Dorel Living DL058-CH User manual

Model Number: UPC Code: Color:
DL058-CH
0-65857-20363-9 Grey
Date of Purchase: _____ / _____ / _____ Lot Number:
(Located on carton)
Chair
For more great furniture ideas, check out our website at www.dorelliving.com
You can also keep up to date on all the latest trends by liking our Facebook page
and Instagram page.
NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
Congratulations on your latest furniture purchase! Dorel Living furniture has been developed with quality,
convenience and style in mind. We trust it will provide you with many years of exceptional comfort and
service.
Before beginning assembly, we encourage you to familiarize yourself with your new furniture piece by
taking a few minutes to go through this booklet. It contains important information on our warranty and care
tips to keep your furniture looking as good as new.
Questions, concerns, missing parts? Customer satisfaction is important to us at Dorel Asia. CONTACT
OUR CUSTOMER SERVICE DEPARTMENT BEFORE RETURNING PRODUCT TO THE RETAILER.
Our agents are available Monday to Friday 8am to 5pm (EST) to take your call and answer any questions. For faster
service, always have the model number ready when contacting us.
toll free #: 1-800-295-1980
You can also reach us by email or by visiting our website and clicking on the Support tab:
[email protected]
www.dorelliving.com

* CAUTION: Adult assembly required.
* Estimated assembly time: 15 minutes.
CUSTOMER SERVICE
You can also contact us by writing to the address listed below. Please include the product model number, color and a
detailed description of your enquiry.
Dorel Living - Customer Service Department
12345 Albert-Hudon Boulevard, Suite 100
Montreal, Quebec
Canada, H1G 3L1
NOTES
* Ensure all parts and components are present before beginning assembly.
* Assembly and handling will require two people.
* Assemble on a soft, smooth surface to prevent damage to the product finish.
* Read all instructions completely before assembly.
* DO NOT use power tools.
* The cushions have been vacuum packed for transportation purposes. After unpacking, please allow up to 72 hours
so that they can return to their original shape.
CARE, CLEANING AND MAINTENANCE
1-YEAR LIMITED WARRANTY
WARNING: Should this product become damaged, and/or components are
broken or missing, DO NOT USE.
Dust regularly with a soft, dry cloth to prevent soil build up. Keep away from heat to avoid glazing, melting or
scorching. Use a professional cleaning service to clean the fabric.
Dorel warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect.
This warranty covers 1 year from the date of original purchase from authorized retailers. This warranty is valid only
upon presentation of proof of purchase. This is solely limited to the repair or replacement of defective furniture
components and no assembly labor is included. This warranty does not apply to any product which has been
improperly assembled, subjected to misuse or abuse or which has been altered or repaired in any way. The warranty
does not cover wearing, tearing, fading or splitting of the fabric (where applicable). This warranty gives you specific
legal rights and you may also have other rights which vary from State to State or Province to Province.

PARTS LIST
A B
C D
E F
G H
CHAIR
DL058-CH
CHAIR BACK
SEAT PANEL
1 PC
1 PC
FRONT RAIL
LEFT ARM
1 PC
1 PC
RIGHT ARM
SEAT CUSHION
1 PC
1 PC
BACK CUSHION
FOOT
1 PC
4 PCS

HARDWARE LIST
1 2
3
CHAIR
DL058-CH
BOLT 1/4" X 1 1/10"
WASHER
12 PCS
12 PCS
ALLEN KEY 4MM
1 PC

STEP 1
CHAIR
DL058-CH
Place all parts on a clean, smooth surface.
Attach feet (H) to right arm (E) and left arm (D) with bolts (1) and washers (2).
E
3
D
1
2
H

STEP 2
CHAIR
DL058-CH
Attach front rail (C) to right arm (E) and left arm (D) by inserting the metal brackets on the front rail (C)
into the metal plate on left and right arms (D & E) as shown.
Push the front rail (C) with a downward force to secure it into place.
E
D/E
C
D
C
D/E
C

STEP 3
CHAIR
DL058-CH
Attach seat panel (B) to left arm (D) and right arm (E) by inserting the metal brackets of seat panel (B)
into the metal glides on left arm (D) and right arm (E).
Push the seat panel (B) with a downward force to secure it into place
B
D
D/E
E
B
C

STEP 4
CHAIR
DL058-CH
Attach chair back (A) to left and right arms (D & E) by inserting the brackets on chair back (A) into the
metal glides on left and right arms (D & E).
Push the chair back (A) with a downward force to secure it into place.
Secure the fabric flaps on chair back (A) to left arm(D) and right arm(E) using the Velcro strips.
NOTE: Both sides
must be inser
ted
at the same time.
This step is best
performed with 2
people.
B
A
D
E
C
A
D
E

CHAIR
DL058-CH
STEP 5
Remove the cushions from their vacuumed sealed package.
Place the cushions (F & G ) onto the chair using the Velcro strips.
F
G
NOTE:The cushions have been vacuum
packed for transportation purposes. After
unpacking, please allow up to 72 hours so
that they can return to their original shape.

CHAIR
DL058-CH
CAUTION: This unit is intended for use only with the products
and/or maximum weights indicated. Use with other products and/or
products heavier than the maximum weights indicated may result in
instability or cause possible injury.
Dust regularly with a soft, dry cloth to
prevent soil build up. Keep away from
heat to avoid glazing, melting or
scorching. Use a professional
cleaning service to clean the fabric.
That's it! You've finished assembling your chair.
DO NOT RETURN PRODUCT TO THE RETAILER.
If a part is missing or damaged, contact our customer service department.
We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [email protected]
Fax #: [phone]
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]
Recommended Maximum Weight =
225 lbs.
