Doro 8020X User manual
Doro 8020X
Quick Start Guide
Live life.
Micro USB Headset port
Power
on/o
Assistance
buon
Home End callAnswer call
Volume
+ /-
2www.doro.com
Doro 8020x
TABLE OF CONTENTS
1. Unboxing your new phone.................................................. 3
Package contents ......................................................................3
......................................................... 4
Insert memory card and SIM card ............................................4
Charging the baery .................................................................4
Turn on the phone ....................................................................5
First Start-Up .............................................................................5
PC connecon and les transfer ...............................................6
Presentaon of the phone icons...............................................6
.................................................................. 7
To make a call ............................................................................7
To receive a call .........................................................................7
The home screen.......................................................................7
...............................................................7
............................................................8
Hardware reboot.......................................................................8
Factory reset..............................................................................8
.............................................................. 8
...................................................... 11
8. Warranty .......................................................................... 12
.............................................. 12
........................................ 13
...................................... 13
.................... 14
.................................................................. 14
.......................................... 15
3www.doro.com
Doro 8020x
1. UNBOXING YOUR NEW PHONE
The rst step is to unbox the phone and assess the items
and equipment included in the delivery. Make sure to read
through the manual so you can familiarise yourself with the
equipment and the basic funcons.
• The items supplied with the device and any available
accessories may vary depending on the region or service
provider.
• The supplied items are designed for this device and may
not be compable with other devices.
• Appearances and specicaons are subject to change
without prior noce.
• You can purchase addional accessories from your local
Doro retailer. Make sure they are compable with the
device before purchase.
• Only use baeries, chargers and accessories that have
been approved for use with this parcular model.
Connecng other accessories may be dangerous and may
invalidate the phone’s type approval and warranty.
Check that the following is included in the product box:
• Device
• Quick start guide
• USB cable
• USB charger
• Stereo headset
• Card tool
4www.doro.com
Doro 8020x
2. STARTING UP THE DEVICE
CAUTION
Since this device has a non-remov-
able baery, all aempts of device
disassembly (baery cover included) will
void the warranty.
1. Open the plasc cap on the right side
of the phone to access the micro SIM
and micro SD card slots as shown:
2. Use the tool provided in the box to
insert the SIM card, making sure
that the cut o corner is on the right
place. This device accepts micro SIM
or 3FF SIM card. Use of incompat-
ible SIM cards may damage the
card or the device, and may corrupt
data stored on the card. If your SIM
format is not compable, contact
your operator.
3. If you have a memory card (Micro SD
format), insert it in the memory card
slot as described:
Note: It is possible to insert and remove
your SD card while the mobile is switched
on without aecng its operaon. It is
recommended to unmount your card in
â
Storage
â
before removing it in case the mobile is
turned on. It allows to not corrupng some of the data on the SD
card.
A micro USB cable and a charger are provided with your
phone.
1. First, connect the USB port in the charger.
2. Then, connect the micro USB plug of the cable to the
connector of your phone and plug in the charger to an
electrical outlet to start charging the baery.
GB
5www.doro.com
Doro 8020x
Turn on the phone
Once you’ve fully charged the device:
• Turn it on by pressing and holding the
Power ON / OFF
key. Keep it pressed unl the display lights up.
• Enter your SIM card PIN if requested, then select to
conrm. Tap to erase.
• Wait for the phone to start.
Note: In case of any problem, you have the opon to restart your
device by pressing the
Power ON / OFF
key for more than 10 seconds.
Note! When turning on your phone, the installed applicaons may
need to be updated. Applicaon updates requires Internet connecon
and can take a few minutes. A Wi-Fi connecon is preferable. The
phone may appear a bit slow during the update.
1. When you are starng your mobile phone for the rst
me, an intuional conguraon help is started.
2. To be able to fully use your new smartphone you need a
Google Account. If you don’t have one yet, no worries, as
you will be guided through a account setup when starng
the phone for the rst me.
Tip: By seng the opon
your data is
backed up at your Google Account which allows you to access your
conguraons any me at your Google account and to transfer the
data to any other AndroidTM device.
6www.doro.com
Doro 8020x
1. A Micro USB-cable allows you to connect your mobile
phone to your computer and to transfer all types of
documents (images, music,..) from your computer to your
mobile phone or reverse. The mobile phone is detected
as a mulmedia device and you can copy/paste the les
from your computer to your mobile phone.
2. Once your mobile phone is connected to your computer,
a message
is displayed in the noca-
on bar.
3. In the nocaon screen click on the
and select
in order to
make sure that the internal and external memory
(micro SD card) is accessible via your computer.
Current signal strength Bluetooth is acvated
No network available Baery charge level
Flight mode acve Baery is charging
2G connecon New voice mail is received
3G connecon Missed call
3G+ connecon New SMS/MMS received
4G connecon New e-mail is received
You are connected to a
foreign network, roaming
fees might apply
Connected to USB
Wi-Fi is acvated Downloading in progress
Hotspot Wi-Fi Synchronisaon in progress
Alarm acvated
7www.doro.com
Doro 8020x
3. PHONE FUNCTIONS
1. Press the buon or the phone app.
2. Select number or contact.
3. Press to make a call.
4. Press to end the call.
Tip: For internaonal calls, always use + before the country code for
best operaon. Long press 0 (zero) for the internaonal prex +.
1. Press to answer.
Alternavely press to reject directly (busy signal).
2. Press to end the call.
Your phone has a
on which you can install your
and/or
. You have also the possibility
to add new screens by sweeping an applicaon or a widget
from the last screen available to the right border.
1. Press to return to the
.
4. ASSISTANCE BUTTON
In order to possibly make everyday safer, the phone has
an assistance buon. The assistance buon makes it easy
to contact the help numbers you have predened in the
Assistance number list . Before the assistance buon can
be used, the assistance funcon has to be acvated, phone
numbers added to the number list and, the text message
edited with the informaon you want to send.
1. Press and hold the
to congure it.
Select how to acvate the assistance funcon:
•
to acvate by pressing the buon 3 mes
within 1 second.
•
to acvate by pressing and holding the buon
for approximately 3 seconds, or press it twice within 1
second.
8www.doro.com
Doro 8020x
5. RESETTING THE PHONE
This device has an internal baery and therefore the
hardware cannot be rebooted by the removal of the baery.
Should you need to reboot the hardware, if your device
becomes frozen and unresponsive, press and hold the Power
key for more than 10 seconds to reboot it. Aer the device is
rebooted, it will restart automacally.
If you reset your phone to the sengs that were congured
at the factory, all of your personal data from internal phone
storage, including informaon about your Google Account,
any other accounts, your system and applicaon sengs,
and any downloaded applicaons will be erased. Reseng
the phone does not erase any system soware updates
you’ve downloaded or any les on your microSD card, such
as music or photos.
1. On the Sengs screen, touch
â
.
2. When prompted, touch
, and then touch
ERASE EVERYTHING
. The mobile phone resets the sengs
to the original factory sengs, and then restarts.
6. SAFETY INSTRUCTIONS
CAUTION
The unit and the accessories can contain small parts. Keep all of the equipment
out of the reach of small children. The mains adapter is the disconnect device
between the product and mains power. The mains socket outlet must be close to
the equipment and easily accessible.
Your device is approved for use on the 4G LTE FDD 3 (1800), 7 (2600), 20 (800) MHz
/ WCDMA 1 (2100), 2 (1900), 5 (850), 8 (900) MHz / GSM 850, 900, 1800, 1900 MHz
networks. To use the device, you need a subscripon with a service provider.
Using network services may result in trac costs. Some product features require
support from the network, and you may need to subscribe to them.
Follow the rules and laws that apply wherever you are, and always turn o the unit
whenever its use is prohibited or can cause interference or hazards. Only use the
unit in its normal user posion.
Parts of the unit are magnec. The unit can aract metal objects. Do not keep credit
cards or other magnec media near the unit. There is a risk that informaon stored
on them can be erased.
9www.doro.com
Doro 8020x
This equipment may be operated in all European countries.
The 5150 - 5350 MHz band is restricted to indoor use only.
AT BE BG CH CY CZ DE DK EE ES FI FR
GR HR HU IE IS IT LI LT LU LV ME MK
MT NL NO PL PT RO RS SE SI SK TR UK
The use of equipment that transmits radio signals, for example, mobile phones, can
interfere with insuciently protected medical equipment. Consult a doctor or the
manufacturer of the equipment to determine if it has adequate protecon against
external radio signals, or if you have any quesons. If noces have been put up at
health care facilies instrucng you to turn o the unit while you are there, you
should comply. Hospitals and other health care facilies somemes use equipment
that can be sensive to external radio signals.
To avoid potenal interference, manufacturers of implanted medical devices recommend a
minimum separaon of 15 cm between a wireless device and the medical device.
Persons who have such devices should:
• Always keep the wireless device more than 15 cm from the medical device.
• Should not carry the phone in a breast pocket.
• Hold the wireless device to the ear opposite the medical device.
If you have any reason to suspect that interference is taking place, turn the phone
o immediately If you have any quesons about using your wireless device with an
implanted medical device, consult your health care provider.
Always turn o the unit when you are in an area where there is a risk of explosion.
Follow all signs and instrucons. There is a risk of explosion in places that include
areas where you are normally requested to turn o your car engine. In these areas,
sparks can cause explosion or re which can lead to personal injury or even death.
Turn o the unit at lling staons, and any other place that has fuel pumps and auto
repair facilies. Follow the restricons that apply to the use of radio equipment near
places where fuel is stored and sold, chemical factories and places where blasng
is in progress. Areas with risk for explosion are oen – but not always – clearly
marked. This also applies to below decks on ships; the transport or storage of
chemicals; vehicles that use liquid fuel (such as propane or butane); areas where the
air contains chemicals or parcles, such as grain, dust or metal powder.
This product contains a Li-Polymer baery. There is a risk of re and burns if the
baery pack is handled improperly.
WARNING
Danger of explosion if baery is incorrectly replaced. To reduce risk of re or
burns, do not disassemble, crush, puncture, short external contacts, expose to
temperature above 60° C (140° F), or dispose of in re or water. Recycle or dispose
of used baeries according to the local regulaons or reference guide supplied
with your product.
• To remove/replace the baery, contact an authorised service centre. Please nd
latest informaon at www.doro.com.
• For your safety, you must not aempt to remove the baery. If the baery is
not properly removed, it may lead to damage to the baery and device, cause
personal injury, and/or result in the device being unsafe.
• Doro does not accept liability for any damage or loss if these warnings and
instrucons are not followed.
10 www.doro.com
Doro 8020x
This device has been tested to comply with the Sound Pressure Level requirement
laid down in the applicable EN 50332-1 and/or EN 50332-2 standards.
WARNING
Excessive exposure to loud sounds can cause hearing damage. Exposure to
loud sounds while driving may distract your aenon and cause an
accident. Listen to a headset at a moderate level, and do not hold the
device near your ear when the loudspeaker is in use.
Mobile phones use radio signals, the mobile phone network, the terrestrial
network and user-programmed funcons. This means that connecon cannot be
guaranteed in all circumstances. Therefore, never rely only on a mobile phone for
very important calls such as medical emergencies.
Some products provide GPS/Locaon based funcons. Locaon determining
funconality is provided “As is”. No representaon or warranty are made as to the
accuracy of such locaon informaon. Use of locaon-based informaon by the
device may not be uninterrupted or error free and may addionally be dependent
on network service availability.
Please note that funconality may be reduced or prevented in certain environments
such as building interiors or areas adjacent to buildings.
WARNING
Do not use GPS funconality in a manner which causes distracon from driving.
Radio signals can aect electronic systems in motor vehicles (for example, electronic
fuel injecon, ABS brakes, automac cruise control, air bag systems) that have
been incorrectly installed or are inadequately protected. Contact the manufacturer
or its representave for more informaon about your vehicle or any addional
equipment.
Do not keep or transport ammable liquids, gases or explosives together with the
unit or its accessories. For vehicles equipped with air bags: Remember that air bags
ll with air with considerable force.
Do not place objects, including xed or portable radio equipment in the area above
the airbag or the area where it might expand. Serious injuries may be caused if the
mobile phone equipment is incorrectly installed and the airbag lls with air. It is
prohibited to use the unit in ight. Turn o the unit before you board a plane. Using
wireless telecom units inside a plane can pose risks to air safety and interfere with
telecommunicaons. It may also be illegal.
Protect your personal data and prevent leakage or misuse of sensive informaon:
• While using your device, be sure to back up important data.
• When disposing of your device, back up all data and then reset your device to
prevent misuse of your personal informaon.
• Carefully read the permissions screen when downloading applicaons. Be
parcularly cauous with applicaons that have access to many funcons or to a
signicant amount of your personal informaon.
• Check your accounts regularly for unapproved or suspicious use. If you nd any
sign of misuse of your personal informaon, contact your service provider to
delete or change your account informaon.
• In the event your device is lost or stolen, change the passwords on your accounts
to protect your personal informaon.
• Avoid using applicaons from unknown sources and lock your device with a
paern, password, or PIN.
11 www.doro.com
Doro 8020x
To protect your device from malware and viruses, follow these usage ps. Failure
to do so may result in damages or loss of data that may not be covered by the
warranty service.
• Do not download unknown applicaons.
• Do not visit untrusted websites.
• Delete suspicious messages or email from unknown senders.
• Set a password and change it regularly.
• Deacvate wireless features, such as Bluetooth, when not in use.
• If the device behaves abnormally, run an anvirus program to check for infecon.
• Run an anvirus program on your device before you launch newly-downloaded
applicaons and les.
• Do not edit registry sengs or modify the device’s operang.
7.
Your unit is a technically advanced product and should be treated with the greatest
care. Negligence may void the warranty.
• The charger is not water-resistant. Keep it dry. Protect the charger from water
or vapour. Do not touch the charger with wet hands, otherwise it may lead to a
short circuit, a malfuncon of the device and an electric shock to the user.
• Do not use or keep the unit in dusty, dirty environments. The unit’s moving parts
and electronic components can be damaged.
• Do not keep the unit in warm places. High temperatures can reduce the lifespan
for electronic equipment, damage baeries and distort or melt certain plascs.
• Do not keep the unit in cold places. When the unit warms up to normal
temperature, condensaon can form on the inside and can damage the
electronic circuits.
• Do not try to open the unit in any other way than that which is indicated here.
• Do not drop or shake the unit. If it is treated roughly the circuits and precision
mechanics can be broken.
• Do not use strong chemicals to clean the unit.
• Do not disassemble, open, crush, bend, deform, puncture or shred.
• Do not modify or remanufacture, aempt to insert foreign objects into the
baery, expose to re, explosion or other hazard.
• Only use the baery for the system for which it is specied.
• Only use the baery with a charging system that has been qualied with the
system per IEEE-Std-1725. Use of an unqualied baery or charger may present a
risk of re, explosion, leakage, or other hazard.
• Do not short circuit a baery or allow metallic conducve objects to contact
baery terminals.
• Replace the baery only with another baery that has been qualied with the
system per this standard, IEEE-Std-1725. Use of an unqualied baery may
present a risk of re, explosion, leakage or other hazard.
• Promptly dispose of used baeries in accordance with local regulaons.
• Baery usage by children should be supervised.
• Improper baery use may result in a re, explosion or other hazard.
For devices that ulize a USB port as a charging source, the device’s user manual
shall include a statement that the device shall only be connected to CTIA cered
adapters, products that bear the USB-IF logo or products that have completed the
USB-IF compliance program.
The advice applies to the unit, baery, power adapter and other accessories. If the
phone is not working as it should, please contact the place of purchase for service.
Don’t forget the receipt or a copy of the invoice.
12 www.doro.com
Doro 8020x
Your device is water- and dust-resistant (IP67). Follow the below ps to keep the
water- and dust-resistance of your device. Failure to do so may result in damage
to your device.
• Do not immerse the device in water deeper than 1 m and keep it submerged for
more than 30 minutes.
• Do not expose the device to water moving with force, such as running water from
taps, ocean waves, or waterfalls.
• Do not open the device’s covers when the device is in water or in very humid
places, such as swimming pools or bathrooms.
• If the device is exposed to clean water, dry it thoroughly with a clean, so cloth. If
the device is exposed to other liquids, rinse it with clean water and dry it thoroughly
with a clean, so cloth. If you do not follow these instrucons, the device’s
performance and appearance may be aected.
• If the device has been immersed in water or the microphone, speaker, or receiver
is wet, sound may not be heard clearly. Wipe the device dry.
• The water-resistant design of the device can cause it to vibrate slightly in certain
condions, for example when the volume level is high. This is due to the protecve
membranes and is normal and do not aect the device’s performance.
• The touchscreen and other features may not work properly if the device is used
in water.
• Your device has been tested in a controlled environment and cered to be water-
and dust-resistant in specic situaons (meets requirements of classicaon IP67 as
described by the internaonal standard IEC 60529). Despite this classicaon, it is
sll possible for your device to be damaged in certain situaons.
8. WARRANTY
This product is guaranteed for a period of 24 months and for original accessories for
a period of 12 months (such as the baery, charger, charging cradle or handsfree
kit) which may be delivered with your device, from the date of purchase. In the
unlikely event of a fault occurring during this period, please contact the place of
purchase. Proof of purchase is required for any service or support needed during
the guarantee period.
This guarantee will not apply to a fault caused by an accident or a similar incident or
damage, liquid ingress, negligence, abnormal usage, non-maintenance or any other
circumstances on the user’s part. Furthermore, this guarantee will not apply to any
fault caused by a thunderstorm or any other voltage uctuaons. As a maer of
precauon, we recommend disconnecng the charger during a thunderstorm.
Please note that this is a voluntary manufacturer’s warranty and provides rights in
addion to, and does not aect statutory rights of end-users.
9. COPYRIGHT AND OTHER NOTICES
Copyright© 2017 Doro AB. All rights reserved.
Other product and company names menoned herein may be the trademarks of
their respecve owners.
Any rights not expressly granted herein are reserved. All other trademarks are
property of their respecve owners.
To the maximum extent permied by applicable law, under no circumstances shall
Doro or any of its licensors be responsible for any loss of data or income or any
special, incidental, consequenal or indirect damages howsoever caused.
Doro does not provide a warranty for or take any responsibility for the funconality,
content, or end-user support of third-party apps provided with your device. By using
an app, you acknowledge that the app is provided as is. Doro does not make any
representaons, provide a warranty, or take any responsibility for the funconality,
content, or end-user support of third-party apps provided with your device.
The unauthorised copying of copyrighted materials is contrary to the provisions
of the Copyright Laws of the United States and other countries. This device is
intended solely for copying non-copyrighted materials, materials in which you own
the copyright, or materials which you are authorised or legally permied to copy.
13 www.doro.com
Doro 8020x
If you are uncertain about your right to copy any material, please contact your
legal advisor.
You are entled to receive a copy of the source code of soware licensed under
an open source license that gives you the right to receive the source code for that
soware (for example GPL or LGPL) to you on an appropriate media, against an
administrave fee covering Doro AB’s cost for handling the distribuon and costs for
media. Please direct such request to Doro AB, Open Source Soware Operaons,
Magistratsvagen 10, SE 226 43 Lund, Sweden. To be valid, such a request must be
made within three (3) years from the date of the distribuon of this product by Doro
AB, or in the case of code licensed under the GPL v3 for as long as Doro AB oers
spare parts or customer support for this product model.
10.
This device meets applicable internaonal safety requirements for exposure to radio
waves. Your mobile device is a radio transmier and receiver. It is designed not to
exceed the limits for exposure to radio waves (radio frequency electromagnec
elds) recommended by internaonal guidelines from the independent scienc
organizaon ICNIRP (Internaonal Commission of Non-Ionizing Radiaon Protecon).
The radio wave exposure guidelines use a unit of measurement known as the
Specic Absorpon Rate, or SAR. The SAR limit for mobile devices is 2 W/kg
averaged over 10 grams of ssue and include a substanal safety margin designed to
assure the safety of all persons, regardless of age and health.
Tests for SAR are conducted using standard operang posions with the device
transming at its highest cered power level in all tested frequency bands. The
highest SAR values under the ICNIRP guidelines for this device model are:
: 0.436 W/kg
: 0.897 W/kg
During normal use, the SAR values for this device are usually well below the
values stated above. This is because, for purposes of system eciency and to
minimize interference on the network, the output power of your mobile device is
automacally decreased when full power is not needed for the call. The lower the
power output of the device, the lower its SAR value.
This device meets RF exposure guidelines when used against the head or when
posioned at least 1.5 cm away from the body. When a carry case, belt clip or other
form of device holder is used for body-worn operaon, it should not contain metal
and should provide at least the above stated separaon distance from the body.
The World Health Organizaon (WHO) has stated that current scienc informaon
does not indicate the need for any special precauons when using mobile devices. If
you are interested in reducing your exposure, they recommend you reduce your usage
or use a hands-free accessory to keep the device away from your head and body.
11. CORRECT DISPOSAL OF THIS PRODUCT
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collecon systems)
This marking on the product, accessories or manual indicates that the
product and its electronic accessories (e.g. charger, headset, USB cable) should
not be disposed of with other household waste. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please separate
these items from other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this
product, or their local government oce, for details of where and how they can take
these items for environmentally safe recycling. Business users should contact their
supplier and check the terms and condions of the purchase contract. This product
and its electronic accessories should not be mixed with other commercial wastes for
disposal. This product is RoHS compliant.
14 www.doro.com
Doro 8020x
12. CORRECT DISPOSAL OF BATTERIES IN THIS PRODUCT
(Applicable in countries with separate collecon systems)
The marking on the baery, manual or packaging indicates that the baery in
this product should not be disposed of with other household waste. Where
marked, the chemical symbols Hg, Cd or Pb indicate that the baery contains
mercury, cadmium or lead above the reference levels in EC Direcve 2006/66. If
baeries are not properly disposed of, these substances can cause harm to human
health or the environment. To protect natural resources and to promote material
reuse, please separate baeries from other types of waste and recycle them
through your local, free baery return system.
13. SPECIFICATIONS
Network bands (MHz)
[maximum radio-frequency
power/dBm]:
2G GSM
3G UMTS
4G LTE FDD
850 (33), 900 [33], 1800 [30], 1900 [30]
1 (2100) [24], 2 (1900) [24], 5 (850) [24], 8 (900) [24]
3 (1800) [24], 7 (2600) [24], 20 (800)
Operang system: Android 6.0
SIM card size Micro SIM (3FF)
Wi-Fi (MHz) [maximum radio-
frequency power/dBm]: IEEE 802.11 b/g/n (2412 - 2472) [19]
Bluetooth (MHz) [maximum
radio-frequency power/dBm]: 4.0 (2402 - 2480) [10]
GPS receiver: Category 3
Dimensions: 140 mm x 74 mm x 13 mm
Weight: 185 g (including baery)
Baery: 3.8 V / 3000 mAh Li-Polymer baery
Image format: BMP, GIF, JPG, PNG
Video format: AVI, MP4, 3GP, 3GP2
Audio format: WAV, AMR, MIDI, MP3, AAC
Main camera resoluon:
Front camera resoluon:
5 MP
VGA
Camera digital zoom: 4x
Display: Size
Resoluon
Colour Depth
4.5”
480 x 854
16 M
RAM:
Internal memory:
External memory
1 GB
8 GB
MicroSD, microSDHC, microXDHC max. 128 GB
Sensors: Accelerometer, light, proximity, compass,
Operang ambient
temperature:
Min: 32°F (0°C)
Max: 104°F (40°C)
Charging ambient temperature: Min: 32°F (0°C)
Max: 104°F (40°C)
Storage temperature: Min: -4°F (-20°C)
Max: 140°F (60°C)
Other manuals for 8020X
2
Table of contents
Other Doro Cell Phone manuals
Doro
Doro PHONEEASY 612 User manual
Doro
Doro 1361 User manual
Doro
Doro PHONEEASY 612 User manual
Doro
Doro PhoneEasy 626 User manual
Doro
Doro 6520 User manual
Doro
Doro Liberto 650 User manual
Doro
Doro PHONEEASY 410S gsm User manual
Doro
Doro 1370 User manual
Doro
Doro 2404 User manual
Doro
Doro PhoneEasy 345gsm User manual
