Dometic Classic Notes on using the manual
5
Please read this manual carefully before installation and starting up the
device. Keep it in a safe place for future reference. If you pass on the
device to another person, hand over this instruction manual along with
it.
Contents
1 Notes on using the manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4 Optional extras. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7 Before initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
8 Using the portable grill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
9 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
10 Cleaning the portable grill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
11 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
12 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
13 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
1 Notes on using the manual
!WARNING!
Safety instruction: Failure to observe this instruction can cause
fatal or serious injury.
!CAUTION!
Safety instruction: Failure to observe this instruction can lead to
injury.
_Dometic_Classic.book Seite 5 Donnerstag, 27. Januar 2011 6:37 18

General safety instructions Dometic Classic
6
ANOTICE!
Failure to observe this instruction can cause material damage and
impair the function of the product.
INOTE
Supplementary information for operating the product.
➤Action: This symbol indicates that action is required on your part. The
required action is described step-by-step.
✓This symbol describes the result of an action.
fig. 15, page 3: This refers to an element in an illustration. In this case,
item 5 in figure 1 on page 3.
Please observe the following safety instructions.
2 General safety instructions
The manufacturer will not be held liable for claims for damage resulting from
the following:
zFaulty assembly or connection
zDamage to the product resulting from mechanical influences and excess
voltage
zAlterations to the product without express permission from the manu-
facturer
zUse for purposes other than those described in the operating manual
2.1 General safety
!WARNING!
zOnly use category l3liquid gas (propane/butane). Do not use
any other fuel sources.
ANOTICE!
zUse the device only as intended.
_Dometic_Classic.book Seite 6 Donnerstag, 27. Januar 2011 6:37 18

Dometic Classic General safety instructions
7
2.2 Safety precautions when handling liquid gas
!WARNING!
zKeep combustible materials away from heating or cooking
devices and other light or heat sources.
zCompare the pressure information on the type plate with the
pressure information on the propane or butane gas cylinder.
zNever store liquid gas cylinders in unventilated areas or below
ground level (funnel shaped holes in the ground).
zKeep liquid gas cylinders away from direct sunlight. The temper-
ature may not exceed 50 °C.
2.3 Operating the device safely
!WARNING!
zOnly use the device outdoors.
zIf you smell gas:
– Close the valve on the gas cylinder and keep it closed until
the error is rectified.
– Never attempt to find a gas leak with a naked flame.
zPersons whose physical, sensory or mental capabilities or
whose lack of experience and knowledge prevent them from
using the device safely should not use it without supervision or
instruction by a responsible person.
zChildren must be supervised to ensure that they do not play with
the device.
zNever leave the device unattended when in use for prolonged
periods of time.
zUse long matches or a suitable lighter. Check the gas outlets
when you ignite the burners. Do not ignite the burners if you
cannot see them directly.
Take your hand away quickly once the burner is ignited.
zWear appropriate clothing when using the portable grill.
Do not wear loose-fitting clothing which could easily catch fire.
zLeave the portable grill to cool down properly before you touch
it with bare hands.
zReplace porous or damaged hoses immediately.
zNever change the nozzles, injector or burners.
_Dometic_Classic.book Seite 7 Donnerstag, 27. Januar 2011 6:37 18

General safety instructions Dometic Classic
8
ANOTICE!
zNever use the rack without the drip tray.
zOnly use pots and pans with a level base and a diameter of
10 to 20 cm.
zEnsure that pots and pans are stable when cooking.
zNever allow pot or pan handles to protrude over the edge of the
portable grill. Turn all the handles inwards. This reduces the risk
of spillage, the ignition of flammable materials and serious
scolding.
zProceed with caution when heating oil or fat, as they can ignite
under excessive heat.
zOnly use dry pot holders to avoid steam build-up. Do not use
towels or cloths as these can catch fire.
zNever leave the portable grill unattended while in use. Pots
which boil over can cause smoke and fires.
zHot parts should not be allowed to come into contact with oil,
water or any other liquids.
zNever move the device when it is still hot.
_Dometic_Classic.book Seite 8 Donnerstag, 27. Januar 2011 6:37 18

Dometic Classic Scope of delivery
9
3 Scope of delivery
No. in
fig. 1,
page 2
Quantity Designation
1 1 Burner with cooking rings
2 2 Side panel
3 1 Gas hose
4 1 Drip tray with rack
5 1 Grill rack holder
6 4 Stoppers
7 4 Stands
8 1 Roasting spit
92Meatclamps
10 4Fastening plates
11 1 Case
12 1Handle
13 1 Lock
– 2 Screws and nuts M3
– 1 Screw and nut M4
– 1 Operating manual
_Dometic_Classic.book Seite 9 Donnerstag, 27. Januar 2011 6:37 18

Optional extras Dometic Classic
10
4 Optional extras
5 Intended use
The Classic 1 and Classic 2 portable grills from Dometic are intended for
mobile use outdoors.
You can barbecue as well as cook on cooking rings of the upper part at the
same time. Depending on the model, the portable grill is connected to a gas
cylinder or the gas socket of a caravan.
The portable grill must not be used indoors.
6 Technical description
The portable grill can be dismantled and is easy to transport. All the parts fit
into the case.
Category I3(propane/butane) liquid gas is used as fuel.
6.1 Specifications for the portable grill models
The portable grill is available in different models and with different connec-
tions:
zClassic 1: portable grill with three cooking rings
zClassic 2: portable grill with two cooking rings
Both models are available with the following connections:
zConnection to gas cylinder
zConnection to gas socket
Designation Item no.
Grill trays 9103300804
Grill basket midi 9103300800
Grill basket maxi 9103300801
Grill motor battery 1.5 V 9103300802
Combination grill motor 9103300807
_Dometic_Classic.book Seite 10 Donnerstag, 27. Januar 2011 6:37 18

Dometic Classic Before initial use
11
6.2 Gas pressure
The permitted gas pressure can be found on the type plate in the bottom of
the case.
Models with a gas cylinder connection must be used with a pressure reducing
valve.
Only use pressure reducing valves that have been specified and approved in
your country.
!WARNING! Beware of injury
The outlet pressure of the valve must always match the connection
pressure (gas pressure) of the portable grill (see additional sheet).
7 Before initial use
➤Remove the protective film from the top of the burner (fig. 11, page 2).
➤Insert a stopper (fig. 21, page 2) into the bottom end of each stand
(fig. 22, page 2).
➤Screw the handle (fig. 112, page 2) into the lower part of the case with
both the screws M3.
➤Attach the lock (fig. 113, page 2) to the lid of the case with the screw
M4.
➤Clean the rack and the drip tray with a standard cleaning agent.
➤Only for models which are for connecting to gas cylinders: Connect
a pressure reducing valve (not included in delivery scope) to the end of
the gas hose (see additional sheet).
_Dometic_Classic.book Seite 11 Donnerstag, 27. Januar 2011 6:37 18

Using the portable grill Dometic Classic
12
8 Using the portable grill
8.1 Mounting the portable grill (fig. 3, page 3)
When selecting the location for barbecuing, observe the following instruc-
tions:
zSet up the portable grill outside in a well-ventilated place. Do not place it
in a dip to prevent any gases from accumulating there.
zThe ground must be firm, level and stabile.
zKeep the portable grill protected from the wind.
zNever place the portable grill near flammable materials, even when cool-
ing down. Keep a distance of at least 20 cm.
zObserve the safety instructions, see chapter “Safety precautions when
handling liquid gas” on page 7.
➤Unlock and open up the lid (1).
➤Gather all the individual parts and put them to one side.
➤Fasten the stands (3) onto the base:
– Place the fastening plates (2) in the base and hold in position with one
hand.
– Screw in the stand through the hole in the base from underneath.
– Turn the stand by hand in the fastening plates.
➤Attach the side panels:
– Hang the side panel (4) in the slot in the upper part of the portable grill
(1)(A).
– Fold it down.
– Hook the side panel onto the front of the grill base (B).
➤Place the burners (8) onto the side panels.
ANOTICE!
Never use the device without the drip tray. Without a drip tray the
signs in the base of the portable grill could get dirty, damaged from
the heat and illegible.
➤Slide the rack and drip tray in (5) at the required height.
➤If required, insert the roasting spit (6) into the rails on the side panels.
_Dometic_Classic.book Seite 12 Donnerstag, 27. Januar 2011 6:37 18

Dometic Classic Using the portable grill
13
➤Insert the injector (7) of the gas hose in the burners (8) until you hear it
click.
8.2 Connecting the portable grill to the gas cylinder
(only certain models)
!WARNING! Beware of injury
zOnly use propane or butane gas cylinders with an approved
pressure reducing valve and a suitable head.
zCompare the pressure information on the type plate with the
information on the pressure reducing valve.
Only use the gas hose supplied.
➤Place the gas cylinder (fig. 41, page 3) upright and at least 50 cm
away from the portable grill.
➤Check that the valve (fig. 42, page 3) on the gas cylinder is closed.
➤Screw the pressure reducing valve (fig. 43, page 3) onto the gas cylin-
der firmly by hand.
➤Make sure that the gas hose
– is not crushed or kinked
– is a safe distance from the burner
8.3 Connect the portable grill to the gas socket
(only certain models)
Only use the gas hose supplied.
➤Plug the gas hose into the gas socket.
➤Make sure that the gas hose
– is not crushed or kinked
– is a safe distance from the burner
_Dometic_Classic.book Seite 13 Donnerstag, 27. Januar 2011 6:37 18

Using the portable grill Dometic Classic
14
8.4 Igniting the portable grill
!WARNING! Beware of injury
zDo not leave the portable grill unattended while in use.
zIgnite the burners as soon as you have turned on the gas sup-
ply. Otherwise gas can accumulate in the burner area and could
cause an explosion.
zThe complete ignition process must be visible from above and
must not be hidden by pots placed on top of the hob.
➤Turn on the gas supply.
➤Ignite the burner immediately at the gas outlet (fig. 51, page 4) using
a long match or a suitable lighter. Remove your hand quickly as soon as
the burner is lit.
➤After it is ignited, check that the flames are burning on both sides along
the whole length of the burner pipe (fig. 52, page 4).
INOTE
zWhile it is operating, you will be able to hear a slight noise
caused by the gas flowing out. This is completely harmless.
zSmoke can occur when using it for the first time. This is caused
by deposits of machine oil burning and stops after approx.
10 minutes.
zThe stainless steel burners turn blue from the high temperature.
This does not affect the operation or the quality of the material.
_Dometic_Classic.book Seite 14 Donnerstag, 27. Januar 2011 6:37 18

Dometic Classic Using the portable grill
15
8.5 Cooking and barbecuing
Please note the following information when cooking and barbecuing:
!CAUTION! Danger of burns
zAlways use the grill rack holder when you want to raise or lower
the drip tray and spit while hot.
zRemove the grill rack holder while you are barbecuing.
Otherwise it gets very hot.
zDo not use any pots with curved bases.
zOnly use pots with a diameter between 10 cm and 20 cm.
zWhen barbecuing, control the temperature by raising or lowering the drip
tray and rack using the holder.
zThe very top recesses at the sides are intended for barbecuing steaks
quickly with intense heat.
zNever use the device without the drip tray. Without a drip tray the signs in
the base of the portable grill could get dirty, damaged from the heat and
illegible.
Using the drip tray also allows the heat from the burners to be used more
efficiently.
zAttach the food, such as poultry or a joint for roasting, with the two meat
clamps on the spit. Place the spit in the holders on the portable grill.
zA grill motor (optional extra) is ideal here for turning the joint. First attach
the grill motor to the left side panel by putting the fastener into the keyhole.
Then plug in the head of the roasting spit into the motor.
zWhen barbecuing with the roasting spit, the meat juices in the drip tray
can be used for making sauces according to taste.
8.6 Switching off the portable grill
➤Turn off the gas supply.
✓The flames go out.
_Dometic_Classic.book Seite 15 Donnerstag, 27. Januar 2011 6:37 18

Troubleshooting Dometic Classic
16
8.7 Dismantling the portable grill
!CAUTION! Beware of burns
The portable grill is very hot when you use it. Leave the portable
grill to cool down before you clean, dismantle or transport it.
➤Disconnect the portable grill from the gas supply.
➤Dismantle the portable grill once it has cooled down.
➤Clean the individual parts (see chapter “Cleaning the portable grill” on
page 17).
➤Store the individual parts in the case.
➤Close the case with the zip.
8.8 Replacing the gas cylinder
!WARNING! Beware of injury
Change the gas cylinder in a well-ventilated location.
Ensure that there are no open flames in the vicinity.
Only replace the gas cylinder when the portable grill is switched off.
➤Completely close the valve on the gas cylinder.
➤Unscrew the pressure reducing valve from the cylinder.
➤Check the condition of the gas hose.
Replace the hose line if the material is brittle or porous.
➤Tightly screw the pressure reducing valve by hand onto the new cylinder.
9 Troubleshooting
Repairs to the gas supply parts on the device may only be carried out by a
qualified technician.
➤Shut off the gas supply immediately if a fault occurs.
➤Check again that the device has been assembled correctly and the parts
are undamaged, especially the gas hose and injector.
➤Replace the damaged parts.
➤Only use the device again once all the faults have been rectified.
_Dometic_Classic.book Seite 16 Donnerstag, 27. Januar 2011 6:37 18

Dometic Classic Cleaning the portable grill
17
10 Cleaning the portable grill
ACaution
Do not use any sharp or hard objects for cleaning since they may
damage the device.
Only use standard cleaning agents.
➤Allow the device to cool down properly before cleaning it.
➤Clean the surfaces. Pay special attention to removing sticky fat and oil
residue.
➤Do not use a steam cleaner to clean the device under any circumstances.
➤Allow the device to dry before packing and storing.
11 Guarantee
The statutory warranty period applies. If the product is defective, please
contact the manufacturer's branch in your country (see the back of the
instruction manual for the addresses) or your retailer.
For repair and guarantee processing, please include the following docu-
ments when you send in the device:
zA copy of the receipt with purchasing date
zA reason for the claim or description of the fault
12 Disposal
➤Place the packaging material in the appropriate recycling waste bins
wherever possible.
➤If you wish to finally dispose of the product, ask your local recycling centre
or specialist dealer for details about how to do this in accordance with the
applicable disposal regulations.
_Dometic_Classic.book Seite 17 Donnerstag, 27. Januar 2011 6:37 18

Technical data Dometic Classic
18
13 Technical data
Description, connection pressure Item no.
Portable grill Classic 1, 50 mbar, D/A/CH 9103300043
Portable grill Classic 1, 30 mbar, DK/NO 9103300063
Portable grill Classic 1, 30 mbar, ES 9103300118
Portable grill Classic 1, 30 mbar, FI 9103300048
Portable grill Classic 1, 30 mbar, FR 9103300061
Portable grill Classic 1, 30 mbar, GB/IT/SE 9103300071
Portable grill Classic 1, 30 mbar, NL 9103300084
Portable grill Classic 1, 30 mbar, gas socket 9103300055
Description, connection pressure Item no.
Portable grill Classic 2, 50 mbar, D/A/CH 9103300009
Portable grill Classic 2, 30 mbar, DK/NO 9103300025
Portable grill Classic 2, 30 mbar, ES 9103300119
Portable grill Classic 2, 30 mbar, FI 9103300024
Portable grill Classic 2, 30 mbar, FR 9103300023
Portable grill Classic 2, 30 mbar, GB/IT/SE 9103300126
Portable grill Classic 2, 30 mbar, NL 9103300117
Portable grill Classic 2, 30 mbar, gas socket 9103300026
_Dometic_Classic.book Seite 18 Donnerstag, 27. Januar 2011 6:37 18

Dometic Classic Technical data
19
Variations, technical improvements and delivery options reserved.
Dometic Classic 1
Gas consumption: 385 g/h
Gas category: Category I3, propane/butane
Number of cooking rings: 3
Burner output: 5300 W
Dimensions: Closed portable grill: 288 x 620 x 128 mm
Drip tray with rack: 290 x 600 mm
Sheet metal: 238 x 544 mm
Rack: 234 x 540 mm
Weight: 10 kg
Inspection/certification:
Dometic Classic 2
Gas consumption: 320 g/h
Gas category: Category I3, propane/butane
Number of cooking rings: 2
Burner output: 4300 W
Dimensions: Closed portable grill: 288 x 510 x 128 mm
Drip tray with rack: 290 x 506 mm
Sheet metal: 238 x 435 mm
Rack: 234 x 431 mm
Weight: 8 kg
Inspection/certification:
_Dometic_Classic.book Seite 19 Donnerstag, 27. Januar 2011 6:37 18

Hinweise zum Benutzen der Anleitung Dometic Classic
20
Bitte lesen Sie diese Anleitung vor dem Einbau und der Inbetriebnahme
sorgfältig durch und bewahren Sie sie auf. Geben Sie sie im Fall einer
Weitergabe des Geräts an den Nutzer weiter.
Inhalt
1 Hinweise zum Benutzen der Anleitung . . . . . . . . . . . . . . . . . . . . . . 20
2 Allgemeine Sicherheitshinweise . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3 Lieferumfang . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4 Zubehör . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5 Bestimmungsgemäßer Gebrauch . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6 Technische Beschreibung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7 Vor dem ersten Gebrauch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
8 Koffergrill benutzen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
9 Störungsbeseitigung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
10 Koffergrill reinigen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
11 Gewährleistung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
12 Entsorgung. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
13 Technische Daten . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
1 Hinweise zum Benutzen der Anleitung
!WARNUNG!
Sicherheitshinweis: Nichtbeachtung kann zu Tod oder schwerer
Verletzung führen.
!VORSICHT!
Sicherheitshinweis: Nichtbeachtung kann zu Verletzungen
führen.
AACHTUNG!
Nichtbeachtung kann zu Materialschäden führen und die Funktion
des Produktes beeinträchtigen.
_Dometic_Classic.book Seite 20 Donnerstag, 27. Januar 2011 6:37 18
