs of
adjustable legs according to enclosed delivery
note, including (for more detailed descripon
see also secon 3.2 on page 11-16 in this
manual):
• disposer of ordered model and
motor voltage,
• pump of ordered model and
motor voltage, incl. temperature
monitor with display,
• complete control system according
to this manual aached electrical
connecon and wiring diagram,
and component layout diagram,
mounted in IP66 rated enclosure,
including:
• contactor for disposer and
pump with reseable motor
protecon, zero-voltage
release and operang coil,
• controls with push-buons
and indicator lights,
• running me gauge,
• solenoid valve and line
strainer, G½”,
• safety interlock switch.
Splash guard, 1 pc. for ”on-site assembly” on
the inlet bench as shown on the above photo,
and also in secon 3.2, page 13.
Bracket, 2 pcs. for xing the machine against
long wall (or corner wall) as shown in secon
3.2, page 12.
Jam release wrench, 1pc. for release of
disposer grinding unit, if a non-grindable
object by mistake happens to fall therein. Is
placed in the holder on the le-hand door
inside the cabinet.

User manual in Original
Doc. ref: 500A_GTS-E65_am_en_210608
DISPERATOR AB Tel: [phone] E-mail: [e-mail]
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
20 / 48
6. Installation Description for the Machine
6.1.1. Deployment of the Machine
Unless otherwise requested in your order, the machine comes with its legs on a pallet. To
minimize the risk of injury, at least two persons must be present when the machine is deployed.
The machine has a net weight as per secon 3.2 above, page 14, so the liing equipment (e.g.
forkli and pallet jack) to be used must be checked to withstand this weight.
Li the machine from the pallet at the socket posions in the cabinet boom plate shown in the
“Front view” in secon 3.2, page 11 in this manual. Then move the machine to the designated
place of installaon.
Before the machine is set down on the oor, adjust the four legs so that the desired machine
height is obtained. Aer the machine has been placed on the oor, check with a spirit level that it
is horizontal, and adjust the legs if necessary.
6.1.2. Fixation of the Machine
The machine must be xed to the wall/bulkhead or oor/oor plate. When stopping quickly
(e.g. if cutlery mistakenly jams the grinding unit) the torque of the disposer motor will cause
the machine to turn. This can give undesirable forces on the pump’s connecon to the drain
pipe that goes to the tank (see paragraph 6.3 below), which can cause leakage. To prevent this,
two adjustable brackets are included in the delivery for xing the machine against a long wall or
alternavely using 1pc against long wall and 1pc against corner wall. See secon 3.2 (page 12,
“Top view”) and secon 5.2 above.
For marine installaon the machine is instead xed by means of e.g. plates which are welded to
the oor plate, whereupon the machine legs are placed and screwed onto these plates as shown
below.
6.1.3. Mounting of the Splash Guard
The delivered splash guard (see secon 5.2 above) to be mounted against the outer edge of
the cabinet top plate in such a way that one side of the cover is placed on back of the cabinet.
Depending on the wishes of the kitchen, one or both short sides of the machine may also be
equipped with splash guard. See secon 3.2 above, page 13. Fix the delivered splash guard by
screwing into the ready made holes in the outer edge of the cabinet top plate. Aer the splash
guard has been xed by screwing into these holes, seal o the gap between the top plate and
splash guard with rubber sealant (silicone).
6.1. Assembly of the Machine
