Dorel 5047096COMUK User manual

–Unit can !p over causing severe injury or death.
–Anchor unit to stud in wall (if instructed to)
–Do not allow children climb on unit
–Put heavy items on lower shelves or drawers
5047096COMUK
Date of Purchase: ____/____/_____
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
WARNING
Do Not Return This Product!
Contact our customer service team for help first
Call: 01942 524100
E-mail: cseur[email protected]om
Easy Tough
Assembly Difficulty Meter

PEOPLE NEEDED FOR ASSEMBLY: 1-2
ESTIMATED ASSEMBLY TIME: 1 HOUR
2
- Open your item in the area you plan to keep it for less heavy li!ing
- Iden"fy, sort and count the parts before a#emp"ng assembly
- Compression dowels are tapped in with a hammer
- Slides are labeled with a R (right) and L (le!) for proper placement
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge
- Use all the nails provided for the back panel and spread them out equally
- Back Panel must be used to make sure your unit is sturdy
- Do NOT use harsh chemicals or abrasive cleaners on this item
- Never push, pull, or drag your furniture
Helpful Hints

Before You Start
Cam Lock Fastening System
3
P
P
P
P
P
This Cam Lock Fastening System will be used throughout the assembly process.
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Cau•on: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is •ght.
Failure to do so may result in stripping the screw.
Quick
Tip
Assembly
1
3
2
4

Board Iden•fica•on
Not actual size
4
x2
T5047096010UD
SIDE TOP
x1
T5047096020UD
MIDDLE TOP
x4
T5047096030UD
UPPER SUPPORT PANEL
x2
T5047096040UD
SIDE BOTTOM
x1
T5047096050UD
MIDDLE BOTTOM
1
5
2 3
4
x2
T5047096060UD
LOWER SUPPORT PANEL
6
x2
T5047096070UD
LOWER SUPPORT PANEL
7
x1
T5047096080UD
BOTTOM SUPPORT PANEL
8
x4
T5047096090UD
LEG
9
x4
T5047096100UD
FOOT
10

Part List
Actual Size
5
x4
TUD0029
BOLT
M6 X 70
x42
TUD0001
Cam Bolt
M6 X 23
x42
TUD0002
Cam Lock
15-12
x26
TUD0030
DOWEL
M6 X 30

6
Step 1
x26
TUD0001
x10
TUD0030

7
Step 2
x8
TUD0001
x8
TUD0030

8
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 3
x18
TUD0002

9
Step 4
x8
TUD0001
x8
TUD0030

10
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 5
x16
TUD0002

11
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 6
x8
TUD0002

12
Step 7
x4
TUD0029

13
Maximum Loads
This unit has been designed to support the maximum loads shown. Exceeding these load limits
could cause sagging, instability, product collapse, and/or serious injury.
1. This cer!ficate applies to Dorel Home Furnishings, Inc. product iden!fied by this instruc!on manual.
2. This cer!ficate applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303).
3. This product is distributed by:
4. Site of Manufacturer: Muar, Malaysia.
5. See front page of instruc!on manual for date of manufacturer.
Dorel Home Furnishings Europe Ltd.
Building 4, Imperial Place Maxwell Road
Borehamwood WD6 1JN United Kingdom
01942 524100
Cer!ficate of Confirmity
Warning: Risk of serious injury to person - do not place a television on this furniture. This furniture
is not approved for use with a television.
