dosatron GREEN LINE D90 Series User manual

NTD90GL-12-20
DOSATRON INTERNATIONAL S.A.S.
Rue Pascal - B.P. 6 - 33370 TRESSES (BORDEAUX) - FRANCE
Tel. [phone]
Fax. [phone]
[email protected] - www.dosatron.com
Certified QEH&S System
NORTH & CENTRAL AMERICA
DOSATRON INTERNATIONAL INC.
2090 SUNNYDALE BLVD. CLEARWATER - FL 33765 - USA
Tel. [phone] - Fax [phone]
Site web: www.dosatronusa.com
MANUFACTURED BY
CUSTOMER SERVICE DEPARTMENT

D90 - GREEN LINE
User manual

© DOSATRON INTERNATIONAL S.A.S / 2
The eco-design challenge
By extending the scope of its ISO 14001 certification and
integrating design and development activities, DOSATRON
is proud to adopt a genuine eco-design process.
The D90GL dosing pump is a product of this process and
illustrates our desire to create innovative, eco-designed products:
• by reducing the number of parts.
• by developing a lighter product.
• by designing cardboard packaging made from 100% recycled
materials.
• by working with local or national suppliers to limit transport
distances.
In collaboration with APESA, all our teams have perfectly
integrated the concepts and tools inherent to eco-design.*
More broadly, DOSATRON is committed to a global
environmental approach by implementing concrete actions to
reduce its environmental impact.
* Sources APESA - Global environmental impact - ecological scarcity method 2013.

© DOSATRON INTERNATIONAL S.A.S / 2© DOSATRON INTERNATIONAL S.A.S / 3
You have just acquired a DOSATRON water-powered dosing pump.
Congratulations on your choice.
More than 40 years of experience have perfected the development
of this model and our teams have placed the Dosatron series at the
forefront of the technical development of water-powered dosing pumps.
Over time, this Dosatron will prove to be a most faithful ally. A few
regular maintenance operations will guarantee its operating reliability
and banish the word “failure” forever.
THEREFORE, PLEASE READ THIS MANUAL CAREFULLY
BEFORE USING THE DEVICE
This document does not form a contractual obligation and is for information
only. DOSATRON INTERNATIONAL reserves the right to modify its
appliances at any time.
© DOSATRON INTERNATIONAL S.A.S 2020
English
Important!
You will find your Dosatron’s part number and serial number on
the technical data label affixed to the pump body and the Dosatron
regulator.
Please record these numbers in the space provided below for
easy referral when contacting or requesting information from your
vendor.
Ref. ..............................................
Serial No. ....................................
Date of purchase: ......................

© DOSATRON INTERNATIONAL S.A.S / 4
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
NOTES

© DOSATRON INTERNATIONAL S.A.S / 4© DOSATRON INTERNATIONAL S.A.S / 5
MARKINGS / IDENTIFICATION / SPECIFICATIONS
Understanding the part number ............................................... 9
Specifications.......................................................................... 10
Dimensions ............................................................................. 10
INSTALLATION
Precautions ............................................................................. 13
Assembling the Dosatron........................................................ 13
Installing the Dosatron ............................................................ 16
Changing the dosing scale view ............................................. 18
Connecting the suction hose .................................................. 20
Installation tips ........................................................................ 21
Automatic product anti-siphoning ........................................... 23
COMMISSIONING
Using for the first time............................................................. 24
Use.......................................................................................... 25
Adjusting the dosing rate ........................................................ 25
Dosing principle ...................................................................... 26
MAINTENANCE
Recommendations .................................................................. 28
Draining the Dosatron............................................................. 29
Dismantling the suction hose.................................................. 30
Dismantling / Reassembling the dosing assembly ................. 31
Replacing the dosing seals .................................................... 32
Dismantling / Reassembling the dosing piston....................... 33
Cleaning and reassembling the suction valve ........................ 34
Changing the motor piston ..................................................... 35
TROUBLESHOOTING.............................................................. 36
WARRANTY.............................................................................. 38
Contents

© DOSATRON INTERNATIONAL S.A.S / 6
D90GL05BPVF
20120435
D90GL05BPVF
20120435
D90GL05BP S/N 19220004
25 m³/h - 90 m³/h
0.1 - 0.5% [1:1000 - 1:200]
25 - 450 l/h
0.5 - 8 bar
40°C
Débit de fonctionnement
Operating flow rate
Dosage
Injection rate
Débit d’injection
Injection flow rate
Pression de fonctionnement
Operating pressure
Température maxi.
Maxi. temperature
DOSATRON INTERNATIONAL S.A.S Rue Pascal - B.P.6 - TRESSES - FRANCE
Tél. [phone] - [email protected] - www.dosatron.com
THE MANUFACTURER declines all responsability in event of use not conforming with the owner’s manual
LE FABRICANT décline toute responsabilité en cas d’utilisation non conforme au manuel d’utilisation
Markings / Identification
Specifications
Your dosing pump has 2 main marking zones which enable it to be identified
in detail:
A 2-line engraving on the section of the top cover (see picture below), con-
taining the exact part number for the appliance and the serial number.
A technical data label on each side of the dosing pump body stating the part
number and the technical performance data for the appliance.
REF.
Serial No.

© DOSATRON INTERNATIONAL S.A.S / 6© DOSATRON INTERNATIONAL S.A.S / 7
REF.:................................................. Serial No. ......................................
Example D90 GL 05 BP V• VF II
Dosatron range
Product line GL:
Green Line (fertigation)
Maximum injection
rate (% or ratio)
BP: Integrated manual bypass
V: Optional kit for Viscous Products (>400 cPs)
Dosing seal type:
AF = Alkaline Fluid pH 7-14 / VF = Acidic Fluid pH 1-7 / K = Strong acids (>15%)
Other extensions (please specify)
UNDERSTANDING THE PART NUMBER

© DOSATRON INTERNATIONAL S.A.S / 8
SPECIFICATIONS
D90GL05BPVF
Operating flow rate: 25 m3/h - 90 m3/h [110 US gpm - 400 US gpm]
Max. operating temperature: ..................................................40°C [104°F]
Operating pressure:
bar
psi
0.5 - 8
7.25 - 116
Dosing adjustable from the exterior:
%
Ratio
0.1 - 0.5
1/1 000 - 1/200
Concentrated product injection flow:
Min. l/h - Max. l/h
US gpm - MIN.
US gpm - MAX.
25 - 450
0.11
1.98
Connection: ..................Flange DN 100 EN PN16 - DN 4" ASME B16.5
Hydraulic motor capacity (every two clicks of the piston):
around 1.7 l [0.449 US Gallons]
IMPORTANT! The DOSATRON is not pre-set, please refer to the
paragraph on ADJUSTING THE DOSING
DIMENSIONS
Length: cm ["] 120 [47"1/4]
Total height: cm ["] 80 [31"1/2]
Overall width: cm ["] 53 [20"3/4]
Weight: ± kg [lbs] 50 [110.2]
PACKAGE COMPOSITION: 1 Dosatron / 1 Dosatron Regulator /
1 Suction hose for concentrate / 1 Suction strainer / 1 Quick-start guide.
PACKAGE WEIGHT: Approx. 50 kg [~ 110.2 US lbs]

© DOSATRON INTERNATIONAL S.A.S / 8© DOSATRON INTERNATIONAL S.A.S / 9
Dosatron TECHNOLOGY
Unique technology incorporating all dosing functions.
DOSATRON is fitted directly to the water supply system and uses
water pressure as its power source. When activated in this way, it
takes up the required dose of concentrate and then mixes it with the
motive water. The solution produced is then propelled downstream.
The dose of injected product is always proportional to the volume of
water passing through the Dosatron, regardless of variations in flow or
pressure in the water supply line.
Motor piston
Clean mains
water
Water
+ % product
solution
Dosing piston
Dosing rate
setting
(%) ratio
Concentrate
to be injected

© DOSATRON INTERNATIONAL S.A.S / 10
2
1
4
3
14
6
7
10
5
8
9
11
12
13
D90RE05_ill_001_07
2
1
4
3
14
6
7
10
5
8
9
11
12
13
D90RE05_ill_001_07
1D90 frame
2Fully equipped D90 regulator assembly
3612 mm long pipe sub-assembly, equipped with seals
4433 mm long pipe sub-assembly, equipped with seals
5Mounting bracket
6GREEN LINE D9 bell-housing
7Complete bypass sub-assembly
8Motor piston
9Dosing piston sub-assembly
10
1½''GREEN LINE body sub-assembly
11 D90GL05 injection assembly
12
Suction valve sub-assembly
13
Valve nut
14
20 x 27 suction assembly, 4-meter hose

© DOSATRON INTERNATIONAL S.A.S / 10 © DOSATRON INTERNATIONAL S.A.S / 11
Installation
PRECAUTIONS
1-GENERAL
- When connecting a Dosatron either
to the public water supply line or to
its own water source, it is essential to
conform to the standards concerning
protection and disconnection for
the country in which the appliance
is installed. Dosatron recommends
fitting a backflow preventer to avoid
contaminating the water supply.
- When connecting the Dosatron to
the water supply system, ensure that
the water flows in the direction of the
arrows shown on your appliance.
- If the system is located at a higher
level than the Dosatron itself, there
is a possible risk of water and
concentrate flowing back into the
Dosatron. Installing a non-return
valve downstream of the appliance is
therefore recommended.
- Fitting an anti-siphoning valve
downstream of the dosing pump is
recommended in installations where
there is a risk of siphoning.
- Do not install the Dosatron above a
container of acid or any aggressive
products. Place the container to
the side and cover it to avoid any
product fumes.
- Keep the Dosatron away from
excessive heat sources, and protect
it from frost in winter.
- Do not install the Dosatron on the
suction side of the motive water
pump (risk of siphoning).
The user has sole responsibility
for replacing the dosing assembly
seals on an annual basis to ensure
accurate dosing.
The user has sole responsibility for
the adjustment of the Dosatron’s
dosing rate. The user must adhere
strictly to the recommendations of the
manufacturer of the chemicals used.
WARNING
During the installation, operation
and maintenance of the Dosatron
water-powered dosing pump,
the following safety instructions
must be observed: use suitable
tools, protective clothing and
safety goggles when working on
the equipment and install it in
such a way as to ensure risk-free
operation.
Follow the instructions in this
manual and take safety measures
appropriate to the nature of the
liquid additives and the water
temperature. Be extremely
cautious in the presence of
dangerous substances (corrosive,
toxic, dissolving, acids, caustic
substances, inflammable
substances, etc.).

© DOSATRON INTERNATIONAL S.A.S / 12
- Before injecting these
substances, please consult
your distributor to confirm their
compatibility with the dosing
pump.
IMPORTANT! The personnel in
charge of installing, operating
and maintaining this equipment
must be fully acquainted with the
contents of this manual.
Ensure that the water flow and
pressure of the installation are
compliant with the Dostatron’s
specifications.
- The dosing adjustment must be
carried out with no pressure in the
system. Turn off the water supply
and allow the pressure to drop to
zero.
- The user has sole responsibility
for choosing the correct Dosatron
settings to obtain the desired dosing
rate.
- Problems with airtightness,
impurities or chemical aggression
of the seal can disrupt the dosing
operation. You are therefore advised
to check periodically that the
concentrate to be dosed is being
correctly drawn into the Dosatron.
- Change the Dosatron suction hose
as soon as it seems damaged by
the concentrate being dosed.
- Release the pressure in the system
after use (recommended).
- Rinsing of the Dosatron is
essential:
. whenever the product is changed
. before each intervention on the
Dosatron, to avoid any contact with
aggressive products.
- All assembly and tightening
operations should be carried out
using the appropriate tools, or
manually without tools (unless there
are specific recommended tightening
torques).
2-PARTICLE-LADEN WATER
- In the case of heavily particle-laden
water, a filter (e.g. 200 to 120 mesh
- 80 to 130 microns depending on
the quality of your water) MUST be
installed upstream of the Dosatron.
If this filter is not installed, abrasive
particles will cause premature wear
in the Dosatron.
3-WATER HAMMER / EXCESS
FLOW
For installations subject to water
hammer, a water-hammer arrestor
must be fitted (pressure/flow control
system).
For automated installations, it is
preferable to use slow-opening and
slow-closing solenoid valves.
If a Dosatron serves several
sectors, activate the solenoid valves
simultaneously (closure of one
sector and opening of another sector
at the same time).
PRECAUTIONS (continued)

© DOSATRON INTERNATIONAL S.A.S / 12 © DOSATRON INTERNATIONAL S.A.S / 13
4-LOCATION OF THE
INSTALLATION
- The Dosatron and the dosing
additive must be accessible at all
times. Their installation must not,
under any circumstances, pose a
pollution or contamination risk.
The marking of all water pipes
with notices bearing the statement
“CAUTION! Non-potable water” is
recommended, to indicate that the
water contains additives.
5-MAINTENANCE
- After use, the aspiration of clean
mains water through the system is
recommended.
- Annual maintenance will optimise
the service life of your Dosatron.
Replace the dosing assembly seals
and the product suction hose on an
annual basis.
6-SERVICE
- This Dosatron was tested prior to
packaging.
- Replacement sub-assemblies and
packs of seals are available upon
request.
- Do not hesitate to call your
distributor or Dosatron for any after-
sales service requirements.

© DOSATRON INTERNATIONAL S.A.S / 14
INSTALLATION MUST BE CARRIED OUT USING THE APPROPRIATE
TOOLS.
The Dosatron is supplied with:
One regulator with double-bore flange holes according to EN (Europe) and
ASME (USA) standards, dimensions: DN 100 EN PN16 / DN4" ASME B 16.5.
One D9D90 GL dosing pump pre-equipped with elbow fittings.
Two supply tubes (one short upstream / one long downstream).
One 4-meter suction hose and strainer.
A user manual.
INSTALLING THE DOSATRON
Fig. 1
Remove the plugs and protective caps (Fig.1) covering the ports
of your dosing pump before connecting it to the water system.

© DOSATRON INTERNATIONAL S.A.S / 14 © DOSATRON INTERNATIONAL S.A.S / 15
1 - Direction of water flow
- Verify the direction in which
the appliance is fitted and the
direction of the water flow.
2 - Preparation of the dosing
pump
- Attach the dosing pump
mounting bracket onto the left-
hand side of the frame
3 - Regulator position
- Your regulator is factory-fitted on
the frame.
4 - Assembly of the D9D90 dosing pump
Refer to the diagram below
- Take the D9D90 dosing device pre-equipped with its two elbow fittings and
fix it to its mounting bracket.
- Take the short hose and screw it onto the left-hand side of the regulator, with
a seal inserted between the two parts.
- Take the long hose and screw it onto the right-hand side of the regulator, with
a flat seal inserted between the two parts.
- Screw the ends of the hoses onto the dosing pump: the short hose to the
'inlet' elbow fitting on the dosing pump, and the long hose to the 'outlet' elbow
fitting on the dosing pump, with a flat seal inserted between the two parts
on each occasion.

© DOSATRON INTERNATIONAL S.A.S / 16
The Dosatron’s dosing rate can be adjusted according to two scales:
percentage- and ratio-based. These scales are positioned on either side of
the dosing assembly (Fig.2).
Depending on the direction of flow in the hydraulic system and the direction
in which the dosing pump is mounted on its bracket, it may be necessary to
change the orientation of this scale.
CHANGING THE DOSING SCALE VIEW
- Completely unscrew the fixing nut on the dosing assembly
- Pull downwards and rotate half a turn to release the dosing assembly and
view the correct dosing adjustment scale (Fig.3).
Fig. 3Fig. 2

© DOSATRON INTERNATIONAL S.A.S / 16 © DOSATRON INTERNATIONAL S.A.S / 17
Insert the dosing body into the pump
body, taking care to align the centring pins
(Fig.4). If necessary, to obtain a clearer
view of the pins, unscrew the dosing
adjustment nut as far as the middle of its
travel.
- Manually retighten the fixing
nut on the dosing assembly
(Fig.5).
Fig. 5
Fig. 4

© DOSATRON INTERNATIONAL S.A.S / 18
Ø20
The Dosatron is supplied with a suction hose (to be shortened as
necessary), which enables it to be used with a large-capacity container.
This hose must be equipped with the strainer and ballast.
N.B. The maximum suction head is 4 metres [13 ft].
CONNECTING THE SUCTION HOSE
- Push the suction hose onto the suction valve stem and secure the hose
using the hose clamp supplied (Fig.6)
- Fit the strainer on the other end of the hose using the same method and
secure it using the other hose clamp (Fig. 7 & 8).
Fig. 6 Fig. 8Fig. 7

© DOSATRON INTERNATIONAL S.A.S / 18 © DOSATRON INTERNATIONAL S.A.S / 19
INSTALLATION ADVICE
The Dosatron should be installed in a full hydraulic bypass.
An in-line installation is possible but not recommended because it does not
enable the dosing pump to be easily isolated for maintenance (the water
supply must be turned off).
A by-pass installation enables the system to be supplied with clean mains
water when the Dosatron is not operating and enables it to be easily
dismantled.
If your flow rate is above the specified limits for the Dosatron, see
§ EXCESS FLOW.
To prolong the Dosatron’s service life, it should be fitted with an upstream
filter (e.g. 200 to 120 mesh - 80 to 130 microns, depending on the quality of
your water).
This precaution is essential if the water contains impurities or particles,
especially if the water comes from a well or if it is surface water.
Fig. 9
EXCESS FLOW (for information)
If your Dosatron clicks more than 44 times in 15 seconds, (i.e. 22 cycles)
you are beyond the upper flow-capacity limit.
