Perfecta 76 UC Operating instructions

1/01 E Service Instructions 1
The Service Instructions manual
belongs to the hands of the
repair and maintenance personnel !
PERFECTA 76 / 92 / 115 / 132 / 168
UC /TV
SERVICE
INSTRUCTIONS
(Servo)

1/01 E Service Instructions 2
Table of Contents Page
General Instructions ...................................................................................................................... 4
Safety Inspection........................................................................................................................... 4
Knife Drive..................................................................................................................................... 6
Setting the Automatic Stopping Device ............................................................................... 6
Knife Drive Clutch and Brake Assembly ............................................................................. 6
Clutch/Brake Assembly Maintenance ................................................................................. 8
Malfunctions in the Knife Drive............................................................................................ 8
Clamping System .......................................................................................................................... 9
Gap Between the Knife Back and the Clamp Edge............................................................. 9
Play in the Clamp Guideways ............................................................................................. 10
Clamp Parallelism with the Cutting Table............................................................................ 11
Cutting System.............................................................................................................................. 13
Play in the Knife Beam Guideways ..................................................................................... 13
ReadjustingtheKnifeCut-ThroughPosition ........................................................................ 15
Non-RepeatDevice.............................................................................................................. 15
CuttingSystem Maintenance .............................................................................................. 18
CuttingTable ................................................................................................................................. 18
Backgauge DriveSystem .............................................................................................................. 18
BackgaugeGuidance........................................................................................................... 19
ThreadBacklashCompensation .......................................................................................... 20
MeasuringSystem......................................................................................................................... 21
CalibratingtheMeasuringSystem ....................................................................................... 21
Setting the Proximity Switches............................................................................................ 21
HydraulicClampingSystem .......................................................................................................... 22
Pre-Clamping ....................................................................................................................... 24
CutTriggering ...................................................................................................................... 25
MainClamping..................................................................................................................... 26
Decompression.................................................................................................................... 27
ClampReturn....................................................................................................................... 28
Start-Up ............................................................................................................................... 29
Adjusting the Hydraulic Clamping System ........................................................................... 29
CheckingtheAdjustment..................................................................................................... 30
Main Clamping Pressure Setting Instructions ...................................................................... 30
HydraulicClampingSystemMaintenance ........................................................................... 30
Malfunctions in the Hydraulic Clamping System............................................................................ 31

1/01 E Service Instructions 3
ComputerControl........................................................................................................................... 33
Control Processor ...............................................................................................................33
SafetyModule...................................................................................................................... 34
PC Design ........................................................................................................................... 35
Software ........................................................................................................................................ 35
UC Software Change .......................................................................................................... 35
TV Software Change........................................................................................................... 36
Settings/OperatingData................................................................................................................. 37
ServiceNenu ................................................................................................................................. 39
I/O Test Menu ............................................................................................................................... 41
KeyboardCode .............................................................................................................................. 45
SensorTest Menu ......................................................................................................................... 46
Activating the Differential Display .................................................................................................. 47
SpeedMenu .................................................................................................................................. 49
CharacterSetMenu ....................................................................................................................... 50
Texts Menu ................................................................................................................................... 50
KnifeControl(ControlSwitches) .................................................................................................... 51
PSG16 Light Guard....................................................................................................................... 62
ErrorMessages .............................................................................................................................63

1/01 E Service Instructions 4
General Instructions
This Service Instructions manual
isprovidedasasupplementtothe
OperatingInstructionsmanualfor
the repair and maintenance
personnel and, therefore, is
referredto the OperatingInstruc-
tions manual in several cases.
As a great deal of setting and
repairinstructionsaffectthesafety
oftheoperatorandofthemachine,
such work should be performed
bytrainedorinstructedpersonnel.
In this place, a few fundamental
instructions be given which, as
practice shows, are often disre-
garded:
• Whenever you remove sepa-
ratingguardingssuchashoods,
panelings etc. for repair and
maintenance purposes, always
remember that, in most cases,
machine elements with hazard-
ousmovementsarebehind. For
this reason, guardings must, by
all means, be refitted after com-
pletion of work.
• Open switch cabinets and
switching rooms do not only col-
lectdustthatleadstofailures,but
also involve danger to life and
limb.
You are encouraged to take
theopportunityPERFECTAof-
fers you to have your techni-
cians trained at our Training
Centre.
Safety Inspection
Duetotheirwayofoperationcon-
sisting of hazardous movements
such as clamping and cutting,
guillotinesmustmeetanumberof
safety regulations. Such regula-
tionsaremetby"SafetyDevices"
described under the same cap-
tion in the Operating Instructions
manual.
According to the Accident Pre-
ventionProceduresforthePrint-
ing and Paper Processing In-
dustry, VBG 7i, § 40, the user
must ensure that the safety
devices-particularlythecontrol
system-shouldbeinspectedby
aspecialisteveryfiveyears.The
result of the inspection should
be recorded and filed.
Fig.2showsanacceptancecheck
list as used by PERFECTA.
Machines accepted without any
objections are provided with a
plaquette (Fig. 1) which shows
the next inspection date.
Fig. 1

1/01 E Service Instructions 5
Fig. 2

1/01 E Service Instructions 6
Knife Drive
The timing of the S52, S53, S54
control switches on the crank-
shaft is explained by a chart in
the "Knife Control" section (con-
trol switches).
Theproperfunctioningofthecon-
trolswitchescanbecheckedfrom
the service menu (I/O Test).
S53
- Knife-down travel.
-Clamp locking whilethe knife is
coming down.
S54
- Checking the UDC.
- Emergency shut-off in case of
S52 failure.
The gap shown in the timing
chart (switching distance) be-
tween S54 and S53 should be
1/3to1/2ofaflywheelturn.For
thispurpose,energizetheclutch
(referto"ManualCranking"inthe
Operating Instructions manual)
andchecktheswitchingdistance.
Whentheknifedriveisautomati-
callystopped,theknifeedgemust
protrude at least 6 mm over the
right-hand clamp bottom edge.
Setting the
Automatic Stopping
Device
Fig. 3
8
9
7
54
6
1
2
3
14
11
12 13 10
The cam of S52 should be set
sothatthemachinewouldstop
at the upper dead centre and
thecamfollowerofS54comes
to stop within the first third of
its cam length.
When the knife beam runs over
the UDC (S54 no longer oper-
atedatstopposition),anysubse-
quent cut triggering is disabled.
The display reads Error 28:
Safety Module Detecting Error.
Bypressingthe"C"key,concrete
Error 7 appears: Knife Overrun.
After turning off and on the ma-
chine,thesubsequentcutcanbe
restarted by the knife pushbut-
tons.
If there is another overrun at the
UDC,slightpre-stoppingcorrec-
tioncan beperformed byturning
forward the entire cam package
within the permissible range.
If such correction by the above-
mentioned cam shifting is not
successful, i. e. if there is still
overrun, checking the clutch/
brakeassemblyoftheknifedrive
should,underanycircumstances,
be checked.
The control switches have the
followingfunction:
S52
-Takingoverknifeup-movement
fromthelowerdeadcentre(LDC).
- Deactivating the light guard ef-
fect.
- Stopping the knive travel to-
wards the upper dead centre
(UDC).
Knife Drive Clutch
and Brake Assembly
System Design (Fig. 3)
Armature disk 3 provided with
brake lining 1 or clutch lining 2,
respectively, is axially movable
on a spline bushing. It is forced
againstbrakering6bysprings5.
Thisreliablybrakesthemachine.
When the clutch is energized,
armature disk 3 is attracted by
the magnetic field of coil body 7
and pressed against friction ring
8. The machine is engaged.

1/01 E Service Instructions 7
Checking and Setting the Air
Gap
Under normal operating condi-
tions, the air gap should be
checked once per year.
For air gap A, refer to the Table
(Fig. 5).
• Engaged state (clutch "ON"):
If air gap A min is smaller than
specified in the Table, Fig. 5,
shims 10 of uniform thickness
should be inserted
between coil body 7 and friction
ring 8 (Fig. 4) for
machine sizes 76 and 92, or
between friction ring 8 and
spacing segment 9 (Fig. 3) for
machine sizes 115 and 132.
Forthispurpose,slackenscrews
11aroundthecircumferenceand
then re-tighten them uniformly.
The shims are available in vari-
ous thicknesses. Refer to the
Spare Parts Catalogue in the
Operating Instructions manual.
After the successful installation
of the shims, make sure that air
gapAmaxspecifiedintheTable
is not exceeded (use thinner
shims) and air gap A min in the
brakedstate(clutch"OFF")isnot
undercut.
Checking the Bearing Play
Formachinesizes115and132
only.
De-energize the clutch.
No perceptible play in the bear-
ing must appear when the fly-
wheelrimtopispulledandpushed
by hand.
In case of evident play, replace
the antifriction bearings.
Caution!
Bringtheknifebeamtoitslow-
ermost position prior to dis-
mantling the clutch/brake as-
sembly,asthebrake becomes
ineffectivewhenthecompres-
sion springs are relieved.
Fig. 4
8
7
2 1 6
3 4 5
Fig. 5
Knife Drive Clutch/Brake Assembly Air Gaps ( mm )
Braked state (clutch "OFF")
If air gap A max is wider than
specified in the Table, shims 12
of the same thickness should be
inserted between brake ring 6
and gearbox cover 14. For this
purpose, energize the clutch as
described in the Operating In-
structionsmanualunder"Manual
Cranking", slacken screws 13
around the circumference, and
then re-tighten them uniformly.
1411
10
13
12
Machine Size 76 92 115 132 168
Clutch "ON" A min 0,2 0,2 0,2 0,2 0,2
A max 0,4 0,5 0,5 0,5 0,6
Clutch "OFF" A min 0,6 0.7 0,7 0,7 0,7
A max 0,8 11,2 1,2 1,4

1/01 E Service Instructions 8
Clutch/Brake
Assembly
Maintenance
Check the air gap annually as
describedaboveandcorrectwith
shims, if required.
Keep the slip rings clean and
grease-free.Cleanwithfine-grain
abrasive cloth, if necessary. En-
sure proper contacting between
the carbon brushes and the slip
ring to avoid brush sparking.
Removecarbondustwithabrush
(without metal ring).
If the brake or clutch linings are
badly worn out or contaminated
with oil, the armature disk must
be replaced. Before installing a
newarmaturedisk,cleanthefric-
tion surfaces of the clutch and
brake rings with white spirit.
After installation, check the air
gapsinconformitywiththeTable
(Fig. 5).
Protecttheasbestos-freefriction
liningsfromoilandgrease.Even
when doing installation and set-
tingwork,makesureyourmeas-
uring tools and also your hands
are grease-free.
Caution!
Bringtheknifebeamtoitslow-
ermost position prior to dis-
mantling the clutch/brake as-
sembly,asthebrake becomes
ineffectivewhenthecompres-
sion springs are relieved.
Malfunctions in the
Knife Drive
The following malfunctions may
occur in the knife drive and are
not indicated by the computer
control system as error codes:
• The main motor cannot be
started.
Remedy:
- Switch S56 for "Manual Crank-
ing" (refer to the Operating In-
structions manual) under the fly-
wheel guard is locked. Unlock
the switch.
-The flywheel guard is not prop-
erly closed. Turn in the screw
until the safety switch is closed.
-Defectivefuses.Replacethecor-
responding fuses.
•Theknifeorclampdrivecannot
be started.
Remedy:
-Main motor switched off.
-Defective two-hand control
pushbutton.Replacepushbutton.
-No contact between the carbon
brushesand theslip rings.Refer
to"Clutch/BrakeAssemblyMain-
tenance".
-Refer to "Malfunctions in the
HydraulicClampingSystem"(flow
indicator).
-Pedallocked(S69).
-Y62doesnotmakecontactoris
defective.
• Heavy jerk when the knife re-
verses at its lowermost position.
Remedy:
- The overload protection device
hasbecomeloose.Re-tightenthe
overloadprotectionscrew.Refer
to "Knife Drive Assembly Over-
load Protection Device" in the
OperatingInstructionsmanual.
- Very dull knives are often the
cause for the responding of the
overloadprotectionring.

1/01 E Service Instructions 9
Clamping
System
Fig. 7
7
1
4
6
5
8
3
9
2
Fig. 6
Keeping specified gaps, it is im-
portanttobringtheclampingpres-
sure as close as possible to the
cutting line.
Gaps shown in Fig. 6 should be
0.2 + 0.1 mm.
Clamp 1 can be readjusted with
respect to cutting line 2 as fol-
lows:
In addition to gap s between the
knife back and the clamp edge,
the play of the clamp in its
guidewaysisdecisivetoobtaina
high-quality and high-accuracy
cut.
Gap Between the
Knife Back and the
Clamp Edge
Machine Size 76 (Fig. 7)
• Slacken screws 3 to release
clamp guideway 4 at the clamp
left and right rear sides.
•Adjustrequiredgapsbymeans
ofshims5tobeinsertedbetween
clamp 1 and clamp guideway 4.
Inserting shims reduces the gap
by the shim thickness, while re-
moving shims widens the gap.
The shims are 0.05 and 0.2 mm
thick. Refer to the Spare Parts
Catalogue in the Operating In-
structions manual.
• Tighten the clamp guideway
and check the gap across the
entire cutting width with a feeler
gauge.

1/01 E Service Instructions 10
Machine Size 92 (Fig. 8)
Fig. 8 shows shims3 under pre-
tensioned roller guideway 4 by
means of which the position of
clamp 1 with respect to cutting
line 2 was set in the factory.
Inserting shim 3 between clamp
1and roller guideway 4 mini-
mizes gap s by the shim thick-
ness, while removing shim 3 in-
creases the gap.
For the proper procedure, refer
to"PlayintheClampGuideway".
Machine Sizes 115/132 (Fig. 9)
• Slacken lower nuts 3 at the
clamp left and right sides.
•Slightly turningeccentric pins4
(bothsidesuniformly)movesthe
clamp away from or towads the
cutting line.
Check gap s across the entire
cuttingwidthwithafeelergauge.
•Whenjammingthenuts,ensure
thatthepositionsoftheeccentric
pins are locked.
Fig. 8
Fig. 9
Play in the Clamp
Guideways
Machine Size 76 (Fig. 7)
• Slacken screws 6of adjusting
strip 7.
• Move adjusting strip 7 against
clamp guideway4with eccentric
pin 8 until play a between both
parts is < 0.05 mm.
When performing this setting,
ensure that clamp guideway 4
restsonguidestrip9oftheoppo-
siteside.Forthispurpose,press
the clamp towards the knife.
5
8
7
6
1
2
34
184
9
3
7
8
5 6
1
9
65
12
11
10
10
4

1/01 E Service Instructions 11
Machine Size 92 (Fig. 8)
The clamp is guided by pre-
tensionedrollerguideways,i.e.it
isplay-free. Therefore, readjust-
ing is not necessary.
If any wear is found due to long
andharduseofthemachine,the
rollerguidesshouldbereplaced.
Forthis purpose,proceed asfol-
lows:
• Support clamp 1 by wooden
wedges, for example.
• Pull out pins 5 and slacken
screws6ofknifebeamguidestrip
7.
• Remove roller guideway 4 by
slackening screws 8. Observe
the assignment of shims 3.
• Slightly tighten the new roller
guideways with their associated
shims 3 by means of screws 8.
•Re-pin knife beamguide strip7
and tighten with screws 6.
• Check air gap a on the roller
guideway. Gap a should be
0.5mmwhentherollerguideway
is properly pre-tensioned.
•Ifnecessary,re-tensiontheouter
roller guide strip by means of
screws to be introduced into the
tappedholesinknifebeamguide
strip 7 until gap a is obtained.
Then,tightentherollerguideway
with screws 8.
Removethewoodenwedgesand
check the clamp for free move-
ment by pressing the pedal.
Machine Sizes 115/132 (Fig. 9)
•Slackenlocknuts5onadjusting
screws 6.
• Slightly slacken screws 7 on
adjusting strip 8.
• Reset adjusting strip 8 against
guide blocks 9 by adjusting
screws6untilplayabetweenthe
adjustingstripandtheguideblock
is < 0.05 mm.
Whenperformingthisadjustment,
ensure that guide blocks 9 rest
ontheoppositesideofguidestrip
10. For this purpose, press the
clamp towards the knife.
•Aftercompletingtheadjustment,
tighten the screws and nuts and
check the play over the entire
clampstrokewithafeelergauge.
Thelateralplay(faceplay)should
be b = 0.1 + 0.05 mm.
Forthispurpose,adjustsupport-
ing screws 11 with screws 12
slightly slackened until play b is
obtained between guide strip10
andguideblock9.Tightenscrews
12.
Clamp Parallelism
with the Cutting
Table
Inthefactory,theclampisaligned
in parallel with the cutting table
surface.
This can be checked by pre-
clamping with paper strips put
under the left and right sides of
the clamp.
If correction should be neces-
sary, proceed as follows:
Machine Sizes 76/92
Fig.10 shows the clamping prin-
ciple for machine sizes 76 and
92.
Machine Size 76 (Fig. 11):
• Remove the hydraulic system
front paneling under the cutting
table.
• Slacken clamping screws 1 in
pusher rod eyes 2 and 3.
• Turn pusher rod 4 as follows:
-Increasingthedistancebetween
thepusherrodeyesmovesdown
the clamp on the right.
Fig. 10
Fig. 11
5 2 4 3
3 4 1 2

1/01 E Service Instructions 12
-Reducingthedistancebetween
the pusher rod eyes moves up
the clamp on the right.
• Tighten clamping screws 1,
checkforparallelismasdescribed
above, and re-fit the paneling.
Machine Size 92 (Fig. 12):
Adjusting the clamp right-hand
side is analogue to that for ma-
chine size 76.
Theclampleft-handsidemustbe
adjusted on clamp lever bearing
5 in Fig. 10. For this purpose,
proceed as follows:
• Slacken clamping screw 1 on
the front of the cross beam.
• Turn clamping lever pivot pin 2
fromthemachinebackusingkey
surface 3.
• After checking for parallelism
with paper strips, tighten clamp-
ing screw 1.
MachineSizes115/132(Fig.14)
The clamping principle is shown
in Fig. 13.
• Remove the clamping system
frontandrearpanelingunderthe
cutting table.
• Slacken screw 1 on the front
lower cross beam.
•Gentlyturnclampingleverpivot
pin2or3bythekeysurfacefrom
the back of the machine until the
paper strip, see above, is seized
by the clamp.
Onlyreadjustthatclampinglever
pivot pin where the deviation ex-
ists.
• Tighten screw 1 and re-fit the
paneling.
Fig. 12
Fig. 13
Fig. 14
31 2
2 3
132

1/01 E Service Instructions 13
Cutting System
All PERFECTA guillotines work
on the basis of what is called the
slantrockingcut,i.e.theknifeas
the cutting tool moves along a
curved path from left to right.
All findings and experience
related to the cutting system
regardingthequestionsofcutting
stock, knives, clamping, cutting
inaccu-racies and their
rectification are summarized in
our"CuttingCompendium"that
youcanob-tainfromPERFECTA.
Play in the Knife
Beam Guideways
Inadditiontomanyotherfactors,
a smooth guidance of the knife
beam is a prerequisite to a high-
quality and high-accuracy cut.
Over the years, and depending
uponthe workingconditions, the
guideways are subject to wear,
although the latter is minimal.
Therefore, the play in the knife
beam guideways should, from
time to time, also be measured
andreadjusted,ifrequired.
Machine Sizes 76/92 (Fig. 16)
Knife beam 1 moves between
slide surfaces 2 on the machine
frameandguidestrips3.Theguide
strips have been adjusted with
respect to the knife beam with
shims4sothatgapsrequiredfor
establishing the necessary
lubrication film is
< 0.05 mm.
Checking the play:
• Push the knife beam (without
knife)against the framefrom the
rear at the top and bottom posi-
tions. Check the play between
the knife beam and the guide
strip on the left and right sides
using a feeler gauge.
• Removing shims reduces air
gaps. Underany circumstances
shoulditbeensuredthatthegap
is not too small, as, otherwise,
lubricationisnotguaranteed,with
the knife beam tending to get
jammed.
Thiswouldresultinseizureofthe
sliding surfaces.
Whenever the positions of the
guide strips are changed, the air
gap between the knife back and
the clamp edge must always be
checked as described under
"Clamping System" and read-
justed, if necessary.
12
34
Fig.16
Machine Size 168 (Fig. 15 )
Slacken upper lock nut3on ten-
sionspindle2locatedinclamp1.
Turn nuts 4to adjust the clamp
in parallel with the cutting table.
Thighten lock nut3.
Onlyadjustthesidewhichshows
thedeviation.
3
1
2
4
Abb.15

1/01 E Service Instructions 14
MachineSize168(Fig.18)
Knifebeam1movesbetweenthe
slidesurfacesonmachineframe
2and guide strips 3. On top, the
guidestripsrestontwostudbolts
4 each and are fixed to the ma-
chine frame by two nuts 5.
Below, the guide strips are sup-
ported on the machine frame by
four threaded bushes 6and are
fastened to the frame by screws
7.
Gapsshould be < 0.05 mm.
Checking the play:
• Push the knife beam (without
knife)against theframe from the
rear at the top and bottom posi-
tions.Useafeelergaugetocheck
theplay between the knife beam
andtheguidestripontheleftand
right sides.
If required, readjust gap sas
follows:
•Removethelightguardsandthe
upperlateralpaneling.
• Set the knife beam to medium
feed height and push it against
the frame.
• Slacken nuts 5and screws 7.
•Usenuts5andthreadedbushes
6to adjust the play.
• Lock nuts5and tighten screws
7and check the play once again
at the topmost and lowermost
positionsoftheknifebeamonthe
left and right of the guide strip.
Correct,ifrequired.
•Re-fit thepaneling andthe light
guards.
Important: Check the light
guardsforproperfunctioning.
Checking the play:
• Push the knife beam (without
knife)against theframe from the
rear at the top and bottom posi-
tions. Check the play between
the knife beam and the guide
strip on the left and right sides
using a feeler gauge.
If required, readjust gapsas fol-
lows:
• Set the knife beam to medium
feed height and push it against
the frame.
• Remove the front paneling.
• Slacken clamping screws 8 on
the left and right of the cutting
table (8 screws in total).
• Remove plastic cover 7 and
adjust guide strip 3 against the
knifebeamwithadjustingscrews
6 until the required play is ob-
tained.
• Re-tighten clamping screws 8
and check the play at the knife
beam top and bottom positions
once again.
• Re-fit the front paneling.
MachineSizes115/132(Fig.17)
Knife beam 1 moves between
slide surfaces 2 on the machine
frame and guide strips 3. The
guide strips are supported in
machinefrontpart5byguidepins
4. By means of adjusting screws
6 located under plastic covers 7
on the machine front parts, the
guidestripscanbemovedtowards
the knife beam. On the cutting
table side, guide pins 4 and
adjusting screws 6 are secured
against moving or turning by
clamping screws8.
Gap sshould be < 0,05 mm .
Fig.17
5
3
8
2
1
6
7
4
Fig.18
5
3
2
6
7
4
1

1/01 E Service Instructions 15
Readjusting the
Knife Cut-Through
Position
The cut-through position is de-
scribedunder"AdjustingtheCut-
ThroughPosition"intheOperating
Instructionsmanual.
MachineSize76/92(Fig.19)
Fora.m.cuttingsizestheKnifeCut-
throughpositionisreadjustedatthe
righthandsideofthemachineas
following:
Rightside:
Removecapfromopening3.
Loosenscrew5bytwoturns.
Insertknifechangingtool1into
centreofbolt6.
Anticlockwiseturning:Liftknife.
Clockwiseturning:Dropknife.
Tightenscrew5.Theposition
ofscrew5indicatestheposition
oftheknife.Screwupmeansknifeup.
Removethetoolaftersetting!
5
63
3
1
Fig.19
Non-Repeat Device
Theupperdeadcentreoftheknife
beam is stopped and controlled
bycontrolswitchesS52andS54
and is monitored by the safety
processor control system which
immediatelystopstheknifetravel
incaseofanyirregularities.Refer
to "Setting the Automatic Stop-
ping Device".
In addition, all PERFECTA
guillotines are provided with a
mechanicalnon-repeatdevice
(catch/lockingpin), a thirdsafety
meansfortheupperdeadcenter,
whichlockstheknifebeamtothe
machineframe.
Ifthisnon-repeatdeviceresponds
due to excessive overrun, the
knife beam must be manually
returnedtoitsupperdeadcentre.
Referto"ManualCranking".
In case the overload protection
device responds, refer to "Knife
Drive Assembly Overload Pro-
tection Device".

1/01 E Service Instructions 16
Setting Instructions
Machine Size 76 (Fig. 20)
The length of chain 1between
solenoid Y80 and catch 2is set
by a screw 3so that the catch
formsagap s=0.6-1.0mmwith
re-specttothebearingsurfaceon
the frame.
Alignswitchplate4withscrews5
sothatswitchS81isoperatedby
stop6whenthesolenoidisdead,
and switch S82 is operated by
stop6whenthesolenoidisener-
gized (by activating the manual
clutch - refer to "Manual Crank-
ing").
Set the spring-contact switch so
that the cam follower still travels
ap-prox. 1.5 mm beyond the
switchingpoint.
Machine Size 92 (Fig. 21)
Catch2connected with solenoid
Y80 through chain 1 forms gap
s = 0.6 - 1.0 mm with the stop
located on the machine frame
whenthesolenoidisdead.Atthis
position, S81 is operated. In the
energizedstate(byactivatingthe
manual clutch - refer to "Manual
Cranking" in the Operating In-
structions manual), S82 is oper-
ated by stop 3.For this purpose,
switches S81 and S82 can be
aligned on switch plate 6 within
therangeoftheiroblongholesby
screws5.
1
3
6
S82
Y80
52
S81
Fig.21
1
2 6 3
S81
5
S82
6
4
Y80
Fig.20

1/01 E Service Instructions 17
Machine Sizes 115 and 132
(Fig.22)
Screwin chain1whichconnects
solenoid Y80 with catch 2 with
the aid of threaded pin 3to be
turnedindeepenoughandlockit
sothatbetweencatch2andcatch
stop4isagapofs=0.6-1.0mm
whenthesolenoidisdead.Atthis
position,S81mustbeinactuated
state.
SwitchS82shouldbealigned so
that it is operated by the catch
when the solenoid is energized
(byactivatingthemanualclutch-
referto"Manual Cranking" inthe
OperatingInstructionsmanual).
Machine Sizes 168
(Fig.23)
S81
Y80
Fig.22
S82
1
4
2
3
Important!
Whenthecatchrestsontheknife
beam contour with Y80 being
dead,S82must not yet be oper-
ated (except machine size 168).
Lockingpin1isguidedbybush2
supported by machine frame3.
Solenoid Y80 withdraws this pin
againstpull-backspring4sothat
a gap ofs = 2 - 3 mm isobtained
betweenknifebeamslidesurface
5ontheframeandthefaceofthe
locking pin.
Adjuststop6inthesolenoidaxis
so thatS81is actuatedwhen the
solenoid is in its de-energised
state.
Adjust switch S82 so that it is
actuated by the stop when the
solenoid is in its
energisedstate(byactivatingthe
manual clutch - refer to "Manual
Cranking" in the Operating
Instructionsmanual).
53124
S82 S81 Y80
6
Fig.23

1/01 E Service Instructions 18
Cutting System
Maintenance
Itshouldbeensuredthattheknife
beamguidewaysarelubricatedatthe
top and bottom positions of the
knifebeam.Referto"Lubrication"in
theOperatingInstructionsmanual.
Alubricationchartisprovidedon
thebackofthemachine.
Neveruseknivesotherthanthose
assignedtotherespectivema-chine
modelsandsizes.
ForPERFECTAguillotinesofthe
samemodelsandsizes,theknives
areinterchangeable.
Whenchangingtheknife, ensure,
underanycircumstances,thatthe
tappedholesintheknifeareclean
andtheknifeboltsareundamaged.
Cutting Table
All PERFECTA guillotines are
suppliedwithstandardcuttingta-
bles and the associated side ta-
bleswith groundsurfaces andof
special-quality cast iron. In the
factory, the tables are provided
withtemporarycorrosionprotec-
tivebefore beingshipped. When
the machine is installed at the
user's, this corrosion preventive
mustberemovedwithwhitespirit.
Never use any caustic agents.
The clean table is susceptible to
corrosion,particularlyinthehan-
dlingarea.
PERFECTAofferscorrosion-pro-
tective wax which inhibits corro-
sionandimprovestheslidingprop-
erties.
Duetotheabrasioncausedbythe
cuttingstock,thetreatmentmust
be repeated from time to time.
If small deposits of rust should
have built up as a result of insuf-
ficientcareornegligence,remove
them immediately. Never use
abrasive cloth or sand paper. Ti-
tanium fleece or a conventional
householdfibrescouringpadhas
proven useful for this purpose.
When treating the table always
workin the grindingdirection.
PERFECTA offers optional cut-
tingandsidetableswithupgraded,
i.e.corrosion-resistantsurfaces.
Backgauge
DriveSystem
AllPERFECTAguillotineshavea
controlled backgauge drive sys-
tem.The advantage of this drive
systemisagentleapproachingto
and a soft, precise positioning of
the cut measurement. The opti-
mum backgauge speed is auto-
maticallydeterminedfromthedis-
tance between the cut marks.
For most of the applications, the
guillotinesarefactory-settoopti-
mum.Viathe"Speed"(TV)/"Set-
tings"(UC)menu,thebackgauge
speeds as well as the start and
stoprampscanbeadaptedtothe
stock to be processed and to
otherrequirements.
Formanualpositioning,cuttingor
programming according to the
print,PERFECTAguillotineshave
a so-called "electronic hand-
wheel"withninedifferentforward
and reverse speeds each. Refer
to "Backgauge" in the Operating
Instructionsmanual.

1/01 E Service Instructions 19
Backgauge Guidance
Machine Sizes 115 and 132
The backgauges of the 115 and
132size machines havea round
guidance(slideguidance)located
above the cutting table.
If any play on the backgauge
should be noted, check the set-
screws between the backgauge
andtheguidewayforfirmseating
andproperlockingandre-tighten
them,ifnecessary. Referto"Ad-
justing Square Cutting" in the
Operating Instructions manual.
Ifexcessiveplayinthebackgauge
guidancemayoccurafteralonger
time of operation, readjust the
play with draw-in screws 1 and
adjusting screws2(Fig. 24).
Checktheplayontherearhubof
guide block3. For this purpose,
bring the hub to rest on guide
column4bymanuallypushingthe
backgauge on the left and right
andreadtheabsoluteplayoffthe
dial gauge in no-load condition.
The play should be within the
limits of 0.03 - 0.04 mm. by
Depending upon the operating
conditions, the guide column
shouldbecleanedwithwhitespirit
onceperyear. Thelubricationcy-
cle specified under "Lubrication"
in the Operatring Instructions
manualorinthelubricationchart
onthebackofthemachineshould
be kept.
Machine Sizes 76 and 92
Thebackgaugesofthe76and92
sizeguillotinesareguidedby pre-
tensionedlinearguideways(roller
guideways), i. e. the guideways
workinaplay-freemanner.There-
fore, resetting is not necessary.
If any play on the backgauge
should be noted, check the set-
screws between the backgauge
andtheguidewayforfirmseating
andproperlockingandre-tighten
them,ifnecessary. Referto"Ad-
justing Square Cutting" in the
OperatingInstructionsmanual.
Depending upon the operating
conditions, the linear guideways
should be cleaned (with white
spirit)andlubricatedatleastonce
peryear.Referto"Lubrication"in
theOperatingInstructionsmanu-
al.
2 1
4
3
Fig.24

1/01 E Service Instructions 20
Thenchecktherollersforsmooth
running over the entire length of
theguideway.
Depending upon your operating
conditions,usewhitespirittoclean
therollersandtheguideways.Do
not grease the rollers and the
guideways.
4231
Thread Backlash
Compensation
Machine Sizes 76, 92, 115, 132,
168(Fig.26)
For these machine sizes, the
backgaugeismovedbyanacme
thread leadscrew 1. The cutting
positionsarealwaysapproached
inforwarddirection. Theexisting
backlashinthethreadiscompen-
sated by a compression spring2
which permanently and firmly
presses nut 3 fixed to the back-
gaugeagainstthedrivingflankof
the leadscrew via nut 4 axially
movablebutlockedagainsttwist-
ing. This flank contact, particu-
larlyat thepositioning orbraking
phase, is not discontinued.
Depending upon the operating
conditions, the acme thread
leadscrew should, as applicable
to the backgauge guide assem-
bly, be cleand with white spirit
and be greased according to the
specified lubrication cycle once
peryear.
Referto"Lubrication"intheOper-
ating Instructions manu-al, or to
the lubrication chart on the back
of the machine.
Fig.26
Machine Sizes 168 (Fig. 25)
Backgauge 1 is guided by a car-
riage2which,runonrollers,moves
along a profile guideway beam3
fitted over the cutting table.
If you find any play on the back-
gaugechecksettingscrews4on
the side of the backgauge for
tightnessandproperlocking.Re-
tighten, if required. Refer to
"Adjusting Square Cutting"in the
OperatingInstructionsmanual.
Around the horizontal axis, the
carriage is supported by three
fixedrollers5and one eccentric-
ally adjustable roller above the
guideway beam and by four ec-
centrically adjustable rollers 6
beneath.
Around the vertical axis, the
carriage is secured against dis-
tortionbytwofixedrollers5onthe
right and two eccentrically
adjustable rollers6 on the left.
Ifsome play should occur aftera
longer period of operation, you
can use the eccentric rollers to
eliminate it.
For this purpose, slacken outer
nut7and gently rotate eccentric
pin 8 until the roller gets into
contact with the guideway. Re-
tighten the nut.
3
4
1 2 6
5
7
6
8
Fig. 25
