Doro HANDLEEASY 326GSM User manual

HandleEasy
326GSM
English
Svenska
Norsk
Dansk
Suomi
Français

4
2
1
3
56
7
8
9

1 UPP volym/
navigering
2 NED volym/
navigering
3 Menyknapp/OK w
4 Uppringnings/
svarsknapp
5 *och knapplås
6 #och ringsignal/
vibrator
7 Nedkopplingsknapp
(AV/PÅ)
8 Direktvalsknappar
9 Laddnings/
headset-uttag
Svenska
1 Volume UP/
navigation
2 Volume DOWN/
navigation
3 Menu button/OK w
4 Dialling/answer
button
5 *and keypad lock
6 #and ring setup/
vibrator
7 Disconnect button
(ON/OFF)
8 One-touch
memory buttons
9 Charging/headset
socket
English
1 OPP volum/
navigering
2 NED volum/
navigering
3 Menyknapp/OK w
4 Oppringings-
/svarknapp
5 *og tastelås
6 #og ringesignal/
vibrator
7 Nedkoblingsknapp
(AV/PÅ)
8 Hurtigtaster
9 Lade-/hodesettuttak
Norsk

1 Augmentation du
volume/navigation
2 Diminution du
volume/navigation
3 Touchededélement
du menu/OK w
4 Touche de décroché
5 Touche *et de
verrouillage du clavier
6 Touche #et
de réglage de
sonnerie/vibreur
7 Touche de raccroché
et de mise en/
hors service
8 Touches de
mémoires directes
9 Prise du chargeur
et du casque
Français
1 Lisää
äänenvoimakkuutta
/ siirtyminen ylös
2 Vähemmän
äänenvoimakkuutta
/ siirtyminen alas
3 Valikkonäppäin/OK w
4 Soitto-/vastauspainike
5 *ja näppäinlukko
6 #ja soittoääni/
värinähälytin
7 Katkaisu-/virtapainike
8 Pikavalintapainikkeet
9 Lataamis-/
kuulokeliitäntä
Suomi
1 OP lydstyrke/
navigering
2 NED lydstyrke/
navigering
3 Menutast/ OK w
4 Opkalds-/besvartast
5 *og tastaturlås
6 #og ringesignal/
vibrator
7 Afbrydertast FRA/TIL
8 Hurtigvalgstaster
9 Stik til opladning/
headset
Dansk

1
English
Operation
Important!
Before you can make or receive calls you must carry out the steps
detailed in Settings / Installation.
Turning On/Off
The telephone can be turned on by pressing
down L/1until the ON signal is heard and
the display lights up.
If the SIM card is locked with a PIN code
(PersonalIdenticationNumber)“Enter PIN:”
will be shown in the display. Enter your pin
codeandconrmwithw on the side.
Normally the SIM card will be locked after three
incorrect entries. The display shows how many
attempts you have left with ”Trials Remain:”.
If the PIN code is locked by mistake you will
need the PUK code (Personal Unblocking Key)
supplied with your SIM card to unlock it.
Normally you will have ten attempts to enter the
correctPUKcodeandconrmwithw. Then
enteranewPINcodeandconrmit.
The telephone can be turned off by pressing
down L/1until the OFF signal is heard.
If the codes were not supplied with the SIM
card you can get them from your network
operator.

2
English
Making a call
1. Enter the desired number followed by q. A
signal will be heard as the number is dialled.
Move the cursor backwards and delete/
change with L.
2. Press Lto end the call.
Please note!
When making international calls press *twice for the
international prex (the + sign replaces the prex).
Dialling with the one-touch buttons
1. Press A-D followed by q. A signal will be
heard as the number is dialled. Alternatively,
hold down A-D until the signal is heard
(approx. 2 seconds).
2. Press Lto end the call.
Dialling with speed dial numbers
1. Press wand scroll between the entries with
}/{. Alternatively enter the speed dial entry
number (1-50) for quick selection.
2. Press qfor the desired number. A signal is
heard as the number is dialled.
3. Press Lto end the call.
Receiving a call
1. Wait for ring signal.
2. Press qto answer. Press Lto end the call.
Alternatively, press Limmediately to reject
the call.

3
English
Speaker function
The speaker function means that the telephone
can be placed on the table, leaving your hands
free.
1. Dial the number in the usual way.
2. When the call is connected, press q.
3. Placethetelephoneonaatsurface,e.g.atable.
4. Speak into the microphone on the lower front
edge of the telephone (max 1 metre away).
5. The volume can be adjusted during a call
with }/{.
6. To change between the speaker function
and handset use, press q.
7. Press Lto end the call.
Please note!
In speaker mode, it is only possible for one person at a time to
talk. The alternation between the one speaking and the one
listening is automatic and dependent on the sound level in the
room containing the telephone (you) and the sound from the line
(caller). It is therefore essential that there are no loud noises, e.g.
music, in the immediate vicinity of the telephone, as this will
disrupt the speaker function.
Volume control
The volume can be adjusted during a call with
}/{on the side.

4
English
Redial
Press qand scroll between the 15 most
recent dialled/incoming numbers with }/{.
Press qto dial or Lto end.
New calls (Caller ID memory)
The display shows who is calling before you
answer, or you can view the 10 most recent
missed calls.
Missed calls are indicated with the symbol
and the number of missed calls.
If multiple calls are received from the same
number only the most recent of these calls will
be saved.
Retrieving and dialling
1. Press w.
2. Scroll to the desired entry with {/}.
3. Press qto dial or Lto end.
Calleridenticationmessages
In addition to number display, the following
messages will be shown occasionally:
?????? No information available, i.e. an
international call or a withheld number.

5
English
Emergency calls
When the telephone is switched on, it is
possible to place an emergency call (999/112)
by entering 999/112 followed by q. Most
mobile networks accept emergency calls even
when the SIM card is not in the telephone.
Keypad lock
The keypad lock is turned on/off by pressing
down */Lfor approx. 2 seconds).
is shown in the display when the keypad
lock is active.
Headset
The telephone can be used with a headset/ear
hook, and is equipped with a socket for this.
When using a headset calls are answered and
made in exactly the same way as usual. When
a headset is connected, the microphone in the
telephone is disconnected automatically. This
telephone supports the answer function with a
button on the headset cable.
Warning!
Only use batteries, charger and accessories that have been
approved for use with this particular model. Connecting other
accessories may invalidate the telephone’s type-approval and
guarantee; furthermore it could be dangerous.
Connection to a USB port on a computer may damage the
telephone or the computer. The volume may be high on the
headset. This can be adjusted during the rst call.

6
English
Settings
Saving one-touch numbers
This telephone is able to save 4 telephone
numbers on the one-touch A-D buttons.
1. Enter the telephone number, including the
area code. Skip backwards/change with L.
2. Press down the desired one-touch button A-D
until is shown in the display.
3. Press wto save or Lto end.
Saving speed dial numbers
The telephone is able to save 50 speed dial
numbers.
1. Enter the telephone number, including the
area code. Skip backwards/change with L.
2. Press wand scroll to the desired entry with
}/{.
3. Press wto save or Lto end.
Please note!
It is not possible to delete saved numbers. If you need to change
a number just save the new number in the same location as the
old one. To save an international number, press *twice for the
international prex (the + sign replaces the prex) and enter
the country code, area code (possibly leaving out the rst zero)
and telephone number. If a pause (approx. 3 seconds) is required
in the telephone number, press *three times until pis shown.

7
English
If you want to save a number that can dial numbers after the
call is answered, save the number with a win front of the
numbers that you wish to send. Press *four times until wis
shown. When you make the call, the telephone will enter all the
numbers before the w. Wait for an answer and then press wto
send the numbers after w.
Ring Setup
Choose between the 9 different ring signals by:
1. Press w, the one-touch numbers will be
shown.
2. Press down wfor approx. 2 seconds, the
ring signals will be shown.
3. Scroll between the ring signals with {/}.
4. When you have selected the ring signal you
want, press w.
5. Press Lto end.
Ring signal strength is adjusted in standby
mode by holding }or {pressed down for
approx. 2 seconds and then pressing }or {.

8
English
Vibrator
Press down #for approx. 2 seconds to
activate the vibrator with or without ring signal.
Press and hold repeatedly to move between
the different modes.
Ring signal
Vibrator only
Ring signal and vibratorRing signal and vibrator
Time/date
1. Press w, the one-touch numbers will be
shown.
2. Press down wfor approx. 2 seconds, the
ring signals will be shown.
3. Press down wfor approx. 2 seconds).
4. Press wto enter time (HH:MM). Press wto
save.
5. Scroll to date with }/{. Press wand enter
date (YYYY.MM.DD). Press wto save.
6. Press Lto end.

9
English
Installation
Always ensure that the telephone is turned off
before the battery cover is removed.
Charging
Connect the mains adapter to the wall socket
and the socket on the telephone. Charge the
telephonefor24hoursthersttime.
Battery
As batteries only have a certain lifespan it is
quite normal that call time and standby time
will decrease somewhat compared to the
specicationswhenthetelephoneisused
regularly. Fully-charged batteries (5 hours
charging) will last for approx 160 hours standby
time or approx 140 minutes call time. These times
apply at normal room temperature. Full battery
capacity will not be reached until the batteries
have been charged 4-5 times. The telephone has
an automatic charging mechanism that prevents
the batteries from being overcharged or damaged
due to prolonged charging.
When the battery is running low, is
displayed and a warning signal will be heard.
Warning!
Only use batteries, charger and accessories that have been
approved for use with this particular model.

10
English
Connecting other accessories may invalidate the telephone’s
type-approval and guarantee; furthermore it could be dangerous.
Connection to a USB port on a computer may damage the
telephone or the computer.
Battery cover
To remove the battery cover on the back of
the telephone, press carefully on the ribbed
surface and slide the cover downwards.
To replace, slide the cover from below and up
along the telephone.
Installation/removal of battery
Insert the battery with the contacts facing upwards.
Place the top of the battery in the holders on the
telephone. Then press carefully on the bottom of
the battery until it locks in place. To remove the
battery, carefully press and lift the bottom of the
batteryinthe“nger-shaped”groove.
Installation/removal of SIM card
The SIM card holder is located under the
battery cover behind the battery. Make sure
that the SIM card’s gold contacts are facing
inwards and the cut-off corner is correctly
positioned (upwards). The SIM card and its
contacts are easy to damage if you scratch or
bend them, so be careful when you handle,
insert or take out the card. If the SIM card is
missing or has been inserted incorrectly,
will be shown in the display.

11
English
The display
Indicator Status
Charging is in progress
Charging completed
Signal strength
Line 1 (certain operators have 2 lines)
Battery indicator
Keypad lock activated.
Missed call.
Roam, connected to another network
Headset connected
No SIM card
SIM card error
Error indication
Volume indicator
No light Turned off

12
English
Care and Maintenance
Your unit is a technically advanced product and should
be treated with the greatest care. By following the
advice below, you can ensure that the guarantee will
cover any damage.
• Protect the unit from moisture. Rain/snowfall,
moisture and all types of liquid can contain
substances that corrode the electronic circuits. If the
unit gets wet, you should remove the battery and
allow the unit to dry completely before you replace it.
• Do not use or keep the unit in dusty, dirty
environments. The unit’s moving parts and electronic
components can be damaged.
• Do not keep the unit in warm places. High
temperatures can reduce the lifespan for electronic
equipment, damage batteries and distort or melt
certain plastics.
• Do not keep the unit in cold places. When the unit
warms up to normal temperature, condensation can
form on the inside which can damage the electronic
circuits.
• Do not try to open the unit in any other way than that
which is indicated here.
• Do not drop the unit. Do not knock or shake it either.
If it is treated roughly the circuits and precision
mechanics can be broken.
• Do not use strong chemicals to clean the unit.
• Use the charger indoors.
The advice above applies to the unit, battery, charger
or other accessories. If the telephone is not working
as it should, please contact the place of purchase for
service. Don’t forget the receipt or a copy of the invoice.

13
English
Further safety information
The unit and the accessories can contain small parts.
Keep them out of the reach of small children.
Operating environment
Remember to follow any particular rules that may
apply wherever you happen to be, and always turn off
the unit whenever its use is forbidden, or it can cause
interference or danger. Only use the unit in its normal
user position. This unit complies with guidelines for
radiation when it is used either in a normal position
against your ear, or when it is at least 2.2 cm (7/8 inch)
from your body. If the unit is carried close to your body
in a case, belt holder or other holder these should not
contain any metal, and the product should be placed
atthedistancefromyourbodyspeciedabove.Make
sure that the distance instructions above are followed
until the transfer is complete. Parts of the unit are
magnetic. The unit can attract metal objects. Do not
keep credit cards or other magnetic media near the unit,
as information stored on them can be erased.
Medical units
The use of equipment that transmits radio signals,
e.g.mobilephones,caninterferewithinsufciently
protected medical apparatus. Consult a doctor or the
manufacturer of the apparatus to determine if it has
adequate protection against external radio signals, or if
you have any questions. If notices have been put up at
health care facilities instructing you to turn off the unit
while you are there, you should comply. Hospitals and
other health care facilities sometimes use equipment
that can be sensitive to external radio signals.

14
English
Pacemaker
Pacemaker manufacturers recommend a distance of
at least 15 cm (6 inches) between a mobile phone and
a pacemaker to avoid the risk of interference with the
pacemaker. These recommendations are in accordance
with independent research and recommendations from
Wireless Technology Research. People with pacemakers
should:
• always keep the unit at a distance of at least 15 cm from
the pacemaker
• not carry the unit in a breast-pocket
• hold the unit against the ear on the opposite
side from the pacemaker to reduce the risk of
interference.
If you suspect that there is a risk of interference, turn off
the unit and move it further away.
Hearing aids
Some digital wireless units can cause interference to
some hearing aids. Using the Doro HearPlus eh346m
EarHook can eliminate this for hearing aids with a ‘T’
position. If any other interference occurs, please contact
your operator.

15
English
Vehicles
Radio signals can affect electronic systems in motor
vehicles (e.g. electronic fuel injection, ABS brakes,
automatic cruise control, air bag systems) that have
been incorrectly installed or are inadequately protected.
Contact the manufacturer or its representative for
more information about your vehicle or any additional
equipment.
Donotkeeportransportammableliquids,gasesor
explosives together with the unit or its accessories. For
vehicles equipped with air bags: Remember that air
bagsllwithairwithconsiderableforce.
Donotplaceobjects,includingxedorportableradio
equipment in the area above the airbag or the area
where it might expand. Serious injuries may be caused
if the mobile phone equipment is incorrectly installed
andtheairbagllswithair.
Itisforbiddentousetheunitwhilstying.Turnoffthe
unit before you board a plane. Using wireless telecom
units inside a plane can involve risks for air safety and
interfere with telecommunications. It can also be illegal.
Areas with explosion risk
Always turn off the unit when you are in an area
where there is a risk of explosion and follow all signs
and instructions. An explosion risk exists in places
that include areas where you are normally requested
to turn off your car engine. Within such an area,
sparkscancauseexplosionorrewhichcanleadto
personalinjuries,evendeath.Turnofftheunitatlling
stations i.e. near petrol pumps and garages. Follow
the restrictions that are in force on the use of radio
equipment near places where fuel is stored and sold,

16
English
chemical factories and places where blasting is in
progress. Areas with risk for explosion are often - but
not always - clearly marked. This also applies to below
decks on ships; the transport or storage of chemicals;
vehicles that use liquid fuel (such as propane or
butane); areas where the air contains chemicals or
particles, such as grain, dust or metal powder.
Emergency calls
Important! Mobile phones such as this unit use radio
signals, the mobile phone network, the terrestrial network
and user-programmed functions. This means that
connection in all circumstances cannot be guaranteed.
Therefore you should never rely solely on a mobile phone
for very important calls such as medical emergencies.
Subscription
Bear in mind that certain Pay As You Go accounts only
inform the user when it is time to top up the account via
SMS. As this phone has no SMS function, some other
way must be used to ensure that the account is working.
Specic Absorption Rate (SAR)
This device meets applicable international safety
requirements for exposure to radio waves. This
telephone measures 0.3 W/kg (GSM 900MH�), 0.20.3 W/kg (GSM 900MH�), 0.2
W/kg (DCS 1800MH�) (measured over 10g tissue). The(measured over 10g tissue). The
max. limit according to WHO is 2W/kg (measured over
10g tissue).
