DK Custom DK-LED-RBT-MOD User manual

LEDRun-Brake-TurnModule
Parts included:
1- LED Run-Brake-Turn Module
3- Posi Lock Connectors
5- Posi Tap Connectors
INSTRUCTIONS
(Please read all instructions before beginning install, including the Wiring Supplement)
1. Remove Main Fuse OR disconnect battery before proceeding.
2. Locate the hot wires that are used for the brake light, running lights, left turn signal, and the
right turn signal. It is helpful to have a basic understanding of how to use a volt-meter or test
light. This will help identify which wires get connected between the bike and the Run-Brake-Turn
Module.
3. This Module is going to be installed between the stock wires you have located and the
run-brake-turn lights. Decide on where you want to mount this Module. (typically this is under
the seat or inside the left side cover.)
4. This Module has 5 wires on the “input” side and 6 wires on the “output” side. The output
side is the side leading to the run-brake-turn lights, depending on your light, only three
or four of the six wires will be used. The two wires not used are blue and yellow.
5. Match the “input” side wires on this Module with the same function wire on the motorcycle.
Ground=Black
Tail/Running=Orange
Left Turn=Purple
Brake=Red
Right Turn=Brown
We do not know which wires are which on your bike. The service manual will tell you, but even
that can't be trusted 100% of the time, because HD is not 100% consistent in which color wires
they use.
The only way to know for sure is to use a voltmeter to identify, on the bike, which wire is getting
12 volts when the running lights are on, which is getting 12 volts when the brakes are on, and
which are getting 12 volts when the left or right blinkers are on.

6. Connect this Module’s input side wires to the bike wires using the supplied Posi Connectors.
7. Match the “output” side wires on this Module with the same function wire on your LED lights.
If you are using our DK Custom Universal Stealth RBT LED Lights see number 8 below. If
you are using any other LED lights see the instructions that came with your lights.
This Module's output side wires are as follows:
Ground=Black
Left Side RBT=White
Right Side RBT=Green
Center Brake=Red (If applicable)
8. For DK Custom Universal Stealth RBT LED: Use a battery to determine which red wire on
your Universal Stealth RBT Lights is for the right side of the LED Light Strip. Use a Posi Lock to
connect this red wire to the Green wire on this Module. Connect the other red wire on the LED
Light Strip to the White wire. Then connect black wire on the Led Light Strip to the black wire on
this Module. (The dual intensity converters that come with your Universal Stealth RBT Lights will
not be used with this Module.)
Brake Strobe Feature:
This Module is shipped with the brake strobe feature enabled. If you would like to disable the
strobe feature so that the brake light goes immediately solid when the brake is applied follow
these steps:
(This Module should already be installed to do this, with the key in the OFF position)
1. Hook the black wire on the input side of this Module to a negative 12 volt battery.
2. Hook the brown wire on the input side of this Module to the positive on the same battery.
3. Now hook the orange wire to the positive on the same battery.
4. Your connected led light should “wig wag” letting you know the setting has been
changed. You have now disabled the strobe brake feature.
Important Notes:
● The rider’s safety depends on the correct installation of this conversion module. Please
do not attempt if you have any doubts of your ability to install.
● When wiring this Module, make sure to make good connections and to carefully route &
insulate to avoid grounding out. This Module is water resistant, but not waterproof.
Install in a location that does not get a steady stream of water on it. After you have
installed it, you may put a dab of silicone sealer at each of the 4 points where the wires
exit the module.
