Double E M70 Operating instructions

USERS AND MAINTENANCE MANUAL FOR
M70, M80, AND M100 CORE CUTTERS

www.ee-co.com M70-100 Manual V2 Page 2 of 22
USER’S GUIDE AND MAINTENANCE MANUAL FOR M70, 80, and 100 CORE CUTTER
Version 2.0
September
2018
Copyright © Double E Company, LLC
All rights reserved.
This publicaon cannot be reproduced, completely or parally, without prior wrien authorizaon from Double E Company. Double E Company’s prod-
ucts are subject to frequent changes due to updates and improvements. Therefore, the informaon included in this publicaon can undergo modicaons
without noce. Double E Company appreciates any feedback relang to possible mistakes or omissions.

www.ee-co.com M70-100 Manual V2 Page 3 of 22
A. INTRODUCTION
A.1 Introducon
We thank you for choosing Double E Company Manual Core Cuers and are pleased to
have you as a customer. We are condent that our product will provide you with years
of sasfacon. For opmal performance, please use and maintain your Core Cuer as
outlined in this manual.
We recommend that you read this manual carefully and refer to it whenever a problem
may arise. Our Technical Support department is also always available for advice and
assistance. This manual describes the installaon, operaon, usage precauons, and
detailed informaon about this product’s accessories and opons.
The product must be used according to the instrucons. Keep this manual as a reference
for the future.
Double E Company reserves the right, at any me, to make changes (without any obligaon
of revision), felt to be useful for the product improvement or for any construcve or
commercial reason. Copying, buering and transmission in any form (electronic,
mechanical, by photocopying, translang or others) of this publicaon is forbidden
without express Double E Company authorizaon.

www.ee-co.com M70-100 Manual V2 Page 4 of 22
A.2 Table of Contents
A. Introducon 3
A.1 Introducon 3
A.2 Table of Contents 4
A.3 Important 5
A.4 Warranty 5
B. Safety 5
B.1 Safety Instrucon - Symbology 5
B.2 Safe Operaon of Equipment 6
C. Terminology 7
C.1 Core Cuer Components 7
D. Operang Instrucons 8
D.1 Installing Core Adapters 8
D.2 Seng Cung Assembly Height 9
D.3 Adjusng Core Stops 10
D.4 Adjusng Core Length Bar 11
D.5 Making the Cut 12
E. Product Specicaons 13
E.1 Technical Specicaons 13
F. Maintenance 14
F.1 Roune Inspecon 14
F.2 Annual Maintenance 14
F.3 Non-Roune Maintenance 14
F.4 Decomissioning 14
G. Troubleshoong 15
G.1 Mechanical Troubleshoong 15
G.1 Electrical Troubleshoong 18
H. Manufacturers Declaraon 19
I. Returns 19

www.ee-co.com M70-100 Manual V2 Page 5 of 22
A.3 Important
• Do not use this product before having read and understood the whole content of this
manual.
• Double E Company has done everything possible to make this manual complete and
correct.
• Please transfer this manual to subsequent users if the product is lent or sold.
• Should this documentaon or the warning labels applied on the device be lost or
damaged, please request replacements from the supplying company.
A.4 Warranty
See general terms of sale.
B. SAFETY
B.1 Safety Instrucon - Symbology
• For safe operaon of the Core Cuers, carefully read these safety instrucons before
use.
• Follow every WARNING and ATTENTION note, described in this secon, as they are
extremely important for safety.
• In this manual, warnings and are indicated by the following signal word convenons.
Indicates a potenally dangerous situaon that, if not avoided, is almost
ceran to cause serious injury or death.
Indicates a potenally dangerous situaon that, if not avoided, can cause
moderate to serious injuries, or even death.
Indicates a potenally dangerous situaon that, if not avoided can cause
minor to moderate injuries or damage to the equipment.
Highlights informaon needed to ensure proper use of this device.

www.ee-co.com M70-100 Manual V2 Page 6 of 22
B.2 Safe Operaon of Equipment
Double E Company designs and manufactures core cuutters with maximum safety in
mind. Please take careful note of the following rules for safe operation:
· Double E recommends always using the core cuer carefully without abusing it. Avoid strong
collisions and/or accidental impacts with foreign bodies. These collisions can damage the
machines internal and external parts.
· There is risk of injury or pinching from the rotaon of the cuer during cung. Keep
sucient distance during cung and do not touch any part of the moving machine during
rotaon.
· Do not wear loose hair or clothing near rotang parts for risk of entanglement.
· Do not use the core cuer in working condions dierent than stated in the specicaons
table or on any notes on the assembly drawing.
· Do not exceed the operang loads of the machine as specied on the customer quotaon
and/or assembly drawing. This voids the warranty and can be unsafe.
· Make sure all fasteners and guards are in place before operaon.
All replacement parts on this core cuer should be original equipment supplied by the
DoubleE Company.

www.ee-co.com M70-100 Manual V2 Page 7 of 22
C. TERMINOLOGY
C.1 Core Cuer Components
1. Machine Frame
2. Control Box
3. Motor/Gearbox
4. Core Support Bar
5. Core Adapter Set
6. Cung Assembly
7. Length Stop

www.ee-co.com M70-100 Manual V2 Page 8 of 22
D. OPERATING INSTRUCTIONS
D.1 Installing Core Adapters
Do not perform any installation while the main switch is on
Install the sliding core adapter (13), the staonary core adapter (14), the spacer (15), and anvil
(16) on the core support bar. Use the washer (17) and athead socket screw (18) to clamp the
pieces on the bar securely. Insure the sliding and staonary core adapters rotate freely.
HINT: For quicker diameter change, leave the 6” and 3” sliding adapters on the bar at all
mes.
Slide a core onto the support bar. Be sure the bar is level with the core resng on the drive
rolls. If not, raise or lower the le end of the bar as necessary. Lock it in place with the
clamping lever.
Be careful working in the area around the guarded cung blade.

www.ee-co.com M70-100 Manual V2 Page 9 of 22
D.2 Seng Cung Assembly Height
Do not perform any installation while the main switch is on.
With the core sll on the bar, loosen bolt 7 and adjust the height so the cung arm 6 is
horizontal when the blade contacts the core. When completed, reghten olt 7 to lock the
assembly at the correct height.

www.ee-co.com M70-100 Manual V2 Page 10 of 22
D.3 Adjusng Core Stops
Do not perform any installation while the main switch is on.
The core stop help keep the core from bouncing when cut. Loosen lever 8 to allow the stopsto
slide. Slide arm 17 so the bearing is lightly touching the core above it’s center point. Tighten
lever 8.

www.ee-co.com M70-100 Manual V2 Page 11 of 22
D.4 Adjusng Core Length Bar
Do not perform any installation while the main switch is on.
The core length bar (11) slides to allow seng the core length. It is provided with a rule and is
locked with lever 10. The stop (12) is located on the right and should be ipped out of the way
before the cut is made to prevent jamming the cut core.

www.ee-co.com M70-100 Manual V2 Page 12 of 22
D.5 Making the Cut
Do not perform any installation while the main switch is on.
Once the core is loaded on the support bar and the adjustments have been made, the cung
process is easy. Be sure the main switch is set to on and the Emergency stop switch is not
depressed. Pressing the Green buon while pulling evenly down on the cung handle will
start the core rotang. Pulling down to force the knife through the core will complete the cut.

www.ee-co.com M70-100 Manual V2 Page 13 of 22
E. PRODUCT SPECIFICATIONS
E.1 Technical Specicaons
Do not exceed the operatng parameters of the core cutter as listed here. This will
void the machine guarantee and could cause injury.
The M70, M80 and M100 core cuers designed for dust-free manual core cung
of cardboard cores and so plasc cores tested and approved by Double E.It uses
circumferenal propulsion to cut cores; the circular knife is staonary while pressing against a
core and then it is cut.
This machine is designed only for industrial use only. Do not operate in an unvenlated area.
TECHNICAL DATA
Length 75, 85, or 105 Inches
Width 19 Inches
Height (xed part) 55 Inches
Weight 275 Pounds
Supply Voltage 110 or 220 VAC (see nameplate)
Control Voltage 24 VDC
Frequency 50/60 Hz.
Installed Power 1 HP
Motor-Single Phase Asychronous 1100 RPM
Cung material: cardboard cores with inner diameters from 3.0” to 6.0” with a maximum wall
thickness of 1/2”.
Maximum length of cut cores: 70”, 80”, 100” depending on model.

www.ee-co.com M70-100 Manual V2 Page 14 of 22
F. MAINTENANCE
F.1 Roune Inspecon
Perform roune inspecon weekly. Roune inspecon can usually be accomplished without disassembly or removal of
parts from the machine. The purpose of roune inspecon is to ensure that the machine is funconing properly prior
to being used. Check the electrical system to ensure that the machine can not start without intenon and check the
funconing of the emergency stop buon. Ensure that all fasteners are ghtened properly and are not missing. Check for
worn or broken parts; if necessary, replace. Check the rubber drive rollers for dirt and dust and clean if necessary.
F.2 Annual Maintenance
Perform annual inspecon/maintenance yearly. Ensure that all fasteners are ghtened properly and that the safety
systems work properly. The machine condion should be evaluated and any worn or dirty parts replaced or cleaned. The
area around the machine should be kept free of dust and dirt so the operator can freely move without risk of tripping
over cut cores or components.
F.3 Non-Roune Maintenance
If the product is used under normal condions and inspected regularly, it is rare that any non-roune or extraordinary
maintenance will be needed. In the event that it is necessary, it is recommended that you contact Double E Company
Technical Support at 508-588-8099 extension 571.
F.4 Decomissioning
If the product is withdrawn or removed from service, it is necessary to make all at-risk components harmless through
proper demolion. These operaons must be carried out in accordance with the provisions exisng in the naon in which
the product will be disposed.

www.ee-co.com M70-100 Manual V2 Page 15 of 22
G. TROUBLESHOOTING
G.1 Mechanical Troubleshoong
I. Core is not completely cut or burrs on the ID of the cut
Possible Causes:
1. Anvil is worn out meaning the notch is greater then the 1mm depth set at the factory.
How to Proceed:
Rotate or replace the anvil
2. The inside core diameter is larger than the allowable core tolerance (core tolerance
is + / - 0.3 mm).
Consequently, the core is not properly gripped during the cung
operaon.
How to Proceed:
If the customer’s cores are out of tolerance by more than + / - 0.3 mm, the cores ID should be
measured precisely
and a new anvil should be ordered according to the actual size. Alternavely,
adjust the ball catches on the adapters to beer grip the core.
3. Knife does not go down completely and consequently it doesn’t cut a core completely.
How to Proceed:
Loosen the height locking handle and posion the cuer head properly so it can completely
penetrate the core. Reghten the locking handle

www.ee-co.com M70-100 Manual V2 Page 16 of 22
4. Knife blade is worn out, blunt or it is
jagged.
How to Proceed:
Rotate or replace the worn out knife blade with a new
one.
II. Screw Cung
Possible Causes:
1. The Core Support Bar is not level or straight
How to Proceed:
Conrm that the core bar assembly is not bent. Adjust the horizontal locaon by loosening
and
adjusng the core bar assembly support to the center of the gear drive. If the core bar assembly is
bent, aempt to straighten it. If
this procedure fails, replace the core bar assembly .
During the cung operaon, the core moves parallel to its axis. As a result, the knofe does not cut through the core,
rather it makes a cut similar in appearance to a screw thread
III. Diculty pung core onto Core Support Bar
Possible Causes:
1. The inside diameter of a core is too small (core ID is out of the required tolerance + / - 0.3mm).
How to Proceed:
Measure the core ID the customer uses and order a new set of core adapters according to
customer’s
needs.

www.ee-co.com M70-100 Manual V2 Page 17 of 22
IV. Core is not in proper contact with the drive rollers
Possible Causes:
1. The core bar assembly of the core cuer is not parallel to the machine frame .
How to Proceed:
Loosen the core bar assembly fastener and adjust to a level posion, placing it in parallel to the
machine frame, ghten fastener.
This operaon should be carried out with a core placed on the
machine.
As a result the core slides on the drive rollers. Aer cung a core, a secon of the original core stays on the
machine
and moves to the right or to the le.

www.ee-co.com M70-100 Manual V2 Page 18 of 22
G.1 Electrical Troubleshoong
I. Motor does not work aer turning on the machine and pressing the START buon while
pulling the cung arm assembly down
Possible Causes:
1. Micro-switch placed inside the knife cover K2 is damaged.
How to Proceed:
Check if the micro-switch is jammed. If it is jammed remove the two screws and micro- switch cover
and adjust
its posion so it does not jam.
If this procedure does not yield sasfactory results, replace the micro - switch.
2. Current protecon breaker inside the electrical box has been acvated.
How to Proceed:
Press the black reset switch on the Q1 circuit breaker.
3. The S1 contactor is damaged.
How to Proceed:
Check with a multi-meter if the contacts operate properly. Check with a multi-meter if contactor coil
is
damaged..
5. EMERGENCY STOP switch, contact K1 - (red contact) - is damaged.
How to Proceed:
Check with a multi-meter if the contacts operate properly. If needed replace them.
6. Power Supply is damaged or there is short-circuit in the 24VDC circuit.
How to Proceed:
Check if there is 24VDC at power supply output and if the green diode is illuminated.
If the diode is not illuminated, check if 120 VAC is at the power supply input. If it is present, the
power supply is damaged.
If the green LED is blinking, the 24VDC circuit has an electrical short
present. Trace the short and repair

www.ee-co.com M70-100 Manual V2 Page 19 of 22
H. MANUFACTURERS DECLARATION
Buyer shall aord Double E Company prompt and reasonable opportunity to inspect any goods as to which a claim is
made and Double E Company shall have the right of nal determinaon of the cause and existence of any defect under this
warranty. No material may be returned to Double E Company without Double E Company‘s express prior permission in
the form of a return authorizaon number.
Correcon of non-conformies, in the manner and for the period provided above, shall constute fulllment of all
liabilies of Double E Company to Buyer with respect for the goods, whether based on contract, negligence, strict tort,
or otherwise.
I. RETURNS
Warranty and non-warranty returns are iniated through the issuance of a return material authorizaon (RMA) number
from an authorized Double E Company sales or service/support representave. This can be obtained by calling Double E
Company in West Bridgewater, MA at 508-588-8099.
The RMA number should be clearly evident on the shipping label and/or invoice and the package should be shipped freight
prepaid. If quesons arise or if addional informaon is required, please call the Inside Sales department at 508-588-8099
Product returns should be sent to the address below:
Double E Company, LLC
319 Manley Street
West Bridgewater, MA 02379 ATTN:
RMA # ________________

www.ee-co.com M70-100 Manual V2 Page 20 of 22
Notes
