Dividia DVS User manual

Digital Video Server
User Guide
Version 3.0
by Dividia Technologies, L.L.C.
01/05/2009

2

3
DISCLAIMER
No warranty or representation, either expressed or implied, is made with respect to the contents of this documentation, its
quality, performance, merchantability, or tness for a particular purpose. Information presented in this documentation
has been carefully checked for reliability; however, no responsibilities are assumed for inaccuracies. The information
contained in this documentation is subject to change without notice.
In no event will Dividia Technologies be liable for direct, indirect, special, incidental, or consequential damages arising
out of the use or inability to use this product or documentation, even if advised of the possibility of such damages.
COPYRIGHT
2002-2009 by Dividia Technologies, L.L.C. All rights reserved. No part of this publication may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language in any form by any means without the written
permission of Dividia Technologies, L.L.C.

4

Contents
1 Preface 7
1.1 PackageContents.................................................. 7
1.2 Specications.................................................... 8
1.3 LimitedWarranty ................................................. 8
1.3.1 WarrantyLength.............................................. 8
1.3.2 Whoisprotected? ............................................. 8
1.3.3 Whatisandisnotcovered?........................................ 8
1.3.4 What we will and will not pay for? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.3.5 ContactInformation............................................ 9
2 DVS Introduction 11
3 Live Video Monitoring 13
3.1 1-CameraDisplay................................................. 14
3.2 4-CameraSplitDisplay.............................................. 14
3.3 8-CameraSplitDisplay.............................................. 14
3.4 9-CameraSplitDisplay.............................................. 14
3.5 16-CameraSplitDisplay............................................. 15
3.6 FullScreenDisplay................................................. 15
3.7 AutoScan...................................................... 15
4 Playback of Recorded Video 17
4.1 Overview ...................................................... 17
4.2 VideoPreview ................................................... 18
4.3 VideoPlayer .................................................... 18
5 Setting up your DVS System 19
5.1 SystemSetup.................................................... 20
5.1.1 DVRName................................................. 20
5.1.2 RecordingFrameRate........................................... 20
5.1.3 AutoScanInterval............................................. 20
5.1.4 EmailSetup................................................. 21
5

6 CONTENTS
5.1.5 DigitalOutput(Optional)......................................... 21
5.2 DeviceSetup .................................................... 22
5.3 UsersSetup..................................................... 23
5.3.1 Overview .................................................. 23
5.3.2 SetupaNewUser ............................................. 23
5.3.3 Setup a New User by Copying an existing User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.3.4 EditUserAccessRights.......................................... 24
5.3.5 DeleteaUserfromthesystem ...................................... 24
5.3.6 ApplyingChangesforauser ....................................... 24
5.4 CameraSetup.................................................... 25
5.4.1 General ................................................... 25
5.4.2 Video .................................................... 26
5.4.3 PTZ..................................................... 28
5.5 Date/TimeSetup.................................................. 29
5.6 NetworkSetup ................................................... 30
5.7 Report........................................................ 31
5.7.1 Summary .................................................. 31
5.7.2 CameraActivity .............................................. 32
5.7.3 Alarm(Optional).............................................. 33
5.7.4 POSReports ................................................ 34
5.8 POS(Optional)................................................... 35
5.8.1 JWS/Apex(Optional).......................................... 36
5.8.2 ValveSensing(Optional) ......................................... 37
5.8.3 ScaleSensing(Optional).......................................... 38
5.8.4 PTZ Control Conguration (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.8.5 Digital Output Conguration (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6 Utilities 41
6.1 Export........................................................ 41
6.2 Report........................................................ 42
6.3 JWS Ticket Searching (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
6.4 Support ....................................................... 43
7 Remote Access 45

Chapter 1
Preface
Dividia Technologies Digital Video Server (DVS) is the latest in digital surveillance technology. It enables you to more
easily manage and catalog your video information. Your DVS implements the latest in Motion Detection technology.
When activity is detected, it automatically catalogs this information for easy access at a later time. The system will
automatically alert you to the events you are interested in. You no longer need to wade through hours of video to nd
the information you need.
1.1 Package Contents
Dividia Technologies DVS package includes:
• DVS (Digital Video Server)
• Power Cable
• Keyboard and Mouse
• BNC Breakout Cable(s)
7

8 CHAPTER 1. PREFACE
1.2 Specications
Features
Standard HDD 250GB - 750GB
Maximum HDD 2TB
Minimum Storage 15 Days
Raid Mirroring Optional
External Storage DVD, HDD, USB
Video Compression MPEG4
Resolution 320 X 240, 640 X 480
Recording Modes Motion, 24/7
FPS per Camera 1 - 30
Display Modes 1, 4, 8, 9, or 16
Search Modes Time/Date and text (only w/ POS Interface)
PTZ Support Yes
Network Capability Yes
Export Video Yes
Field Upgradeable Yes
Operating System Linux
Video System NTSC
Video Inputs BNC
Video Outputs VGA
Supported Cameras CCTV, TCP, IP
Dimensions 16.7 X 6.3 X 16
Weight 23.5lbs
AC Power Input 115/230V
1.3 Limited Warranty
Dividia Technologies, L.L.C. warrants that this product to be free of defects resulting from faulty manufacturing or
components under the following terms:
1.3.1 Warranty Length
Labor is warranted for 12 months from the date of purchase.
Replacement products will be warranted for 12 months from the date of purchase.
All warranted items must be shipped to Dividia Technologies, L.L.C. for work to be completed unless otherwise stated.
1.3.2 Who is protected?
This warranty is enforceable only by the rst consumer purchaser.
1.3.3 What is and is not covered?
Except as specied below, this warranty covers all defects resulting from faulty manufacturing of this product. The
following are not covered by the warranty.
1. Any product on which the serial number has been defaced, modied, or removed.
2. Damage, deterioration, or malfunction resulting from:

1.3. LIMITED WARRANTY 9
• Accident, abuse, misuse, neglect, re, water, lightning, or other acts of nature, unauthorized product modi-
cation, or failure to follow instructions included with the product.
• Misapplication of service by someone other than the manufacturer's representative.
• Any shipment damages. (Claims must be made with carriers)
• Any other cause that does not relate to a product defect.
3. Cartons, cases, batteries, cabinets, tapes, or accessories used with the product.
4. Dividia Technologies, L.L.C. does not warrant that this product will meet your requirements; it is your responsibility
to determine the suitability of this product for your purpose.
1.3.4 What we will and will not pay for?
We will pay labor and material expenses for covered items. However, we will not pay for the following:
1. Removal or installation charges
2. Shipping charges
3. Any incidental charges
1.3.5 Contact Information
2901 Alta Mere Dr, Suite 800
Fort Worth, TX 76116
TEL: [phone]
FAX: [phone]
WEB: www.dividia.net

10 CHAPTER 1. PREFACE

Chapter 2
DVS Introduction
Once everything is connected properly, press the power button located on the front of the DVS system. This will begin
the boot-up process. Once the system completes the self-test and normal boot-up procedure, you are presented with a
login screen. Before you can begin to use your new DVS, you must rst login. This keeps unauthorized persons from
accessing your video information.
There are varying levels of access to your DVS system. By default, the admin account has access to all features of the
system. To start using your system, please login with the default information:
Username Password
admin admin
11

12 CHAPTER 2. DVS INTRODUCTION

Chapter 3
Live Video Monitoring
After logging into the system, you are presented with the Live Monitoring screen. This screen allows you to view all your
cameras in varying congurations on the screen. There are 5 split display modes to choose from:
13

14 CHAPTER 3. LIVE VIDEO MONITORING
1 - Camera Display
4 - Camera Split Display
8 - Camera Split Display
9 - Camera Split Display
16 - Camera Split Display
3.1 1 - Camera Display
In this display, you are able to monitor a single camera at a time. While in this display, you will be presented with a
button for each camera 1-16 to choose from. By clicking on one of these buttons, that camera will be displayed.
3.2 4 - Camera Split Display
In this display, you are able to view 4 cameras at a time. The groups of cameras displayed will be 1-4, 5-8, 9-12, and
13-16 depending on the number of cameras supported by your DVS. If all the cameras for a particular group have been
disabled, then that button will be inactive. You will not be able to click on an inactive button.
If you would like to view one of the cameras in the display in full view, then double click on that camera. When you
would like to return to the split display, double click on the camera's video. This will return you to your split display.
3.3 8 - Camera Split Display
In this display, you are able to view 8 cameras at a time. This display is only available on systems supporting 8 or more
cameras. The groups of cameras displayed will be 1-8 and 9-16 depending on the number of cameras supported by your
DVS. If all the cameras for a particular group have been disabled, then that button will be inactive. You will not be able
to click on an inactive button.
This display is very eective when monitoring several areas at one time. You are able to double click on any camera's
video to move that camera to the large display area. However, the other 7 cameras remain visible for monitoring at the
same time. This way, you are able to continue monitoring all cameras while reviewing a certain camera.
3.4 9 - Camera Split Display
In this display, you are able to view 9 cameras at a time. This display is only available on systems supporting 9 or more
cameras. The groups of cameras displayed will be 1-9 and 8-16 depending on the number of cameras supported by your
DVS. If all cameras for a particular group have been disabled, then that button will be inactive. You will not be able to
click on an inactive button.
If you would like to view one of the cameras in the display in full view, then double click on that camera. When you
would like to return to the split display, double click on the camera's video. This will return you to your split display.

3.5. 16 - CAMERA SPLIT DISPLAY 15
3.5 16 - Camera Split Display
In this display, you are able to view 16 cameras at a time. This display is only available on systems supporting 16
cameras. The group of cameras displayed will be 1-16.
If you would like to view one of the cameras in the display in full view, then double click on that camera. When you
would like to return to the split display, double click on the camera's video. This will return you to your split display.
3.6 Full Screen Display
From this screen, you are also able to monitor your cameras in full screen. This makes the camera viewing area take all
the available space on the screen. You are still able to move from single to split display while in full screen mode.
To exit the full screen display, right click anywhere on the screen.
3.7 Auto Scan
In each of the above mentioned camera displays, you are able to turn on auto scan. Auto Scan allows you to scan through
each of the camera groups continuously. For instance, if you are in 1 Camera Display, Auto Scan will move from Camera
1 to Camera 2, etc. The Auto Scan interval defaults to 10 seconds; however, this interval can be congured through
system setup. Click on any camera group to exit Auto Scan.

16 CHAPTER 3. LIVE VIDEO MONITORING

Chapter 4
Playback of Recorded Video
4.1 Overview
The playback screen allows you to access all recorded video. You are able to retrieve recorded video by Date and Time.
Additionally, you can apply various Filters to the search. Each lter, limits the amount of video you have to review to
nd the video you are looking for. You can view video using the following procedure:
17

18 CHAPTER 4. PLAYBACK OF RECORDED VIDEO
1. Select a camera to view.
2. Select any Filters you wish to have applied to the search.
3. Select a Date and Time.
4. Click the Find button.
If no video was found for that camera, then you will receive a prompt notifying you that there is nothing to review.
Otherwise, your desired video will start playing automatically.
4.2 Video Preview
The video review area consists of two sections. On the left will be the video preview area. This area contains snapshots
of the activity that occurred around your desired time. Click on a preview snapshot to begin playing that segment of
video. The video will begin to play in the player section of the video review area.
If the video you are looking for is not located in the preview area, you can click the Next or Previous buttons to load
another set of 9 previews. In this, you are able to quickly step through all recorded video for this camera. For instance,
you may be looking for the time a car left your parking lot. You could easily scan through hours of video to determine
when the car left, all without the need to watch video.
4.3 Video Player
From the player section, you are able to control the video with VCR like controls. You can Play, Pause, Stop, Rewind,
and Fast Forward the video. If you would like to see more detail, you can click the Full Screen button. While in the Full
Screen view, only the player is visible. This allows for an optimum viewing experience. When you are ready to leave Full
Screen, just click the Full Screen button again to exit this display.

Chapter 5
Setting up your DVS System
From the Setup screen, you are able to change how your DVS system operates. You are able to Setup the following:
1. System
This section contains basic system settings such as Auto Scan Interval, UPS support, etc.
2. Device
This seciton allows you to add camera input devices (Capture Cards, Moxa's, Network Cameras, etc).
3. Users
This section allows you to add and remove users from the system. You can also change access rights.
4. Cameras
This section allows you to adjust camera settings, such as Name, Brightness, etc.
5. Date/Time
This section allows you to adjust the Date and Time settings of your DVS.
6. Network
This section allows you to adjust your networks settings, such as DHCP, Static, DNS, etc.
7. Report
This section allows you to create various reports, such as Summary (Event Totals, etc), Camera Activity, etc.
8. POS
This section allows you to setup interfaces between your DVS system and various POS systems. POS System
support is sold separately.
19

20 CHAPTER 5. SETTING UP YOUR DVS SYSTEM
5.1 System Setup
5.1.1 DVR Name
You have the ability to name your DVS. You should pick a name that uniquely describes the system. Oftentimes, this
may be the physical location. This name can be 32 alphanumeric characters in length.
5.1.2 Recording Frame Rate
You are able to adjust the recording frame rate for each of the cameras independently. If you would like to set all the
cameras to the same recording frame rate, just select the All Check Box. Now you can adjust any one camera and the
others will follow. The recommended setting is from 2-5 fps. The higher you set the fps, the more storage your video
will occupy. This means that higher settings allow you to record less days.
You can also congure how many seconds before and after the triggering motion you would like to record. You can only
record a maximum of 2 seconds before the triggered motion. This is useful to see what was going on just before the
activity occurred. Recording extra time after the event is useful to maintain continuity throughout multiple events.
5.1.3 Auto Scan Interval
Auto Scan allows you to continuously scan through your cameras under the Live Monitoring Display. This is the interval
to wait before switching cameras. For instance, this interval is set to 10 seconds and you are in 4 Camera Split Display.
