DOSKO 2961090 User manual

1
Owner's Manual
Instructions for Operation, Maintenance
Compact Stump and Root Grinder
2961090 (200-6H)
Your Dosko grinder is intended for outdoor-use only and can be used to remove many tree stumps and
exposed root systems close to ground level. By moving the blade in sweeping movements laterally over
the top and front of the stump, you can gradually grind it away. Make sure you completely read and
understand this manual before using the grinder for the first time.
WARNING
READ and UNDERSTAND this manual completely before using the grinder! Failure to properly operate,
and maintain this grinder could result in serious injury or death to the operator or bystanders.
All machines have hazards associated with their operation. This stump grinder has certain special hazards,
which you must be aware of. As an operator or owner you have a duty to be aware of these hazards and know
preventive measures to take to avoid them. When reading this manual pay particular attention to avoiding these
hazards.
In particular, be aware of the following:
Know location of buried electrical and other utility lines.
Do not allow children or untrained adults to operate.
Wear eye protection and other personal protection against flying rocks and debris.
Check that cutter wheel teeth are secured, sharp and not missing.
Do not operate if operator presence bar fails to stop engine upon release.
Make sure no children or bystanders are within 75 feet of stump grinding operation.
Protect cars, windows and other objects within 75 feet from flying debris.
Be prepared for machine "kickback" when initially contacting the stump.
Be aware of potential for carbon monoxide (CO) poisoning.
Prevent fires/explosions from fueling.
Do not attempt to perform adjustments, declog or clean unit while engine is running.
Avoid burns from engine or hot exhaust.
Avoid using in wet or icy conditions where falls may occur.
Details about these hazards are found throughout the manual and are summarized at the end of the manual under
"Important Safety Information."
STOP!
ADD ENGINE OIL:Your stump grinder comes fully assembled and requires only that you add engine oil to crankcase
and fuel to tank.
INSPECT COMPONENTS:Closely inspect to make sure no components are missing or damaged. See the "Receiving
Your Unit" section for instructions on whom to contact to report missing or damaged parts.
Any Questions, Comments, Problems, or Parts Orders
Call your dealer or Dosko Customer Service 1-800-822-0295
MODEL NUMBER: 2961090
SERIAL NUMBER: _____________
M2961090A

M2961090 Exploded View –Rev A
29

M2961090 Parts List –Rev A
30
Item
Part #
Description
Qty
Item
Part #
Description
Qty
1
606512
Honda GX200 engine
1
34
786081
Rear rubber flap
1
2
785906
Exhaust deflector
1
35
786488
Rubber bumper
2
3
785907
Screw, exhaust deflector
2
36
786080
Front rubber flap
1
4
82319
5/16"-18 set screw
1
37
785850
Frame
1
5
783570
Wire lock collar
1
38
786214
Tire
2
6
783569
Spring, brake band
1
39
305200
3/4" dia. wheel retainer
2
7
786082
Brake cable
1
40
786079
Clutch
1
8
783547
Brake lever
1
41
785889
Retaining washer, clutch
1
9
82014
5/16"-18 x 1/2" HHSF bolt
4
42
82100
5/16" split lock washer
7
10
786472
Hinge bracket (right)
1
43
82412
5/16"-24 x 1-1/4" HHCS
1
11
786380
Pivot spacer
2
44
82141
3/16" x 1-1/2" key
1
12
82020
5/16"-18 nyloc nut
4
45
786038
Belt guard
1
13
82226
5/16"-18 x 1-1/4" HHCS bolt
2
46
785914
AX37 belt
1
14
82440
5/16"-18 x 1-5/8" eyebolt
2
47
82143
1/4" x 1-3/4" key
1
15
38578
T-handle knob
2
48
785913
AK30 x 1" sheave
1
16
786083
Throttle cable
1
49
786037
Bracket mounting, belt guard
1
17
786103
Dosko decal
1
50
786213
Cutting wheel
1
18
785867
Handle
1
51
786403
Tooth set
Black, standard
1
19
783769
Microswitch bracket
1
786462
Red, sand & clay
opt.
20
783545
Microswitch
1
786461
Gold, rock
opt.
21
785880
Throttle lever
1
52
785400
1" pillow block
2
22
785534
1/4" x 5/16" vinyl cap
4
53
82391
7/16"-14 x 1-1/2" flange bolt
4
23
782399
Ball joint
1
54
82115
7/16"-14 nyloc nut
4
24
82312
5/16"-24 hex nut
1
55
783568
Floating pin, brake band
2
25
82407
5/16"-24 x 3-1/4" HHCS bolt
1
56
783567
4" brake band
1
26
82021
5/16" USS flat washer
1
57
82015
5/16"-18 x 3/4" HHSF bolt
6
27
785883
Operator presence handle
1
58
786067
Hub
1
28
783924
Spring
1
59
82408
5/16"-18 x 1-1/34" coupling nut
3
29
783815
1-3/4" vinyl cap
1
Personal Protection Equipment (not shown):
30
783283
Wire harness
1
n/a
174630
Reusable corded earplugs
1
31
82434
3/8" x 1/2" shoulder bolt
2
174653
Face shield
1
32
786473
Hinge bracket (left)
1
174690
Safety eyewear
1
33
82435
3/8" x 1-1/4" PTFE washer
2
8467
Safety gloves
1
