HP ProLiant DL380 User instructions

Front View:
Front View:Front View:
Front View: Rear View:
Rear View:Rear View:
Rear View:
1. Eight sockets for PC2-5300 Fully Buffered DIMMs (DDR2-
667)
1. Torx service tool
2. Hot-plug fans, full redundancy 2. Optional pass through cable door
3. Systems Insight Display 3. Two Embedded NC373i Multifunction Gigabit Server
Adapters with TCP/IP Offload Engine
4. Quick release lever for rapid server access
5. Support for eight Small Form Factor hot plug hard drives
bays
4. Hot plug power supply bays, redundancy option (High
performance models include redundant power supply)
6. Front LEDs (show server status) and Unit Identification
button/LED (for easy in rack server identification)
5. Integrated Lights-Out 2 (iLO 2) Remote management port
6. Video Port
7. Two front USB ports (2 rear USB ports, 1 internal USB port) 7. Two USB 2.0 Ports
8. Intel Xeon Processor (Performance models include two
processors)
8. Serial Port
9. Keyboard Port
9. Hot plug power supply, redundancy option (High
performance models include redundant power supply)
10. Mouse PS/2 Port
10. Three full-size PCI-E expansion slots in standard expansion
cage (or optional mixed PCI-X/E expansion cage). Two
additional low-profile PCI-E slots embedded on the system
board. Four slots available for use; one consumed by Smart
Array controller (Base and Performance models)
11. Two low-profile PCI Express x8 slots. Slot 1 is consumed by
the P400 Smart Array controller. (Base and Performance
models)
12. Three full-size PCI Express slots in standard cage (or
optional mixed PCI-X/E expansion cage)
11. Quick removal access panel
What's New
What's NewWhat's New
What's New
New Intel® Xeon® Dual-core 5200 series processors
At A Glance
At A GlanceAt A Glance
At A Glance
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Overview
DA - 12477 North America — Version 37 — March 14, 2008 Page 1

The HP ProLiant DL380, the world's best selling server, delivers on its history of design excellence with enterprise-class uptime and
manageability, proven 2-way Intel® Xeon® performance, and 2U density for a variety of rack deployments and applications.
Processors:
Processors:Processors:
Processors:
Quad-Core and Dual-Core Intel® Xeon® processors for blazing performance; systems support up to 2 processors (2
processors standard on all Performance models)
Preconfigured Performance models save valuable deployment time at a discounted bundle price
Intel® 5000P chipset
Memory:
Memory:Memory:
Memory:
Up to 32 GB PC2-5300 Fully Buffered DIMMs (DDR2-667) with 4:1 and 2:1 interleaving available, online spare and
mirrored memory capabilities
Storage Controller:
Storage Controller:Storage Controller:
Storage Controller:
Performance Models: HP Smart Array P400/512MB BBWC Controller (RAID 0/1/1+0/5/6)
Base Models: HP Smart Array P400/256MB Controller (RAID 0/1/1+0/5)
Entry Models: HP Smart Array E200/64MB Controller (RAID 0/1/1+0)
Internal Drive Support:
Internal Drive Support:Internal Drive Support:
Internal Drive Support:
(8) small form factor (SFF) hot-plug drive bays to support Serial-attached SCSI (SAS) and Serial ATA (SATA) drives
Slimline media bay supporting Optical or Floppy drive
Network Controller:
Network Controller:Network Controller:
Network Controller:
Two embedded NC373i Multifunction Gigabit Network Adapters with TCP/IP Offload Engine, including support for
Accelerated iSCSI through an optional Licensing Kit
Expansion Slots:
Expansion Slots:Expansion Slots:
Expansion Slots:
Four available PCI-Express slots, optional mixed PCI-X / PCI-Express configurations available (see "Standard Features -
Expansion Slots" section below for more details)
USB Ports:
USB Ports:USB Ports:
USB Ports:
USB 2.0 support
5 total ports: (2) ports up front; (2) ports in back; (1) port internal
Redundancy:
Redundancy:Redundancy:
Redundancy:
Fully redundant hot plug fans (N+1)
Hot plug power supply with optional redundancy (Included in Performance models)
Management:
Management:Management:
Management:
HP Insight Control Environment server management software
Integrated Lights-Out 2 featuring Integrated Remote Console with KVM over IP performance over shared network
access
HP Power Meter and Power Regulator for ProLiant, delivering integrated power monitoring and server level, policy
based power management with industry leading energy efficiency and savings on system power and cooling costs.
Automatic Server Recovery (ASR), ROM Based Setup Utility (RBSU), HP System Insight Manager, Status LEDs including
system health and UID and SmartStart
System Insight Display on the front bezel for quick and easy server diagnostics
Form Factor:
Form Factor:Form Factor:
Form Factor:
Rack (2U), (3.5-inch); Depth 26 inches (66 cm)
Deployment/Serviceability:
Deployment/Serviceability:Deployment/Serviceability:
Deployment/Serviceability:
Quick Deploy Rail System includes sliding universal rails, an ambidextrous cable management arm and quick release
levers for fast and easy serviceability
Tool-less access to all system components for easy in rack serviceability
Warranty:
Warranty:Warranty:
Warranty:
This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP
Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years from date of
purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to
warranty services are available through HP Care Pack services or customized service agreements. SATA hard drives
have a one-year warranty.
NOTE:
NOTE:NOTE:
NOTE: Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response.
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Overview
DA - 12477 North America — Version 37 — March 14, 2008 Page 2

Additional information regarding worldwide limited warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Overview
DA - 12477 North America — Version 37 — March 14, 2008 Page 3

NOTE:
NOTE:NOTE:
NOTE: For a brief, printer friendly data sheet that describes this product and informs you of the essential capabilities and
specifications, please visit: http://h71028.www7.hp.com/ERC/downloads/5983-0605EN.pdf .
NOTE:
NOTE:NOTE:
NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory
Integrated Models" section.
Processor
ProcessorProcessor
Processor
One of the following
depending on Model
Quad-Core Intel® Xeon® Processor X5460 (3.16 GHz, 120 Watts, 1333 Front Side Bus (FSB))
Quad-Core Intel® Xeon® Processor X5450 (3.0 GHz, 120 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5450 (3.00 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5440 (2.83 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5430 (2.66 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5420 (2.50 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5410 (2.33 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5405 (2.00 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor X5365 (3.00 GHz, 120 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor X5355 (2.66 GHz, 120 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5345 (2.33 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor L5335 (2.00 GHz, 50 Watts, 1333 FSB, Low Voltage)
Quad-Core Intel® Xeon® Processor E5335 (2.00 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5320 (1.86 GHz, 80 Watts, 1066 FSB)
Quad-Core Intel® Xeon® Processor L5320 (1.86 GHz, 50 Watts, 1066 FSB)
Quad-Core Intel® Xeon® Processor E5310 (1.60 GHz, 80 Watts, 1066 FSB)
Dual-Core Intel® Xeon® Processor X5260 (3.33 GHz, 80 Watts, 1333 FSB)
Dual-Core Intel® Xeon® Processor E5205 (1.86 GHz, 65 Watts, 1066 FSB)
Dual-Core Intel® Xeon® Processor 5160 (3.0 GHz, 80 Watts, 1333 FSB)
Dual-Core Intel® Xeon® Processor 5150 (2.66 GHz, 65 Watts, 1333 FSB)
Dual-Core Intel® Xeon® Processor 5148 (2.33 GHz, 40 Watts, 1333 FSB, Low Voltage)
Dual-Core Intel® Xeon® Processor 5140 (2.33 GHz, 65 Watts, 1333 FSB)
Dual-Core Intel® Xeon® Processor 5130 (2.0 GHz, 65 Watts, 1333 FSB)
Dual-Core Intel® Xeon® Processor 5120 (1.86 GHz, 65 Watts, 1066 FSB)
Dual-Core Intel® Xeon® Processor 5110 (1.6 GHz, 65 Watts, 1066 FSB)
NOTE:
NOTE:NOTE:
NOTE: Up to 2 processors supported. Performance configurations include two processors. Mixing
different processor models is not supported.
Cache Memory
Cache MemoryCache Memory
Cache Memory
One of the following
depending on Model
12MB (2 x 6MB) Level 2 cache (5400 series)
8MB (2 x 4MB) Level 2 cache (5300 series)
6MB (2 x 3MB) Level 2 cache (5200 series)
4MB (1 x 4MB) Level 2 cache (5100 series)
4MB (2 x 2MB) Level 2 cache (5000 series)
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Standard Features
DA - 12477 North America — Version 37 — March 14, 2008 Page 4

Chipset
ChipsetChipset
Chipset Intel® 5000P Chipset
NOTE:
NOTE:NOTE:
NOTE: For more information regarding Intel chipsets, please see the following URL:
http://www.intel.com/products/server/chipsets/ .
Upgradeability
UpgradeabilityUpgradeability
Upgradeability Upgradeable to 2 processors (8 cores)
Future upgradeable to Xeon® Series 5400/5300 Quad-Core processors (Please contact your regional
sales support to determine quad core upgradeability. Some of the earlier shipping models may not
support this upgrade). 5100 Dual-Core models are not upgradeable to the 5200 Dual-Core processors.
Memory Protection
Memory ProtectionMemory Protection
Memory Protection Advanced ECC (multi-bit error protection), Online Spare, Mirroring
4-way Interleaving
Memory
MemoryMemory
Memory Type PC2-5300 Fully Buffered DIMMs (DDR2-667) with 4:1 and 2:1 interleaving
available (interleaving requires identical DIMMs)
Standard
(Entry Models)
1 GB (2 x 512 MB)
Standard
(Base Models)
2 GB (2 x 1 GB)
Standard
(Performance Models)
4 GB (4 x 1 GB)
Maximum 32 GB (8 x 4 GB)
NOTE:
NOTE:NOTE:
NOTE: Memory DIMMs in systems with the Front Side Bus (FSB) running at 1333 MHz will run at 667
MHz and in systems with a FSB running at 1066 MHz or 667 MHz the memory DIMMs will run at 533
MHz.
Network Controller
Network ControllerNetwork Controller
Network Controller Two embedded NC373i Multifunction Gigabit Network Adapters with TCP/IP Offload Engine, including
support for Accelerated iSCSI through an optional Licensing Kit
Expansion Slots
Expansion SlotsExpansion Slots
Expansion Slots
Embedded Slots
Embedded SlotsEmbedded Slots
Embedded Slots Slot
SlotSlot
Slot
Number
NumberNumber
Number
Bus Speed
Bus SpeedBus Speed
Bus Speed * Bus Number
Bus NumberBus Number
Bus Number ** Device
DeviceDevice
Device
Number
NumberNumber
Number ***
Hot Plug
Hot PlugHot Plug
Hot Plug PCI Voltage
PCI VoltagePCI Voltage
PCI Voltage
1 x4 PCIe (x8
connector)
6 0 no N/A
2 x4 PCIe
(x8 connector)
11 0 no N/A
NOTE:
NOTE:NOTE:
NOTE: Embedded slots support half-height low profile cards. For Base and Performance models, the
integrated Smart Array P400 (SAS Controller) is installed in Slot 1.
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Standard Features
DA - 12477 North America — Version 37 — March 14, 2008 Page 5

PCIe Riser
PCIe RiserPCIe Riser
PCIe Riser (Standard) Slot
SlotSlot
Slot
Number
NumberNumber
Number
Bus Speed
Bus SpeedBus Speed
Bus Speed * Bus Number
Bus NumberBus Number
Bus Number ** Device
DeviceDevice
Device
Number
NumberNumber
Number ***
Hot Plug
Hot PlugHot Plug
Hot Plug PCI Voltage
PCI VoltagePCI Voltage
PCI Voltage
3 x4 PCIe
(x8 connector)
14 0 no N/A
4 x8 PCIe
(x16 connector)
23 0 no N/A
5 x8 PCIe
(x16 connector)
19 0 no N/A
NOTE:
NOTE:NOTE:
NOTE: Riser slots support full-size PCIe/PCI-X cards. For Entry model, the standard Smart Array E200
Controller with 64MB Cache (SAS Controller) is installed in Slot 3.
PCIe/PCI-X Riser
PCIe/PCI-X RiserPCIe/PCI-X Riser
PCIe/PCI-X Riser
(Optional)
Slot
SlotSlot
Slot
Number
NumberNumber
Number
Bus Speed
Bus SpeedBus Speed
Bus Speed * Bus Number
Bus NumberBus Number
Bus Number ** Device
DeviceDevice
Device
Number
NumberNumber
Number ***
Hot Plug
Hot PlugHot Plug
Hot Plug PCI Voltage
PCI VoltagePCI Voltage
PCI Voltage
3 x8 PCIe
(x16 connector)
23 0 no N/A
4 64-bit/133MHz
PCI-X
18 1 no 3.3 Volt
5 64-bit/133MHz
PCI-X
18 2 no 3.3 Volt
NOTE:
NOTE:NOTE:
NOTE: Server has 5 total slots with 4 slots are available for use; one slot populated by the internal
storage controller.
* x4 slots support x8 cards, but will run at x4 speeds. x8 slots support x16 cards, but will run at x8
speeds.
** Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment number.
*** Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID
by bus (starting with the lowest bus).
Storage Controller
Storage ControllerStorage Controller
Storage Controller
One of the following
depending on Model
Performance Models: HP Smart Array P400/512MB BBWC Controller (RAID 0/1/1+0/5/6)
Base Models: HP Smart Array P400/256MB Controller (RAID 0/1/1+0/5)
Available upgrades
Available upgradesAvailable upgrades
Available upgrades : 512MB battery-backed write cache (BBWC) or
standalone battery for RAID 0/1/1+0/5/6
Entry Models: HP Smart Array E200/64MB Controller (RAID 0/1/1+0)
Available upgrades
Available upgradesAvailable upgrades
Available upgrades : 128MB battery-backed write cache (BBWC) for RAID
0/1/1+0/5
Storage
StorageStorage
Storage Diskette Drive None Standard
Optical Drive
One of the following
depending on Model
None Standard
IDE DVD-ROM/CDRW Combo included on Performance models
Hard Drives None Standard
Maximum Internal
Maximum InternalMaximum Internal
Maximum Internal
Storage
StorageStorage
Storage
Hot Plug SAS 1.168TB 8 x 146GB with standard internal hot plug SFF
SAS drive cage
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Standard Features
DA - 12477 North America — Version 37 — March 14, 2008 Page 6

Remote Management
Remote ManagementRemote Management
Remote Management Integrated Lights Out 2 (iLO2) Standard Management:
Virtual Text Remote Console (pre-OS only)
Remote Serial Console
Virtual Power Button Control
Virtual Unit ID control
Integrated Remote Console
Dedicated & full function shared network connectivity
Embedded system health
Browser, command line and scripted access
Automatic IP Configuration via DHCP/DNS/WINS
Industry Standard 128-bit Secure Sockets Layer (SSL) and Secure Shell security (SSH)
OS independent hardware health status
IML and iLO Event Logging
Support for 12 user accounts with customizable access privilege
Intelligent Manageability
Intelligent ManageabilityIntelligent Manageability
Intelligent Manageability HP Systems Insight Manager
SmartStart
Management Agent
Redundant ROM
Remote Flash ROM
ROM-Based Setup Utility (RBSU)
Integrated Management Log
Automatic Server Recovery (ASR)
Dynamic Sector Repairing (with Smart Array controller)
Drive Parameter Tracking (with Smart Array controller)
Hot Spare Boot
NOTE:
NOTE:NOTE:
NOTE: Upon the event of a failed processor in a multi-processing environment, the system will
automatically reboot and attempt to use the remaining good processor.
Pre-Failure Warranty (covers processors, SAS hard drives and memory)
Interfaces
InterfacesInterfaces
Interfaces Serial 1
Pointing Device (Mouse) 1
Graphics 1
Keyboard 1
VGA 2 (1 front, 1 back)
Network RJ-45 2
iLO 2 remote
management port
1
USB 2.0 Ports 5 total: 2 front, 2 back, 1 internal
NOTE:
NOTE:NOTE:
NOTE: Please see the following URL for additional information regarding
USB support:
http://h18004.www1.hp.com/products/servers/platforms/usb-support.html .
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Standard Features
DA - 12477 North America — Version 37 — March 14, 2008 Page 7

Graphics
GraphicsGraphics
Graphics Integrated ATI ES1000, 32MB video standard
16 bit color: maximum resolution of 1600 x 1200
32 bit color: maximum resolution of 1280 x 1024
NOTE:
NOTE:NOTE:
NOTE: Maximum resolution available via iLO 2 remote console is 1280x1024.
Form Factor
Form FactorForm Factor
Form Factor Rack (2U); Height 3.38-inch (8.59 cm); Depth: 26 inches (66 cm)
HP Insight Control
HP Insight ControlHP Insight Control
HP Insight Control
Management Suites
Management SuitesManagement Suites
Management Suites
HP Insight Control Environment delivers foundation management, including remote monitoring,
hardware resource deployment, health monitoring, software version control, performance monitoring,
vulnerability scanning and patch management, and power management.
HP Insight Control Environment installs and licenses the following components by default using a wizard-
based integrated installer:
HP Systems Insight Manager
HP iLO Advanced Pack
HP Rapid Deployment Pack
HP Insight Power Manager
HP Performance Management Pack
HP Vulnerability and Patch Management Pack
Additional ProLiant Essentials software and management tools included on the Insight Control
Management kit can be installed manually:
HP Server Migration Pack - Universal Edition
HP Open Service Event Manager
HP Instant Support Enterprise Edition
NOTE:
NOTE:NOTE:
NOTE: Server Migration Pack - Universal Edition can be installed from the SMP Universal CD included
in the Insight Control Management media kit.
NOTE:
NOTE:NOTE:
NOTE: For additional product and licensing information about HP Insight Control Environment, visit:
http://www.hp.com/go/ice .
HP Insight Control management suites and most HP ProLiant Essentials include a one year of 24 x 7 HP
Software Technical Support and Update Service ensuring rapid access to HP support staff and proactive
delivery of software updates. For more information about this service, please visit:
http://www.hp.com/services/insight .
Server Management
Server ManagementServer Management
Server Management
Stand Alone Software
Stand Alone SoftwareStand Alone Software
Stand Alone Software
Product - ProLiant
Product - ProLiantProduct - ProLiant
Product - ProLiant
Essentials
EssentialsEssentials
Essentials
HP Systems Insight
Manager
HP Systems Insight Manager (HP SIM) provides a unified, secure and
extensible standards-based environment to centrally manage servers, storage
and other infrastructure devices, (both HP and non-HP) across multiple
operating system platforms.
ProLiant Essentials Rapid
Deployment Pack
Rapid Deployment Pack (RDP) extends HP Systems Insight Manager with a
complete deployment solution for HP ProLiant servers. RDP provides a
central location to configure server hardware, deploy Windows, Linux and
VMware ESX operating environments and install HP ProLiant Support Pack
drivers using images and scripted profiles. For more information, visit:
http://www.hp.com/go/rdp .
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Standard Features
DA - 12477 North America — Version 37 — March 14, 2008 Page 8

ProLiant Essentials Server
Migration Pack - Universal
Edition
Upgrading, replacing, or virtualizing your existing server? Effortlessly
transition to new virtual or physical HP ProLiant servers or BladeSystem with
automated, accurate and affordable migration of OS, application and data.
SMP Universal automates the manual processes required for migrating
servers between physical or virtual platforms, whether migrating to VMware
or Microsoft virtual machines. SMP Universal allows all of the following
migrations:
physical to ProLiant
physical to virtual
virtual to virtual
virtual to ProLiant
NOTE:
NOTE:NOTE:
NOTE: For more information, visit: http://www.hp.com/go/migrate .
ProLiant Essentials
Performance Management
Pack
Performance Management Pack (offered exclusively through the Insight
Control suites) - a performance management solution that identifies and
explains hardware performance bottlenecks on ProLiant servers and attached
options enabling users to better utilize their valuable resources.
Integrated Lights-Out
Advanced Pack
Upgrades the iLO 2 processor with comprehensive remote control including
Virtual KVM remote graphical console, enhanced console sharing and
replay, virtual media (floppy, CD/DVD, USB key), virtual folders, and
enterprise security (directory services and two-factor authentication).
Integrated Lights-Out
Select Pack
Upgrades the iLO 2 processor with enhanced console sharing and replay,
virtual media (floppy, CD/DVD, USB key), virtual folders, historical power
reporting, power capping and enterprise security (directory services and two-
factor authentication) for servers managed using remote consoles available
in iLO 2 Standard and iLO 2 Standard Blade Edition.
iLO Power Management
Pack
Energy-efficient management software that delivers centralized control,
reliable security, and energy savings for your BladeSystem infrastructure.
iPMP combines the total control of iLO 2 Advanced in the area of remote
management with the energy monitoring and control of the Insight Power
Manager to deliver a robust solution capable of full remote control and
power management of ProLiant servers through a unified interface within HP
Systems Insight Manager.
ProLiant Essentials
Accelerated iSCSI Pack
Enables the embedded Multifunction network controller to serve as both a
NIC and an iSCSI HBA providing access to SAN storage over the same
connection used for networking. Processing of the protocol stack is offloaded
to the NIC reducing CPU utilization and greatly improving the speed with
which the requests are processed and sent to the network.
HP Insight Power Manager
(IPM)
Upgrades the single-server remote management capabilities of iLO
Select/Advanced to include centralized reporting and policy-based
management of power consumption and thermal output provided by the
Insight Power Manager. IPM unifies all of this functionality within a single
user interface - HP Systems Insight Manager.
NOTE:
NOTE:NOTE:
NOTE: Flexible and volume quantity license kits are available for ProLiant Essentials Value Packs. Refer
to: http://www.hp.com/servers/proliantessentials or the various ProLiant Essentials Value Pack product
QuickSpecs for more information.
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Standard Features
DA - 12477 North America — Version 37 — March 14, 2008 Page 9

Core Infrastructure
Core InfrastructureCore Infrastructure
Core Infrastructure
Management
ManagementManagement
Management
SmartStart SmartStart is a tool that simplifies server setup, providing a rapid way to
deploy reliable and consistent server configurations. For more information,
please visit the SmartStart Web site at:
http://www.hp.com/servers/smartstart .
SmartStart version supported (minimum): SmartStart 7.51
Insight Management
Agents
The Insight Management Agents should be installed on all HP servers to
present system instrumentation, health and configuration information into HP
Systems Insight Manager and the HP System Management Homepage. The
HP System Management Homepage aggregates systems data from Insight
Management Agents and other HP management tools, providing a
consolidated browser-based interface for managing individual servers.
Insight Management Agents and The HP System Management Homepage
are included on ProLiant Support Packs, and can also be installed using the
server profiles provided with the ProLiant Essentials Rapid Deployment Pack
For additional information about the Management Agents and the HP System
Management Homepage please visit the management Web site at:
http://www.hp.com/servers/manage .
Subscriber's Choice Subscriber's Choice Driver and Support Alerts/Notifications is a web-based
email subscription service that provides software and driver change
notifications for ProLiant products. Sign up at:
http://www.hp.com/go/subscriberschoice
and customize your profile to receive various new alerts as they become
available, on a weekly or monthly basis.
ProLiant Support Packs
and ROMPaq, software
The latest software, drivers, and firmware fully optimized and tested for your
ProLiant server and options, available through ProLiant Support Packs the
ProLiant Essentials Rapid Deployment Pack, SmartStart or downloaded from
software and drivers download pages website at:
http://www.hp.com/go/support .
Industry Standard
Industry StandardIndustry Standard
Industry Standard
Compliance
ComplianceCompliance
Compliance
ACPI 2.0 Compliant
PCI 2.2 Compliant
WOL Support
Microsoft® Logo certifications
USB 2.0 Support
Security
SecuritySecurity
Security Power-on password
Keyboard password
Diskette drive control
Diskette boot control
QuickLock, Network Server Mode
Parallel and serial interface control
Administrator's password
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Standard Features
DA - 12477 North America — Version 37 — March 14, 2008 Page 10

Server Power Cords
Server Power CordsServer Power Cords
Server Power Cords An IEC13 to IEC14 jumper cord ships standard with all part numbers if connecting to a UPS or PDU. If a
localized cable is desired or required for each geographic specific model, it needs to be purchased,
including the US.
UPS and PDU Power
UPS and PDU PowerUPS and PDU Power
UPS and PDU Power
Cord Matrix
Cord MatrixCord Matrix
Cord Matrix
Please see the UPS and PDU cable matrix that lists cable descriptions, requirements, and specifications
for UPS and PDU units:
http://h18004.www1.hp.com/products/servers/proliantstorage/power-protection/index.html
Power Supply
Power SupplyPower Supply
Power Supply 800Watt, CE Mark Compliant
Optional Hot Plug AC Redundant Power Supply
System Fans
System FansSystem Fans
System Fans Fully redundant hot plug fans ship standard (N+1).
OS Support
OS SupportOS Support
OS Support Microsoft Windows Server 2000
Microsoft Windows Server 2003
Microsoft Windows Small Business Server 2003, R2
Microsoft Windows Server 2008
Novell NetWare
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
SCO UnixWare, OpenServer
VMware Virtualization Software
Solaris 10 32/64-bit
NOTE:
NOTE:NOTE:
NOTE: For more complete and up-to-date information on how to buy server operating systems from HP
please visit the OS product site at: http://h18004.www1.hp.com/products/servers/software/OEM.html .
NOTE:
NOTE:NOTE:
NOTE: For a more complete and up-to-date listing of supported OSs and versions, please visit our OS
Support Matrix at: http://www.hp.com/go/supportos .
NOTE:
NOTE:NOTE:
NOTE: For an up-to-date listing of the latest software and drivers available for your server, please select
your server: http://h20000.www2.hp.com/bizsupport/TechSupport/Product.jsp?lang=en&cc
=us&taskId=135&prodTypeId=15351&prodCatId=241435 .
NOTE:
NOTE:NOTE:
NOTE: For more Linux OS support & certification information, please visit our the ProLiant &
BladeSystem Server Linux matrix: http://h18004.www1.hp.com/products/servers/linux/hpLinuxcert.html
NOTE:
NOTE:NOTE:
NOTE: For more information on HP's Certified and Supported ProLiant Servers, please visit the VMware
Server Support Matrix at:
http://h18004.www1.hp.com/products/servers/software/vmware/hpvmwarecert.html .
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Standard Features
DA - 12477 North America — Version 37 — March 14, 2008 Page 11

Rack Airflow
Rack AirflowRack Airflow
Rack Airflow
Requirements
RequirementsRequirements
Requirements
Rack 10000 series Cabinets
Rack 10000 series CabinetsRack 10000 series Cabinets
Rack 10000 series Cabinets
The increasing power of new high-performance processor technology requires increased cooling
efficiency for rack-mounted servers. The 10000 Series Racks provide enhanced airflow for maximum
cooling, allowing these racks to be fully loaded with servers using the latest processors.
CAUTION:
CAUTION:CAUTION:
CAUTION: If a third-party rack is used, observe the following additional requirements to ensure
adequate airflow and to prevent damage to the equipment:
Front and rear doors: If your 42U server rack includes closing front and rear doors, you must
allow 830 square inches (5,350 sq cm) of hole evenly distributed from top to bottom to permit
adequate airflow (equivalent to the required 64 percent open area for ventilation).
Side: The clearance between the installed rack component and the side panels of the rack must be
a minimum of 2.75 inches (7 cm).
CAUTION:
CAUTION:CAUTION:
CAUTION: Always use blanking panels to fill all remaining empty front panel U-spaces in the rack. This
arrangement ensures proper airflow. Using a rack without blanking panels results in improper cooling
that can lead to thermal damage.
NOTE:
NOTE:NOTE:
NOTE: For additional information, refer to the Setup and Installation Guide or the Documentation CD
provided with the server, or to the server documentation located in the Support section at the following
URL: www.hp.com/servers/dl380 .
Rack Kit
Rack KitRack Kit
Rack Kit The HP ProLiant DL380 quick deploy rail system provides tool-free support for racks with square or
round mounting holes (including Compaq/HP 7000*, 9000, 10000 and HP series), with an adjustment
range of 24" - 36". The ambidextrous cable management arm can be mounted on either the left or right
side for improved cable management.
NOTE:
NOTE:NOTE:
NOTE: Cable management arm must be removed to access hot-plug power supplies when the cable
management arm is mounted on the right.
* NOTE:
NOTE:NOTE:
NOTE: High Airflow Inserts (High Air Flow Rack Door Insert for the 7142 Rack (single) - PN: 327281-
B21; or High Air Flow Rack Door Insert for the 7142 Rack (6-pack) - PN: 327281-B22) are required to
support the HP ProLiant DL380 G5 in 7000 series racks. The DL380 G5 Cable Management Arm is not
supported on 7000 series racks.
Telco Rack Support
Telco Rack SupportTelco Rack Support
Telco Rack Support DL380 G5 Telco Rack Kit:
Support for all 2-post Telco racks requires the use of the standard rack kit and an additional option kit
from Rack Solutions: http://www.racksolutions.com/hp/ .
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Standard Features
DA - 12477 North America — Version 37 — March 14, 2008 Page 12

Factory Express Portfolio
Factory Express PortfolioFactory Express Portfolio
Factory Express Portfolio
for Servers and Storage
for Servers and Storagefor Servers and Storage
for Servers and Storage
HP Factory Express offers configuration, customization, integration and deployment services for HP
servers and storage products. Customers can choose how their factory solutions are built, tested,
integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading, asset
tagging, and custom packaging. HP products supported through Factory Express include a wide array of
servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000
servers as well as the MSA1000, VA7xxx, EVA, XP, rackable tape libraries and configurable network
switches.
For more information on Factory Express services for your specific server model please contact your sales
representative or go to: http://www.hp.com/go/factory-express .
HP Enterprise
HP EnterpriseHP Enterprise
HP Enterprise
Configurator
ConfiguratorConfigurator
Configurator
The HP eCo-Enterprise Configurator now provides factory default racking for our HP hardware portfolio.
This approach is aligned with our strategic direction to meet the needs and expectations of our valued
customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or
an Authorized Partner for assistance.
http://www.hp.com/products/configurator .
Service and Support
Service and SupportService and Support
Service and Support HP Care Pack services include coverage for the HP branded hardware options qualified for the server
and purchased at the same time or afterward that are internal to the enclosure. This also includes the
22" and smaller external monitors and tower UPS options up to 3kVA. These items will be covered at the
same service level and for the same coverage period as the server. Coverage of UPS Battery is not
included, and standard warranty terms & conditions apply. For servers or storage systems installed within
a rack, service also covers all HP qualified rack options installed within the same rack.
To fully capitalizing on your HP ProLiant servers' capabilities requires a service partner who thoroughly
understands your server technology and systems environment. HP Services, an industry leader in
provision of multi vender support solutions, provides a range of support services designed to meet the
varying needs of your business. Whether an SMB, or large global corporation, HP has a ProLiant server
support offer to help you speedily deploy and maximize system uptime.
Recommended Service
Recommended ServiceRecommended Service
Recommended Service - simplify ProLiant solution implementation, maintenance, and management.
Support
SupportSupport
Support : 3-Year 4-Hour response 24x7 Same Business Day Coverage only
Deployment Service
Deployment ServiceDeployment Service
Deployment Service : Installation and Start up only
Enhanced Service
Enhanced ServiceEnhanced Service
Enhanced Service - optimize service level to increase IT performance and availability.
Support
SupportSupport
Support : 3-Year Support Plus 24 only
Refer to the information on "Installation & Start-Up" for service on ProLiant server and Microsoft or Linux
O/S per the Customer Description and/or Data Sheet; to be delivered on a scheduled basis 8am-5pm,
M-F, excluding HP holidays.
NOTE:
NOTE:NOTE:
NOTE: For a complete listing of service offerings and information visit:
http://www.hp.com/services/proliantservices
http://www.hp.com/go/proliant/carepack
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Standard Features
DA - 12477 North America — Version 37 — March 14, 2008 Page 13

NOTE:
NOTE:NOTE:
NOTE: High Performance Computing (HPC) interconnect technologies are available for the DL380 under the Cluster Platform
product portfolio. These high-speed interconnects are fully supported by HP when they are part of these configure to order clusters.
Solutions can be defined with a lot of flexibility with the help of configuration tools. Please visit the following URL to configure HPC
Clusters with InfiniBand, Gigabit Ethernet or Myrinet Interconnects: http://www.hp.com/techservers/clusters/ucp/index.html
HPC Interconnect
HPC InterconnectHPC Interconnect
HPC Interconnect InfiniBand
InfiniBandInfiniBand
InfiniBand PCI-X and PCI-Express adapters
Gigabit Ethernet
Gigabit EthernetGigabit Ethernet
Gigabit Ethernet Use embedded ports
Myrinet XP
Myrinet XPMyrinet XP
Myrinet XP PCI-X Rev D and Rev E adapters
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
HPC Interconnects
DA - 12477 North America — Version 37 — March 14, 2008 Page 14

NOTE:
NOTE:NOTE:
NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory
Integrated Models" section.
HP DL380 G5
HP DL380 G5HP DL380 G5
HP DL380 G5
Performance Models
Performance ModelsPerformance Models
Performance Models
Quad-Core Models
Quad-Core ModelsQuad-Core Models
Quad-Core Models
HP DL380G5 X5460 4G
HP DL380G5 X5460 4GHP DL380G5 X5460 4G
HP DL380G5 X5460 4G
458561-001
HP DL380G5 X5450 4G
HP DL380G5 X5450 4GHP DL380G5 X5450 4G
HP DL380G5 X5450 4G
458562-001
HP DL380G5 E5345 4G
HP DL380G5 E5345 4GHP DL380G5 E5345 4G
HP DL380G5 E5345 4G
433524-001
Dual-Core Models
Dual-Core ModelsDual-Core Models
Dual-Core Models
HP DL380G5 5160 4G
HP DL380G5 5160 4GHP DL380G5 5160 4G
HP DL380G5 5160 4G
HPM
HPMHPM
HPM
418315-001
HP DL380G5 5150 4G
HP DL380G5 5150 4GHP DL380G5 5150 4G
HP DL380G5 5150 4G
HPM
HPMHPM
HPM
418314-001
Processor(s)
Processor(s)Processor(s)
Processor(s)
Two of the following
depending on Model
(2) Quad-Core Intel® Xeon® X5460 Processors (3.16 GHz, 120 Watt,
1333 FSB)
(2) Quad-Core Intel® Xeon® X5450 Processors (3.00 GHz, 120 Watt,
1333 FSB)
(2) Quad-Core Intel® Xeon® E5345 Processors (2.33 GHz, 80 Watt, 1333
FSB)
(2) Dual-Core Intel® Xeon® 5160 Processors (3.00 GHz, 80 Watt, 1333
FSB)
(2) Dual-Core Intel® Xeon® 5150 Processors (2.66 GHz, 65 Watt, 1333
FSB)
Cache Memory
Cache MemoryCache Memory
Cache Memory
Two of the following
depending on Model
12MB (2 x 6MB) Level 2 cache - Intel® Xeon® processor 5400 sequence
8MB (2 x 4MB) Level 2 cache - Intel® Xeon® processor 5300 sequence
6MB (2 x 3MB) Level 2 cache - Intel® Xeon® processor 5200 sequence
4MB (1 x 4MB) Level 2 cache - Intel® Xeon® processor 5100 sequence
Memory
MemoryMemory
Memory 4 GB (4 x 1 GB of PC2-5300 Fully Buffered DIMMs (DDR2-667) with
Advanced ECC, mirrored and online spare memory capabilities
Network Controller
Network ControllerNetwork Controller
Network Controller Two Embedded NC373i Multifunction Gigabit Server Adapters
Storage Controller
Storage ControllerStorage Controller
Storage Controller HP Smart Array P400/512MB BBWC Controller (RAID 0/1/1+0/5/6)
Hard Drive
Hard DriveHard Drive
Hard Drive None ship standard
Internal Storage
Internal StorageInternal Storage
Internal Storage 1.168TB (with optional hard drives)
Optical Drive
Optical DriveOptical Drive
Optical Drive IDE DVD-ROM/CDRW combo
Form Factor
Form FactorForm Factor
Form Factor Rack (2U), Height 3.38-inch/8.59 cm; Depth: 26 inches (66 cm)
Availability
AvailabilityAvailability
Availability Hot Plug Fully Redundant Fans and Power Supplies
HP DL380 G5 Base
HP DL380 G5 BaseHP DL380 G5 Base
HP DL380 G5 Base
Models
ModelsModels
Models
Quad-Core Models
Quad-Core ModelsQuad-Core Models
Quad-Core Models
HP DL380G5 E5440 2G
HP DL380G5 E5440 2GHP DL380G5 E5440 2G
HP DL380G5 E5440 2G
458563-001
HP DL380G5 E5430 2G
HP DL380G5 E5430 2GHP DL380G5 E5430 2G
HP DL380G5 E5430 2G
458565-001
HP DL380G5 E5420 2G
HP DL380G5 E5420 2GHP DL380G5 E5420 2G
HP DL380G5 E5420 2G
458567-001
HP DL380G5 E5335 2G
HP DL380G5 E5335 2GHP DL380G5 E5335 2G
HP DL380G5 E5335 2G
433525-001
HP DL380G5 E5320 2G
HP DL380G5 E5320 2GHP DL380G5 E5320 2G
HP DL380G5 E5320 2G
433526-001
Dual-Core Models
Dual-Core ModelsDual-Core Models
Dual-Core Models
HP DL380G5 5160 2G
HP DL380G5 5160 2GHP DL380G5 5160 2G
HP DL380G5 5160 2G
417458-001
HP DL380G5 5150 2G
HP DL380G5 5150 2GHP DL380G5 5150 2G
HP DL380G5 5150 2G
417457-001
HP DL380G5 5140 2G
HP DL380G5 5140 2GHP DL380G5 5140 2G
HP DL380G5 5140 2G
417456-001
Processor(s)
Processor(s)Processor(s)
Processor(s)
One of the following
depending on Model
(1) Quad-Core Intel® Xeon® Processor E5440 (2.83 GHz, 80 Watts, 1333
FSB)
(1) Quad-Core Intel® Xeon® Processor E5430 (2.66 GHz, 80 Watts, 1333
FSB)
(1) Quad-Core Intel® Xeon® Processor E5420 (2.50 GHz, 80 Watts, 1333
FSB)
(1) Quad-Core Intel® Xeon® Processor E5335 (2.00 GHz, 80 Watts, 1333
FSB)
(1) Quad-Core Intel® Xeon® E5320 Processors (1.86 GHz, 80 Watt, 1066
FSB)
(1) Dual-Core Intel® Xeon® Processor X5260 (3.33 GHz, 80 Watts, 1333
FSB)
(1) Dual-Core Intel® Xeon® 5160 Processors (3.00 GHz, 80 Watt, 1333
FSB)
(1) Dual-Core Intel® Xeon® 5150 Processors (2.66 GHz, 65 Watt, 1333
FSB)
(1) Dual-Core Intel® Xeon® 5140 Processor (2.33 GHz, 65 Watt, 1333
FSB)
(1) Dual-Core Intel® Xeon® 5130 Processor (2.0 GHz, 65 Watt, 1333 FSB)
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Models
DA - 12477 North America — Version 37 — March 14, 2008 Page 15

417457-001
HP DL380G5 5140 2G
HP DL380G5 5140 2GHP DL380G5 5140 2G
HP DL380G5 5140 2G
417456-001
HP DL380G5 5130 2G
HP DL380G5 5130 2GHP DL380G5 5130 2G
HP DL380G5 5130 2G
417455-001
Cache Memory
Cache MemoryCache Memory
Cache Memory
One of the following
depending on Model
12MB (2 x 6MB) Level 2 cache - Intel® Xeon® processor 5400 sequence
8MB (2 x 4MB) Level 2 cache - Intel® Xeon® processor 5300 sequence
6MB (2 x 3MB) Level 2 cache - Intel® Xeon® processor 5200 sequence
4MB (1 x 4MB) Level 2 cache - Intel® Xeon® processor 5100 sequence
4MB (2 x 2MB) Level 2 cache - Intel® Xeon® processor 5000 sequence
Memory
MemoryMemory
Memory 2 GB (2 x 1 GB) PC2-5300 Fully Buffered DIMMs (DDR2-667) with
Advanced ECC, mirrored and online spare memory capabilities
Network Controller
Network ControllerNetwork Controller
Network Controller Two Embedded NC373i Multifunction Gigabit Server Adapters
Storage Controller
Storage ControllerStorage Controller
Storage Controller HP Smart Array P400/256MB Controller (RAID 0/1/1+0/5)
Hard Drive
Hard DriveHard Drive
Hard Drive None ship standard
Internal Storage
Internal StorageInternal Storage
Internal Storage 1.168TB (with optional hard drives)
Optical Drive
Optical DriveOptical Drive
Optical Drive Optional DVD, DVD/CD-RW combo, DVD+R/RW or floppy drive
Form Factor
Form FactorForm Factor
Form Factor Rack (2U), Height 3.38-inch/8.59cm; Depth: 26 inches (66 cm)
Availability
AvailabilityAvailability
Availability Hot Plug Fully Redundant Fans Standard
HP DL380 G5 Entry
HP DL380 G5 EntryHP DL380 G5 Entry
HP DL380 G5 Entry
Models
ModelsModels
Models
Quad-Core Models
Quad-Core ModelsQuad-Core Models
Quad-Core Models
DL380G5 E5405 1G
DL380G5 E5405 1GDL380G5 E5405 1G
DL380G5 E5405 1G
458568-001
HP DL380G5 E5310 1G
HP DL380G5 E5310 1GHP DL380G5 E5310 1G
HP DL380G5 E5310 1G
433527-001
Dual-Core Models
Dual-Core ModelsDual-Core Models
Dual-Core Models
HP DL380G5 5120 1G
HP DL380G5 5120 1GHP DL380G5 5120 1G
HP DL380G5 5120 1G
417454-001
HP DL380G5 5110 1G
HP DL380G5 5110 1GHP DL380G5 5110 1G
HP DL380G5 5110 1G
417453-001
Processor(s)
Processor(s)Processor(s)
Processor(s)
One of the following
depending on Model
(1) Quad-Core Intel® Xeon® E5405 Processor (2.0 GHz, 80 Watt, 1333
FSB)
(1) Quad-Core Intel® Xeon® E5310 Processor (1.60 GHz, 80 Watt, 1066
FSB)
(1) Dual-Core Intel® Xeon® 5120 Processor (1.87 GHz, 65 Watt, 1066
FSB)
(1) Dual-Core Intel® Xeon® 5110 Processor (1.60 GHz, 65 Watt, 1066
FSB)
Cache Memory
Cache MemoryCache Memory
Cache Memory
Two of the following
depending on Model
12MB (2 x 6MB) Level 2 cache - Intel® Xeon® processor 5400 sequence
8MB (2 x 4MB) Level 2 cache - Intel® Xeon® processor 5300 sequence
6MB (2 x 3MB) Level 2 cache - Intel® Xeon® processor 5200 sequence
4MB (1 x 4MB) Level 2 cache - Intel® Xeon® processor 5100 sequence
Memory
MemoryMemory
Memory 1 GB (2 x 512 MB) PC2-5300 Fully Buffered DIMMs (DDR2-667) with
Advanced ECC, mirrored and online spare memory capabilities
Network Controller
Network ControllerNetwork Controller
Network Controller Two Embedded NC373i Multifunction Gigabit Server Adapters
Storage Controller
Storage ControllerStorage Controller
Storage Controller HP Smart Array E200/64MB Controller (RAID 0/1/1+0)
Hard Drive
Hard DriveHard Drive
Hard Drive None ship standard
Internal Storage
Internal StorageInternal Storage
Internal Storage 1.168TB (with optional hard drives)
Optical Drive
Optical DriveOptical Drive
Optical Drive Optional DVD, DVD/CD-RW combo, DVD+R/RW or floppy drive
Form Factor
Form FactorForm Factor
Form Factor Rack (2U), Height 3.38-inch/8.59cm; Depth: 26 inches (66 cm)
Availability
AvailabilityAvailability
Availability Hot Plug Fully Redundant Fans Standard
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Models
DA - 12477 North America — Version 37 — March 14, 2008 Page 16

The ProLiant Smart Buy program offers a collection of promotional server and option products that are configured with SMB in mind,
offered at discounted prices, and positioned for quick delivery. Smart Buy server offers are available for a limited time only.
S-Buy DL380G5 E5345
S-Buy DL380G5 E5345S-Buy DL380G5 E5345
S-Buy DL380G5 E5345
2GB
2GB2GB
2GB
470064-511
Processor(s)
Processor(s)Processor(s)
Processor(s) (1) Quad-Core Intel Xeon Processor E5345 (2.33 GHz, 80 Watts, 1333
FSB)
Cache Memory
Cache MemoryCache Memory
Cache Memory 8MB (2 x 4MB) Level 2 cache (5300 series)
Memory
MemoryMemory
Memory 2 GB (2 x 1 GB) PC2-5300 Fully Buffered DIMMs (DDR2-667) with
Advanced ECC, mirrored and online spare memory capabilities
Network Controller
Network ControllerNetwork Controller
Network Controller Two Embedded NC373i Multifunction Gigabit Server Adapters
Storage Controller
Storage ControllerStorage Controller
Storage Controller HP Smart Array P400/256MB Controller (RAID 0/1/1+0/5)
Hard Drive
Hard DriveHard Drive
Hard Drive None ship standard
Internal Storage
Internal StorageInternal Storage
Internal Storage 1.168TB (with optional hard drives)
Optical Drive
Optical DriveOptical Drive
Optical Drive Slimline CD-RW/DVD-ROM Combo
Form Factor
Form FactorForm Factor
Form Factor Rack (2U), Height 3.38-inch/8.59cm; Depth: 26 inches (66 cm)
Availability
AvailabilityAvailability
Availability Hot Plug Fully Redundant Fans and Power Supplies
S-Buy DL380G5 E5355
S-Buy DL380G5 E5355S-Buy DL380G5 E5355
S-Buy DL380G5 E5355
4GB, 2P
4GB, 2P4GB, 2P
4GB, 2P
470064-552
Processor(s)
Processor(s)Processor(s)
Processor(s) (2) Quad-Core Intel Xeon Processor X5355 (2.66 GHz, 120 Watts, 1333
FSB)
Cache Memory
Cache MemoryCache Memory
Cache Memory 8MB (2 x 4MB) Level 2 cache (5300 series)
Memory
MemoryMemory
Memory 4 GB (2 x 2 GB) PC2-5300 Fully Buffered DIMMs (DDR2-667) with
Advanced ECC, mirrored and online spare memory capabilities
Network Controller
Network ControllerNetwork Controller
Network Controller Two Embedded NC373i Multifunction Gigabit Server Adapters
Storage Controller
Storage ControllerStorage Controller
Storage Controller HP Smart Array P400/256MB Controller (RAID 0/1/1+0/5)
Hard Drive
Hard DriveHard Drive
Hard Drive None ship standard
Internal Storage
Internal StorageInternal Storage
Internal Storage 1.168TB (with optional hard drives)
Optical Drive
Optical DriveOptical Drive
Optical Drive Slimline DVD-ROM
Form Factor
Form FactorForm Factor
Form Factor Rack (2U), Height 3.38-inch/8.59cm; Depth: 26 in (66 cm)
Availability
AvailabilityAvailability
Availability Hot Plug Fully Redundant Fans and Power Supplies
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Smart Buys
DA - 12477 North America — Version 37 — March 14, 2008 Page 17

S-Buy DL380G5 E5440
S-Buy DL380G5 E5440S-Buy DL380G5 E5440
S-Buy DL380G5 E5440
2GB
2GB2GB
2GB
459584-005
Processor(s)
Processor(s)Processor(s)
Processor(s) (1) Quad-Core Intel Xeon Processor E5440 (2.83 GHz, 80 Watts, 1333
FSB)
Cache Memory
Cache MemoryCache Memory
Cache Memory 12MB (2 x 6MB) Level 2 cache
Memory
MemoryMemory
Memory 2 GB (2 x 1 GB) PC2-5300 Fully Buffered DIMMs (DDR2-667) with
Advanced ECC, mirrored and online spare memory capabilities
Network Controller
Network ControllerNetwork Controller
Network Controller Two Embedded NC373i Multifunction Gigabit Server Adapters
Storage Controller
Storage ControllerStorage Controller
Storage Controller HP Smart Array P400/256MB Controller (RAID 0/1/1+0/5)
Hard Drive
Hard DriveHard Drive
Hard Drive None ship standard
Internal Storage
Internal StorageInternal Storage
Internal Storage 1.168TB (with optional hard drives)
Optical Drive
Optical DriveOptical Drive
Optical Drive Slimline CD-RW/DVD-ROM Combo
Form Factor
Form FactorForm Factor
Form Factor Rack (2U), Height 3.38-inch/8.59cm; Depth: 26 inches (66 cm)
Availability
AvailabilityAvailability
Availability Hot Plug Fully Redundant Fans and Power Supplies
S-Buy DL380G5 E5440
S-Buy DL380G5 E5440S-Buy DL380G5 E5440
S-Buy DL380G5 E5440
4GB, 2P
4GB, 2P4GB, 2P
4GB, 2P
459585-005
Processor(s)
Processor(s)Processor(s)
Processor(s) (2) Quad-Core Intel Xeon Processor E5440 (2.83 GHz, 80 Watts, 1333
FSB)
Cache Memory
Cache MemoryCache Memory
Cache Memory 12 MB (2 x 6 MB) Level 2 cache
Memory
MemoryMemory
Memory 4 GB (2 x 2 GB) PC2-5300 Fully Buffered DIMMs (DDR2-667) with
Advanced ECC, mirrored and online spare memory capabilities
Network Controller
Network ControllerNetwork Controller
Network Controller Two Embedded NC373i Multifunction Gigabit Server Adapters
Storage Controller
Storage ControllerStorage Controller
Storage Controller HP Smart Array P400/256MB Controller (RAID 0/1/1+0/5)
Hard Drive
Hard DriveHard Drive
Hard Drive None ship standard
Internal Storage
Internal StorageInternal Storage
Internal Storage 1.168TB (with optional hard drives)
Optical Drive
Optical DriveOptical Drive
Optical Drive Slimline CD-RW/DVD-ROM Combo
Form Factor
Form FactorForm Factor
Form Factor Rack (2U), Height 3.38 in/8.59 cm; Depth: 26 in (66 cm)
Availability
AvailabilityAvailability
Availability Hot Plug Fully Redundant Fans and Power Supplies
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Smart Buys
DA - 12477 North America — Version 37 — March 14, 2008 Page 18

NOTE:
NOTE:NOTE:
NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO
product offerings and requirements.
NOTE:
NOTE:NOTE:
NOTE: HP does not allow factory integration of options into standard models listed above. Configure-to-order servers must start
with a CTO Chassis.
NOTE:
NOTE:NOTE:
NOTE: This product offering does not support HP Factory Express Server Configuration Level 1.
NOTE:
NOTE:NOTE:
NOTE: FIO indicates that this option only available as a Factory Installable Option.
Step 1: Base Configuration (choose one of the following configurable models)
Step 1: Base Configuration (choose one of the following configurable models)Step 1: Base Configuration (choose one of the following configurable models)
Step 1: Base Configuration (choose one of the following configurable models)
Models
ModelsModels
Models HP ProLiant DL380G5 Rack CTO Chassis 391835-B21
Factory Integrated Model ships with:
Factory Integrated Model ships with:Factory Integrated Model ships with:
Factory Integrated Model ships with:
(8) SFF Serial Attached SCSI (SAS) Drive Bays
Two Embedded NC373i Multifunction Gigabit Server Adapters
PCI-Express Riser Cage
800Watt hot plug power supply, CE Mark Compliant
One IEC Power cord
Rack (2U), (3.5-inch)
Step 1A: Choose Controller (must choose only one of the following)
Step 1A: Choose Controller (must choose only one of the following)Step 1A: Choose Controller (must choose only one of the following)
Step 1A: Choose Controller (must choose only one of the following)
Controllers
ControllersControllers
Controllers HP Smart Array P400/256 for DL380 G5/ DL385 G2 FIO Controller
NOTE:
NOTE:NOTE:
NOTE: PCI Express
405160-B21
HP Smart Array P400/512 BBWC for DL380 G5/ DL385 G2 FIO Controller
NOTE:
NOTE:NOTE:
NOTE: PCI Express
405162-B21
HP Smart Array E200/128 BBWC Controller
NOTE:
NOTE:NOTE:
NOTE: PCI Express
411508-B21
HP Smart Array P800/512 BBWC Controller
NOTE:
NOTE:NOTE:
NOTE: PCI Express SA-P800 Controller supports both internal and external drives.
381513-B21
HP Smart Array P600/256 BBWC Controller
NOTE:
NOTE:NOTE:
NOTE: PCI-X. SA-P600 Controller supports both internal and external drives.
337972-B21
HP Smart Array E200/64 FIO Controller 405528-B21
HP Smart Array 6402/512 FIO Controller 441508-B21
HP Smart Array 6404/512 FIO CNTRLR 452240-B21
Step 2: Choose Required Options (only one of the following from each list unless otherwise
Step 2: Choose Required Options (only one of the following from each list unless otherwiseStep 2: Choose Required Options (only one of the following from each list unless otherwise
Step 2: Choose Required Options (only one of the following from each list unless otherwise
noted)
noted)noted)
noted)
Processors
ProcessorsProcessors
Processors Quad-Core Intel® Xeon® Processor X5460 (3.16 GHz, 120 Watts, 1333 FSB)
DL380 FIO Kit
458581-L21
Quad-Core Intel® Xeon® Processor X5450 (3.0 GHz, 120 Watts, 1333 FSB) DL380
FIO Kit
462593-L21
Quad-Core Intel® Xeon® Processor E5450 (3.0 GHz, 80 Watts, 1333 FSB) DL380
FIO Kit
458583-L21
Quad-Core Intel® Xeon® Processor E5440 (2.83 GHz, 80 Watts, 1333 FSB) DL380
FIO Kit
458585-L21
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Configuration Information - Factory Integrated Models
DA - 12477 North America — Version 37 — March 14, 2008 Page 19

Quad-Core Intel® Xeon® Processor E5430 (2.66 GHz, 80 Watts, 1333 FSB) DL380
FIO Kit
458575-L21
Quad-Core Intel® Xeon® Processor E5420 (2.50 GHz, 80 Watts, 1333 FSB) DL380
FIO Kit
458577-L21
Quad-Core Intel® Xeon® Processor E5410 (2.33 GHz, 80 Watts, 1333 FSB) DL380
FIO Kit
459142-L21
Quad-Core Intel® Xeon® Processor E5405 (2.00 GHz, 80 Watts, 1333 FSB) DL380
FIO Kit
458579-L21
Quad-Core Intel® Xeon® Processor X5365 (3.0 GHz, 120 Watts, 1333 FSB) DL380
FIO Kit
445560-L21
Quad-Core Intel® Xeon® Processor L5335 (2.0 GHz, 50 Watts, 1333 FSB) DL380
FIO Kit
452640-L21
Quad-Core Intel® Xeon® Processor X5355 (2.66 GHz , 120 Watts, 1333 FSB)
DL380 G5 FIO Kit
437939-L21
Quad-Core Intel® Xeon® Processor E5345 (2.33 GHz, 80 Watts, 1333 FSB) DL380
G5 FIO Kit
437940-L21
Quad-Core Intel® Xeon® Processor E5335 (2.00 GHz, 80 Watts, 1333 FSB) DL380
G5 FIO Kit
437941-L21
Quad-Core Intel® Xeon® Processor E5320 (1.86 GHz, 80 Watts, 1066 FSB) DL380
G5 FIO Kit
433522-L21
Quad-Core Intel® Xeon® Processor L5320 (1.86 GHz, 50 Watts, 1066 FSB) DL380
G5 FIO Kit
435934-L21
Quad-Core Intel® Xeon® Processor E5310 (1.60 GHz, 80 Watts, 1066 FSB) DL380
G5 FIO Kit
437943-L21
Dual-Core Intel® Xeon® Processor X5260 (3.33 GHz, 80 Watts, 1333 FSB) DL380
FIO Kit
461461-L21
Dual-Core Intel® Xeon® Processor E5205 (1.86 GHz, 65 Watts, 1066 FSB) DL380
FIO Kit
461465-L21
Dual-Core Intel® Xeon® Processor 5160 (3.0 GHz, 80 Watts, 1333 FSB) DL380 G5
FIO Kit
418324-L21
Dual-Core Intel® Xeon® Processor 5150 (2.66 GHz, 65 Watts, 1333 FSB) DL380
G5 FIO Kit
418323-L21
Dual-Core Intel® Xeon® Processor 5148 (2.33 GHz, 40 Watts, 1333 FSB, Low
Voltage) DL380 G5 FIO Kit
432333-L21
Dual-Core Intel® Xeon® Processor 5140 (2.33 GHz, 65 Watts, 1333 FSB) DL380
G5 FIO Kit
418322-L21
Dual-Core Intel® Xeon® Processor 5130 (2.0 GHz, 65 Watts, 1333 FSB) DL380 G5
FIO Kit
418321-L21
Dual-Core Intel® Xeon® Processor 5120 (1.86 GHz, 65 Watts, 1066 FSB) DL380
G5 FIO Kit
418320-L21
Dual-Core Intel® Xeon® Processor 5110 (1.6 GHz, 65 Watts, 1066 FSB) DL380 G5
FIO Kit
418319-L21
Base Memory
Base MemoryBase Memory
Base Memory 1 GB FBD PC2-5300 2 x 512 MB Kit 397409-B21
2 GB FBD PC2-5300 2 x 1 GB Kit 397411-B21
2 GB FBD PC2-5300 2 x 1 GB LP Kit 461826-B21
4 GB FBD PC2-5300 2 x 2 GB Kit 397413-B21
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Configuration Information - Factory Integrated Models
DA - 12477 North America — Version 37 — March 14, 2008 Page 20
