DK2 Power OPG888E User manual

OPG888E STUMP GRINDER
User Manual
SAFETY AND OPERATION INSTRUCTIONS
IMPORTANT:Read safety rules and instructions carefully before operating equipment.

Table of Contents
Table of Contents
PART I: General Safety Rules 2
PART II:Familiar with the STUMPGRINDER 8
PART III: Operating the STUMPGRINDER 9
PART IV: Maintaining the STUMPGRINDER 11
PARTV: Troubleshooting andParts List 13
Conventions used in this manual
WARNING
This indicates a hazardous situation, which, if not avoided, could result in death or serious
injury.
CAUTION
This indicates a hazardous situation, which, if not avoided, could result in minor or
moderate injury.
NOTICE
This information is important in proper using of your machine. Failure to follow this
instruction could result in damage to your machine or property.
Additional Information and Potential Changes
We reserve the right to discontinue, change, and improve our products at any time without
notice or obligation to the purchaser. The descriptions and specifications contained in this
manual were in effect at printing. Equipment described within this manual may be optional.
Some illustrations may not be applicable to your machine.
1

Part I: General Safety Rules
PART I: General Safety Rules
Safety Labels Found onYour Unit
2

Part I: General Safety Rules
Should make sure the emergency stop switch is available before every use. Or may result in
serious injury even death.
WARNING
Read this Safety & Operating Instructions manual before you use the Stump Grinder.
Become familiar with the operation and service recommendations to ensure the best
performance of your machine.
Propose
CAUTION
This machine is designed solely to grind stumps and must not be used for any other purpose.
It should only be used by trained operators who are familiar with the content of this manual.
It is potentially hazardous to fit or use any parts other than DK2 OEM parts. The company
disclaims all liability for the consequences of such use, which in addition voids the machine
warranty.
3

Part I: General Safety Rules
Before using the Stump Grinder
NOTICE
A．Operators must be fully trained before using this machine.
B．User Manual is read and understood.
C．Machine is positioned on level ground; all guards are fitted and in good condition.
D．Teeth are in good condition and secure.
E．All fasteners are checked for tightness.
F．Only stumps are removed with this machine.
G．Emergency stop wire is correctly connected and the switch is functional.
H．Fire extinguisher is available on site.
When using the Stump Grinder
NOTICE
A. Always stay clear of the rotating cutter wheel.
B. It is better to have a second trained operator within easy reach of the machine.
C. Always maintain strict discipline and service machine at specified periods.
D. DO NOT grind stumps with tow bar installed.
E. DO NOT put any part of your body near the cutter while the machine is running.
F. DO NOT operate the machine while under the influence of alcohol or drugs.
G. DO NOT operate inside a building or confined space.
Protecting Yourself and ThoseAroundYou
WARNING
This is a powerful machine, with moving parts operating with high energy. You must operate the
machine safely. Unsafe operation can create several hazards for you, as well as anyone else in the nearby
area. Always take the following precautions when using this machine:
A. Keep in mind that the operator or user is responsible for accidents or hazards occurring to other
people, their property, and themselves.
B. Always wear protective goggles or safety glasses with side shields while using the Stump Grinder to
protect your eyes from possible thrown debris.
C. Avoid wearing loose clothing or jewelry, which can catch on moving parts.
D. We recommend wearing gloves while using the Stump Grinder. Be sure your gloves fit properly and
do not have loose cuffs or drawstrings.
E. Wear shoes with non-slip treads when using your Stump Grinder. If you have safety shoes, we
recommend wearing them. Do not use the machine while barefoot or wearing open sandals.
F. Wear long pants while operating the Stump Grinder.
G. Always keep bystanders at least 50 feet away from your work area . Stop the engine when another
person or pet approaches.
4

Part I: General Safety Rules
Safety for Children and Pets
WARNING
Tragic accidents can occur if the operator is not alert to the presence of children and pets.
Children are often attracted to the machine and the grinding activity. Never assume that children will
remain where you last saw them. Always follow these precautions:
A. Keep children and pets at least 50 feet from the working area and ensure they are under the watchful
care of a responsible adult.
B. Be alert and turn the machine off if children or pets enter the work area.
C. Never allow children to operate the Stump Grinder.
Safety with Gasoline -
WARNING
Gasoline is a highly flammable liquid. Gasoline also gives off flammable vapor that can be
easily ignited and cause a fire or explosion. Never overlook the hazards of gasoline. Always follow these
precautions:
A. Never run the engine in an enclosed area or without proper ventilation as the exhaust from the engine
contains carbon monoxide, which is an odorless, tasteless, and a deadly poisonous gas.
B. Store all fuel and oil in containers specifically designed and approved for this purpose and keep away
from heat and open flame, and out of the reach of children.
C. Replace rubber fuel lines and grommets when worn or damaged and after 5 years of use.
D. Fill the gasoline tank outdoors with the engine off and allow the engine to cool completely.
Don't handle gasoline if you or anyone nearby is smoking, or if you're near anything that could cause it
to igniteorexplode. Reinstall the fuel tank cap and fuel container cap securely.
E. If you spill gasoline, do not attempt to start the engine.Move the machine away from
the area of the spill and avoid creating any source of ignition until the gas vapors have dissipated. Wipe
up any spilled fuel to prevent a fire hazard and properly dispose of the waste.
F. Allow the engine to cool completely before storing in any enclosure. Never store a machine that
has gas in the tank, or a fuel container, near an open flame or spark such as a water heater, space
heater, clothes dryer or furnace.
G. Never adjust or repair with the engine running. Shut down the engine, disconnect the spark plug
wire, keeping it away from the spark plug to prevent accidental starting, wait 5 minutes before
adjusting or repairing.
H. Never tamper with the engine’s governor setting. The governor controls the maximum safe operation
speed and protects the engine. Over-speeding the engine is dangerous and willcause damage to the
engine and to the other moving parts of the machine.If required, see your authorized dealer for engine
governor adjustments.
5

Part I: General Safety Rules
I. Keep combustible substances away from the engine when it is hot.
J. Never cover the machine while the muffler is still hot.
K. Do not operate the engine with the air cleaner or the carburetor air intake cover
removed. Removal of such parts could create a fire hazard.Do not use flammable
solutions to clean the air filter.
L. The muffler and engine become very hot and can cause a severe burn; do not touch.
General Safety
WARNING
Operating this Stump Grinder safely is necessary to prevent or minimize the risk of death or
serious injury. Unsafe operation can create several hazards for you. Always take the
following precautions when operating:
A. Your machine is a powerful tool, not a plaything. Exercise extreme caution always.
The machine is designed to grind stumps. Do not use it for any other purpose.
B. Know how to stop the Stump Grinder quickly.
C. Never operate your unit on a slippery, wet, muddy, or icy surface. Exercise caution to
avoid slipping or falling.
D. See manufacturer’s instructions for proper operation and installation of accessories.
E. Never use the machine without ensuring that all guards and shields are in place.
F. Never, under any conditions, remove, bend, cut, fit, weld, or otherwise alter standard
parts on the Stump Grinder. This includes all shields and guards. Modifications to your
machine could cause personal injuries and property damage and will invalid your
warranty.
G. If the machine starts to make an unusual noise or vibrate, shut down the engine,
disconnect the spark plug wire, keeping it away from the spark plug to prevent
accidental starting, wait 5 minutes for engine to cool down, then inspect for damage.
Vibration is generally a warning of trouble. Check for broken or missing teeth,loose
cutter wheel bearings and loose or worn drive belt. Also check engine mounting bolts.
H. Never tamper with safety devices. Check their proper operation regularly.
I. Before performing any maintenance or inspection procedure, shut down the engine,
disconnect the spark plug wire keeping it away from the spark plug to prevent
accidental starting, wait 5 minutes for machine to cool down.
J. Never allow people who are unfamiliar with these instructions to use the machine. Allow
only responsible individuals who are familiar with these rules of safe operation to use
your machine.
K. Never operate in gravel or stone. It could result in personal injury or damage to the
machine.
L. While using, don't hurry or take things for granted. When in doubt about the
equipment or your surroundings stop the machine and take time to look things over.
M. Never operate the machine when under the influence of alcohol, drugs, or medication.
6

Part I: General Safety Rules
N. Use the machine only in daylight.
O. Stay alert for hidden hazards.
P. Keep all nuts and bolts tight and keep the equipment in good operating condition.
Q. Tow the equipment safely at 25 MPH off road only. NEVER tow on paved streets as
this will damage your ATV tires.
R. ALLWAYS take the brake off before towing.
ANote toAll Users
List of warnings and cautions cannot be all-inclusive. If situations occur that are not
covered by this manual, the operator must apply common sense and operate this Stump
Grinder in a safe manner. Contact DK2POWER for assistance or questions.
7

Part II: Familiar with the StumpGrinder
PART II: Familiar with the StumpGrinder
It may be helpful to familiarize yourself with the controls and features of the Stump Grinder.
If you have any question, please contact DK2POWER at 702-331-5353 8-4 PST.
TECHNICALSPECIFICATIONS
7
Reco
il Start
E
lectric Start
Eng
ine
14
HP4four stroke
14
HP4four stroke
P
ower
G
asoline
G
asoline
Wheel Diameter
14 inches
14 inches
Cutters
12
12
Stump Height
12
inches
12
inches
Stump Diameter
Any
Any
T
ire
13.75D x 5.25W 145/70
-6
13.75D x 5.25W 145/70
-6

Part IV: Maintaining The StumpGrinder
PART III: Operating the StumpGrinder
It may be helpful to better familiarize yourself with the features of your StumpGrinder
before beginning the steps outlined in this chapter.
WARNING
A. Read and understand all instructions, safety precautions, and/or warnings listed in
“PART I: General Safety Rules”before operating the Stump Grinder. If any doubt or
question arises about the correct or safe method of performing anything found in this
manual, please contact DK2POWER.
B. When operating the Stump Grinder, make sure you are standing in the safe operating
area (OPERATOR ZONE). Never place any part of your body into a position that
causes an unsafe operating condition.
C. Before operating the Stump Grinder, always wear protective gear, including safety
goggles, hearing protection, tight-fitting gloves without draw strings or loose cuffs, and
steel-toed shoes.
D. Never use an incorrect or unsafe method of operation.
Starting
1. Position yourStumpGrinderon flat, dry ground.
2. Put the brake on making sure the brake pin and wheel is engaged and locked.
3. Remove the towbar and towbar locking pin from the unit.
4. Make sure the fuel shut-off valve is in the “ON” position. Slide to the right.
5. Move the choke control lever to the “CHOKE” position (should only be needed if the
engine is cold). Left is on, Right is off.
6. Move the throttle control lever to the “MID”position.
7. Adjust your bow handle to the desired position.
8. Depress the safety shut off bail on the bow handle.
9. Raise the cutter teeth off the ground and start the engine. This is a direct drive unit and
the cutter wheel will rotate during starting.
10. Recoil Start: Turn the Ignition Switch to the “On” position. Grasp the recoil starter
handle and slowly pull until you feel resistance. Let the cord retract a little bit then pull
the cord rapidly to start the engine. One or two pulls usually starts the engine.
11. Electric Start: Turn and hold the Key in the start position until Engine starts then let
the Key return to run position.
12. Move the choke control lever (if used for cold engine) slowly back to the “RUN”
position when the engine is running well. All the way to the right.
13. Increase engine speed to FULL RABBIT RPM.
10

Part IV: Maintaining The StumpGrinder
Stopping
1. Let go of the bail shut off on the bow handle
OR
2.
3.
Recoil Start: Slide the GAS lever to the LEFT to shut engine off.
Electric Start: Turn the Key to the OFFposition.
Operator Zone
StumpGrinding
NOTICE
Clear area around stump to remove all rocks and stones
WARNING
Do not place your feet or hands into the cutting wheel area. This is a very UNSAFE and
could result in injury or death.
Never allow yourself or others to reach or step to the side or the front of of the
Stump Grinder when it is running. This is a very UNSAFE method which could
cause personal injury, even death.
VIBRATION
If the unit starts to vibrate abnormally shut the unit down. Inspect for missing or broken teeth
and replace if required. Check your teeth bolts that are tight. Check your drive belts.
10

Part IV: Maintaining The StumpGrinder
PART IV: Maintaining the StumpGrinder
Regular maintenance is the way to ensure the best performance and long life of your
machine.Please refer to this manual and the engine manufacturer's user manual for
maintenance procedures.
WARNING
Before performing any maintenance procedure or inspection, stop the engine, wait five
minutes to allow all parts to cool. Disconnect the spark plug wire, keeping it away from the
spark plug. Disconnect the Battery Terminals (Electric start only).
Regular Maintenance Checklist
Engine Service
Refer to the engine manufacturer’s user manual for engine maintenance.
11
P
rocedure
Be
fore Each Use
Every 3
H
ours
Every 25
H
ours
Every 100
H
ours
Che
ck engine oil level Δ
Che
ck general equipme
nt
co
ndition
Δ
Che
ck teeth and bolts Δ
Che
ck beltsΔ
Che
ck tire pressure Δ
C
lean engine exterior a
nd
recoil cover
Δ
Ch
ange Engine OilFirst time
5hours
Δ
Rep
lace air filter Δ
Rep
lace spark plug Δ

Part IV: Maintaining The StumpGrinder
Lubrication
NOTICE
All Bearings of your Stump Grinder are sealed units and should have enough lubricant
to last the life of your machine with normal use. Grease Zerks are installed if grease is ever
needed. Use standard bearing grease.
FOR ENGINE WARRANTYCONTACTYOUR NEAREST KOHLER ENGINE DEALER.
VISIT WWW.KOHLERENGINES.COM AND ENTER YOU ZIP CODE IN THE FIND A
DEALER SECTION.
12

Part VI: Troubleshooting and Parts List
PARTV: Troubleshooting and Parts List
Most problems are easy to fix. Consult the Troubleshooting Table below for common
problems and their solutions. If you continue to experience problems, contact DK2POWER
in LAS VEGAS at 702-331-5353 8-4 PST
WARNING
Before performing any maintenance procedure or inspection, stop the engine, wait five
minutes to allow all parts to cool. Disconnect the spark plug wire, keeping it away from the
spark plug.
Troubleshooting Table
13
SYMPTOM POSSIBLE CAUSE
The engine won’t start.
(Please refer to the
engine user manual for
engine-specific
procedures.)
➢Is the SAFETY BAR HELD DOWN to engage the safety cutoff switch?
➢Is the fuel shut-off valve on? SLIDE THE LEVER ALL THE WAY TO THE RIGHT.
➢Are youusing fresh, clean gas? If the gas is old, change it. Use a fuel stabilizer if you keep gas
longer than30 days.
➢Is the spark plug clean? If the spark plug is dirty or cracked, change it. If it’s oily, leave it out, hold
a rag over the plug hole and pull the recoil cord several times to blow out any oil in the cylinder,
then wipe off the plug and reinsert it.
The engine lacks power
or is not running
smoothly.
(Please refer to the
engine user manual
for engine-specific
procedures.)
➢Check that the Throttle Lever is in the “RABBIT”position. TURN OFF THE CHOKE.
➢Is the air filter clean? If it’sdirty, change it following the procedure in the engine manufacturer’
s
owner’s manual.
➢Is the spark plug clean? If it’s fouled or cracked, change it. If it’s oily, leave it out, hold a rag ov
er
the plug hole and pull your recoil cord several times to blow out any oil in the cylinder, th
en
wipe off the plug and reinsert it.
➢Are you using fresh, clean unleaded gas? If it’s old, change it. Use a fuel stabilizer if you keep g
as
longer than30 days.
➢Does your engine have the right amount of clean oil? If it’sdirty, change it following t
he
procedure in the engine manufacturer’s owner’smanual.
➢Check the oil level and adjust as needed.
Engine smokes.
(Please refer to the
engine user manual
for engine-specific
procedures.)
➢Check the oil level and adjust as needed.
➢Check the air filter and cleanor replace if needed.
➢You may be using the wrong oil—too light for the temperature. Refer to your Engine Owner’s
Manual for detailed information.
➢Clean the cooling fins if they’re dirty.
Machine does not seem
to have full grinding
power.
➢The belts may be too loose and slipping. Adjust or replace belts as need.
➢The teeth may be dull or broken, replace.
➢Run engine at full RPM when grinding.

Part VI: Troubleshooting and Parts List
Explosion View and parts list
14

Part VI: Troubleshooting and Parts List
15
Ref Description Ref2 Description3
1
Stop frame
25
Clutch spacer
2
Spacer bush
26
8 holes rubber
3
Top handrail
27
Main frame
4
Brake line fixed block
28
4 holes rubber
5
Brake line fixing piece,
plastic handle
29
4 holes rubber fix
6
Engine
30
External compression spring
7
Plastic battery box
31
Pin retaining sleeve
8
Tire
32
Brake cable limit plate
9
Universal wheel
33
The brake chuck
10
Flange
34
The brake pin
11
Tow hitch
35
Internal compression spring
12
Belt cover
36
Main frame handle
13
Cutter belt wheel
37
Brake line adjusting bolt
14
Bearing
38
Battery
15
Stright blade
39
Trailer rod holder
16
Right blade
40
The knife cover
17
Plate spacer right
41
Bottom handrail
18
Plate
42
Throttle cable
19
Plate spacer right
43
Stop switch
20
Left blade
44
Torsion Spring
21
Plate pulley spacer
45
Brake cable
22
Inner belt cover
46
Tow bar Pin
23
Belt cover spacer
47
Tow bar
24
Clutch
48
Chain

Part VI: Troubleshooting and Parts List
WHAT IS COVERED
DK2 Inc. warrants to the original purchaser of any DK2 product that it will be free and clear of
manufacturing defects in workmanship and materials under normal use and service for a period of
one (1) year from the date of the original purchase.
If within one (1) year from the original date of purchase this product fails due to defect in material or
workmanship. DK2 POWER outdoor power equipment is 1-year parts only warranty no labor.
Upon expiry of one (1) year, Detail K2 will have no further liability related to the product. Detail K2
does not authorize any party, including its authorized distributors or dealers, to offer any other
warranty on behalf of Detail K2 Inc.
KOHLER ENGINES –KOHLER CH SERIES ENGINES COMMERCIAL 3 YR PARTS AND LABOR WARRANTY
see your Kohler manualfor specific warranty.
DIESEL TRACTORS –Chassis component parts only, no labor, ENGINES –1 YR KOHLER WARRANTY
DK2 POWER OUTDOOR EQUIPMENT –1-Year parts only, no labor.
THIS WARRANTY DOES NOT COVER OR APPLY TO:
Damage to the product due to misuse, mishandlingand abuse
(b)) Improper installation, maintenance and storage
(c)Expendable parts such as nuts and bolts, pins and springs, wiring and switch components,
hydraulic hoses andfittings, cutting teeth, cutting chains, cutting blades, throttles, belts and tires.
(d) Normal wear and tear
(e) Consequential damage & incidental damages such as damage to persons or property
PROCEDURE FOR OBTAINING AN RETURN AUTHORIZATION
Within the one (1) year warranty period, the purchaser of the product must notify DK2 of the
claimed defect and provide proof of original purchase. At this time the validity of the claim will be
determined, and if approved replacement parts will be issued.
No returned product will be accepted under warranty unless accompanied by an RGA# issued by
Detail K2 Inc.
RESOLUTION FOR A DEFECTIVE PRODUCT
DK2 POWER–Tractors, Chippers, Stump Grinders, Log Splitters, and Outdoor Power Equipment.
Call DK2 at 702-331-5353 in Las Vegas between 8am-4pm M-F Pacific Time.
PLEASE DO NOT RETURN TO THE STORE
YOU HAVE A 1 YEAR WARRANTY AND DK2 WILL REPLACE A DEFECTIVE PART FOR FREE
CALL US AT 702-331-5353 FOR FAST WARRANTY PARTS AND QUESTIONS
16
