TB15
Thermoelectric cooler
Operating manual . . . . . . . . . . . . . . . . . . . . .5
EN
COOLING BOXES
BORDBAR
TB15-O-16s.book Seite 1 Montag, 7. November 2016 3:55 15
Autogoods “130”
130.com.ua

BordBar TB15
3
LOW BATT. ON/OFF COLD HOT
OFF
2
11
3
1
4 5
6
1
A
C
B
D
2
TB15-O-16s.book Seite 3 Montag, 7. November 2016 3:55 15
Autogoods “130”
130.com.ua

BordBar TB15
4
2. 1.
A B
C
1.
1.
2.
2.
3
TB15-O-16s.book Seite 4 Montag, 7. November 2016 3:55 15
Autogoods “130”
130.com.ua

EN
BordBar TB15
5
Please read this operating manual carefully before starting the device.
Keep it in a safe place for future reference. If the device is passed on to
another person, this operating manual must be handed over to the user
along with it.
The manufacturer cannot be held liable for damage resulting from improper usage
or incorrect operation.
Contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
5 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
7 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
8 Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
9 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
10 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
11 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
12 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
TB15-O-16s.book Seite 5 Montag, 7. November 2016 3:55 15
Autogoods “130”
130.com.ua

EN
Explanation of symbols BordBar TB15
6
1 Explanation of symbols
!
!
A
I
2 Safety instructions
2.1 General safety
!WARNING!
•Do not operate the device if it is visibly damaged.
•If this device's power cable is damaged, it must be replaced by the
manufacturer, customer service or a similarly qualified person in order
to prevent safety hazards.
•This device may only be repaired by qualified personnel. Improper
repairs can lead to considerable hazards.
•This device can be used by childrenaged 8 years or over, as well as by
persons with diminished physical, sensory or mental capacities or a
lack of experience and/or knowledge, providing they are supervised
or have been taught how to use the device safely and are aware of the
resulting risks.
•Cleaning and user maintenance must not be carried out by children
without supervision.
•Children must not play with the device.
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
TB15-O-16s.book Seite 6 Montag, 7. November 2016 3:55 15
Autogoods “130”
130.com.ua

EN
BordBar TB15 Safety instructions
7
•Children must be supervised to ensure that they do not play with the
device.
•Always keep and use the device out of the reach of children under the
age of 8 years.
•Do not store any explosive substances such as spray cans with a
flammable propellant in the device.
!CAUTION!
•Disconnect the device from the power supply
– before each cleaning and maintenance
– after every use
•Food may only be stored in its original packaging or in suitable
containers.
ANOTICE!
•Check that the voltage specification on the type plate corresponds to
that of the energy supply.
•Only connect the device to a DC plug socket in the vehicle (e. g.
cigarette lighter) with the DC cable.
•Never pull the plug out of the socket by the cable.
•Disconnect the cooler and other power consuming devices from the
battery before connecting the quick charging device.
•Disconnect the cooler or switch it off when you turn off the engine.
Otherwise you may discharge the battery.
•The cooling device is not suitable for transporting caustic materials or
materials containing solvents.
•The cooling device contains inflammable cyclopentane in the
insulation. The gases in the insulation material require special disposal
procedures. Deliver the device at the end of its life-cycle to an appro-
priate recycling.
2.2 Operating the device safely
!CAUTION!
•Before starting the device, ensure that the power supply line and the
plug are dry.
ANOTICE!
•Do not use electrical devices inside the cooler unless they are
recommended by the manufacturer for the purpose.
TB15-O-16s.book Seite 7 Montag, 7. November 2016 3:55 15
Autogoods “130”
130.com.ua

EN
Intended use BordBar TB15
8
•Do not place the device near naked flames or other heat sources
(heaters, direct sunlight, gas ovens etc.).
•Danger of overheating!
Ensure at all times that there is sufficient ventilation so that the heat that
arises during operation does not build up. Make sure that the device
is sufficiently far away from walls and other objects so that the air can
circulate.
•Ensure that the ventilation openings are not covered.
•Do not fill the inner container with ice or fluid.
•Never immerse the device in water.
•Protect the device and the cable against heat and moisture.
3 Intended use
The cooler is portable. It can chill products as well as keep them cool or warm.
The device is designed for use with a 12 Vgon-board supply of a car (cigarette
lighter), boat or caravan.
!
4Scopeofdelivery
•BordBar TB15 cooler
•Cable for 12V gconnection
5Accessories
To operate the device using an AC power supply, we recommend using the
following mains rectifier.
Available as accessories (not included in the scope of delivery)
•220 – 240 Vw: CoolPower EPS817
CAUTION! Health hazard!
Please check if the cooling capacity of the device is suitable for storing
the food or medicine you wish to cool.
TB15-O-16s.book Seite 8 Montag, 7. November 2016 3:55 15
Autogoods “130”
130.com.ua

EN
BordBar TB15 Technical description
9
6 Technical description
The cooler can chill products to a maximum of 20 °C below the ambient temperature
as well as cool or keep them warm up to a maximum of 65 °C.
An integrated battery monitor can be switched on to protect your vehicle battery
against excessive discharging.
Control elements
No. in
fig. 1, page 3 Description
1 Ventilation grilles
2LEDLOWBATT
flashes when the battery monitor has switched off the device due to
low voltage
lights up when the battery monitor is switched on and the device is
operating
3 Slide switch for the battery monitor
ON: Battery monitor is switched on
OFF: Battery monitor is switched off
4LEDCOLD
lights up green when the device is cooling
5LEDHOT
lights up red when the device is warming
6 Slide switch for the operating mode
COLD: The device is cooling
OFF: The device is switched off
HOT: The device is warming
TB15-O-16s.book Seite 9 Montag, 7. November 2016 3:55 15
Autogoods “130”
130.com.ua

EN
Operation BordBar TB15
10
7Operation
A
I
Fastening the device on the seat
➤Pull out the fastening rail on the rear of the device until it clicks (fig. 2A, page 3).
➤Place the device on a seat (passenger seat or the middle seat in the back).
➤Push the device back against the backrest so that the fastening rail is inserted
between the seat surface and backrest.
➤Thread the seat belt into one of the belt holders and fasten the device:
– front belt holder (fig. 2B or C, page 3)
– bottom belt holder (fig. 2D, page 3)
I
Switching the device on and off
➤Plug the 12 V connection cable into the cigarette lighter socket or a 12 V socket
in the vehicle.
➤Push the slide switch into the required position.
✓The cooler is switched on and starts cooling or heating the interior.
✓The respective LED lights up.
➤When you want to switch off the cooler, disconnect the plug.
NOTICE!
•Ensure that the objects placed in the cooler are suitable for cooling
to the selected temperature.
•Ensure that food or liquids in glass containers are not excessively
refrigerated. Liquids expand when they freeze and can therefore
destroy glass containers
NOTE
Before starting your new cooling device for the first time, you should
clean it inside and outside with a damp cloth for hygienic reasons
(please also refer to the chapter “Cleaning and maintenance” on
page 11).
NOTE
Press the release button on the bottom of the device to insert the
fastening rail.
TB15-O-16s.book Seite 10 Montag, 7. November 2016 3:55 15
Autogoods “130”
130.com.ua

EN
BordBar TB15 Cleaning and maintenance
11
Using the battery monitor
➤Switch on the battery monitor if you are operating the device with a 12 V on-
board supply.
➤Switch off the battery monitor if you are operating the device with a mains rectifier
(accessory) using an AC power supply.
8 Cleaning and maintenance
!
A
➤Occasionally clean the device interior and exterior with a damp cloth.
➤Make sure that the air inlet and outlet vents on the device are free of any dust and
dirt, so that heat can be released and the device is not damaged.
9Guarantee
The statutory warranty period applies. If the product is defective, please contact the
manufacturer's branch in your country (see the back of the instruction manual for the
addresses) or your retailer.
For repair and guarantee processing, please include the following documents when
you send in the device:
•A copy of the receipt with purchasing date
•A reason for the claim or description of the fault
WARNING!
Always disconnect the device from the power supply before you clean
and service it.
NOTICE! Risk of damage
•Never clean the cooler under running water or in dish water.
•Do not use abrasive cleaning agents or hard objects during cleaning
as these can damage the cooler.
TB15-O-16s.book Seite 11 Montag, 7. November 2016 3:55 15
Autogoods “130”
130.com.ua

EN
Troubleshooting BordBar TB15
12
10 Troubleshooting
11 Disposal
➤Place the packaging material in the appropriate recycling waste bins wherever
possible.
MIf you wish to finally dispose of the product, ask your local recycling centre
or specialist dealer for details about how to do this in accordance with the
applicable disposal regulations.
Fault Possible cause Suggested remedy
Your cooler does not
work (plug is inserted).
There is no voltage
flowing from the 12 V
socket in your vehicle.
The ignition must be switched on in
most vehicles for voltage to flow at the
cigarette lighter.
The cooler does not cool
(plug is inserted).
The inner fan or the
cooling element is
defective.
This can only be repaired by an
authorised customer services unit.
Operation with a 12 V
socket:
The ignition is on and the
cooler is not working.
The cigarette lighter
socket is dirty. This
results in a poor
electrical contact.
If the plug of your cooler becomes very
warm in the cigarette lighter socket,
either the socket must be cleaned or
the plug has not been assembled
correctly.
The fuse of the 12 V
plug has blown.
Replace the fuse (5 A) in the 12 V plug
(fig. 3, page 4).
The vehicle fuse has
blown.
Replace the vehicle's 12 V socket fuse
(usually 15 A). (Please refer to the
operating manual of your vehicle.)
TB15-O-16s.book Seite 12 Montag, 7. November 2016 3:55 15
Autogoods “130”
130.com.ua

EN
BordBar TB15 Technical data
13
12 Technical data
BordBar TB15
Ref. no.: 9600000489
Connection voltage: 12 Vg
Power consumption: 40 W
Battery monitor
Cut-off voltage:
Cut-in voltage:
11.7 V
13.1 V
Cooling capacity: max. 20 °C below ambient temperature
Heating capacity: 65 °C (interior temperature)
Gross capacity: 15 l
Climate class: N, T
Weight: 5.2 kg
Testing/certification:
4
TB15-O-16s.book Seite 13 Montag, 7. November 2016 3:55 15
Autogoods “130”
130.com.ua
