Draw tite 76154 User manual

Installation Instructions

PART NUMBERS: 76154, 84154, C T76154

Applications:

Years Make Models

2017-Current* Nissan Titan

Ratchet

Torque

Wrench

Safety

Glasses Sockets

DO NOT EXCEED LOWER OF TOWING VEHICLE

MANUFACTURER’S RATING OR:

Hitch Type Max Gross Trailer Weight Max Tongue Weight

Weight Carrying 8000 Lb. (3632 Kg) 800 Lb. (363 Kg)

Weight Distributing 12,000 Lb. (5448 Kg) 1200 Lb. (545 Kg)

Representative Vehicle Photo

Installation Time: 30 min.

The time listed above is the average time

for professional installers. If you do not

feel comfortable performing this

installation on your own or are in need of

assistance, please contact a professional

installer.

Hitch Illustration

Front of

Vehicle

17mm

19mm

6” Socket

Extension

Equipment Required:

Wire

brush

Note: check hitch frequently, making sure all fasteners and ball are properly tightened. If hitch is removed, plug all holes in trunk pan or other body panels to prevent entry of water and exhaust fumes. A hitch or ball which has been

damaged should be removed and replaced. Observe safety precautions when working beneath a vehicle and wear eye protection. Do not cut access or attachment holes with a torch.

This product complies with safety specifications and requirements for connecting devices and towing systems of the state of New York, V.E.S.C. Regulation V-5 and SAE J684.

Fastener Kit: 76154F

Proper torque is needed to keep the hitch secure to the vehicle when towing.

Always wear SAFETY GLASSES

when installing hitch

1. Remove tow hook brackets – Using a 17mm socket, remove factory tow hook brackets (if present) by removing (10) M12 flange head bolts. Return bolts & brackets

to vehicle owner. See Figure 2. NOTE: For vehicles without factory tow hook brackets, it may be necessary to clean the existing weldnuts in frame using a wire brush

or compressed air.

2. Install hitch – Raise the hitch into position, raising the passenger’s side hitch bracket above the exhaust first, then raise the driver’s side into position. Using the

supplied hardware, install the M12 bolts, conical toothed washers, and hardened flat washers as shown. See Figure 1.

3. Tighten all M12 CL10.9 fasteners with torque wrench to 76 Lb.-Ft. (103 N*m)

①Qty. (10) Bolt M12 X 1.2 X 40 CL10.9

Part no. 04263040

②Qty. (6) Conical washer ½

Part no. 01292008

③Qty. (4) Flat Washer ½ (Hardened)

Part no. 3306QAD

Teeth side

Against hitch

Conical Washer

Installation Instructions

PART NUMBERS: 76154, 84154, C T76154

①

②

Rear

Figure 1

①

②

①

②

Fasteners

typical

both sides

Figure 2

Factory tow

hook bracket

Both sides

Existing weldnuts

(10) Places

1. Remove tow hook brackets – Using a 17mm socket, remove factory tow hook brackets (if present) by removing (10) M12 flange head bolts. Return

bolts & brackets to vehicle owner. See Figure 2. NOTE: For vehicles without factory tow hook brackets, it may be necessary to clean the existing

weldnuts in frame using a wire brush or compressed air.

2. Install hitch – Raise the hitch into position, raising the passenger’s side hitch bracket above the exhaust first, then raise the driver’s side into position.
