Doro PhoneEasy 341gsm User manual

Doro PhoneEasy®341gsm

1. Power on/off
2. Display
3. Left soft key
4. Call key
5. 1/ Voice mail
6. Numeric keypad
7. */ Key lock
8. # / Change prole
9. End call
10. Arrow keys
11. Right soft key
12. Charging contacts (for use
with charging stand)
13. Emergency call key
14. Battery cover
15. Headset socket
16. Charging socket
17. Loudspeaker
18. Microphone
19. Lanyard
English
1. På/av
2. Display
3. Funktionsknapp vänster
4. Samtalsknapp
5. 1/ Röstbrevlåda
6. Numerisk knappsats
7. */ Knapplås
8. # / Byt prol
9. Avsluta samtal
10. Pilknappar
11. Funktionsknapp höger
12. Laddningskontakter
(för användning med ett
laddningsställ)
13. Knapp för nödsamtal
14. Batterilucka
15. Uttag för headset
16. Uttag för laddare
17. Högtalare
18. Mikrofon
19. Halsrem
Svenska
19

1. Strøm til/fra
2. Display
3. Venstre funktionstast
4. Opkaldstast
5. 1/ Voicemail (telefonsvar)
6. Numerisk tastatur
7. */ Tastaturlås
8. # / Skift prol
9. Afslut opkald
10. Piletaster
11. Højre funktionstast
12. Stik til oplader (til brug med
opladningsholder)
13. Nødopkaldstast
14. Batteridæksel
15. Stik til headset
16. Stik til oplader
17. Højtaler
18. Mikrofon
19. Halssnor
Dansk
1. Virta päälle/pois
2. Näyttö
3. Vasen valintanäppäin
4. Soittopainike
5. 1/ Vastaaja (Verkon
vastaajapalvelu)
6. Numeronäppäimistö
7. */ Näppäinlukko
8. # / Vaihda proilia
9. Lopeta puhelu
10. Nuolinäppäimet
11. Oikea valintanäppäin
12. Latauksen kosketuspinnat
(lataustelinettä varten)
13. Turvapuhelupainike
14. Akkukotelon kansi
15. Kuulokemikrofoniliitäntä
16. Laturin liitäntä
17. Kaiutin
18. Mikrofoni
19. Kaulanauha
Suomi
1. Strøm på/av
2. Display
3. Venstre menytast
4. Ringetast
5. 1/ Talepost
6. Talltastatur
7. */ Tastelås
8. # / Endre prol
9. Avslutt samtale
10. Piltaster
11. Høyre menytast
12. Ladekontakter
(for bruk med ladestativ)
13. Tast for nødanrop
14. Batterideksel
15. Hodesettkontakt
16. Ladekontakt
17. Høyttaler
18. Mikrofon
19. Bærereim
Norsk

1
English
Contents
Installation .................................... 3
Installing the SIM card and battery.................. 3
Charging .................................... 4
Operation...................................... 5
Activating the phone ............................ 5
Making a call ................................. 6
Making a call from the Phonebook .................. 6
Receiving a call ............................... 6
Volume control ................................ 6
Display symbols ................................. 7
Additional functions .............................. 8
Call options .................................. 8
Call waiting .................................. 9
Call information ............................... 9
Call log ..................................... 9
Phonebook .................................. 10
Key lock.................................... 12
Headset .................................... 12
SOS calls 999/911/112 ........................ 12
Silent mode ................................. 13
Emergency Call key ............................ 13
Text input................................... 14
SMS messaging ................................ 15
Creating and sending messages ................... 15
Outbox (outgoing messages)...................... 15
Inbox (incoming messages) ...................... 16

2
English
Settings...................................... 18
Time & date ................................. 18
Tone settings (rings & tones) ..................... 19
Silent...................................... 20
User setup .................................. 20
Blocking functions ............................ 21
Emergency .................................. 22
Voice mail .................................. 23
Speed dial .................................. 23
Call setup................................... 24
SMS settings ................................ 26
Network setup ............................... 26
Services .................................... 27
Security settings .............................. 27
Tasks (reminders) ............................. 29
Calculator................................... 29
Safety instructions .............................. 30
Troubleshooting ................................ 33
Care and maintenance ........................... 37
Warranty and technical data ....................... 38

3
English
Installation
Warning!
Turn off the phone and disconnect the charger before removing
the battery cover.
Installing the SIM card and battery
The SIM card holder is located behind the battery.
1. Remove the battery cover and the battery if it is already
installed.
2. Insert the SIM card by carefully sliding it into the holder.
Make sure that the SIM card’s contacts are facing inwards
and that the cut-off corner is pointing upwards. Take care not
to scratch or bend the contacts on the SIM card.
3. Insert the battery by sliding it into the battery compartment
with the contacts facing upwards to the right.
4. Replace the battery cover.

4
English
Charging
Warning!
Only use batteries, charger and accessories that have been
approved for use with this particular model. Connecting
other accessories may be dangerous and may invalidate the
phone’s type approval and guarantee.
When the battery is running low, is displayed and a warning
signal is heard. To charge the battery, connect the mains adapter
to the wall socket and to the charging socket y.
If the phone is turned on when the charger is connected to the
phone is displayed briey in the display and when it
is disconnected. The battery charge indicator is displayed while
charging.
If the phone is turned off when the charger is connected to the
phone only the battery charge status indicator will be shown in
the display.
It takes approximately 3 hours to fully charge the battery.
is displayed when charging is completed.
Save energy
When you have fully charged the battery and disconnected the
charger from the device, unplug the charger from the wall outlet.
Note!
To save power the LCD backlight goes off after a short while
but the phone is still charging. Press any key to illuminate the
display.
Full battery capacity will not be reached until the battery has
been charged 3–4 times.
Batteries degrade over time, which means that call time and
standby time will normally decrease with regular use.

5
English
Operation
Activating the phone
Press and hold 1on the top of the phone to turn it on/off. The
following messages may be displayed:
SIM card missing or
incorrectly inserted.
SIM card damaged or not
valid.
If the SIM card is valid but protected with a PIN code (Personal
Identication Number), PIN: is displayed. Enter the PIN code
and press OK ( upper left corner of keypad).
Delete with Clear ( upper right corner of keypad).
Note!
If PIN and PUK codes were not provided with your SIM card,
please contact your network operator.
Attempts: # shows the number of PIN attempts left. When
no more attempts remain, SIM blocked is displayed. The
SIM card must now be unlocked with the PUK code (Personal
Unblocking Key).
1. Enter the PUK code and conrm with OK.
2. Enter a new PIN code and conrm with OK.
Changing the language, time and date
The default language is determined by the SIM card. See Settings
on how to change language, time and date.

6
English
Making a call
1. Enter the phone number. Delete with Clear.
2. Press qto dial. Press Abort to cancel dialling.
3. Press Lto end the call.
Note!
When making international calls, press *twice for the
international prex "+". Always use ”+” before the country
code (instead of 00 or similar) for best operation.
Making a call from the Phonebook
1. Press Name to open the phonebook.
2. Use the arrow keys / to scroll through the
phonebook, or quick search by pressing the key corresponding
to the rst letter of the entry, see Text input.
3. Press Call to dial the selected entry, or press Back to return
to standby mode.
Receiving a call
1. Press qto answer, or press Silent to switch off the ring
signal and then Reject to reject the call (busy signal).
Alternately, press Lto reject the call directly.
2. Press Lto end the call.
See also Call options.
Volume control
Use the arrow keys / to adjust the sound volume, during
a call. The volume level is indicated on the display.
