Draper Solar Control Shading Systems
An early Draper Window Shades
catalog from 1928.
e Draper factory c. 1920.























 










Continuing Education
Draper, Inc. 







www.draperinc.com/AIACESEducation.htm or www.aia.org.
Table of Contents
Motorized FlexShades ......................4
Manual FlexShades ........................11
Skylight FlexShades ........................13
FlexShade Panels ............................14
Roman FlexShades .........................15
Snugfold FlexShades ......................15
FlexShade Hardware ......................16
Fabric Information ........................18
For fast and easy information on any products in
this catalog, visit our website at:
www.draperinc.com
Shades of LEED®
The LEED (Leadership in Energy and Environmental Design) Green
Building Rating System is a voluntary, consensus based program
developed by the USGBC for developing high-performance buildings.
LEED provides a complete framework for accessing building
performance and meeting sustainability goals. Based on a system of
prerequisites and credits, LEED registered projects earn points and
then are awarded one of the four certification levels.
Draper FlexShades should be an important part of your next LEED
project. Draper has several LEED® AP certified staff members to help
with your projects and answer questions.
Draper’s most recent white paper, Shades of LEED, provides an in-
depth explanation of how our solar control shading systems can
contribute to LEED points and credits. This document was prepared
by an independent expert on the LEED rating system and intended
design strategy. The white paper describes the benefits of Draper
FlexShades and reviews the specific LEED points and credits to which
they can contribute. Shades of LEED is a must-read for anyone who is
working toward LEED certification for a project.
To view the -page Shades of LEED white paper, visit:
www.draperinc.com/go/green.
Custom Shading
Each FlexShade product is built to order.
Fabric, hardware and operating
mechanisms are specified to satisfy
functional and aesthetic criteria—Draper
builds each unit for an exacting fit.
Draper offers the broadest variety of
operator styles in the industry. Options
include bead chain clutch, crank, spring
roller, motorized roller-operated shades,
and manual and motorized Roman
shades.
Our spectrum of fabric colors and styles
is unmatched. Woven mesh fabrics offer
protection from heat, glare and UV rays,
while maintaining the view. Soft
translucent textiles offer designer appeal.
And our opaque fabrics eliminate all
visible light. Combine them with a
LightBloc System, and you will
achieve total blackout. All fabrics are
fire retardant.
3

Motorized FlexShade Dimensions
Maximum bundle diameter dictates the size of headbox
with endcaps, fascia with endcaps, and standard brackets,
which is governed by the size of shade and choice of fabric.
Consult DRAPER to determine which size is required for your
installation. Hardware details shown on page 16.
Motorized FlexShade
The simplicity of shades with the
versatility of motorized operation.















Dimensions, drawings and specifications available at:
www.draperinc.com/go/MotorizedShade.htm.
Motorized FlexShades with SheerWeave 2000 fabric, 5% openness, and
IntelliFlex controls, SGC4. Carol Grotnes Belk Library, Appalachian State
University, Boone, NC. Installation: Bonitz Contracting Company, Inc.,
Concord, NC. Architects: Pease Associates, Inc., Charlotte, NC; Shepley
Bulfinch Richardson and Abbott, Boston, MA; McCraken & Lopez P.A.,
Charlotte, NC. Photography: © Martin Fox Photography, Fairview, NC.
Motors are installed on the right-hand side as standard. ey may be
specified on the left.
Standard bracket
Optional endcap
and fascia
Headbox/Endcaps Standard
or Fascia/Endcaps Brackets
Small Large Small Large
A¹ ⅞ ⅝ A² ½ ¼
B¹ ¹⁵⁄₁₆ ¼ B² ⅜ 
C¹ ¹¹⁄₁₆ ⁵⁄₁₆ C² ⅝ ⁵⁄₁₆
D¹ ⅜ ⅝ D²  ¼
F¹ ⅜ ⅝ E² ¹⁄₁₆ 
On the Cover:
Heifer International Headquarters, Little Rock,
AR. Newly constructed in February 2006, the
94,000 sq. ft. building was recognized by the
American Institute of Architects as one of
the “Top Ten Green Projects” in the United
States in 2007. e Heifer project utilizes both
motorized and manual DRAPER FLEXSHADES
for solar control. DRAPER installation by Blind
Ambition, and photography © Timothy
Hursley, both of Little Rock, AR.
Cloth width = Overall width - 15 /8"
Overall
height
13
/16"
1
/16"1 /16"
13
/16"
D
2
C
2
E
2
B
2
A
2
5/16"
A
1
B
1
C
1
D
1
www.draperinc.com 800-989-0126
4

Motor Options for FlexShades
No one offers more motor options than Draper. We have a solution for any
application. Whether you are looking for quiet motors, motors with built-in
radio receiver, battery or low voltage operation, Draper has a solution. You will
find details on our complete motor offering below.
• Standard Motor—


• Quiet Standard Motor—


• Radio Technology Motor—



• Quiet Radio Technology Motor—



• Battery Motor with 12V Battery Pack—



• 24V DC Quiet Motor—

• Intelligent Technology Motor—


• Quiet Intelligent Technology Motor—

Control Options for Radio and
Intelligent Technology Motors
Draper offers a variety of controls for use with Radio and Intelligent Technology motors.
You will find details on wall switches, wireless handheld transmitters, and interfaces below.
Wall Switches
❶ Decora Single Channel Wireless Wall Switch
❷ Dec Wireless Wall Switch
❸ Single Station Low Voltage Wall Switch—for use with Intelligent Motor only (not pictured)
❹ Chronis Single Channel Wireless Wall Switch wur Timer
Wireless Remote Controls
❺ Single Channel Handheld Transmitter
❻ Four Channel Handheld Transmitter
❼ Five Channel Handheld Transmitter with Integrated Scroll Wheel
❽ Twenty Channel Handheld Transmitter
Interfaces
➒ Five Channel Multi-Link Universal Interface —Converts Intact to Radio Frequency
➓ Sixteen Channel Multi-Linadio Frequency Interface (not pictured)
Z-Wave Motor Controllers are available
Please contact Draper for more details.
❶ ❷ ❹
❺ ❻ ❼ ❽
➒
Motorized FlexShades controlled by IntelliFlex System, SGC4.
Carol Grotnes Belk Library, Appalachian State University, Boone,
NC. Architects: Pease Associates, Inc., Charlotte, NC; Shepley
Bulfinch Richardson and Abbott, Boston, MA; and McCraken &
Lopez P.A., Charlotte, NC. Installation: Bonitz Contracting
Company, Inc., Concord, NC. Photography: © Martin Fox
Photography, Fairview, NC.
www.draperinc.com 800-989-0126 5

Sun Sensor
• Automatically control shades in response
to the sun.
R2D7 Professional
Integration Interface
• Communicate with AV or BMS systems.
Handheld Transmitter
• Control or program shades with a remote.
Animeo IB + and Pilot PC Window Shade Automation
Systems can be utilized for total building solar control
automation. Please contact DRAPER for details.
Group Control
ISO-Relay
• Upmotors can be wired and controlled by one  amp switch.
• One relay per shade.
GC4
• Four isolating relays in a panelized version.
SGC4
• Panelized version with remote control.
• Supports bi-directional communication.
Individual and Group Control
SC1
• Six stops: fully up, four mid-window, and fully down.
• Remote control capabilities; motors can be parallel wired.
• Supports bi-directional communication.
SPGC4
• Four SC1s in a panelized version with ports for RF or IR
wireless remote control.
• Supports bi-directional communication.
Controls/Input Devices
IntelliFlex Wall Switch
• Labeled switches, job overlays.
• One button: one action.
• Compatible with both group and individual controls, programmable
bus, dry contact or RF.
The smartest shades are controlled with
®
SPGC4SC1 ISO-Relay SGC4GC4
R2D7
Sun Sensor
Intelliflex Wall
Switch
12-channel
Transmitter
24-channel
Transmitter
The shade control system with real brains
Using an IntelliFlex® System, it is possible to control shades
individually or in groups of almost any size, and to program the
operatio



ndard Draper motors
• Up to four intermediate stops
• Automatic calibration
• Group panel installation or individually in junction boxes
• Programmable wall switch; more than 50 options
• Easy to incorporate with building automation systems
Dimensions, drawings and specifications available at:
www.draperinc.com/go/IntelliFlexControl.htm.
FlexShades with Hexcel Screen Vision (XL) fabric at Hancock County Public
Library, Greenfield, IN. Architect: K.R. Montgomery & Associates,
Anderson, IN. Installation: Fred Mann. Photography: Wayne Williams,
Indianapolis, IN.
www.draperinc.com 800-989-0126
6

Shade Width
D
E
Fascia or Headbox Roller Width = Shade Width - 2"
Brackets Only Fabric Width = Shade Width - 17/8"
C
E
Headbox/Fascia
with Endcaps
Brackets Only
A
A
B
B
Endcaps
Motor Retainer Ring
with Screw
Cotter Pin
Motor Cable Strap
Motor/Roller/Fabric
Optional Headbox
or Fascia
Mounting Brackets
Headbox Fascia Brackets
with Endcaps with Endcaps Only
A 6⅝ 6½ 5⁄₁₆
B 6⅝ 6½ 5⁄₁₆
C N/A N/A 3¼
D N/A N/A 3¼
E 1 1 ¹⁵⁄₁₆
FlexShade 2 Dimensions
Brackets are standard
for FlexShade 2
Endcaps supplied with
optional headbox, or
squared or curved fascia
FlexShade 2 Hardware/Parts
Curved fascia
Squared fascia FlexShade 2 window shades with “M” Screen 10% at University of Alabama
at Birmingham Campus Recreation Center. Architect: Williams- Blackstock
Architects, Birmingham, AL. Dealer: Erwin & Associates, Kimberly, AL.
Photography: © Curtis Photographics, Memphis, TN.
FlexShade 2
Intermediate-Sized Motorized Shades with Your
Choice of Hardware Styles and Colors
FlexShade 2 is an intermediate sized shade in between Motorized
FlexShade and Colossal FlexShade.
• Available i












Dimensions, drawings and specifications available at:
www.draperinc.com/go/FlexShade2.htm.
www.draperinc.com 800-989-0126 7

Colossal FlexShade
Motorized Window Shade for
Large Window Openings
Draper’s Colossal FlexShade is one of the largest
motorized window shades on the market today.
• Available 







Optional Accessories:
• Internal junction box
• Wall mount bracket kit
• Ceiling tile flange
Dimensions, drawings and specifications available at:
www.draperinc.com/go/Colossal.htm.
Bottom of extruded aluminum case is fully enclosed except for slot allow-
ing fabric passage. Bottom closure panel may be removed manually for
access to roller and drive unit. Patent pending.
Eyebolts for hoisting shade
(do not lift shade by center of case)
Headbox support brackets
Knockouts for electrical connections
(two per end) with plastic plugs
1/2" threaded
rod by others
(for suspending
shade)
3/8" -16 threaded rod
by others (for adjusting
deflection in extremely
long units)
8"
131/4"
12"
Colossal FlexShades at Wasilla (AK) Multi-Use Sports Complex. Architect:
Kumin Associates, Anchorage, AK. Installation: Carberry & Associates.
Photography: © 2005 Robert Baker, North Star Multimedia, Wasilla, AK.
Colossal FlexShades installation at Mississippi State University in the Griffis
Boardroom of the Palmeiro Center. Installation by Blinds Plus of Clinton,
MS. Photography © Russ Houston, Mississippi State University.
www.draperinc.com 800-989-0126
8

D2
C2
A2
B2
D1
A1
C1
F1
Cloth width with brackets = Overall width - 13/8"
Cloth width with endcaps= Overall width - 15/8"
Overall
height
13/16"
13/16"
1
/16"
1
/16"
Consult Draper to
determine which end-cap
or bracket size is required
for your installation.
ese dimensions are
accurate for all manually
operated shades. See
additional headbox and
fascia details on page 17.
Headbox/Endcaps Standard
or Fascia/Endcaps Brackets
Small Large Small Large
A¹ ⅞ ⅝ A² ³⁄₁₆ ³⁄₁₆
B¹ NA NA B² ¹¹⁄₁₆ ¹¹⁄₁₆
C¹ ¹¹⁄₁₆ ⁵⁄₁₆ C² ⅝ ¼
D¹ ⅜ ⅝ D² ⅜ 
F¹ ½ ⅝ — — —
MANUAL FLEXSHADE
Dimensions
Manual FlexShade
Window treatments with independent control
Manual FlexShades 




Operating Systems
Bead Chain Clutch Operating System—








Crank Operator—












Dimensions, drawings and specifications available at:
www.draperinc.com/go/ManualShade.htm.
Standard
endcap
Collapsible crank may be
permanently mounted or
detachable
Crank-operated, coupled FlexShades
with Soltis 99 fabric and custom
painted hardware. Plainfield
Recreation & Aquatic Center,
Plainfield, IN. Architect: Kenneth
A. Sebree & Associates, Inc., Avon,
IN. Dealer: SPD Textile & Drapery,
Indianapolis, IN. Photography:
Wayne Williams, Indianapolis, IN.
Clutch-operated FlexShades with SheerWeave 2000 at Carol Grotnes
Belk Library, Appalachian State University, Boone, NC. Architects:
Pease Associates, Inc., Charlotte, NC; Shepley Bulfinch Richardson and
Abbott, Boston, MA; and McCraken & Lopez P.A., Charlotte, NC.
Photography: © Martin Fox Photography, Fairview, NC.
15/8"
Endcaps for fascia: mount
through back, top or end
111/16”
Standard Universal Brackets
Bead chain
clutch operator
Standard stainless
steel bead chain
Aluminum slat and
heat-seamed hem
Optional fascia
Metal tube-1¼"
www.draperinc.com 800-989-0126 9

Spring-Roller Shade
Simplicity of design, durable materials and careful workmanship make
Draper Spring-Roller Shades America’s first choice for institutional-
quality light control and room darkening shades.
• Designed specifically for institutional use.
• Manufactured to endure the toughest conditions.
• Spring-Roller Shades are offered in a wide range of room darkening
and woven mesh fabrics.
Spring-Roller Shades with SB9000 at the Hoosier Gym, home court location
for the movie “Hoosiers”, Knightstown, IN. Installation: Fred Mann, New
Castle, IN. Photography: Wayne Williams, Indianapolis, IN.
Optional Fascia
Available with an attractive aluminum fascia to conceal hardware and
roller. See pag
Exclusive Features
• Spring Roller
Traditional window shade operation. Metal
rollers and heavy-duty springs operate any
shade through  wide x  high.
• Large Diameter Institutional Metal Rollers
All shades are mounted on rigid steel rollers that house heavy-duty
springs. Our ball-bearing style locking mechanism operates more
smoothly than other devices on the market. Spring mechanism can be
replaced easily in the field.
• Fabric Attachment
Fabric is attached to roller with an industrial
adhesive, designed to withstand high
temperatures and moisture. This adhesive
attachment eliminates drilling or unsightly
fasteners and gives a strong, permanent bond
that leaves a smooth, attractive surface. Virtually eliminates laddering.
• Heat Seamed
Hems are heat seamed for added strength,
which prevent hems from unraveling
and tearing.
• Kiln-Dried Hard Maple Slats
Indiana hard rock maple, ⅞, 1¼ or ½, at our
discretion. Ten times stronger than pine slats. No
“finger joints”.
• White Cord
Hard braided large diameter cotton cord, at-
tached to slat with screweye and cord clasp.
Screweye doesn’t weaken slat like punched
eyelet holes on shades of lesser quality.
• Each Shade Individually Tested
Every Draper shade is individually tested before
shipment for perfect operation.
• Heavy-Duty Cadmium-Plated Hardware
Heavy plated steel hardware.
Dimensions, drawings and specifications available:
www.draperinc.com/go/SpringRoller.htm.














Screw eye shown
www.draperinc.com 800-989-0126
10

The Access System
Draper’s Most Versatile Shading System
The benefit of the Access System is:
• Simple white, extruded aluminum headbox installed during construction
is the hallmark of the Access System.
• Our Access headbox allows decisions about FlexShade window
treatments to be made at a later date.
• After the window trim is finished and field measurements taken, fill that
headbox with the FlexShade of your choice: manual or motorized, light
blocking or light filtering, left- or right-hand operator.
Above: Access Dual Roller FlexShades with “E” Screen and SB9000 at
Citigroup. Architect: FS Architecture PSC. Installation: Best Blind & Shade.
Photography: ©2005 Kenneth Hayden. All of Louisville, KY. U.S. Patent
Nos. 6,532,109, 6,421,175 and 6,816,308. Other patents pending.
Access Dual Roller FlexShade
This FlexShade allows for both glare control and room darkening in the
same opening. Two complete shades are vertically stacked in a single
headbox.
• Bead chain clutch or motor-in-roller operation.
• Combine a glare control fabric, mesh or translucent, with room darkening
or LightBloc FlexShade (side and sill channel) for complete blackout.
• Optional ˝ wide ceiling tile flange.
Dimensions, drawings and specifications available at:
www.draperinc.com/go/AccessDualRoller.htm.
Access FlexShade
The Access FlexShade is a single motorized or bead chain clutch operated
shade in an extruded aluminum ceiling-recessed pocket.
• A flange along the front of the headbox supports acoustical ceiling tile,
or trims the opening of any type of ceiling.
• A bottom panel forms a slot for passage of the shade, and is easily
removed without tools for unobstructed access into the case for
installation of the window shade.
• The shade (motor-in-roller or clutch with attached shade fabric) can be
installed at a later date in seconds with patented, twist-in roller brackets.
These internal roller brackets slide in a track, so they may be located
wherever appropriate after the pocket is installed. Minimizes shade
damage on the job site.
• Engineered for specific installations. Depending on fabric, maximum
recommended height is . Larger sizes may be available: contact
Draper for details.
Dimensions, drawings and specifications available at:
www.draperinc.com/go/AccessFlexShade.htm.
Brackets rotate into slots,
and can slide along case.
Internal roller
brackets adjust to
align shade.
Mounting brackets
rotate into slots, and
can slide along case.
Ultimate Access FlexShade. U.S. Patents
5,341,241, 6,421,175 and 6,816,308. Other
patents pending.
Ultimate Access FlexShade
A single motorized shade in an extruded aluminum case with automatic
ceiling closure that opens into the case. The Ultimate Access FlexShade
is only available from Draper.
• When closed, the motorized shade is hidden from view inside its case.
• The solid bottom panel gives the ceiling a clean appearance and protects
the shade fabric from dust and dirt.
• At the touch of a switch or wireless transmitter, a separate motor opens
door into case and then motorized shade descends in front of the window.
• Maximum recommended height is .
• Due to the construction of the Ultimate Access FlexShade, unit must
ship factory assembled and without side channels.
Dimensions, drawings and specifications available at:
www.draperinc.com/go/UltimateAccess.htm.
Access FlexShade. U.S. Patents 6,421,175, 6,532,109
and 6,816,308. Other patents pending.
www.draperinc.com 800-989-0126 11

Operating Systems
Motorized Operation—Motor is located within the right (standard)
or left end of the roller for smooth, reliable operation. A wide variety
of control options are available: refer to page
Crank Operator—The compact, bi-directional gear assembly can be
mounted either on the right end (standard) or the left. Crank handle
hinges to form a thin, straight rod at edge of window when not in use.
The crank is permanently mounted (standard), or specify detachable
and use a single crank for more than one shade.
Bead Chain Clutch—Unlike competing clutches, the Draper bi-
directional clutch never needs adjusting and can be mounted either
on the right (standard) or left. Shades stop when chain is released.
Stainless steel (standard) or nylon beaded chain hangs at the side,
leaving the view unobstructed. Up and down stops prevent shades
from being raised or lowered too far. Our Light Seal Kit prevents
light from coming through where the chain exits the headbox.
Spring Roller—Roller is under constant tension,
with a latching chain at sill (see detail at right).
Dimensions, drawings and specifications available at:
www.draperinc.com/go/LightBloc.htm.
Dimensional Drawings–LightBloc System
Available in sizes through  wide x  high. Cannot be coupled. Note:
For proper operation, LightBloc units must be installed square and plumb.
Slat bar
Sill
channel
Catch
LightBloc FlexShade
Provides complete blackout
• Ideal for audiovisual applications.
• Choose from our room-darkening fabrics. For details, see our
website at www.draperinc.com/go/LightBloc.htm.
• When SB/ is specified, our exclusive, patented
Fabric Retention System prevents disengagement of fabric
from the channels.
• Aluminum headbox, side and sill channels available in durable
finish available in clear anodized (standard), black, white, ivory
or charcoal bronze.
• Internal light seals and opacity plates eliminate all light leaks,
which means no light gap at headbox/side channel connection.
• Headboxes are available to recess or surface mount (standard).
• Light proof hem bar recessed into light proof side channel.
• 
Inside mounting of LightBloc requires
mounting angle, not shown.
Channel locator
Fabric retainer
Light seal
Fabric
Stay pocket
Fabric guide
Rivet
Steel stay
Side channel
¾" x 2¾"
Operator endcap
Channel locator
Fabric guide
Side channel
Face/bottom cover
(standard)
Sill channel
Inside Mount
1⅜ x ¾ Face Mount
2¾ x ¾
Sill channel–
see details
Fabric grommet
Slat bar
Stays
Shade
fabric
Roller
Top/back cover
(standard) Motor
To controls
Gudgeon assembly
Retainer clip
Idler endcap
Fastens to ceiling,
face, or jamb
Channel liner
Fabric
retainer
Side channel—Includes ¾ x 1
adjustable mounting angles
O–ring
Opacity
plate
Pictured above and below left: LightBloc FlexShades with SB9000 at St. Stephen
Church & Prayer Retreat Center, Jeffersonville, IN. Design/Installation: Best Blind &
Shade, Louisville, KY. Photography: © 2005 Kenneth Hayden, Louisville, KY.
www.draperinc.com 800-989-0126
12

Dimensions & Installation
Complete details available at: www.draperinc.com/go/Skylight.htm.
Direction of fabric travel
Take-up reel
Access cover
2" dia. motorized roller
Flange/endcap locator
Side support flange
Access cover
1¾" dia. spring roller
2¼" dia. for units
over 8' wide
Shims at both ends
Back cover
Cloth
Slat bar
Take-up cable
Back cover
4" 4"
3½"3½"
4" 4"
31/2"
Take-up reel
Access cover
2" dia. mot. roller
Flange/endcap locator
Access cover
13/4" dia. spring roller
Back cover
Cloth
Slat bar
Take-up cable
Back cover
Direction of fabric travel
Cable Support
System
31/2"
Recess all components into the skylight opening (below right). With outside
mount installation (at left), separate header bars must be attached at both
ends to house the support cable system. With outside installation, fabric stay
pockets are visible from inside the room on all sizes of Skylight FlexShades.
Dimensions shown are for Skylight FlexShades 8´ wide and under.
Due to the force of gravity, Skylight FlexShades are available to a
maximum unsupported width of 42˝. Larger units require one or more
support cables, up to a maximum of 12´ wide x 12´ long. Cables are ³⁄₁₆˝
dia. vinyl clad aircraft cable. Units over 8´ wide must be motorized, inside
mount, with 4⅝˝ x 4⅝˝ headbox and 2¼˝ dia. spring roller.
Skylight FlexShade with “E” Screen 5% at Lawrence North High School.
Installation: SPD Textile & Drapery, Inc. Photography: © Brian Bookwalter.
All of Indianapolis, IN. Shown closed above, partially open below.
Note: To facilitate proper operation, Skylight FlexShades must be installed
square and with rollers level. Installers must be qualified craftsmen.
Skylight FlexShade
An unprotected skylight can generate intense heat and glare. Skylight
FlexShades are the ideal remedy. Inconspicuously recessed into the sky-
light opening, a Skylight FlexShade provides solar and UV control to
protect people and furnishings.
Fabric Support
System
Support cables
for larger units.
Detachable
crank operator
• Contact Draper for size requirements.
• Battens are used to ensure the flattest surface possible.
• Skylight FlexShades can be installed at any angle as long as rollers are
level.
• Select a mesh fabric for light filtration or SunBloc for complete opacity.
• Five choices of hardware finishes: silver (standard), black, white, ivory or
bronze enamel.
• Draper recommends lighter color fabrics and hardware to absorb less
heat.
• Venting space between shade and glass recommended.
• Motorized or clutch operation available. For motor and control
options, see pa
Dimensions, drawings and specifications available at:
www.draperinc.com/go/Skylight.htm.
www.draperinc.com 800-989-0126 13

3
/ 4 "
7
/ 16 "
1
1
/ 16 "
Typical frame cross-section
Installation of Interior Panels
FlexShade
Panel frame
Face Mounting
Inside Mounting
FlexShade
Panel frame
Dimensions and details may
vary. Frame components at
manufacturer’s discretion.
Keeper track
Keeper track
Side mounting
channels
Side mounting
channels
Fixed panel
Installation of Exterior Panels
FlexShade Panels for exterior use are easy to install. Install
mounting channels first. Then, slide fixed panel in from lower
end. Install keeper track to secure panel in frame. At maintenance
time, simply remove the bottom keeper, and slide out the fixed
panel.
SunScreen® SW1000 by Phifer—
For reducing solar heat gain in the summer and heat loss in the winter.
SunScreen® may be installed on the exterior or interior of glass areas.
Sw1000 is a vinyl-coated fiberglass, woven in a ribbed pattern. Virtually
maintenance free—non-combustible and will not rust, corrode, shrink,
scratch or stain. Approximate openness factor of 23%. Up to  roll
width. . oz./sq. yd., . thick. Available in five colors.
FlexShade Panels with Screen2 (XL2®) by Hexcel, 3% openness, mount-
ed above Clutch-operated FlexShades in the Teen Room at New Castle-
Henry County Public Library, New Castle, IN. Installation: Fred
Mann. Photography: Wayne Williams, Indianapolis, IN.
FlexShade Panels
FlexShade fixed frame panels provide solar filtration at a lower cost than
operable solutions. Relieve the discomfort from solar heat and glare often
associated with unprotected glazing. They are particularly well suited for
skylights and sloped glazing in solariums or odd-shaped openings. (Not
suitable for curved framing).
• Help prevent ultraviolet damage to textiles and furniture located in direct
sunlight.
• Heavy-duty fixed panels utilize an extruded aluminum frame. Frames are
available in dark bronze, white or mill finish aluminum (standard).
• Panels mount easily on surface or within framing of windows with clips.
• Clips allow removal of FlexShade Panels for routine maintenance and
cleaning.
• Available in sizes up to   . Panels exceeding  in length require
center support member.
• Furnished in virtually any of our woven mesh fabrics.
Dimensions, drawings and specifications available at:
www.draperinc.com/go/FlexShadePanels.htm.
www.draperinc.com 800-989-0126
14

Roman FlexShades
Above: Roman FlexShades. Light filtering fabric is SheerWeave® by Phifer, color
SW2100 White/Platinum, 10% open. Installation by Tom Stuckey, Window
Watchers, Fort Wayne, IN. Photography © Jeff Bell, Fort Wayne, IN.
Roman FlexShades provide an elegant, softer alternative to traditional
roller shades, blinds or draperies. Ideal for residential installations.
• Valance (included) completely conceals the operating mechanism.
• The award-winning Rollease No-Sew™ System means there are no
visible stitches in the fabric—clearly superior to other methods of
attaching slats.
• Choose a soft, gently draping textile with complete opacity, or select
from our wide variety of light-filtering woven mesh fabrics. May be
installed inside or outside the opening.
Operating Systems
Motorized Operation—For maximum reliability and convenience.
Motor is located inside the right (standard) or left end of the roller.
115 volt tubular gearmotor easily interfaces with a variety of control
systems (details on page 5-6). Larger sizes available in motorized
Roman FlexShades, depending on fabric. Contact Draper for
details.
Clutch—Draper’s clutch system operates approximately five times faster
than competing systems. The clutch never needs adjusting and can be
mounted either right (standard) or left, as preferred. Stainless steel bead
chain is standard.
Dimensions, drawings and specifications available at:
www.draperinc.com/go/Roman.htm.
Snugfold
Snugfold shades are designed to cover large glass areas such as those
found in classrooms, cafeterias and gymnasiums.
• Folds and unfolds smoothly and easily by means of a simple and
reliable cord and pulley system.
• Cord locks enable shade to be stopped at any point. Color-
coordinated #½ cords.
• Permanently attached matching valance conceals shade hardware.
• Only manufactured with Colony fabric.
• Sizes through  wide x  high.
• Three intermediate maple slats allow the Snugfold to fold to
approximately one-sixth its total height.
• Steel stays are midway between each slat to keep folds smooth and flat.
• Large-diameter, self-lubricating nylon pulleys are housed
in heavy-gauge, brass-tone plated steel frames.
• Cord locks are integral to pulley frame for maximum strength and
ease of operation.
Dimensions, drawings and specifications available at:
www.draperinc.com/go/Snugfold.htm.
Above: Snugfolds installed at Test Middle School, Richmond, IN. Installation:
Fred Mann, New Castle, IN. Photography: Wayne Williams, Indianapolis, IN.
Width
Height
Mounting brackets 21/4"2
1/4 " (3 1/4 " on
some l arge sizes)
Fabric width is 1/4" less than valance
(1/8" on each side)
Valance
Stacking Ht.
approx. 12"*
*Varies according
to shade height
4" 4"
www.draperinc.com 800-989-0126 15

Optional Covers for 1⅝˝ brackets
Hardware for FlexShades
Clutch Brackets
Endcaps for Fascia and Headbox
Fascia Finishes
L Angle Side Channel
7/8"7/8"
1 5/8" 1 5/8"
Motor end Idler end
Coupler assembly
FlexShade with motor FlexShade without motor FlexShade without motor
Surface-mounted Headbox is two piece plus endcaps.
4⅝ Large box
3⅜ Small box
4⅝ Large box
3⅞ Small box
4⅝
4⅝
3⅞
3⅜
Large Pocket
Headbox Small Pocket
Headbox
Configuration for pocket
installation (optional)
Pocket-Style Headbox
Wall Clip with Closure
Couplers
1
13/16
"
1/4
"
13/4"
or 3"
Mounting Brackets—The standard mounting hardware
supplied for wall, ceiling or jamb installation of Draper Motorized
and Manual FlexShades. As an option for a pair of ⅝ brackets,
white bracket covers are available. If optional fascia or headbox are
specified, then endcaps (not brackets) are supplied.
Fascia—Optional extruded fascia hides hardware and roller.
Available in clear anodized (standard), black, white, ivory, or charcoal
bronze. ⅞ or ⅝ high as required. Printed color at right may vary
from actual aluminum. Color samples are available.
Couplers—Draper’s FlexShade Coupling System lets one
motor drive up to four additional shade rollers, or a crank operator
may drive two additional rollers. Coupled shades must be same height.
The overall width of a motorized group
may not exceed ; crank-operated groups
may be up to  wide.
Brackets extend ½ from mounting
surface to center line of roller, and may be
wall or ceiling mounted. Ideally, install
FlexShade Coupling System in Draper
Type D Pocket or existing pocket.
Coupled units may also be installed in ⅞ and ⅝ Draper ceiling
pockets. Fascia is available. (Not suitable with LightBloc
FlexShade.)
Dimensions, drawings and specifications available at:
www.draperinc.com/go/FlexShadeCoupler.htm.
Side Channel or “L” Angle—Side Channels or “L”
Angles prevent direct light gaps at sides of shade fabrics. Side
Chls are  deep x e, and mount to the jamb or face of
window opening. “L” Angles measure   ¾ or   ¾ and mount
inside the jamb.
Wall Clip with Closure—Pocket already exists? Specify
FlexShade Wall Clip with a long or short closure. Wall Clip mounts
to the wall and bottom closure panel drops neatly into place without
fasteners, leaving a minimal slot through which the shade descends.
For sleek appearance, use continuous wall clip. Closure sizes ¾ or .
Surface-Mounted Headbox—Complete extruded
headbox is available to hide hardware and roller as an option for
Motorized and Manual FlexShades. Two-piece assembly is
suitable for surface mount to head, jamb or wall, in sizes ⅞ high or
⅝ high as required.
Pocket-Style Headbox—Complete extruded headbox
with endcaps is available for ceiling recessed installation. In sizes ⅞
high or ⅝ high as required.
Custom Powder coating—Custom powder coat paint
colors available for most Draper hardware. Contact Draper for
details. Powder coat provides an extremely durable, attractive finish.
Dimensions, drawings and specifications available at:
www.draperinc.com/go/FlexShadeHardware.htm.
www.draperinc.com 800-989-0126
16

Graphic FlexShades
Virtually any logo or image
You provide the artwork, and Draper will print your logo or
graphic. We use a high quality, digital four-color process to
assure a crisp and clear image.
• Ideal when restrictions are imposed on signage.
• Put your logo or ad on the side of the shade
facing out, and display it to the world.
• Graphic can be printed on either side of shade.
• See your Draper representative for
restrictions and available fabrics.
For more information:
www.draperinc.com/go/ShadeGraphics.htm.
Type D Pocket—An extruded aluminum pocket for
clean, ceiling flush installation. With bottom closure panel
in place, only a narrow slot is visible. Aluminum pockets
offer a convenient architectural solution for mounting either
Motorized or Manual FlexShades at the curtain wall.
Installation of Type D Pocket in coordination with ceiling finishing
allows for later installation of shades. Pockets are finished in white.
FlexShades are installed using standard ceiling brackets.
Draper’s Type D Pocket cross-section dimensions
are ½ deep x ⅝ high. Comes in  lengths. A tile-
support flange along lower edge supports lay-in ceiling.
Pre-welded corners and pocket ends are available. Endcaps
optional. Add ¼ to overall case width if using endcaps.
Hardware for FlexShades
Anchor 2'0" O.C. Pocket type D
with tile support
by Draper
Curtain
wall Removable closure
panel D1 by Draper
FlexShade with ceiling
brackets by Draper
41/2"
31/4"7/8"
1"
45/8"
Graphic FlexShades with Soltis® 99 fabric at University of Missouri, Columbia.
Architect: Hastings & Chivetta Architects, Inc., St. Louis, MO. Installation:
Jack F. Dale & Associates. Photography: © Emily Bach, Columbia, MO.
Graphic FlexShades with SheerWeave® PW3500 fabric at
e Joan Weill Center for Dance (formerly Ailey American
Dance eater). Architects: Iu + Bibliowicz Architects LLP.
Photography: © 2005 Bruce Katz. All located in New York, NY.
www.draperinc.com 800-989-0126 17

FlexShade Fabric Selection
FlexShades are available in a wide variety of mesh, opaque and room
darkening fabrics from national and international manufacturers.
Selection of fabric for your FlexShade solution can contribute to
effective energy conservation, worker comfort (leading to increased
productivity), and decreased expense in cooling.
DRAPER offers more fabric types and colors
than other window shade manufacturers.
For complete fabric lines and details, see our website
at www.draperinc.com/go/ShadeFabric.htm.
Dedicated to Green
Draper, Inc. is proud to be a member of or have our products listed by
several highly respected building industry leaders and standards
organizations dedicated to promoting buildings and products that are
environmentally responsible, profitable, and create healthy places to live
and work. Some of these include:
• The U.S. Green Building Council (USGBC)
see www.usgbc.org for more details.
• The Greenguard Environmental Institute™ (GEI)
see www.greenguard.org for more details.
• GreenSpec
see www.buildinggreen.com for more details.
• Daylighting Collaborative
see www.daylighting.org for more details.
• Texyloop
see www.texyloop.com/internet/gb/ for more details.
• Confidence in Textiles—
see www.oekotex.com for more details.
Energy Conservation
















W/m²K
(i.e.˝ (mm) glass).
Screen2® (XL2®) by Hexcel, Blanc/bronze fabric, North Park Branch Library,
Evansville, IN. Installation by Spindletop Draperies, Louisville, KY.
Photography © Barry Rustin, Evanston, IL.

















    


   




e GreenGuard® logo refers to SheerWeave Series W2000/2100/2400/2600 by Phifer fabrics.
e TexyLoop and Confidence in Textiles logos refer to Soltis®99 by Ferrari Fabric.
www.draperinc.com 800-989-0126
18

Shade Fabric Selection Based on Building Position and Location
Openness Factor By Region
Regions Clear View Obstructed View
A
B
C
D
10%
3%
5% 5%
10%
5%
10% 10%
10%
3%
5% 5%
5%
5%
3% 3%
10%
5%
5% 5%
5%
5%
3% 3%
10%
10%
5% 5%
10%
5%
10% 10%
The compass below
indicates the recom-
mended openness
factor based on the
orientation of your
building.








 










 





WE
N
S
Fabric Openness Factor
The following key identifies four properties of shade fabrics and openness factors. Normally, dark colors provide better glare control because they
absorb light. Light colors offer better heat control because they reflect heat. Duplex fabrics offer both glare control and heat control. All Draper
fabrics are fire retardant. Complete fabric lines and fire retardant ratings available at www.draperinc.com/go/ShadeFabric.htm.
Natural light can be beneficial to health in the working environment. Ensuring protection against glare and reflection is essential when choosing
window shade fabric openness. Openness selection should be based on building position, geographical location or exposure area, office activity,
and view: clear or obstructed.
Use the charts below to make recommendations for window shade openness factor to control glare and work station reflections, for UV protection
and for better view-through capabilities.
Openness factor is the
percentage of openness of
the solar woven fabrics. The
openness factor determines
how much light, heat and
glare the fabric will allow to
enter. The openness factor
also determines how much
of an outward (and inward)
view fabric will allow.
Shade fabric color selected,
building orientation,
and artificial and natural
lighting will affect see-
through capability.
3%
Openness
5%
Openness
10%
Openness
Fenestration Data
Draper offers test data for the specifier’s use in controlling light and heat, view and privacy, and glare level.
• Solar transmittance (TS ), reflectance (RS ), and absorptance (AS ) add up to 100%, indicating that all the sun’s energy striking the
shade is reflected, absorbed, or passed through.
• Visible transmittance (TV ) indicates the amount of glare likely to be perceived.
• Openness factor (OF) concerns the density of the weave.
• Shading coefficients (SC) indicate shading efficiency.
Contact Draper to receive fenestration data for any of our fabrics, or visit www.draperinc.com/go/Fenestration.htm.
These photos demonstrate shades with Screen Vision (XL) fabric by Hexcel in 3%, 5% and 10% openness.
www.draperinc.com 800-989-0126 19

A Word About DRAPER




















Please visit us 24-hours a day on the Web at
www.draperinc.com to download
specifications, CAD details, submittals
and installation instructions. To
receive an architectural specification
CD-ROM, product cut sheets or
additional literature, contact DRAPER
by calling, faxing or e-mailing.
All photographs in this catalog © DRAPER, INC.
unless otherwise noted.
Copyright © 2007 DRAPER, INC. Form_FlexShadeSystems2007 Printed in U.S.A.
Crank operated FlexShades with Hexcel XL2® Blanc/bronze fabric, North
Park Branch Library, Evansville, IN. Installation by Spindletop
Draperies, Louisville, KY. Photography © Barry Rustin, Evanston, IN.
Specifier Services:
Download 24/7 at www.draperinc.com
• 3-part specifications
• Short form specifications
• CADs & PDF detail drawings
• Arcat Spec Wizard customized specifications
Personal Service:
• In person AIA CEU classes, at your location
• Design consultation
Additional Resources:
• www.sweets.com (Sweets Network for Products)
• www. arcat.com
• www.4specs.com
• www.buildinggreen.com
• www.todl.com (Trade Only Design Library)
