Draytek Vigor2860 Series Operator's manual

Vigor2860 Series Quick Start Guide
i

Vigor2860 Series Quick Start Guide ii

Vigor2860 Series Quick Start Guide
i
Vigor2860 Series
VDSL2 Security Firewall
Quick Start Guide
Version: 3.0
Firmware Version: V3.7.8
(For future update, please visit DrayTek web site)
Date: January 07, 2015

Vigor2860 Series Quick Start Guide ii
Copyright Information
Copyright
Declarations
© 2015 All rights reserved. This publication contains information that is
protected by copyright. No part may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language without written
permission from the copyright holders.
Trademarks
The following trademarks are used in this document:
Microsoft is a registered trademark of Microsoft Corp.
Windows, Windows 95, 98, Me, NT, 2000, XP, 7 and Explorer are
trademarks of Microsoft Corp.
Apple and Mac OS are registered trademarks of Apple Computer Inc.
Other products may be trademarks or registered trademarks of their
respective manufacturers.
Safety Instructions and Approval
Safety Instructions
Read the installation guide thoroughly before you set up the router.
The router is a complicated electronic unit that may be repaired only be
authorized and qualified personnel. Do not try to open or repair the router
yourself.
Do not place the router in a damp or humid place, e.g. a bathroom.
Do not stack the routers.
The router should be used in a sheltered area, within a temperature range
of +5 to +40 Celsius.
Do not expose the router to direct sunlight or other heat sources. The
housing and electronic components may be damaged by direct sunlight or
heat sources.
Do not deploy the cable for LAN connection outdoor to prevent electronic
shock hazards.
Keep the package out of reach of children.
When you want to dispose of the router, please follow local regulations on
conservation of the environment.
W
arrant
y
We warrant to the original end user (purchaser) that the router will be free from
any defects in workmanship or materials for a period of two (2) years from the
date of purchase from the dealer. Please keep your purchase receipt in a safe
place as it serves as proof of date of purchase. During the warranty period, and
upon proof of purchase, should the product have indications of failure due to
faulty workmanship and/or materials, we will, at our discretion, repair or replace
the defective products or components, without charge for either parts or labor, to
whatever extent we deem necessary tore-store the product to proper operating
condition. Any replacement will consist of a new or re-manufactured
functionally equivalent product of equal value, and will be offered solely at our
discretion. This warranty will not apply if the product is modified, misused,
tampered with, damaged by an act of God, or subjected to abnormal working
conditions. The warranty does not cover the bundled or licensed software of
other vendors. Defects which do not significantly affect the usability of the
product will not be covered by the warranty. We reserve the right to revise the
manual and online documentation and to make changes from time to time in the
contents hereof without obligation to notify any person of such revision or
changes.
Be a Registered
Owne
r
Web registration is preferred. You can register your Vigor router via
http://www.draytek.com.
Firmware & Tools
Updates Due to the continuous evolution of DrayTek technology, all routers will be
regularly upgraded. Please consult the DrayTek web site for more information on
newest firmware, tools and documents.
http://www.draytek.com

Vigor2860 Series Quick Start Guide
iii
European Community Declarations
Manufacturer: DrayTek Corp.
Address: No. 26, Fu Shing Road, Hukou Township, Hsinchu Industrial Park, Hsinchu County,
Taiwan 303
Product: Vigor2860 Series Router
DrayTek Corp. declares that Vigor2860 Series of routers are in compliance with the following essential
requirements and other relevant provisions of R&TTE 1999/5/EC, ErP 2009/125/EC and RoHS
2011/65/EU.
The product conforms to the requirements of Electro-Magnetic Compatibility (EMC) Directive
2004/108/EC by complying with the requirements set forth in EN55022/Class B and EN55024/Class B.
The product conforms to the requirements of Low Voltage (LVD) Directive 2006/95/EC by complying
with the requirements set forth in EN60950-1.
This product is designed for POT, DSL and 2.4GHz /5GHz WLAN network throughout the EC region.
Regulatory Information
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device may accept any interference received, including interference that may cause undesired
operation.
The antenna/transmitter should be kept at least 20 cm away from human body.
DrayTek Vigor2860 series VDSL2/ADSL2+ routers are compliant with 47 C.F.R. Part 68.
More update, please visit www.draytek.com.

Vigor2860 Series Quick Start Guide iv

Vigor2860 Series Quick Start Guide
v
T
Ta ab bl le e o of f C Co on nt te en nt ts s
1. Introduction ........................................................................................1
1.1 Panel Explanation ...................................................................................... 2
1.1.1 For Vigor2860 ........................................................................................... 2
1.1.2 For Vigor2860n ......................................................................................... 4
1.1.3 For Vigor2860n-plus.................................................................................. 6
1.1.4 For Vigor2860Vn-plus ............................................................................... 8
1.1.5 For Vigor2860ac...................................................................................... 11
1.1.6 For Vigor2860Vac................................................................................... 13
1.2 Package Content...................................................................................... 16
2. Installing Your Router......................................................................17
2.1 Hardware Installation............................................................................... 17
2.2 Printer Installation.................................................................................... 18
3. Quick Setup ......................................................................................27
3.1 Accessing Web User Interface................................................................ 27
3.2 Basic Configuration – Quick Start Wizard ............................................. 28
3.2.1 For WAN1 (ADSL/VDSL2) ...................................................................... 30
3.2.2 For WAN2 (Ethernet) .............................................................................. 34
3.2.3 For WAN3/WAN4 (USB) ......................................................................... 42
3.3 Wireless Configuration............................................................................ 44
3.3.1 Basic Wireless LAN Concept .................................................................. 44
3.3.2 General Setup......................................................................................... 45
3.3.3 Security Settings..................................................................................... 46
3.4 Registering Vigor Router......................................................................... 47
4. Trouble Shooting..............................................................................51
4.1 Checking If the Hardware Status Is OK or Not....................................... 51
4.2 Checking If the Network Connection Settings on Your Computer Is OK
or Not............................................................................................................... 52
4.3 Pinging the Router from Your Computer ............................................... 55
4.4 Checking If the ISP Settings are OK or Not ........................................... 56
4.5 Backing to Factory Default Setting If Necessary................................... 57

Vigor2860 Series Quick Start Guide vi
4.6 Contacting DrayTek ................................................................................. 59

Vigor2860 Series Quick Start Guide
1
1
1. . I In nt tr ro od du uc ct ti io on n
Vigor2860 series is a VDSL2 router with multi-subnet for secure and
efficient workgroup management. It integrates IP layer QoS, NAT
session/bandwidth management to help users control works well with large
bandwidth.
By adopting hardware-based VPN platform and hardware encryption of
AES/DES/3DES, and hardware key hash of SHA-1/MD5, the router
increases the performance of VPN greatly and offers several protocols (such
as IPSec/PPTP/L2TP) with up to 32 VPN tunnels.
The object-based design used in SPI (Stateful Packet Inspection) firewall
allows users to set firewall policy with ease. CSM (Content Security
Management) provides users control and management in IM (Instant
Messenger) and P2P (Peer to Peer) more efficiency than before. In addition,
DoS/DDoS prevention and URL/Web content filter strengthen the security
outside and control inside.
Vigor2860 series supports USB interface for connecting USB printer to
share printing function, 3G/4G USB modem for network connection, or
connectivity for network FTP service.

Vigor2860 Series Quick Start Guide 2
1
1. .1 1 P Pa an ne el l E Ex xp pl la an na at ti io on n
1
1. .1 1. .1 1 F Fo or r V Vi ig go or r2 28 86 60 0
LED Status Explanation
Blinking The router is powered on and running
normally.
ACT (Activity)
Off The router is powered off.
On USB device is connected and ready for use.USB1~2 Blinking The data is transmitting.
On Internet connection is ready.
Off Internet connection is not ready.
WAN2
Blinking The data is transmitting.
On The router is ready to access Internet through
DSL link.
DSL
Blinking Slowly: The DSL connection is ready.
Quickly: The connection is training.
On The VPN tunnel is active.
Off VPN services are disabled
VPN
Blinking Traffic is passing through VPN tunnel.
QoS On The QoS function is active.
WCF On The Web Content Filter is active. (It is enabled
from Firewall >> General Setup).
On The DoS/DDoS function is active.DoS Blinking It will blink while detecting an attack.
LED on Connector
On The port is connected.
Off The port is disconnected.
Left
LED Blinking The data is transmitting.
On The port is connected with 1000Mbps.
WAN2
(Giga)
Right
LED Off The port is connected with 10/100Mbps
On The port is connected.
Off The port is disconnected.
Left
LED Blinking The data is transmitting.
On The port is connected with 1000Mbps.
GigaLAN
1~6
Right
LED Off The port is connected with 10/100Mbps

Vigor2860 Series Quick Start Guide
3
Interface Description
Factory Reset Restore the default settings. Usage: Turn on the
router (ACT LED is blinking). Press the hole and
keep for more than 5 seconds. When you see the
ACT LED begins to blink rapidly than usual, release
the button. Then the router will restart with the
factory default configuration.
USB Connecter for a USB device (for 3G/4G USB
Modem or printer).
VDSL/ADSL Connecter for accessing the Internet.
WAN2 Connecter for local network devices or modem for
accessing Internet.
GigaLAN 1-6 Connecters for local network devices.
PWR Connecter for a power adapter.
ON/OFF Power Switch.

Vigor2860 Series Quick Start Guide 4
1
1. .1 1. .2 2 F Fo or r V Vi ig go or r2 28 86 60 0n n
LED Status Explanation
Blinking The router is powered on and running
normally.
ACT (Activity)
Off The router is powered off.
On USB device is connected and ready for use.USB Blinking The data is transmitting.
On Wireless access point is ready. WLAN Blinking It will blink slowly while wireless traffic
goes through.
ACT and WLAN LEDs blink quickly and
simultaneously when WPS is working, and
will return to normal condition after two
minutes. (You need to setup WPS within 2
minutes.)
On Internet connection is ready.
Off Internet connection is not ready.
WAN2
Blinking The data is transmitting.
On The router is ready to access Internet
through DSL link.
DSL
Blinking Slowly: The DSL connection is ready.
Quickly: The connection is training.
On The VPN tunnel is active.
Off VPN services are disabled
VPN
Blinking Traffic is passing through VPN tunnel.
QoS On The QoS function is active.
WCF On The Web Content Filter is active. (It is
enabled from Firewall >> General Setup).
On The DoS/DDoS function is active.DoS Blinking It will blink while detecting an attack.
LED on Connector
On The port is connected.
Off The port is disconnected.
Left
LED Blinking The data is transmitting.
WAN2
(Giga)
Right On The port is connected with 1000Mbps.

Vigor2860 Series Quick Start Guide
5
LED Off The port is connected with 10/100Mbps
On The port is connected.
Off The port is disconnected.
Left
LED Blinking The data is transmitting.
On The port is connected with 1000Mbps.
GigaLAN
1~6
Right
LED Off The port is connected with 10/100Mbps
Interface Description
Wireless LAN
ON/OFF/WPS Press the button and release it within 2 seconds. When the wireless function is ready, the green LED
will be on.
Press the button and release it within 2 seconds to
turn off the WLAN function. When the wireless
function is not ready, the LED will be off.
When WPS function is enabled by web user
interface, press this button for more than 2 seconds to
wait for client’s device making
network connection
through WPS.
Factory Reset Restore the default settings. Usage: Turn on the
router (ACT LED is blinking). Press the hole and
keep for more than 5 seconds. When you see the
ACT LED begins to blink rapidly than usual, release
the button. Then the router will restart with the
factory default configuration.
USB Connecter for a USB device (for 3G/4G USB
Modem or printer).
VDSL/ADSL Connecter for accessing the Internet.
WAN2 (Giga) Connecter for local network devices or modem for
accessing Internet.
GigaLAN 1-6 Connecters for local network devices.
PWR Connecter for a power adapter.
ON/OFF Power Switch.

Vigor2860 Series Quick Start Guide 6
1
1. .1 1. .3 3 F Fo or r V Vi ig go or r2 28 86 60 0n n- -p pl lu us s
LED Status Explanation
Blinking The router is powered on and running
normally.
ACT (Activity)
Off The router is powered off.
On USB device is connected and ready for use.USB Blinking The data is transmitting.
On Wireless access point with bandwidth of
2.4GHz/5GHz is ready.
2.4G/5G
Blinking It will blink slowly while wireless traffic
goes through.
ACT and WLAN LEDs blink quickly and
simultaneously when WPS is working, and
will return to normal condition after two
minutes. (You need to setup WPS within 2
minutes.)
On Internet connection is ready.
Off Internet connection is not ready.
WAN2
Blinking The data is transmitting.
On The router is ready to access Internet
through DSL link.
DSL
Blinking Slowly: The DSL connection is ready.
Quickly: The connection is training.
QoS On The QoS function is active.
WCF On The Web Content Filter is active. (It is
enabled from Firewall >> General
Setup).
On The DoS/DDoS function is active.DoS Blinking It will blink while detecting an attack.
LED on Connector
On The port is connected.
Off The port is disconnected.
Left
LED Blinking The data is transmitting.
On The port is connected with 1000Mbps.
WAN2
(Giga)
Right
LED Off The port is connected with 10/100Mbps

Vigor2860 Series Quick Start Guide
7
On The port is connected.
Off The port is disconnected.
Left
LED Blinking The data is transmitting.
On The port is connected with 1000Mbps.
GigaLAN
1~6
Right
LED Off The port is connected with 10/100Mbps
Interface Description
Wireless LAN
ON/OFF/WPS Press the button and release it within 2 seconds. When the wireless function is ready, the green LED
will be on.
Press the button and release it within 2 seconds to
turn off the WLAN function. When the wireless
function is not ready, the LED will be off.
When WPS function is enabled by web user
interface, press this button for more than 2 seconds to
wait for client’s device making
network connection
through WPS.
Factory Reset Restore the default settings. Usage: Turn on the
router (ACT LED is blinking). Press the hole and
keep for more than 5 seconds. When you see the
ACT LED begins to blink rapidly than usual, release
the button. Then the router will restart with the
factory default configuration.
USB Connecter for a USB device (for 3G/4G USB
Modem or printer).
VDSL2/ADSL Connecter for accessing the Internet.
WAN2 (Giga) Connecter for local network devices or modem for
accessing Internet.
GigaLAN 1-6 Connecters for local network devices.
PWR Connecter for a power adapter.
ON/OFF Power Switch.

Vigor2860 Series Quick Start Guide 8
1
1. .1 1. .4 4 F Fo or r V Vi ig go or r2 28 86 60 0V Vn n- -p pl lu us s
LED Status Explanation
Blinking The router is powered on and running
normally.
ACT (Activity)
Off The router is powered off.
On USB device is connected and ready for use.USB Blinking The data is transmitting.
On Wireless access point with bandwidth of
2.4GHz/5GHz is ready.
2.4G/5G
Blinking It will blink slowly while wireless traffic
goes through.
ACT and WLAN LEDs blink quickly and
simultaneously when WPS is working, and
will return to normal condition after two
minutes. (You need to setup WPS within 2
minutes.)
On Internet connection is ready.
Off Internet connection is not ready.
WAN2
Blinking The data is transmitting.
On The router is ready to access Internet
through DSL link.
DSL
Blinking Slowly: The DSL connection is ready.
Quickly: The connection is training.
On A PSTN phone call comes (in and out).
However, when the phone call is
disconnected, the LED will be off.
Line
Off There is no PSTN phone call.
On The phone connected to this port is
off-hook.
Off The phone connected to this port is
on-hook.
Phone (1-2)
Blinking A phone call comes.
LED on Connector
On The port is connected.
WAN2 Left
LED Off The port is disconnected.

Vigor2860 Series Quick Start Guide
9
Blinking The data is transmitting.
On The port is connected with 1000Mbps.
(Giga) Right
LED Off The port is connected with 10/100Mbps
On The port is connected.
Off The port is disconnected.
Left
LED Blinking The data is transmitting.
On The port is connected with 1000Mbps.
GigaLAN
1~6
Right
LED Off The port is connected with 10/100Mbps

Vigor2860 Series Quick Start Guide 10
Interface Description
Wireless LAN
ON/OFF/WPS Press the button and release it within 2 seconds. When the wireless function is ready, the green LED
will be on.
Press the button and release it within 2 seconds to
turn off the WLAN function. When the wireless
function is not ready, the LED will be off.
When WPS function is enabled by web user
interface, press this button for more than 2 seconds to
wait for client’s device making
network connection
through WPS.
Factory Reset Restore the default settings. Usage: Turn on the
router (ACT LED is blinking). Press the hole and
keep for more than 5 seconds. When you see the
ACT LED begins to blink rapidly than usual, release
the button. Then the router will restart with the
factory default configuration.
USB Connecter for a USB device (for 3G/4G USB
Modem or printer).
VDSL2/ADSL Connecter for accessing the Internet.
WAN2 (Giga) Connecter for local network devices or modem for
accessing Internet.
GigaLAN 1-6 Connecters for local network devices.
Phone 1/2 Connecter for analog phone(s).
Line Connector for PSTN life line.
PWR Connecter for a power adapter.

Vigor2860 Series Quick Start Guide
11
1
1. .1 1. .5 5 F Fo or r V Vi ig go or r2 28 86 60 0a ac c
LED Status Explanation
Blinking The router is powered on and running
normally.
ACT (Activity)
Off The router is powered off.
On USB device is connected and ready for use.USB Blinking The data is transmitting.
On Wireless access point with bandwidth of
2.4GHz/5GHz is ready.
2.4G/5G
Blinking It will blink slowly while wireless traffic
goes through.
ACT and WLAN LEDs blink quickly and
simultaneously when WPS is working, and
will return to normal condition after two
minutes. (You need to setup WPS within 2
minutes.)
On Internet connection is ready.
Off Internet connection is not ready.
WAN2
Blinking The data is transmitting.
On The router is ready to access Internet
through DSL link.
DSL
Blinking Slowly: The DSL connection is ready.
Quickly: The connection is training.
QoS On The QoS function is active.
WCF On The Web Content Filter is active. (It is
enabled from Firewall >> General Setup).
On The DoS/DDoS function is active.DoS Blinking It will blink while detecting an attack.
LED on Connector
On The port is connected.
Off The port is disconnected.
Left
LED Blinking The data is transmitting.
On The port is connected with 1000Mbps.
WAN2
(Giga)
Right
LED Off The port is connected with 10/100Mbps

Vigor2860 Series Quick Start Guide 12
On The port is connected.
Off The port is disconnected.
Left
LED Blinking The data is transmitting.
On The port is connected with 1000Mbps.
GigaLAN
1~6
Right
LED Off The port is connected with 10/100Mbps
Interface Description
Wireless LAN
ON/OFF/WPS Press the button and release it within 2 seconds. When the wireless function is ready, the green LED
will be on.
Press the button and release it within 2 seconds to
turn off the WLAN function. When the wireless
function is not ready, the LED will be off.
When WPS function is enabled by web user
interface, press this button for more than 2 seconds to
wait for client’s device making
network connection
through WPS.
Factory Reset Restore the default settings. Usage: Turn on the
router (ACT LED is blinking). Press the hole and
keep for more than 5 seconds. When you see the
ACT LED begins to blink rapidly than usual, release
the button. Then the router will restart with the
factory default configuration.
USB Connecter for a USB device (for 3G/4G USB
Modem or printer).
VDSL/ADSL Connecter for accessing the Internet.
WAN2 (Giga) Connecter for local network devices or modem for
accessing Internet.
GigaLAN 1-6 Connecters for local network devices.
PWR Connecter for a power adapter.
ON/OFF Power Switch.
