Dometic breath easy User manual

Breathe Easy™
_BreatheEasy_A5.book Seite 1 Dienstag, 24. Januar 2012 3:31 15
For Sales Information Please Contact
RoadTrucker Inc
(www.RoadTrucker.com)
8312 Sidbury Rd.
Wilmington, NC 28411
[phone] / [phone]

EN
Breathe Easy™
18
Please read this manual carefully before installing and starting up, and
store it in a safe place. If you pass on the product to another person,
include this instruction manual with it.
WARNING
!
Explosion hazard in explosive atmosphere
This component does not meet federal requirements for ignition protection.
Do not install in spaces containing gasoline engines, tanks,
LPG/CPG cylinders, regulators, valves or fuel line fittings.
Failure to comply can result in injury or death.
Electrical shock hazard
Disconnect the power cord before servicing or opening device.
Ultraviolet light is harmful
Eye damage may result from directly viewing the light produced by these
lamps. To reduce the risk of exposure to UV radiation, take UV radiation
protective measures for personnel during servicing.
Ultraviolet lamp may cause injury
Ultraviolet lamps are made of glass and are fragile. Safety eyewear and
puncture resistant gloves must be worn when handling an ultraviolet lamp.
CAUTION
!
Risk of exposure to excessive ultraviolet (UV) radiation. Do not operate
without complete lamp enclosure in place.
The health aspects associated with the use of this product and its ability to
aid in disinfection of environmental air have not been investigated by UL.
The effectiveness of this product has been tested and proven by
Environmental Diagnostics Laboratory, an AIHA accredited and SBA
certified laboratory.
_BreatheEasy_A5.book Seite 18 Dienstag, 24. Januar 2012 3:31 15
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
Breathe Easy™
19
Contents
1 Notes on using the manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4 Replacement parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
7 Installing the Breathe Easy™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
8 Using the Breathe Easy™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
9 Replacing the ultraviolet lamp and the nano-mesh divider . . . . . . . 25
10 Cleaning and caring for Breathe Easy™ . . . . . . . . . . . . . . . . . . . . . 27
11 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
12 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
13 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
14 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
_BreatheEasy_A5.book Seite 19 Dienstag, 24. Januar 2012 3:31 15
For Sales Information Please Contact
RoadTrucker Inc
(www.RoadTrucker.com)
8312 Sidbury Rd.
Wilmington, NC 28411
[phone] / [phone]

EN
Notes on using the manual Breathe Easy™
20
1 Notes on using the manual
DDANGER!
Safety instruction: Failure to observe this instruction will cause
fatal or serious injury.
!WARNING!
Safety instruction: Failure to observe this instruction can cause
fatal or serious injury.
!CAUTION!
Safety instruction: Failure to observe this instruction can lead to
injury.
ANOTICE!
Failure to observe this instruction can cause material damage and
impair the function of the product.
INOTE
Supplementary information for operating the product.
➤Action: This symbol indicates that action is required on your part. The
required action is described step-by-step.
✓This symbol describes the result of an action.
fig. 15, page 3: This refers to an element in an illustration. In this case,
item 5 in figure 1 on page 3.
Please observe the following safety instructions.
_BreatheEasy_A5.book Seite 20 Dienstag, 24. Januar 2012 3:31 15
For Sales Information Please Contact
RoadTrucker Inc
(www.RoadTrucker.com)
8312 Sidbury Rd.
Wilmington, NC 28411
[phone] / [phone]

EN
Breathe Easy™ Safety instructions
21
2 Safety instructions
The manufacturer will not be held liable for claims for damage resulting from
the following:
Faulty assembly or connection
Damage to the product resulting from mechanical influences and excess
voltage
Alterations to the product without express permission from the manu-
facturer
Use for purposes other than those described in the operating manual
2.1 General safety
DDANGER!
Explosion hazard in explosive atmosphere
This component does not meet federal requirements for ignition
protection. Do not install in spaces containing gasoline engines,
tanks, LPG/CPG cylinders, regulators, valves or fuel line fit-
tings.
!WARNING!
Do not operate the device if it is visibly damaged.
This device may only be repaired by qualified personnel.
Inadequate repairs can lead to serious hazards.
Should your device need to be repaired, please contact
customer services.
Persons whose physical, sensory or mental capabilities or
whose lack of experience and knowledge prevent them from
using the device safely should not use it without supervision or
instruction by a responsible person.
Electrical devices are not toys.
Always keep the device out of the reach of children.
Children must be supervised to ensure that they do not play with
the device.
If this device’s power cable is damaged, it must be replaced by
the manufacturer, customer service or a similarly qualified
person in order to prevent safety hazards.
_BreatheEasy_A5.book Seite 21 Dienstag, 24. Januar 2012 3:31 15
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
Safety instructions Breathe Easy™
22
!CAUTION!
Disconnect the power cord before servicing or opening device.
Unplug the device before opening it.
ANOTICE!
Check that the voltage specification on the data plate is the
same as that of the power supply.
Never pull the plug out of the socket by the cable.
2.2 Operating the device safely
!WARNING!
Eye damage may result from directly viewing the light produced
by these lamps. To reduce the risk of exposure to UV radiation,
take UV-radiation protective measures for personnel during
servicing.
!CAUTION!
Do not use the device with wet hands.
If the device falls into water, unplug it immediately. Do not reach
into the water.
Do not attempt to use the device again.
Risk of exposure to excessive ultraviolet (UV) radiation.
Do not operate without complete lamp enclosure in place.
ANOTICE!
Only use the device indoors, never outside.
Never expose the device to moisture.
Make sure that none of the vents are blocked. If necessary,
clean the vents before you use the device.
Do not place the device in areas where uncured siliconised
sealers are used. The vapours they give off inhibit the photo-
catalytic capability.
Only use spare parts that are approved by the manufacturer.
Failure to do this will invalidate the guarantee.
The health aspects associated with the use of this product and
its ability to aid in disinfection of environmental air have not
been investigated by UL.
_BreatheEasy_A5.book Seite 22 Dienstag, 24. Januar 2012 3:31 15
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
Breathe Easy™ Scope of delivery
23
The effectiveness of this product has been tested and proven by
Environmental Diagnostics Laboratory, an AIHA accredited and
SBA certified laboratory.
3 Scope of delivery
4 Replacement parts
Please contact your local service partner if you have questions regarding
spare parts.
5 Intended use
The Dometic Breathe Easy™ (SKU 9108680632) is an air purifier that uses
photocatalytic nano-mesh technology and ultraviolet light to improve the air
quality by constantly circulating the air through the device.
INOTE
Note that the device does not fix the the source of ongoing odor
problems. For example, a leak that caused mold must be repaired
and the mold must be removed.
Quantity Description SKU
1 Breathe Easy™ 9108680632
112 V power cable
1 100 – 240 V, 50 – 60 Hz power adapter
Description
Replacement kit (Ultraviolet lamp, replaceable nano-mesh divider, maintenance
sticker)
Fan
12 V power cable
100 – 240 V, 50 – 60 Hz power adapter
_BreatheEasy_A5.book Seite 23 Dienstag, 24. Januar 2012 3:31 15
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
Technical description Breathe Easy™
24
The device is operated with 12 Vg. Connect it to a 100 – 240 V power supply
using only the power adapter (SKU 9108694411) provided.
6 Technical description
7 Installing the Breathe Easy™
When selecting the installation location, observe the following instructions:
The device is designed for rooms with an area of up to 500 sq. ft. (46 m²).
Select a location where the air flow is not impaired.
Do not install the device in rooms where flammable materials are stored
or flammable gases may accumulate.
Do not install the device near the inlet or outlet of an air conditioning
system.
Keep the power cable away from hot surfaces.
Install the device on a flat, smooth surface.
No. in
fig. 1, page 3 Designation
1Fan
2Removable nano-mesh divider
3 Ultraviolet lamp
4Non-removable nano-mesh strips
5 Lamp socket
6Safety switch
No. in
fig. 2, page 3 Designation
1 Power/Fan-speed switch
2Connection socket
3 Maintenance sticker
_BreatheEasy_A5.book Seite 24 Dienstag, 24. Januar 2012 3:31 15
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
Breathe Easy™ Using the Breathe Easy™
25
This is how to install the device:
➤Fasten the device to a flat, smooth surface using the suction pads.
➤Fill in the current date on the maintenance sticker (fig. 23, page 3). This
tells you when the ultraviolet lamp must be replaced in the following year.
8 Using the Breathe Easy™
!WARNING!
Eye damage may result from directly viewing the light produced by
these lamps. To reduce the risk of exposure to UV radiation, take
UV-radiation protective measures for personnel during servicing.
➤Connect one end of the 12 V power cable to the socket (fig. 22, page 3).
➤Plug the other end of the cable into the 12 V source.
➤Move the switch (fig. 21, page 3) to the required position:
–II (maximum purification, recommended): The fan operates at maxi-
mum speed. The ultraviolet lamp is on (you can see a blue glow
through the vents).
–I: The fan operates at lower speed. The ultraviolet lamp is on (you can
see a blue glow through the vents).
–0: The fan and the ultraviolet lamp are switched off.
9 Replacing the ultraviolet lamp and the
nano-mesh divider
!CAUTION! Ultraviolet lamp may cause injury
Ultraviolet lamps are made of glass and are fragile. Safety eyewear
and puncture resistant gloves must be worn when handling an ul-
traviolet lamp
Ultraviolet lamps have a limited service life. After around 9000 service hours
(about a year of continuous use) they lose their germicidal effectiveness. You
must therefore replace the lamp after this period, even if it still lights up.
INOTE
Each time you switch the ultraviolet lamp on and off, you reduce its
service life by about an hour.
_BreatheEasy_A5.book Seite 25 Dienstag, 24. Januar 2012 3:31 15
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
Replacing the ultraviolet lamp and the nano-mesh divider Breathe Easy™
26
This is how to replace the ultraviolet lamp and the nano-mesh divider:
➤Unplug the device from the electrical outlet.
➤Unscrew the four screws on the corners of the bottom side.
➤Remove the cover.
➤Let the device cool down for 5 minutes.
➤Pull the ultraviolet lamp (fig. 13, page 3) out of the lamp socket
(fig. 15, page 3).
ANOTICE!
Do not touch the new ultraviolet lamp with you bare hands as the
oil you leave on it will shorten its service life.
➤Put the new Dometic ultraviolet lamp into the socket (fig. 15, page 3).
Insert the pins on the lamp firmly into the socket.
➤Place a new maintenance sticker with the current date over the old one
so that you know when the ultraviolet lamp needs to be replaced.
➤Lift the nano-mesh divider (fig. 12, page 3) out of the slots.
➤Insert the new nano-mesh divider lengthways into the slots.
It does not matter which side faces the ultraviolet lamp.
➤Clean the device if necessary (see chapter “Cleaning and caring for
Breathe Easy™” on page 27).
➤Put on the cover.
➤Fasten the cover with the four screws.
➤Connect the device to the electrical outlet.
!WARNING!
Eye damage may result from directly viewing the light produced by
these lamps. To reduce the risk of exposure to UV radiation, take
UV-radiation protective measures for personnel during servicing.
➤Check that the ultraviolet lamp lights up.
You can see a blue glow through the vents.
_BreatheEasy_A5.book Seite 26 Dienstag, 24. Januar 2012 3:31 15
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
Breathe Easy™ Cleaning and caring for Breathe Easy™
27
10 Cleaning and caring for
Breathe Easy™
!CAUTION!
Always disconnect the plug before you clean and service
the device.
!CAUTION! Beware of burns
Let the ultraviolet lamp cool down before cleaning.
ANOTICE!
Never clean the device under running water or in dish water.
Do not use abrasive cleaning agents or hard objects during
cleaning as these can damage the device.
➤Wipe the exterior of the device occasionally with a soft, dry cloth.
➤Pay special attention to dirt and dust in the air vents.
➤Clean the interior with canned air to blow out any dust.
➤Clean the fan (fig. 11, page 3) with a soft brush when you replace the
ultraviolet lamp or if you notice a reduction in the air flow.
➤Clean the removable nano-mesh divider (fig. 12, page 3) if you notice a
reduction in the air flow.
To do this, lift it out of the slots and clean it with a soft brush or with water
and detergent.
Let it dry, then slide it back in the slots.
➤Clean the non-removable nano-mesh strips (fig. 14, page 3) with a soft
brush.
➤If necessary, clean the ultraviolet lamp with a soft cloth and alcohol.
_BreatheEasy_A5.book Seite 27 Dienstag, 24. Januar 2012 3:31 15
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
Troubleshooting Breathe Easy™
28
11 Troubleshooting
No power (the device does not switch on, the fan cannot be heard)
➤Check that the power cable is connected to the device and the power
source.
➤Check that the switch (fig. 21, page 3) is in the I or II position.
➤Verify that the power source is working.
Fan runs but no blue light can be seen
➤Check that the ultraviolet lamp (fig. 13, page 3) is correctly inserted in
the socket (fig. 15, page 3) (see chapter “Replacing the ultraviolet lamp
and the nano-mesh divider” on page 25).
➤Replace the ultraviolet lamp (fig. 13, page 3) if necessary (see chapter
“Replacing the ultraviolet lamp and the nano-mesh divider” on page 25).
➤Check whether the lamp socket (fig. 15, page 3) is defective.
Output seems ineffective
➤Make sure the device is correctly installed:
– In an enclosed room
–Not near the inlet or outlet of an air conditioning system
– The area of the room may not exceed 500 sq. ft. (46 m²)
Output seems low
➤Clean the vents.
➤Clean the removable nano-mesh divider (see chapter “Cleaning and car-
ing for Breathe Easy™” on page 27).
➤Clean the ultraviolet lamp (see chapter “Cleaning and caring for
Breathe Easy™” on page 27).
➤Check whether ultraviolet lamp needs to be replaced (look at the sticker
to see how long it has been in use).
_BreatheEasy_A5.book Seite 28 Dienstag, 24. Januar 2012 3:31 15
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
Breathe Easy™ Guarantee
29
12 Guarantee
The statutory warranty period applies. If the product is defective, please
contact your retailer or the manufacturer's branch in your country (see the
back of the instruction manual for the addresses).
For repair and guarantee processing, please include the following docu-
ments when you send in the device:
A copy of the receipt with purchasing date
A reason for the claim or description of the fault
Guarantee does not cover the ultraviolet lamp.
13 Disposal
➤Place the packaging material in the appropriate recycling waste bins
wherever possible.
MIf you wish to finally dispose of the product, ask your local recycling
centre or specialist dealer for details about how to do this in
accordance with the applicable disposal regulations.
_BreatheEasy_A5.book Seite 29 Dienstag, 24. Januar 2012 3:31 15
For Sales Information Please Contact
RoadTrucker Inc
(www.RoadTrucker.com)
8312 Sidbury Rd.
Wilmington, NC 28411
[phone] / [phone]

EN
Technical data Breathe Easy™
30
14 Technical data
Approved to standard 2009/19/EC (2004/104/EC), Automotive EMC
Directive
Different versions, technical modifications and delivery options reserved.
Breathe Easy™
SKU: 9108680632
Voltage: 12 Vg
Current: 666 mA
Consumption: 8 W
Maximum room size: 46 m² (500 sq. ft.)
Dimensions W x D x H 158 x 114 x 48 mm (6.2" x 4.5" x 1.9")
Weight: Approx. 340 g (12 oz.)
Testing/certification:
89XK
E
_BreatheEasy_A5.book Seite 30 Dienstag, 24. Januar 2012 3:31 15
For Sales Information Please Contact
RoadTrucker Inc
(www.RoadTrucker.com)
8312 Sidbury Rd.
Wilmington, NC 28411
[phone] / [phone]

Europe
aDometic Austria GmbH
Neudorferstrasse 108
2353 Guntramsdorf
[phone]
[phone]
Mail: [email protected]
hDometic Switzerland AG
Riedackerstrasse 7a
CH-8153 Rümlang (Zürich)
[phone]
[phone]
Mail: [e-mail]
lDometic Denmark A/S
Nordensvej 15, Taulov
DK-7000 Fredericia
[phone]
[phone]
Mail: [email protected]
mDometic Spain S.L.
Avda. Sierra del Guadarrama, 16
E-28691 Villanueva de la Cañada
Madrid
[phone]
[phone]
Mail: [email protected]s
pDometic S.N.C.
ZA du Pré de la Dame Jeanne
F-60128 Plailly
[phone]
[phone]
Mail: [email protected]r
qDometic Finland OY
Mestarintie 4
FIN-01730 Vantaa
[phone]
[phone]
Mail: [email protected]i
CDometic Italy S.p.A.
Via Virgilio, 3
I-47100 Forlì
[phone]
[phone]
Mail: [email protected]
LDometic Norway AS
Skolmar 24
N-3232 Sandefjord
[phone]
[phone]
Mail: [e-mail]
NDometic Benelux B.V.
Ecustraat 3
NL-4879 NP Etten-Leur
[phone]
[phone]
Mail: [email protected]
PDometic Poland Sp. z o.o.
Ul. Puławska 435A
02-801 Warszawa
Poland
[phone]
[phone]
Mail: [email protected]
TDometic RUS LLC
Komsomolskaya square 6-1
107140 Moscow
Russia
[phone]
[phone]
Mail: [email protected]
UDometic Scandinavia AB
Gustaf Melins gata 7
S-42131 Västra Frölunda (Göteborg)
[phone]
[phone]
Mail: [email protected]
4Dometic UK Ltd.
Dometic House · The Brewery
Blandford St. Mary
Dorset DT11 9LS
[phone]
[phone]
Mail: [email protected]
Overseas + Middle East
8Dometic Australia
1 John Duncan Court
Varsity Lakes QLD 4227
[phone]
[phone]
Mail: [email protected]
5WAECO Impex Ltd.
Suites 2207-2211 · 22/F · Tower 1
The Gateway · 25 Canton Road,
Tsim Sha Tsui · Kowloon
Hong Kong
[phone]
[phone]
Mail: [email protected]
7WAECO Impex Ltd.
Taipei Office
2 FL-3 · No. 56 Tunhua South Rd, Sec 2
Taipei 106, Taiwan
[phone]
[phone]
Mail: [e-mail]
6Dometic AB
Regional Office Middle East
P O Box 74775
Dubai, United Arab Emirates
[phone]
[phone]
Mail: [email protected]
0Dometic Marine Division
2000 N. Andrews Ave. Extension
Pompano Beach, FL 33069 USA
[phone]
[phone]
Mail: [e-mail]
kDometic WAECO International GmbH
Hollefeldstraße 63 · D-48282 Emsdetten
[phone] · [phone]
Mail: [email protected] · Internet: www.dometic-waeco.de
www.dometic-waeco.com
4445100544 01/2012
_BreatheEasy_A5.book Seite 136 Dienstag, 24. Januar 2012 3:31 15
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]
