Draeger Infinity Acute Care System User manual

Instructions for use
Infinity Acute Care System
Monitoring accessories
Software VG6.n
WARNING
To properly use accessories, read
and comply with all relevant instruc-
tions for use.

2 Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n
Working with these instructions for use
The title of the main chapter
in the header line helps with orientation and
navigation.
The descriptions for the user
combine text and illustrations to provide a visual
and textual overview of the corresponding
accessories, along with their corresponding part
numbers, where appropriate.
Typographical conventions
1Consecutive numbers indicate steps of action,
with the numbering restarting with "1" for each
new sequence of actions.
Bullet points indicate individual actions or differ-
ent options for action.
– Dashes indicate the listing of data, options, or
objects.
(A) Letters in parentheses refer to elements in the
related illustration.
ALetters in illustrations denote elements referred
to in the text.

Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n 3
General notes for IACS
Except for asystole and ventricular fibrillation
events, no other arrhythmia events appear in the
trends of any ICS equipped with software version
VG1.
The Cockpit supports IT applications using a Citrix
client XenApp server (ICA client version 12.3.0.8).
(IT applications chapter)
All devices and accessories referenced in these in-
structions for use may not be approved for sale in
all countries. Please check with your local Dräger
representative.
Trademarks
– Infinity®
– Acute Care SystemTM
– Hemo4®
– Hemo2®
–MPod
®
–MCable
TM
– MonoLead®
are trademarks of Dräger.
– rainbow®
–Masimo
®
–Masimo
®SET®(Signal Extraction Technology)
are registered trademarks of Masimo Corporation.
– NellcorTM
– OxiMaxTM
– DurasensorTM
are trademarks of Covidien.
– Capnoline®
–Microstream
®
are registered trademarks of Oridion Medical 1987
Ltd.
NOTE
Use a FAT32 memory stick for importing or ex-
porting profiles. USB sticks with NTFS format do
not produce reliable results. (System configura-
tion chapter)

4 Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n
Definitions
WARNING
A WARNING statement provides important in-
formation about a potentially hazardous situa-
tion which, if not avoided, could result in
death or serious injury.
CAUTION
A CAUTION statement provides important infor-
mation about a potentially hazardous situation
which, if not avoided, may result in minor or mod-
erate injury to the user or patient or in damage to
the equipment or other property.
NOTE
A NOTE provides additional information intended
to avoid inconveniences during operation.

Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n 5
Contents
Contents
Working with these instructions for use . . . . . . 2
Typographical conventions . . . . . . . . . . . . . . . . 2
General notes for IACS . . . . . . . . . . . . . . . . . . 3
For your safety and that of your patients. . . 7
List of accessories . . . . . . . . . . . . . . . . . . . . . 11
Infinity Acute Care System accessories
overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
General IACS accessories . . . . . . . . . . . . . . . . 17
IACS / M540 options. . . . . . . . . . . . . . . . . . . . . 19
ECG monitoring – reusable leadsets . . . . . . . . 20
ECG monitoring – single-patient use leadsets . 22
ECG monitoring – MonoLead. . . . . . . . . . . . . . 24
ECG monitoring – neonatal . . . . . . . . . . . . . . . 26
Invasive blood pressure (IBP) with Hemo2
Pod or Hemo4 pod . . . . . . . . . . . . . . . . . . . . . . 27
IBP Monitoring with MPod – QuadHemo or
MCable – Dual Hemo . . . . . . . . . . . . . . . . . . . . 28
Non-Invasive blood pressure (NIBP)
monitoring – Dräger connectors . . . . . . . . . . . . 29
Non-invasive blood pressure (NIBP)
monitoring – neonatal . . . . . . . . . . . . . . . . . . . . 31
SpO2 monitoring – Masimo rainbow SET
(rainbow sensors) . . . . . . . . . . . . . . . . . . . . . . . 32
SpO2 monitoring – Masimo rainbow SET (M-
LNCS). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
SpO2 monitoring – Masimo rainbow SET
(LNCS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
SpO2 monitoring – Masimo SET (LNCS) . . . . . 39
SpO2 monitoring – Masimo SET (M–LNCS) . . 41
Masimo SpO2accessories . . . . . . . . . . . . . . . . 43
SpO2 monitoring – Nellcor OxiMax . . . . . . . . . 44
Cardiac (C.O.) output monitoring . . . . . . . . . . . 46
CO2monitoring - Mainstream. . . . . . . . . . . . . . 47
CO2monitoring - Microstream . . . . . . . . . . . . . 48
Temperature monitoring . . . . . . . . . . . . . . . . . . 50
MCable – Analog/Sync . . . . . . . . . . . . . . . . . . . 53
Scio monitoring. . . . . . . . . . . . . . . . . . . . . . . . . 54

6 Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n
This page intentionally left blank.

Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n 7
For your safety and that of your patients
For your safety and that of your patients
Strictly follow these instructions for use . . . . . . 8
General precaution. . . . . . . . . . . . . . . . . . . . . . 8
Training. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Sterile accessories . . . . . . . . . . . . . . . . . . . . . . 8
Availability of accessories. . . . . . . . . . . . . . . . . 8
Connected devices. . . . . . . . . . . . . . . . . . . . . . 8
Installing accessories . . . . . . . . . . . . . . . . . . . . 9

8 Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n
For your safety and that of your patients
Strictly follow these instructions for use
General precaution
Training
Training for users is available via the Dräger orga-
nization responsible (see www.draeger.com).
Sterile accessories
Availability of accessories
Some articles are not available worldwide because
they are not approved in all countries.
Technical documentation is available on request.
Connected devices
WARNING
To maintain patient safety, adhere to all
WARNINGS and CAUTIONS on equipment la-
bels or appearing in the Instructions for use
for the Infinity Acute Care System (IACS) ap-
plications.
CAUTION
Read all cleaning instructions (for example, origi-
nating from the disinfectant manufacturer and the
hospital) carefully before cleaning the device. Re-
fer to the chapter entitled “Reprocessing” for de-
vice-specific cleaning instructions in the Infinity
Acute Care System M540 Instructions for use.
CAUTION
Even accessories designed to be reused have a
limited maximum period of use. Handling and re-
processing can increase wear and markedly
shorten maximum period of use (e.g., disinfectant
residues can attack the material more intensely
during autoclaving). If signs of wear become visi-
ble, such as cracks, deformation, discoloration,
peeling, etc., affected accessories must be re-
placed.
CAUTION
Risk of medical device failure and of patient injury.
Do not use sterile-packaged accessories if the
packaging has been opened, is damaged or if
there are other signs of non-sterility. Single-use
accessories must not be reused, reprocessed, or
resterilized.
WARNING
Risk due to incompatible accessories
Dräger has tested only the compatibility of ac-
cessories listed in the current list of accesso-
ries. If other, incompatible accessories are
used, there is a risk of patient injury due to
medical device failure.
Dräger recommends that the medical device is
only used together with accessories listed in
the current list of accessories.
WARNING
Risk of electric shock and of device malfunc-
tion
Any connected devices or device combina-
tions not complying with the requirements
mentioned in these instructions for use can
compromise the functional integrity of the
medical device and lead to an electric shock.
Before operating the medical device, strictly
comply with the instructions for use of all con-
nected devices or device combinations.

Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n 9
For your safety and that of your patients
Installing accessories
Strictly observe instructions for use.
CAUTION
Risk of device failure
Install accessories to the basic device in accor-
dance with the instructions for use of the basic de-
vice. Make sure that there is a safe connection to
the basic device.
CAUTION
Risk of incorrect use
The accessories are not available individually.
Only one copy of the instructions for use is includ-
ed in the bulk package and must therefore be kept
in a location accessible for users.

10 Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n
This page intentionally left blank.

Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n 11
List of accessories
List of accessories
Infinity Acute Care System accessories
overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
General IACS accessories. . . . . . . . . . . . . . . 17
System components. . . . . . . . . . . . . . . . . . . . . 17
Cables and mouse . . . . . . . . . . . . . . . . . . . . . . 17
Keyboards . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Device interface kits . . . . . . . . . . . . . . . . . . . . . 18
Long ceiling installation cables . . . . . . . . . . . . . 18
Miscellaneous hardware. . . . . . . . . . . . . . . . . . 19
Mounts for workstation . . . . . . . . . . . . . . . . . . . 19
Mounts for power supply . . . . . . . . . . . . . . . . . 19
Mounts for the Cockpit and M500/M540. . . . . . 19
IACS / M540 options . . . . . . . . . . . . . . . . . . . . 19
ECG monitoring – reusable leadsets . . . . . . 20
ECG monitoring – single-patient use
leadsets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
ECG monitoring – MonoLead . . . . . . . . . . . . 24
ECG accessories . . . . . . . . . . . . . . . . . . . . . . . 24
MonoLeads. . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
ECG monitoring – neonatal . . . . . . . . . . . . . . 26
Neonatal leadsets and accessories . . . . . . . . . 26
Invasive blood pressure (IBP) with
Hemo2 Pod or Hemo4 pod. . . . . . . . . . . . . . . 27
Hemodynamic pods and cables . . . . . . . . . . . . 27
Transducer adapter cables. . . . . . . . . . . . . . . . 27
IBP Monitoring with MPod – QuadHemo or
MCable – Dual Hemo . . . . . . . . . . . . . . . . . . . 28
IBP cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Transducer adapter cables. . . . . . . . . . . . . . . . 28
Non-Invasive blood pressure (NIBP)
monitoring – Dräger connectors. . . . . . . . . . 29
NIBP hose . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Reusable adult/pediatric blood pressure cuffs . 29
Single-patient use adult/pediatric blood
pressure cuffs . . . . . . . . . . . . . . . . . . . . . . . . . 30
Non-invasive blood pressure (NIBP)
monitoring – neonatal . . . . . . . . . . . . . . . . . . 31
NIBP hose . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Single-patient use neonatal blood pressure
cuffs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
SpO2 monitoring – Masimo rainbow SET
(rainbow sensors) . . . . . . . . . . . . . . . . . . . . . 32
Masimo rainbow SET MCable. . . . . . . . . . . . . 32
Masimo rainbow SET intermediate cables . . . 32
Masimo rainbow SET ReSposable sensors . . 33
Masimo rainbow SET single-patient use
sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Masimo rainbow SET reusable sensors . . . . . 33
SpO2 monitoring – Masimo rainbow SET
(M-LNCS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Masimo rainbow SET MCable. . . . . . . . . . . . . 34
Masimo rainbow SET intermediate cables . . . 34
Masimo reusable M–LNCS sensors . . . . . . . . 35
Masimo single-patient use M–LNCS sensors . 35
Masimo single-patient use M–LNCS trauma
sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
SpO2 monitoring – Masimo rainbow SET
(LNCS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Masimo rainbow SET MCable. . . . . . . . . . . . . 37
Masimo rainbow SET LNCS intermediate
cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Masimo single-patient use LNCS sensors . . . 38
Masimo reusable LNCS sensors. . . . . . . . . . . 38
Masimo single-patient use LNCS trauma
sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
SpO2 monitoring – Masimo SET (LNCS). . . 39
Masimo SET LNCS intermediate cables . . . . . 39
Masimo single-patient use LNCS sensors . . . 39
Masimo reusable LNCS sensors. . . . . . . . . . . 40
Masimo single-patient use LNCS trauma
sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

12 Instructions for Use – Infinity Acute Care System – Monitoring Accessories VG6.n
List of accessories
SpO2 monitoring – Masimo SET
(M–LNCS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Masimo SET M–LNCS intermediate cables . . . 41
Masimo single-patient use M–LNCS sensors. . 42
Masimo reusable M–LNCS sensors. . . . . . . . . 42
Masimo single-patient use M–LNCS trauma
sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Masimo SpO2accessories. . . . . . . . . . . . . . . 43
SpO2 monitoring – Nellcor OxiMax . . . . . . . 44
Nellcor SpO2cables . . . . . . . . . . . . . . . . . . . . . 44
Nellcor single-patient use sensors . . . . . . . . . . 44
Nellcor reusable sensor . . . . . . . . . . . . . . . . . . 45
Cardiac (C.O.) output monitoring . . . . . . . . . 46
C.O. cables, catheters, and thermistors . . . . . . 46
Cardiac output kits (not shown) . . . . . . . . . . . . 46
CO2monitoring - Mainstream . . . . . . . . . . . . 47
CO2cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Disposable airway adapters . . . . . . . . . . . . . . . 47
Reusable airway adapters . . . . . . . . . . . . . . . . 47
Additional accessories (not shown) . . . . . . . . . 47
CO2monitoring - Microstream . . . . . . . . . . . 48
CO2cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Sample lines for intubated patients . . . . . . . . . 48
Sample lines for non-intubated patients . . . . . . 49
Additional accessories (not shown) . . . . . . . . . 49
Temperature monitoring . . . . . . . . . . . . . . . . 50
Temperature cables . . . . . . . . . . . . . . . . . . . . . 50
Skin temperature sensors . . . . . . . . . . . . . . . . 50
Temperature cables . . . . . . . . . . . . . . . . . . . . . 51
General purpose probes. . . . . . . . . . . . . . . . . . 51
MCable – Analog/Sync . . . . . . . . . . . . . . . . . . 53
Analog/sync cables . . . . . . . . . . . . . . . . . . . . . 53
Scio monitoring . . . . . . . . . . . . . . . . . . . . . . . 54
Scio cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Scio modules . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n 13
List of accessories
Infinity Acute Care System accessories overview
The following diagram is an overview of the accessories available with the Infinity Acute Care System.
086
MPod – Quad Hemo MCable – Dual Hemo Cardiac Output
CO2
Hemo
ECG
Tem p / Au x
NIBP
Masimo rainbow SET Masimo LNCS Masimo M-LNCS Nellcor SpO2
SpO2

List of accessories
14 Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n
087
Mainstream CO2Temp
ECG – reusable ECG – MonoLead ECG – single-use ECG – neo NIBP
Pediatric Adult
CO2Analog/Sync
Adult/Child Neonatal
Microstream CO2Analog & SyncCO2& Analog/Sync

Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n 15
List of accessories
Scio.pdf
Scio Four
Oxi plus
Scio monitoring

List of accessories
16 Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n
This chapter lists the accessories available with the
Infinity Acute Care System (IACS).
The chapter is divided into the following sections:
– "General IACS accessories" on page 17
– "IACS / M540 options" on page 19
– "ECG monitoring – reusable leadsets" on
page 20
– "ECG monitoring – single-patient use leadsets"
on page 22
– "ECG monitoring – MonoLead" on page 24
– "ECG monitoring – neonatal" on page 26
– "Invasive blood pressure (IBP) with Hemo2 Pod
or Hemo4 pod" on page 27
– "IBP Monitoring with MPod – QuadHemo or
MCable – Dual Hemo" on page 28
– "Non-Invasive blood pressure (NIBP) monitor-
ing – Dräger connectors" on page 29
– "Non-invasive blood pressure (NIBP) monitor-
ing – neonatal" on page 31
– "SpO2 monitoring – Masimo rainbow SET (rain-
bow sensors)" on page 32
– "SpO2 monitoring – Masimo rainbow SET (M-
LNCS)" on page 34
– "SpO2 monitoring – Masimo rainbow SET
(LNCS)" on page 37
– "SpO2 monitoring – Masimo SET (LNCS)" on
page 39
– "SpO2 monitoring – Masimo SET (M–LNCS)"
on page 41
– "SpO2 monitoring – Nellcor OxiMax" on
page 44
– "Cardiac (C.O.) output monitoring" on page 46
–"CO
2monitoring - Microstream" on page 48
– "Temperature monitoring" on page 50
– "MCable – Analog/Sync" on page 53
– "Scio monitoring" on page 54
On the following pages, each parameter section in-
cludes a diagram depicting parameter-specific ac-
cessories, along with one or more tables displaying
accessory names and part numbers. The letters
displayed in the diagrams correspond to the letters
in the tables. Because some accessories are too
numerous to list in the diagram, they do not have a
letter associated with them.
Part numbers are subject to change without prior
notice. Contact a Dräger representative for the
most current part numbers.
Failure to use Dräger-approved accessories may
compromise the functional integrity of the IACS.

Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n 17
List of accessories
General IACS accessories
The following table lists the system components,
power cables, system cables, and keyboards for
the IACS.
System components
The following parts are components in the IACS.
They are not available for purchase individually.
Contact a Dräger representative for additional
information.
Cables and mouse
Keyboards
Part Part No.
Infinity M500 MS20407
Infinity M540 MS20401
Infinity P2500 MS22277
Desktop 120W power supply
(PS120)
2606270
IACS Y-piece for PS120 MS29702
Part Part No.
Mouse MS23352
Mouse pad MS24519
System cable, 1.5 m (4.9 ft) MS20135
System cable, 2.5 m (8.2 ft) MK08707
System cable, 3.5 m (11.5 ft) MK08708
System cable, 4.5 m (14.7 ft) MS20614
System cable, 2.2 m (7.2 ft)
(Note that this cable is only to be used
in combination with Zeus IE)
MK04408
Ethernet network cable,
4.9 m (16.1 ft)
4726399
Ethernet cables, 2.4 m (7.9 ft) 4726381
Ethernet cables, 1.2 m (3.9 ft) 4726373
Nurse call cable 8417370
Export protocol cable MS22948
Part Part No.
Standard keyboard (Russian) MS24520
Washable keyboard (Czech) MS22286
Washable keyboard (Denmark) MS20790
Washable keyboard (English) MS22288
Washable keyboard (French) MS22295
Washable keyboard (German) MS22287
Washable keyboard (Greek) MS23692
Washable keyboard (Hungarian) MS22282
Washable keyboard (Italian) MS22283
Washable keyboard (Norwegian) MS22284
Washable keyboard (Portuguese) MS22291
Washable keyboard (Spanish) MS22294
Washable keyboard (Swedish/
Finnish)
MS22285
Washable keyboard (Turkish) MS22292

List of accessories
18 Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n
Device interface kits
The following accessories are available for the In-
finity Acute Care System.
Long ceiling installation cables
Part Part No.
Device connectivity cable, 3 m
(9.8 ft) – connects the IACS to
the following ventilators:
Edwards SvO2/CCO devices:
Vigilance II
Vigileo
EV1000
Dräger ventilators:
V500
V300
VN500
Evita 2D
Evita 4
EvitaXL
Oxylog 3000+
Carina
Savina 300
Maquet ventilator:
Servo-i
BIS device
BIS Vista
NMT devices
Tof S c an
Tof Wa tch S X
MS25836
Device connectivity cable, 5 m
(16.4 ft) – connects the IACS to
the following ventilators:
Edwards SvO2/CCO devices:
Vigilance II
Vigileo
EV1000
Dräger ventilators:
V500
V300
VN500
Evita 2D
Evita 4
EvitaXL
Oxylog 3000+
Carina
Savina 300
Maquet ventilator:
Servo-i
MS25837
Primus, Primus IE, Apollo inter-
face kit
8608532
Perseus A500 & Zeus IE inter-
face kit (requires the Medibus
cable)
Medibus cable (for interface kit
MK09027)
MK09027
and
MK09269
Part Part No.
Universal set, 2 x 5 m (6.5 x 16.4 ft) G26455
Universal set, 2 x 8 m (6.5 x 26.25 ft) G26456
IACS wall box assembly G26740
IACS ceiling connection set G25955
Part Part No.

Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n 19
List of accessories
Miscellaneous hardware
Mounts for workstation
Mounts for power supply
Mounts for the Cockpit and M500/M540
IACS / M540 options
The following table lists the available IACS options.
Check with a local sales representative for options
that might be available for free during certain ongo-
ing promotions. The menu selections on the M540
or the C700/C500 are not available until the corre-
sponding options have been enabled.
Part Part No.
Transport dock and clamp MS28144
Cable hook MS26297
SpO2MCable mount MS26266
Masimo rainbow SET MCable
mount
MS28576
Rolling trolley for M540 RS-0025-05C
Part Part No.
Mount for workstation MS17139
Mount bracket rail GCX MS15934
NOTE
All other hardware from GCX can only be pur-
chased directly from GCX corporation or one of its
distributors.
Part Part No.
Wall mounting adapter CPS/IDS
power supply
4720061
Rail mount for CPS/IDS power
supply
4720095
Wall bracket CPS/IDS power supply 4720129
Power supply rollstand bracket
CPS/IDS
4720103
Mounting bracket for desktop power
supply, 120 W
MS31216
Part Part No.
Dräger lift arm, front rail, VESA,
+300
G96548
Dräger double arm, front rail, VESA G96715
Option M540 standalone C700 C500 Part No.
M540 wireless Yes No No MS16266
Full arrhythmia Yes Yes Yes MS22225
Multi IBP Yes Yes Yes MS20504
12-lead ECG Yes Yes Yes MS20508
12 channels No No Yes MS20505
16 channels No Yes Yes MS20506
Web-enabled layouts No Yes Yes MS20511
Web-enabled tabs No Yes Yes MS20512
View editor No Yes Yes MS20515
Physiological calculations No Yes Yes MS20516

List of accessories
20 Instructions for use – Infinity Acute Care System – Monitoring Accessories VG6.n
ECG monitoring – reusable leadsets
ECG accessories
074
A
E
D
F
FG
C
C
C
B
Part Part No.
AECG extension cable 3/5/6,
2 m (6.5 ft) 1)
MS16256
BECG extension cable, 4 lead,
2 m (6.5 ft)
MS31435
CECG 4-lead spacer, 10 pieces MS22832
NOTE
1) The extension cable (MS16256) works with cer-
tain MonoLeads, traditional leads, and single-
patient use leads. The extension cable is not
compatible with ECG 4-lead grabber sets.
WARNING
To reduce the hazard of burns during electro-
surgery, 4-lead extension cables are not sup-
ported for use in electrosurgical environ-
ments.
