WARNING
This manual describes important points of caution for safe use of this product in potentially explosive atmosphere. Please
read this manual carefully before installing and operating the product.
DOL 46R
Capacitive Sensors
EN
TECHNICAL USER’S GUIDE
ATEX zone 20, 21 and 22, dust
CE0539
II 1D Ex ta IIIC T200 85 oC Da
The DOL 46R capacitive relay sensor series is designed for general
detection of feed, grain and solids. Certified according to ATEX directive
2014/34/EU and IECEx for operation in potential explosive dust
atmospheres. Classified as equipment for use in atmospheres with
continuous presence of explosive dust with an ignition temperature above
85 oC.
Robust design with plastic housing with 7 joule shock/impact test. Available
with trimmer interface with adjustable sensing distance, time delay and
MaxRunTimer.
For other language variants of
this document we refer to www.dol-
sensors.com or your local dealer.
2018.11.29 • 604337 • 17.11 • EN • Made in Denmark
dol-sensors a/s Hedelund 4, Glyngøre 7870 Roslev Denmark Tlf. +45 72 17 58 88 Fax +45 72 17 59 59 www.dol-sensors.com
TECHNICALUSERGUIDE
PRODUCT DESCRIPTION:
DOL 46R is a capacitive relay sensor for
detection of feed, grain and solids. The
sensors have relay output including switch
function. Certified according to ATEX
directive 2014/34/EU and IECEx for
operation in potential explosive dust
atmospheres. Classified as high-level
equipment for use in atmospheres with
continuous presence of explosive dust with
an ignition temperature above 85 °C.
Fields of application:
• Level control in silos and containers
• Controlling the filling and emptying
process.
MOUNTING GUIDE (FIG. 1):
DOL 46R is made in a ø30 mm smooth
design mounted in a gland.
Figure 1
INSTALLATION GUIDE (FIG. 2):
Supply voltage is connected to the blue and
brown wire.
The load is connected in series with the
relay contact of the sensor.
STOP by activating the sensor: Use the
black wires 1 and 3.
START by activating the sensor: Use the
black wires 1 and 4.
NOTE! The internal relay is in position NC
when the supply voltage is connected and
the sensor is activated - wire 1 and 4 are
connected.
Figure 2: No-current sensor
USER’S GUIDE:
•Easy trimmer adjustment on a
single turn 240° trimmer with
linear or non-linear scale.
•Functions which can be made
available for adjustment on
trimmers:
- ON and/or OFF delay
- MaxRunTimer
- Sensitivity
DOL 46R has a red LED, indicating
sensor status and a green LED
indicating power on.
Fig. 3 shows examples of LED
sequences.
Figure 3
TECHNICAL DATA:
Supply voltage:
Voltage:
20 - 280 V AC/DC
Frequency
47 - 63 Hz
Relay:
Max. resistive load,
250 VAC:
4 A
Max. inductive load,
250 VAC:
2 A
Min. relay current,
12 VDC
100 mA
Temperature:
Temp.
operation:
- 30 °C - + 50 °C
- 22 °F - + 122 °F
Temp. storage:
- 40 °C - + 80 °C
- 40 °F - + 176 °F
Degree of protection:
IP:
69K
NEMA:
1, 3, 4, 6, 12, 13
Cable:
Length:
2 m, 5 m or 10 m
6.6, 16.5 or 33 feet
Conductor
dimensions:
5 x 0.5 mm2
5 x AWG20
Dimensions:
Approvals:
ATEX zone 20, 21 and 22, dust
EN/IEC conforms to the Harmonized
standards
CE0539
II 1D Exta IIIC T200 85 oC Da
Relay NC (1-4)
Relay NO (1-3) after delay
LED- sequence
NC (1-4)
NO (1-3)
LED
NC (1-4)
NO (1-3)
LED
NC (1-4)
NO (1-3)
LED
Sensor
No time
delay
Delayed
discon-
nection
Delayed
connec-
tion
2018.11.29 • 604337 • 17.11 • EN • Made in Denmark
dol-sensors a/s Hedelund 4, Glyngøre 7870 Roslev Denmark Tlf. +45 72 17 58 88 Fax +45 72 17 59 59 www.dol-sensors.com
SPECIFICCONDITIONSOF USE
SPECIFICCONDITIONSOF USE
SPECIFIC CONDITIONS OF USE
INSTALLATION / SET-UP
The units must be installed, connected and set up by qualified staff. The qualified staff must have knowledge of protection classes,
regulations and provisions for apparatus in hazardous areas.
Check whether the classification (see "Marking" above and marking on the unit) is suitable for the application.
INSTALLATION REMARKS / INSTALLATION
Make sure only qualified personnel performs the installation/maintenance/service.
Before removing the sensor, or before connecting or disconnecting the wiring, turn off the power supply. Do not
disconnect, unless the area is non-explosive.
Verify that the environmental temperature is within the temperature class required for the area.
•Ambient temperature range is -30 °C to +50 °C.
•Never remove the trimmer cover protector unless the area is non-explosive.
•Adhere to the relevant national regulations and provisions.
•The relevant installation regulations must be adhered to. In particular, take into account the requirements relating
to the temperature limitation as regards the expected dust deposits.
•Avoid electrostatic charging on housings and cables
•In case of cleaning the sensor, this must be done with a damp cloth, in order to prevent build-up of electrostatic
charges.
•If fast moving particles are present a physical barrier shall protect the sensor.
•Cable shall be protected from pulling or twisting.
•The sensor may only be connected/supplied from a circuit having a prospective short circuit current of not
greater than 10kA.
•The sensor must be protected against exposure to direct sunlight and other ultraviolet light sources.
•The sensor is manufactured with a permanently mounted cable gland and permanently connected cable that is
non-replaceable and shall be terminated in a safe area or in a suitable certified termination box.
•If the user reduces the sensitivity to almost minimum, the sensor will not be able to detect objects in front of it. In
this fail situation, the internal relay will always be ON but the temperature class 85oC will never be exceeded.
2018.11.29 • 604337 • 17.11 • EN • Made in Denmark
dol-sensors a/s Hedelund 4, Glyngøre 7870 Roslev Denmark Tlf. +45 72 17 58 88 Fax +45 72 17 59 59 www.dol-sensors.com
SPECIFICCONDITIONSOF USE
FUNCTIONS AND FEATURES
•Use in hazardous areas according to the classification
(group II, category IIIC, apparatus for dust atmosphere).
Complies with the requirements of the standards EN/IEC 60079-0 and EN/IEC 60079-31.
•Label information
II 1 D Ex ta IIIC T200 85 oC Da
II: The sensor is classified for explosion group II, which concerns all remaining risk areas but mines
1: Category 1. The sensor can be used in zone:
20: Flammable material present continuously or long periods.
21: Flammable material present occasionally.
22: Flammable material present in abnormal conditions for short periods.
D: For use in hazardous areas, in which explosive dust are present.
Ex: Conforms to the Harmonized Standards.
ta: Protection by enclosure, highest level
IIIC: Conductive dust.
T200 85 oC: The max. surface temperature of the sensor, 85oC.
Da: EPL Da. See Category 1 D above.
•Permissible operating temperature of the application (proper usage):
Ta: -30°C...+50°C
MAINTENANCE / REPAIR
The unit must not be modified nor can it be repaired. In case of a fault please contact the manufacturer.
