Dover Triton FT5000 Operating instructions

CORPORATE HEADQUARTERS: RMA(RETURN MATERIAL AUTHORIZATION)
RETURNADDRESS:
522 E. Railroad Street 21405Avenue “B”
Long Beach, MS 39560 Long Beach, MS 39560
PHONE: [phone]
FAX: [phone]
MODEL FT5000
AUTOMATED TELLER MACHINE
SITE PREPARATION AND
INSTALLATION GUIDE
VERSION 4.0
TDN 07100-00004D 02/2006
COPYRIGHTNOTICE
© 2003 - 2006 Delaware Capital Formation, Inc. All Rights Reserved. TRITON,
TRITON WHERE MONEY COMES FROM, TRITON WAVES, DOVER and DO-
VERlogo areregistered trademarksof DelawareCapital Formation,Inc., awholly-owned
subsidiary of Dover Corporation.

2
FEDERALCOMMUNICATIONSCOMMISSION(FCC)COMPLIANCE
Statement of Compliance: This equipment complies with Part 68 of the FCC rules.
Located in the control area of theAutomated Teller Machine (ATM) is the product
label. Thislabel liststheFCC registrationnumberandringer equivalencenumberof
the unit. If requested, this information must be provided to the telephone company.
USCO/FIC Codes: When ordering service from the telephone company for the
FT5000ATM,thefollowinginformation should be supplied:
UniversalServiceOrderCode(USOC): RJ-11C
TheFacilityInterfaceCode(FIC): 02LS2
Plug and Jack: The plug and jack used to connect this equipment to premise wiring
and telephone network must comply with the applicable FCC Part 68 rules and
requirements adopted byACTA. Acompliant telephone cord and modular plug is
provided with this product. The telephone cord is designed to be connected to a
compatiblemodularjack that isalsocompliant.
RingerEquivalent Number(REN): TheREN isusedto determinethenumberof the
devices that may be connected to a telephone line. Excessive RENs on a telephone
linemay resultinthe devicesnotringing inresponseto anincomingcall. In mostbut
not all areas, the sum of the RENs should not exceed five (5). To be certain of the
number devices that may be connected to a line, as determined by the local RENs,
contact the local telephone company.
Harmto theNetwork: IftheFT5000ATMcausesharmtothe telephonenetwork,the
telephone company will notify the customer that a temporary discontinuous of
servicemayberequired. Ifadvancednotice is not possible, the telephone company
willnotifythe customer assoonaspossible. Youwill be advisedofyourright to file
a complaint with the FCC if you believe it’s necessary.
NotificationofChangesinTelephoneCompany Equipment: Thetelephonecompany
may make changes in its facilities, equipment, operations, or procedures that could
affect the operation of the equipment. If this happens, the telephone company will
provideadvancednoticeinorderforyoutomakenecessarymodificationstomaintain
uninterrupted service.
FT5000-SITE PREPARATION AND INSTALLATION GUIDE
** CAUTION **
Changesormodifications not expresslyapprovedbyTriton
Systems could void the regulatory compliance approval
and the warranty. Use of this product in a manner other
thanthose described in thismanual may resultinpersonal
injury!

3
Ifthe equipmentiscausing harmtothe network,thetelephonecompanymay request
that you disconnect the equipment until the problem is resolved. Repairs should be
made only by qualified factory representatives.
Party Lines: The FT5000ATM must not be used on party lines.
AlarmEquipment: The FT5000ATM shouldhaveits owndedicatedphoneline. Do
notinstall the FT5000 on the same line as alarmequipment.
ElectricalSafetyAdvisory: telephonecompaniesreportthatelectricalsurges,typically
lightening transients, are very destructive to customer equipment connected toAC
power sources. This has been identified as a major nationwide problem. A
commercially available, power surge suppressor, is recommended for use with the
FT5000to minimize damageinthe event ofanelectrical surge.
CANADIANICCOMPLIANCE
NOTICE:
The Industry Canada label identifies certified equipment. This certification means
that the equipment meets telecommunications network protective, operational and
safety requirements as prescribed in the appropriate terminal equipment technical
requirements document(s). The department does not guarantee the equipment will
operate to the user’s satisfaction.
Before installing this equipment, users should ensure that it is permissible to be
connected to the facilities of the local telecommunications company. The equip-
ment must also be installed using an acceptable method of connection. The cus-
tomer should be aware that compliance with the above conditions may not prevent
degradation of service in some situations.
Repairs to certified equipment should be coordinated by a representative desig-
natedbythe supplier. Any repairs or alterationsmadebythe user to thisequipment,
or equipment malfunctions, may give the telecommunications company cause to
request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections
ofthepowerutility,telephonelines,andinternalmetallicwater pipesystem,ifpresent,
areconnected together. Thisprecautionmay be particularlyimportantin ruralareas.
Caution:Usersshould notattempttomake suchconnectionsthemselves,but should
contact the appropriate electric inspection authority, or electrician, as appropriate.
FT5000-SITE PREPARATION AND INSTALLATION GUIDE
RepairsandReturns: Iftelecomcompatibilitytroubleisexperiencedwiththe FT5000
ATM, you may contact for repairs and warranty information: Triton at 1-228-868-
1317
TritonSystemsof Delaware, Inc.
522East RailroadStreet
LongBeach,MS39560

4
NOTICE:
The REN assigned to each terminal device provides an indication of the maximum
numberofterminals allowed tobeconnectedto a telephoneinterface. Thetermina-
tion on an interface may consist of any combination of devices subject only to the
requirement that the sum of the RENs of all the devices does not exceed 5.
AVIS:
L’étiquetted’IndustrieCanadaidentificlematérielhomologué. Cetteétiquettecertifie
quelematérielestconformeauxnormes de protection, d’exploitation et de sécurité
desréseaux detélécommunications,commeleprescrivent lesdocumentsconcernant
lesexigencestechniquesrelativesaumatérielterminal. LeMinistèren’assuretoutefois
pas que le matériel fonctionnera à la satisfaction de l’utilisateur.
Avantd’installercematériel,l’utilisateurdoits’assurer qu’ilest permisdeleraccorder
aux installations de 1’entreprise locale de télécommunication. Le maté-riel doit
égalementêtre installé ensuivantune méthode acceptéederaccordement. L’abonné
ne doit pas oublier qu’il est possible que la comformité aux conditions énoncées ci-
dessus n’empêche pas la dégradation du service dans certaines situations.
Lesréparations dematérielhomologué doiventêtrecoordonnées parunreprésentant
désigné par le fournisseur. L’entreprise de télécommunications peut demander à
I’utilisateur de débrancher un appareil à la suite de réparations ou de modifications
effectuées par l’utilisateur ou à cause de mauvais fonctionnement.
Pour sa propre protection, l’utilisateur doit s’assurer que tous les fils de mise à la
terredelasourced’énergieélectrique, des lignes téléphoniques et des canalisations
d’eau métalliques, s’fl y en a, sont raccordés ensemble. Cette précaution est
particulièrementimportante dans lesrégionsrurales. Avertissement: L’utilisateurne
doitpas tenter defaireces raccordementslui-même;il doit avoirrecoursà anservice
d’inspection des installations électriques, ou à un électricien, selon le cas.
FT5000-SITE PREPARATION AND INSTALLATION GUIDE
UNITED KINGDOM
Thisequipment has beenapprovedin accordancewithCouncilDecision 98/482/EC
for pan-European single terminal connection to the Public Switched Telephone
Network(PSTN). However, due to differencesbetweentheindividualPSTNspro-
vided in the different countries, the approval does not, of itself, give unconditional
assuranceofsuccessful operation oneveryPSTNnetwork termination point. Inthe
event of problems, contact your equipment supplier in the first instance. This unit
uses only Dual-Tone Multi-Frequency (DTMF) address signaling.

5
EMISSIONS (EMI)
This device complies with Part 15 of the FCC rules. Operation is subject to the
followingtwo(2) conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that
may cause undesired operation.
Note:
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operationofthisequipmentinaresidentialareaislikelyto causeharmful interference
inwhich case theuserwill berequiredtocorrect theinterferenceat hisownexpense.
Changesor modificationstothisunitnot expresslyapprovedbytheparty responsible
for compliance could void the user’s authority to operate the equipment.
CANADIANEMISSIONREQUIREMENTS
This digital apparatus does not exceed the ClassAlimits for radio noise emissions
from digital apparatus set in the Radio Interference Regulations of the Canadian
Department of Communications. This Class A digital apparatus complies with
CanadianICES-003.
Le present appareil numerique n’emet pas de bruits radioelectriques depassant les
limitesapplicablesauxappareilsnumeriquesdelaClassAprescritesdansleReglement
sur le brouillage radioelectrique edicte par le ministere des Communications du
Canada. Cet appareil numerique de la classeAest conforme a la norme NMB-003
Canada.
UK/AUSTRALIANEMISSIONREQUIREMENTS
Warning:
This is a ClassAproduct. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
FT5000-SITE PREPARATION AND INSTALLATION GUIDE
AVIS:
L’indice d’équivalence de la sonnerie (IES) assigné à chaque dispositif terminal
indiquele nombre maximaldeterminaux qui peuventétreraccordés à uneinterface.
La terminaison d’une interface téléphonique peut consister en une combinaison de
quelques dispositifs, à la seule condition que la somme d’indices d’équivalence de
la sonnerie de tous les dispositifs n’exède pas 5.

6
FT5000-SITE PREPARATION AND INSTALLATION GUIDE
What’sinThisInstallationGuide
This Installation Guide provides information for the preparation and installation of
theFT5000ATM. Itcontains requirementsforsitepreparation, electricalspecifica-
tions, and cabinet accessibility that comply with all relevant codes, laws and regu-
lations. The Installation Guide is divided into the following sections:
Introduction. Summarizesthebasicstepsthatmustbecompletedtophysically
installaFT5000ATM. Configurationofoperatingparametersisnot covered!
Refer to the applicable Configuration and/or Service Manual for instructions
on configuring the operating parameters.
ATM Installation for Accessibility. Describes the basic Americans with
DisabilitiesAct(ADA) requirementsforATMlocationandaccess.Note:These
are the general requirements that should be applicable to most installation
locations. Please verify the specific requirements with the state where the
ATM is to be installed, prior to installation. For state contact information, you
maycalltheADAinformationlineat1-800-514-0301.
ATM Environmental Precautions Checklist. Describes the general
environmentalprecautions consideredwheninstalling theATM.To helpensure
proper operation of the ATM, ensure the environmental criteria listed in this
checklistare met.
Site Preparation/Installation. Describes site preparation for exterior wall or
vestibule locations. Instructions provide dimensions/clearances needed to
install the FT5000 and procedures for installing the cabinet and front fascia.
NEW-Optionalplatforms(“plinths”)availablein2sizesexpediateraising
theunit, ifneeded. [ P/N 06100-00071 (2-3/8") and P/N 06100-00072 (4-
3/4")]Also,cabinetsnowcomewiththeirownlevelingfeet.
PowerandCommunication.Describeshow toconnect theATMto thefacility
power and telephone connections.
Dispensing Mechanism Installation. Describes how to install/remove the
dispensing mechanism into the ATM security cabinet.
InstallingtheRearServicePanel(RSP). Describeshowtoinstall andconnect
the RSP to the cabinet sleeve.
TCP/IP (Ethernet) CableInstallation. Describes whereto installthe
10Base-TCAT-5 cableforEthernet communication.
VSATCableInstallation. Describeswhereto installtheoptionalVSATcable.

7
FT5000-SITE PREPARATION AND INSTALLATION GUIDE
INTRODUCTION
This document contains the information necessary for the preparation and
installation of a FT5000 TritonATM. It’s important that the site complies with the
requirements specified in this document. In addition, electrical wiring and
mechanical systems must also comply with all relevant laws and regulations.
The site must be prepared by the customer or his agent who is fully conversant
with the requirements of installing through-the-wallATM equipment. The
responsibility for ensuring that the site is prepared in compliance with this
document remains with the customer.
For information and guidance only, a list is provided in general terms of those
matters for which the customer is responsible. The list is not intended to be
comprehensive and in no way modifies, alters, or limits the responsibility of the
customer for all aspects of adequate site preparation.
1. Location of the equipment and site preparation.
2. Sitewiring(power,communication).
3. Location of otherequipmentthat may causeelectrical,electromagnetic, or
heat induced interference.
4. Make building alterations to meet wiring and other site requirements.
5. Install all communication cables, wall jacks, andassociatedhardware.
6. Provide and install necessary power distribution boxes, conduits and
grounds.
7. Ensureallapplicablecodes,regulationsandlaws(electrical,building,safety)
are adhered to.
8. Ensure the environmental requirements of this unit are met.
9. Install the unit at a height which meets theADAaccessibility regulations
for the state/country installed.

THIS PAGE INTENTIONALLY LEFT BLANK
8
FT5000-SITE PREPARATION AND INSTALLATION GUIDE

9
ATM INSTALLATION FOR ACCESSIBILITY

AGuide tothe NewADA-ABAAccessibility Guidelines
FT5000-SITE PREPARATION AND INSTALLATION GUIDE
On July 23, 2004, the U.S. Access Board, an independent Federal agency,
issued updated accessibility guidelines for new or altered facilities covered by
Americans with Disabilities Act and the Architectural Barriers Act. These
guidelines address a wide range of facilities in the private and public sectors.
Presented here is an overview of the new guidelines that also highlights sig-
nificant changes.The following guidelines (305 and 308) pertain to floor/
ground space and reach ranges.
Whenwill the newguidelines take effect?
The Board’s guidelines are not mandatory on the public, but instead serve as
the baseline for enforceable standards (which are) maintained by other Federal
agencies. In this respect, they are similar to a model building code in that they
are not required to be followed except as adopted by an enforcing authority.
Under theADA, the Department of Justice (and in the case of transit facilities,
the Department of Transportation) are responsible for enforceable standards
based on the Board’s guidelines. These agencies will update their ADA stan-
dards based on the new guidelines. In doing so, they will indicate when the new
standards are to be followed. Several other agencies (the General ServicesAd-
ministration, Department of Defense, Department of Housing and Urban Devel-
opment, and the U.S. Postal Service) hold a similar responsibility for standards
used to enforce the ABA.
ExistingFacilities
TheADA and ABAguidelines cover new construction and planned alterations
and generally do not apply to existing facilities except where altered. Facilities
built or altered according to earlier versions of theADA orABAstandards will
not necessarily have to meet the updated version except where they are subse-
quently altered or renovated. The Department of Justice, which regulates re-
quirements for existing facilities under theADA, intends to address coverage of
facilitiesbuiltor altered according to the originalADAstandards in its rulemaking
to update the standards. It will also address facilities retrofitted under ADA
provisions for existing facilities, such as the requirement for barrier removal in
places of public accommodation. With respect toABAfacilities, the Board has
clarified in the guidelines that facilities built to earlierABAstandards are subject
to the new requirements only in relation to planned alterations.
10

ATMINSTALLATION FOR ACCESSIBILITY
305 ClearFloororGroundSpace
305.1 General.Clearfloor orgroundspaceshall complywith305.
305.2 FloororGroundSurfaces.Floororgroundsurfaces of aclearfloor or
ground space shall comply with 302. Changes in level are not permitted.
EXCEPTION:Slopes notsteeperthan1:48shall bepermitted.
305.3 Size.Theclear floor or groundspaceshallbe 30 inches(760mm)mini-
mumby48inches(1220mm)minimum.
305.4 KneeandToeClearance. Unless otherwisespecified,clear flooror
ground space shall be permitted to include knee and toe clearance com-
plyingwith306.
305.5 Position. Unless otherwise specified, clear floor or ground space shall be
positioned for either forward or parallel approach to an element.
305.6 Approach. One full unobstructed side of the clear floor or ground space
shall adjoin an accessible route or adjoin another clear floor or ground
space.
Figure 305.3 Clear Floor or Ground Space
Figure 305.5 Position of Clear Floor or Ground Space
11

FT5000-SITE PREPARATION AND INSTALLATION GUIDE
305.7 ManeuveringClearance.Wherea clear floor or ground space is located
in an alcove or otherwise confined on all or part of three sides, additional
maneuvering clearance shall be provided in accordance with 305.7.1 and
305.7.2.
305.7.1 ForwardApproach.Alcovesshallbe36inches(915mm)widemini
mumwhere thedepthexceeds 24inches(610 mm).
Figure 305.7.1 Maneuvering Clearance in an Alcove, Forward Approach
305.7.2 ParallelApproach.Alcovesshall be60 inches(1525mm)widemini-
mumwhere thedepthexceeds 15inches(380 mm).
Figure 305.7.2 Maneuvering Clearance in an Alcove, Parallel Approach
308ReachRanges
308.1 General.Reach rangesshallcomply with308.
308.2 ForwardReach.
308.2.1 Unobstructed.Where a forward reachisunobstructed,the high forward
reachshall be48inches(1220mm) maximumandthelowforward reach
shallbe 15 inches(380mm) minimum abovethefinish floororground.
12

ATMINSTALLATION FOR ACCESSIBILITY
Figure 308.2.1 Unobstructed Forward Reach
308.2.2 ObstructedHighReach. Where a high forward reach is overanobstruc-
tion, the clear floor space shall extend beneath the element for a distance
not less than the required reach depth over the obstruction. The high for-
wardreach shallbe48 inches(1220mm) maximumwherethe reachdepth
is20 inches(510mm)maximum.Wherethereach depthexceeds20inches
(510mm),thehighforwardreachshallbe44inches(1120 mm)maxi-
mumand thereachdepthshallbe 25inches (635mm)maximum.
Figure 308.2.2 Obstructed High Forward Reach
308.3 SideReach.
308.3.1 Unobstructed.Where a clearflooror ground spaceallowsaparallel ap-
proach to an element and the side reach is unobstructed, the high side
reachshall be48inches (1220mm)maximum andthelow sidereach
shallbe 15 inches(380mm) minimum abovethefinish floororground.
EXCEPTIONS: 1. An obstruction shall be permitted between the clear floor or
ground space and the element where the depth of the obstruction is 10 inches (255
mm)maximum.
2. Operable parts of fuel dispensers shall be permitted to be 54 inches (1370 mm)
maximummeasured fromthesurface ofthevehicularwaywherefueldispensers are
installed on existing curbs.
13

14
FT5000-SITE PREPARATION AND INSTALLATION GUIDE
Figure 308.3.1 Unobstructed Side Reach
308.3.2 ObstructedHighReach.Where aclearflooror ground spaceallowsa
parallel approach to an element and the high side reach is over an obstruc-
tion,theheight oftheobstructionshall be34inches(865 mm) maximum
andthedepth of theobstructionshallbe 24 inches (610mm)maximum.
Thehigh sidereachshall be48inches (1220mm)maximum forareach
depthof 10 inches(255mm) maximum.Wherethereach depthexceeds
10inches (255mm),thehigh sidereachshall be46inches (1170mm)
maximumforareachdepthof24inches(610mm)maximum.
EXCEPTIONS:1. Thetopof washingmachinesand clothesdryersshall bepermit-
tedto be36inches (915mm)maximumabovethe finishfloor.
2. Operable parts of fuel dispensers shall be permitted to be 54 inches (1370 mm)
maximummeasured from thesurfaceof the vehicularwaywhere fuel dispensersare
installed on existing curbs.
Figure 308.3.2 Obstructed High Side Reach

15
ATMINSTALLATION FOR
ACCESSIBILITY
1. Thisdocumentsupersedesall other
informationprovided byTritonfor
ATM installation for accessibility.
2. Information provided in this
manual is based on federal guide-
lines(ADAAccessibilityGuidelines
for Buildings and Facilities –
ADAAG)as amended through
January1998.Youshould verifyit
has not been amended. States may
also have accessibility codes.
These codes may be more restric-
tive than the federal guidelines.
Please verify this with the state
where the ATM is to be installed
prior to installation. For state con-
tact information, you may call the
ADAinformationline.
3. For countries other than the US,
please use the guidelines for ac-
cessibility for that country.
4. A complete copy of the ADAAG
referred to here can be found at
http://www.access-board.gov. In-
cluded in this document is the sec-
tionoftheADAAGspecificallyfor
ATMs. For additional information
on floor surfaces and other
ADAAG requirements, please see
the complete specification.
4.34 AutomatedTellerMachines.
4.34.1 General. Each machine re-
quired to be accessible by 4.1.3
shall be on an accessible route and
shallcomply with4.3.4.
4.34.2 ClearFloorSpace.Theauto-
mated teller machine shall be lo-
catedso thatclearfloor spacecom-
plyingwith4.2.4 is provided to al-
lowapersonusing a wheelchair to
makeaforwardapproach,aparallel
approach, or both to the machine.
4.34.3 ReachRanges.
(1) ForwardApproachOnly.Ifonlya
forward approach is possible, operable
partsofallcontrolsshallbeplacedwithin
the forward reach range specified in
4.2.5.
(2) ParallelApproachOnly.Ifonlya
parallel approach is possible, operable
parts of controls shall be placed as fol-
lows:
(a) Reach Depth NotMoreThan 10
inches (255 mm). Where the reach
depth to the operable parts of all con-
trolsasmeasuredfromtheverticalplane
perpendicular to the edge of the unob-
structed clear floor space at the farthest
protrusion of the automated teller ma-
chine or surround is not more than 10
inches (255 mm), the maximum height
above the finished floor or grade shall
be54inches(1370mm).
ATMINSTALLATION FOR ACCESSIBILITY

16
FT5000-SITE PREPARATION AND INSTALLATION GUIDE
(b) ReachDepthMoreThan10inches
(255 mm). Where the reach depth to
theoperablepartsofanycontrol asmea-
sured from the vertical plane perpen-
dicular to the edge of the unobstructed
clear floor space at the farthest protru-
sion of the automated teller machine or
surround is more than 10 inches (255
mm),themaximumheightabovethefin-
ishedfloor or grade shall be as follows:
(3) ForwardandParallelApproach.If
both a forward and parallel approach
are possible, operable parts of controls
shallbeplaced withinatleastone ofthe
reach ranges in paragraphs (1) or (2) of
this section.
SNOITACIFICEPSYTILIBISSECCA
HTPEDHCAERTHGIEHMUMIXAM
sehcnI sretemilliM sehcnI sretemilliM
01552450731
110822/1350631
21503355431
310332/1255331
415532/1150131
51083155921
615042/1055821
71034050721
815542/1945521
9158
4945421
020152/1840321
125352/1745021
22065745911
325852/1640811
42016640711
EXCEPTION:Whereafunctioncanbe
performed in a substantially equivalent
manner by using an alternate control,
only one of the controls needed to per-
formthat functionisrequired tocomply
withthissection.Ifthecontrolsareiden-
tifiedbytactilemarkings,suchmarkings
shall be provided on both controls.
4.34.4 Controls. Controls for user
activationshall complywith4.27.4.
4.34.5 EquipmentforPersonswith
Vision Impairments. Instructions and
allinformation foruseshallbemade ac-
cessible to and independently usable
by persons with vision impairments.
(20) Where automated teller ma-
chines(ATMs)areprovided,eachATM
shall comply with the requirements of
4.34exceptwhere two or morearepro-
vided at a location, then only one must
comply.
EXCEPTION:Drive-up-onlyautomated
tellermachines arenotrequired tocom-
plywith4.27.2,4.27.3and4.34.3.
4.2.4* ClearFloororGround
SpaceforWheelchairs.
4.2.4.1 SizeandApproach.Themini-
mum clear floor or ground space re-
quired to accommodate a single, sta-
tionary wheelchair and occupant is 30
inches by 48 inches (760 mm by 1220
mm) (see Fig. 4a). The minimum clear
floor or ground space for wheelchairs
maybepositioned for forwardorparal-
lel approach to an object (see Fig. 4b
and4c).Clear floor or groundspacefor
wheelchairs may be part of the knee
space required under some objects.
(4) Bins. Where bins are provided for
envelopes, waste paper, or other pur-
poses, at least one of each type pro-
vided shall comply with the applicable
reachranges inparagraph(1), (2),or(3)
of this section.

17
4.2.4.2 RelationshipofManeuvering
ClearancetoWheelchairSpaces.One
full unobstructed side of the clear floor
or ground space for a wheelchair shall
adjoin or overlap an accessible route or
adjoin another wheelchair clear floor
space.Ifa clear floorspaceislocated in
an alcove or otherwise confined on all
orpart of threesides,additional maneu-
vering clearances shall be provided as
showninFig.4(d) and 4(e).
4.2.4.3 Surfaces for Wheelchair
Spaces. Clear floor or ground spaces
forwheelchairs shall complywith4.5.
4.2.5* Forward Reach. If the clear
floor space only allows forward ap-
proach to an object, the maximum high
forwardreachallowedshallbe48inches
(1220mm)(seeFig.5(a)).Theminimum
lowforwardreachis15inches(380mm).
If the high forward reach is over an ob-
struction, reach and clearances shall be
as shown in Fig. 5(b).
4.2.6* Side Reach. If the clear floor
spaceallows parallelapproachby aper-
sonina wheelchair,the maximumhigh
side reach allowed shall be 54 inches
(1370mm)andthelowsidereachshall
benolessthan9inches(230mm)above
thefloor (Fig. 6(a) and 6(b)). If the side
reach is over an obstruction, the reach
and clearances shall be as shown in Fig
6(c).
Figure 4a. Clear floor space.
Figure 4b. Forward approach.
Figure 4c. Parallel approach.
ATMINSTALLATION FOR ACCESSIBILITY

18
FT5000-SITE PREPARATION AND INSTALLATION GUIDE
For a front approach, where the depth
of the alcove is equal to or less than 24
inches(610mm),therequiredclearfloor
spaceis30inchesby48inches (760mm
by1220mm).
Forasideapproach, where the depth of
the alcove is equal to or less than 15
inches(380mm),therequiredclearfloor
spaceis30inchesby48inches (760mm
by1220mm).
Figures 4d. Clear Floor Space in
Alcoves.
For a front approach, if the depth of the
alcoveisgreaterthan24inches(610mm),
theninadditiontothe30-inch(760mm)
width, a maneuvering clearance of 6
inches(150 mm)inwidth isrequired.
Forasideapproach, where the depth of
thealcove isgreaterthan 15inches(380
mm),theninadditiontothe48-inch(1220
mm)length, anadditionalmaneuvering
clearance of 12 inches (350 mm) is
required.
Figures 4e. Clear Floor Space in
Alcove.

19
Figure 6a. Parallel approach - side
reach. Figure 6b. Parallel approach - high/
low side reach.
Figure 5a. Forward reach, unobstructed.
Figure 5b. Forward reach, obstructed.
ATM INSTALLATION FOR ACCESSIBILITY

20
Figure 6c. Side reach, obstructed.
Figure 7. ADA access dimensions for through-
the-wall ATM.
Groundexterior
FloorInterior
RearServicePanel
aerAsseccApacidnaHedistuO
"84 )mm9121( -ssorcA- "03 )mm267( -peeD-
*
derusaeM foretnecmorf lenaPlortnoC *aicsaF
FT5000-SITE PREPARATION AND INSTALLATION GUIDE
