Dometic CK 40D DC User manual

CK40DDC
Compressor Cooler
Operating manual . . . . . . . . . . . . . . . . . . . . .3
Kompressor-Kühlbox
Bedienungsanleitung . . . . . . . . . . . . . . . . . 13
Glacière à compression
Notice d’utilisation . . . . . . . . . . . . . . . . . . .24
EN
DE
FR
COOLING BOXES
COOLFUN
CK40D-DC-O-3s.book Seite 1 Freitag, 1. Dezember 2017 12:29 12

CK40DDC
2
520
410
510
270
455
364
1
2
ON/OFF
TEMP TEMP
-+
°C
1
23 4
1
3
CK40D-DC-O-3s.book Seite 2 Freitag, 1. Dezember 2017 12:29 12

EN
CK40D DC Explanation of symbols
3
Please read this operating manual carefully before starting the device.
Keep it in a safe place for future reference. If the device is passed on to
another person, this operating manual must be handed over to the user
along with it.
The manufacturer cannot be held liable for damage resulting from improper usage
or incorrect operation.
Contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
4 Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
7 Cleaning and care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
9 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
10 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
11 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
1 Explanation of symbols
!
!
A
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
CK40D-DC-O-3s.book Seite 3 Freitag, 1. Dezember 2017 12:29 12

EN
Safety instructions CK40D DC
4
I
2 Safety instructions
2.1 General safety
!WARNING!
•Do not operate the cooling device if it is visibly damaged.
•If this cooling device's power cable is damaged, it must be replaced
by the manufacturer, customer service or a similarly qualified person in
order to prevent safety hazards.
•This cooling device may only be repaired by qualified personnel.
Improper repairs can lead to considerable hazards.
•This cooling device can be used by children aged 8 years or over, as
well as by persons with diminished physical, sensory or mental capac-
ities or a lack of experience and/or knowledge, providing they are
supervised or have been taught how to use the cooling device safely
and are aware of the resulting risks.
•Cleaning and user maintenance must not be carried out by children
without supervision.
•Children must not play with the cooling device.
•Children must be supervised to ensure that they do not play with the
cooling device.
•Always keep and use the cooling device out of the reach of children
under the age of 8 years.
•Do not store any explosive substances such as spray cans with a
flammable propellant in the cooling device.
!CAUTION!
•Disconnect the cooling device from the power supply
– before each cleaning and maintenance
– after every use
•Food may only be stored in its original packaging or in suitable
containers.
NOTE
Supplementary information for operating the product.
CK40D-DC-O-3s.book Seite 4 Freitag, 1. Dezember 2017 12:29 12

EN
CK40D DC Safety instructions
5
ANOTICE!
•Check that the voltage specification on the type plate corresponds to
that of the energy supply.
•Only connect the cooling device to a DC power supply in the vehicle
with the DC cable.
•Never pull the plug out of the socket by the cable.
•Disconnect the cooling device and other power consuming devices
from the battery before connecting a quick charging device.
•Disconnect the cooling device or switch it off when you turn off the
engine. Otherwise you may discharge the battery.
•The cooling device is not suitable for transporting caustic materials or
materials containing solvents.
•The insulation of the cooling device contains flammable cyclopentane
and requires special disposal procedures. Deliver the cooling device
at the end of its life-cycle to an appropriate recycling.
2.2 Operating the cooling device safely
!CAUTION!
•Before starting the cooling device, ensure that the power supply line
and the plug are dry.
ANOTICE!
•Do not use electrical devices inside the cooling device unless they are
recommended by the manufacturer for the purpose.
•Do not place the cooling device near naked flames or other heat
sources (heaters, direct sunlight, gas ovens etc.).
•Danger of overheating!
Ensure at all times that there is a minimum of 50 mm ventilation on all
four sides of the cooling device. Keep the ventilation area free of any
objects that could restrict the air flow to the cooling components.
Do not place the cooling device in closed compartments or areas with
none or minimal air flow.
•Ensure that the ventilation openings are not covered.
•Do not fill the inner container with ice or fluids.
•Never immerse the cooling device in water.
•Protect the cooling device and the cable against heat and moisture.
CK40D-DC-O-3s.book Seite 5 Freitag, 1. Dezember 2017 12:29 12

EN
Scope of delivery CK40D DC
6
3Scopeofdelivery
4Properuse
The coolbox is suitable for cooling and freezing foodstuffs.
The device is designed for use with a 12/24 V vehicle electrics socket of a car (such
as a cigarette lighter), boat or caravan (see voltage specification on the type plate)
The appliance may also be used for camping use. The appliance shall not to be
exposed to rain.
!
5 Technical description
The device can cool goods down and keep them cool or freeze them.
A maintenance-free refrigerant circuit with compressor provides the cooling. The
extra strong insulation and powerful compressor ensure especially fast cooling.
You can use the digital display to set the temperature.
The lid is sealed all round and has a magnetic lock.
The cooler has the following control elements:
Quantity Description
1Coolbox
1 Instruction manual
CAUTION! Health hazard!
Please check if the cooling capacity of the device is suitable for storing
the food or medicine you wish to cool.
No. in
fig. 2,
page 2
Description Explanation
1 Display Shows the current or required temperature.
2 ON/OFF Switches the cooler on or off.
3 TEMP – Decreases the desired cooling temperature by 1 °C.
4 TEMP + Increases the desired cooling temperature by 1 °C.
CK40D-DC-O-3s.book Seite 6 Freitag, 1. Dezember 2017 12:29 12

EN
CK40D DC Operation
7
6Operation
!
I
6.1 Energy saving tips
•Choose a well ventilated installation location which is protected against direct
sunlight.
•Allow warm food to cool down first before placing it in the cooling device to
keep cool.
•Do not open the cooling device more often than necessary.
•Do not leave the cooling device open for longer than necessary.
6.2 Connecting the cooler to 12 V/24 V
➤Make sure the cable between the cooler and the battery is protected by a fuse
(maximum 5 A).
➤Plug the 12 V/24 V connection cable (fig. 3, page 2) into the DC power outlet
or a 12 V/24 V socket in the vehicle.
➤Press the “ON/OFF” button (fig. 22, page 2)
✓The cooler starts cooling the interior.
I
CAUTION! Health hazard!
Food may only be stored in its original packaging or in suitable
containers.
NOTE
•Before starting your new coolbox for the first time, you should clean
it inside and outside with a damp cloth for hygienic reasons (please
also refer to the chapter “Cleaning and care” on page 10).
•A few water drops may form inside the cooler if it has been cooling
for a lengthy period. This is normal because the moisture in the air
condenses to water when the temperature in the cooler falls. The
cooler is not defective. Wipe it out with a dry cloth if necessary.
NOTE
In most vehicles the ignition must be turned on before power will be
supplied to the DC power outlet.
CK40D-DC-O-3s.book Seite 7 Freitag, 1. Dezember 2017 12:29 12

EN
Operation CK40D DC
8
6.3 Using the battery monitor
The device is equipped with a multi-level battery monitor that protects your vehicle
battery against excessive discharging when the device is connected to the on-board
DC supply.
If the cooler is operated when the vehicle ignition is switched off, the cooler switches
off automatically as soon as the supply voltage falls below a set level. The cooler will
switch back on once the battery has been recharged to the restart voltage level.
A
In “HIGH” mode, the battery monitor responds faster than at the levels “LOW” and
“MED” (see the following table).
The battery monitor mode can be selected as follows:
➤Switch on the cooler.
➤Long press the “TEMP –” (fig. 23, page 2) button.
➤Use the “TEMP –” (fig. 23, page 2) or “TEMP +” (fig. 24, page 2) buttons to
select the battery monitor mode.
✓Display will be as follows:
Lo (LOW), ΠEd (MED), Hi (HIGH)
✓The selected mode then appears in the display for a few seconds. The display
flashes several times before it returns to the current temperature.
I
NOTICE! Danger of damage!
When switched off by the battery monitor, the battery will no longer be
fully charged. Avoid starting repeatedly or operating current consumers
without longer charging phases. Ensure that the battery is recharged.
Battery monitor mode LOW MED HIGH
Switch-off voltage at 12 V 10.1 V 11.4 V 11.8 V
Restart-voltage at 12 V 11.1 V 12.2 V 12.6 V
Switch-off voltage at 24 V 21.5 V 24.1 V 24.6 V
Restart voltage at 24 V 23.0 V 25.3 V 26.2 V
NOTE
When the cooler is supplied by the starter battery, select the battery
monitor mode “HIGH”. If the cooler is connected to a supply battery,
the battery monitor mode “LOW” will suffice.
CK40D-DC-O-3s.book Seite 8 Freitag, 1. Dezember 2017 12:29 12

EN
CK40D DC Operation
9
6.4 Using the cooler
A
➤Place the cooler on a firm foundation.
➤Switch the cooler on by pressing the “ON/OFF” button (fig. 22, page 2).
✓The display switches on and shows the current cooling temperature in °C.
✓The cooler starts cooling the interior.
➤To switch the cooler off, press the “ON/OFF” button (fig. 22, page 2).
➤The display switches off.
6.5 Setting the temperature
The cooling capacity can be influenced by:
•The ambient temperature
•The number of goods to be cooled
•The frequency with which the door is opened
➤Press the “TEMP –” (fig. 23, page 2) button to decrease the desired cooling
temperature by 1 °C.
➤Press the “TEMP +” (fig. 24, page 2) button to increase the desired cooling
temperature by 1 °C.
✓The cooling temperature set in °C then appears in the display for a few seconds.
✓The display flashes to confirm that the selected temperature has been set.
NOTICE! Risk of damage
•Do not switch on the device immediately after transporting it. This
could damage the cooling system. Leave the device to stand for
about 30 minutes after transporting, before you switch it on. This
allows the refrigerant to collect again in the compressor, and the
compressor does not run dry.
•Ensure that the objects or goods placed in the cooling device are
suitable for cooling to the selected temperature.
•Ensure that food or liquids in glass containers are not excessively
refrigerated. Liquids expand when they freeze and can therefore
destroy glass containers.
•Ensure that your cooler is well ventilated so that any heat created can
dissipate. Otherwise proper functioning cannot be ensured. It is
especially important not to cover the air vents.
CK40D-DC-O-3s.book Seite 9 Freitag, 1. Dezember 2017 12:29 12

EN
Cleaning and care CK40D DC
10
6.6 Defrosting the cooler
Humidity can form frost in the interior of the cooling device or on the vaporiser. This
reduces the cooling capacity. Defrost the device in good time to avoid this.
A
To defrost the cooler, proceed as follows:
➤Take out the contents of the cooling device.
➤If necessary, place them in another cooling device to keep them cool.
➤Switch off the device.
➤Leave the cover open.
➤Wipe off the defrosted water.
7 Cleaning and care
!
A
➤Occasionally clean the device interior and exterior with a damp cloth.
➤Make sure that the air inlet and outlet vents on the device are free of any dust and
dirt, so that heat can be released and the device is not damaged.
NOTICE! Danger of damaging the device!
Never use hard or pointed tools to remove ice or to loosen objects
which have frozen in place.
WARNING!
Always disconnect the device from the power supply before you clean
and service it.
NOTICE! Risk of damage
•Never clean the cooler under running water or in dish water.
•Do not use abrasive cleaning agents or hard objects during cleaning
as these can damage the cooler.
CK40D-DC-O-3s.book Seite 10 Freitag, 1. Dezember 2017 12:29 12
