Dräger RVP 2400 User manual

System Center Lübeck
Dräger RVP
Communication

2 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Dräger RVP - Communication
Content
Introduction
Network Cable
RVP 2400
RVP 3900
RVP 5000
Remote Communication

3 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
There are 3 different variants of the
RVP available.
Every variant has a different way of
communication to its connected
controller.
We will show the different types of
communication for the RVP 2400,
RVP 3900 and RVP 5000.
Dräger RVP - Communication
Introduction

4 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
There are 5 different norms of network cable in the world.
As shown in the table below each type uses different colours. The cable type in the manuals of
the RVP's and this presentation refer to the EIA/TIA 568B norm.
Dräger RVP - Communication
Network Cable
Cable pair
Pin
EIA/TIA 568A
EIA/TIA 568B
IEC
REA
DIN 47.100
1 4/5 blue/white blue/white blue/white white/blue white/brown
2
3/6
white/orange
white/green
red/orange
turquoise/violet
green/yellow
3
1/2
white/green
white/orange
black/grey
white/orange
grey/pink
4
7/8
white/brown
white/brown
yellow/brown
turquoise/violet
blue/red

5 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
The RVP 2400 can be connected to up of 5
Regard 24xx / RailGard-XX Controller to
visualize the data.
A configuration on the RVP 2400 is not
necessary. The addressing will be done via
the Regard 24x0 configuration software.
Dräger RVP - Communication
RVP 2400

6 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Each controller has to get its own
address. The addressing starts from 1
up to 5, regarding the quantity of
connected controller.
Baud rate, Bits, Parity and Stop bit
must not be changed. The default
settings are 19200/8N1.
The controller will be visible on the
RVP 2400 with the same numbers
addressed in the configuration
software.
Dräger RVP - Communication
RVP 2400

7 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Communication
The Regard 24xx / RailGard-XX controller will be connected to the internal or external converter
(SC00041 / SC00042). The converter transforms the incoming signals of the controller from RS232
to RS485. The RVP 2400 gets the data from the RS485 interface and make them visible on the
screen.
35
1 17
18
RS232
Power Reset
Channel A B C D E F
Concentration
F1 F2
x10 ErrorHu
A1
A2
RailGard-S6
A3
A4
A B C
DE F
35
1 17
18
RS232
Power Reset
Channel A B C D E F
Concentration
F1 F2
x10 ErrorHu
A1
A2
RailGard-S6
A3
A4
A B C
DE F
Dräger RVP - Communication
RVP 2400

8 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Connection of the converter
colour of cable orange/white: RJ45 jack PIN 1 (TxB) →Converter connector A
colour of cable orange: RJ45 jack PIN 2 (TxA) →Converter connector B
colour of cable green: RJ45 jack PIN 6 →Converter connector COM
Dräger RVP - Communication
RVP 2400

9 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
The RVP 3900 is able to display data of up to 8 Regard 3900/3910 controller.
RS-485 max 1,2 Km
Dräger RVP - Communication
RVP 3900

10 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Example: RVP 3900, connected to 2 Regard 3910 systems
CAN Bus intern
RS 485 / Modbus
System 1
System 2
Dräger RVP - Communication
RVP 3900

11 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Internal the Regard 39x0 system
communicates via the CAN Bus
protocol.
To make it possible to visualize these
data on the RVP 3900 they first have
to be transformed to the Modbus RTU
protocol.
This will be done by the Regard 3900
Modbus Gateway (SC00083).
Each Regard 3900 that should be
connected to a RVP 3900 needs this
gateway.
(5x Regard 39X0 = 5x Gateway)
In every delivery there's a software and
a Nullmodem cable for the
configuration (addressing).
Dräger RVP - Communication
RVP 3900

12 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Regard 3900 Modbus Gateway
Overview Connectors:
Dräger RVP - Communication
RVP 3900

13 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Dräger Regard 3900
display board
Connection Regard 3900 Modbus
Gateway cable to Regard 3900 display
board (Connector for Regard 3900
Configuration Cable)
Regard 3900 Modbus
Gateway cable
( C00084)
Connector for
Regard 3900
configuration cable
(4208785)
Connection:
Cable Gateway
PIN 2 → High
PIN 4 → Low
Regard 3900
Modbus Gateway
( C00083)
Communication Regard 3900
Regard 3900 Modbus Gateway
Dräger RVP - Communication
RVP 3900

14 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Connection Regard 3910 Modbus
Gateway cable to Regard 3910
internal system bus cable
Regard 3910 Modbus
Gateway cable
( C00085)
Connector for
Regard 3900
configuration cable
(4208785)
Connection:
Cable Gateway
PIN 2 → Low
PIN 3 → High
Regard 3900
Modbus Gateway
( C00083)
Regard 3900/3910 ribbon cable
Communication Regard 3910
Regard 3900 Modbus Gateway
Dräger RVP - Communication
RVP 3900

15 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Communication Regard 3900 Modbus Gateway
RVP 3900
orange/white: RJ45 jack PIN 1 (TxB) →Gateway RS485 "+"
orange: RJ45 jack PIN 2 (TxA) →Gateway RS485 "-"
CAN R 485
Dräger RVP - Communication
RVP 3900

16 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Addressing the Regard 3900 Modbus Gateway:
Every gateway has to be addressed before it
can be used. Procedure:
Set 'Boot' Jumper from Pos. 2 to Pos. 3
(without power supply).
Connect to power supply (yellow LED will blink
fast).
Connect Nullmodem cable.
Start Configuration program, choose Address-
file from the directory.
Download file to the gateway
After finishing disconnect the gateway from
the power supply and set back the 'Boot'
Jumper.
Reconnect the unit to the power supply.
Dräger RVP - Communication
RVP 3900

17 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Das RVP 5000 get's the required data from
the Modbus Gateway Card.
In the standard application the RVP 5000 is
able to visualize up to 99 channel from only
1 Regard system.
As the Regard system only transfers status
messages and values and not any data of
the system configuration the RVP 5000
needs a configuration file.
Dräger RVP - Communication
RVP 5000

18 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Creating the configuration file via the
REGARD Configuration software:
Login into Service Level
load/create a system configuration
click button "Export to CSV"
choose file name (max. 8 digits) and
save csv file
Copy file onto the CF card of the
RVP 5000(via card reader or USB
connection to unit)
Dräger RVP - Communication
RVP 5000

19 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Loading the configuration file on the
RVP 5000:
Login as administrator in the menu
"Settings".
Touch the button "Import
Configuration".
Touch the field below "File Name"
and type in the file name with
extension ".csv".
Touch the button "Import-Conf".
Wait 300 Seconds until the file is
saved in the system.
Dräger RVP - Communication
RVP 5000

20 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Command No. Command Name Function Default Settings
Settings
Modbus Card
Software version V 1.9
00-0 QUIT Leave command mode
00-1 P.WD Enter password CCCC
00-2 SAVE Save settings
00-3
PCHG
Change password
CCCC
14-0 TLED Test display and LED's
14-6 TSLV Test REGARD-communication
14-7
TBUS
Test Modbus-communication
52-1 GATE Set Modbus slave number 1 1
52-2 BAD2 Function 02 disable exceptions YES NO
52-3 BAD4 Function 04 disable exceptions YES NO
52-4 BAUD Set baudrate 4800 9600
52-5 PRTY Set pirarity NONE NONE
52-6 CKSM REGARD communication check sum CRC CRC
52-7
FRMT
Set gas concentration format
SIGN
SIGN
60-1 DISP Switch displayon/off OFF ON
SW2: Set switch on REGARD Modbuscard to RS422/485
52-1: For more connected Systems the address has to be countedup
(2 forSystem 2, 3 for….)
Configuration Menu of the Modbus Gateway Card:
Settings to be changed:
Dräger RVP - Communication
RVP 5000
