Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
Step 3: Set the blue body aside and inspect the
wishbone (Part #: MP014) on the top. If anything is
broken or missing, replace.
Step 2: Grab the metal wishbone and pull the piston
straight out.
NOTE: Before you start, make sure the unit is clicking.
Step 1: Unscrew and remove the lid. It’s helpful to have
a Strap Wrench (Part #: TOOL01).
D128R Service
Scan the QR
code to watch
our D128R
Service video.

Page 2
800-523-8499 lwww.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
Step 5: Unscrew and remove the stem.
Step 6: Remove the top seal that is located between the
blue body and the black stem. Please note the top seal
sometimes remains in the body. Just remove it.
D128R Service
Step 4: Inspect the actuator springs (Part #: M009) on
the bottom. If anything is broken or missing, replace.

Page 3
800-523-8499 lwww.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
D128R Service
Step 9: Replace a new bottom seal (Part #: J003)
into the cap, making sure the raised center portion is
facing upward.
Step 8: Remove the bottom seal located in between the
black stem and the cap.
Step 7: Unscrew the gray hose nut if it isn’t
already removed.

Page 4
800-523-8499 lwww.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
D128R Service
Step 12: Thread the stem on hand tight.
Step 11: To replace the top seal, just place it into the
body with the raised center portion facing up.
Step 10: Now thread the cap onto the bottom of the
black stem and reinstall the gray hose nut, hand tight.

Page 5
800-523-8499 lwww.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
D128R Service
Step 14: To nish up, thread the lid on and hand tighten.
Step 13: Carefully insert the piston assembly into the
body, pressing it in as far as it will go.
Note: To watch the video go to Dosatron’s video page www.dosatronusa.com/videos.aspx or
YouTube Channel www.youtube.com/user/DosatronIntl
