Drag2Zero Cervelo P5 User manual

CERVELO P5 BOX INSTALL
Bolts supplied (from left to right)
A. 2 x longer countersunk screws to attach tab to frame
B. 1 x shorter countersunk screw used to attach tab to box
C. 2 x short counterbore with nuts –used to attach tab to water bottle mount
D. 1 x longer counterbore –to be inserted into storage box to frame
Ensure bolts are torqued up prior to each use
1. 1 x Countersunk to attach tab to box (Bolt B)

2. 2 x countersunk bolts to attach tab to frame (Bolts A)
4. 2 x counterbore bolts to attach bottle mount to tab (Bolt C)
Please take care to ensure the bolts do not come in contact with your frame, when attaching the
bottle mount.
5. Full assembly (protruding bolts would be in frame)
Please ensure bolts are torqued up, prior to each use.
