Draytek Vigor 2135 Series User manual

i

ii
Vigor2135 Series
Gigabit Broadband Router
Quick Start Guide
(for RF Model)
Version: 1.3
Firmware Version: V4.4.2.1
(For future update, please visit DrayTek web site)
Date: June 14, 2023

iii
Intellectual Property Rights (IPR) Information
Copyrights © All rights reserved. This publication contains information that is protected
by copyright. No part may be reproduced, transmitted, transcribed, stored in
a retrieval system, or translated into any language without written permission
from the copyright holders.
Trademarks The following trademarks are used in this document:
Microsoft is a registered trademark of Microsoft Corp.
Windows 8, 10, 11 and Explorer are trademarks of Microsoft Corp.
Apple and Mac OS are registered trademarks of Apple Inc.
Other products may be trademarks or registered trademarks of their
respective manufacturers.
Safety Instructions and Approval
Safety
Instructions
Read the installation guide thoroughly before you set up the router.
The router is a complicated electronic unit that may be repaired only be
authorized and qualified personnel. Do not try to open or repair the
router yourself.
Do not place the router in a damp or humid place, e.g. a bathroom.
Do not stack the routers.
The router should be used in a sheltered area, within a temperature
range of 0 to +45 Celsius.
Do not expose the router to direct sunlight or other heat sources. The
housing and electronic components may be damaged by direct sunlight
or heat sources.
Do not deploy the cable for LAN connection outdoor to prevent
electronic shock hazards.
Keep the package out of reach of children.
When you want to dispose of the router, please follow local regulations
on conservation of the environment.
Warranty
We warrant to the original end user (purchaser) that the router will be free
from any defects in workmanship or materials for a period of two (2) years
from the date of purchase from the dealer. Please keep your purchase receipt
in a safe place as it serves as proof of date of purchase. During the warranty
period, and upon proof of purchase, should the product have indications of
failure due to faulty workmanship and/or materials, we will, at our discretion,
repair or replace the defective products or components, without charge for
either parts or labor, to whatever extent we deem necessary tore-store the
product to proper operating condition. Any replacement will consist of a new
or re-manufactured functionally equivalent product of equal value, and will
be offered solely at our discretion. This warranty will not apply if the product
is modified, misused, tampered with, damaged by an act of God, or subjected
to abnormal working conditions. The warranty does not cover the bundled or
licensed software of other vendors. Defects which do not significantly affect
the usability of the product will not be covered by the warranty. We reserve
the right to revise the manual and online documentation and to make changes
from time to time in the contents hereof without obligation to notify any
person of such revision or changes.

iv
Declaration of Conformity
Hereby, DrayTek Corporation declares that the radio equipment type Vigor2135 series router is in
compliance with Directive 2014/53/EU.
The full text of the EU Declaration of Conformity is available at the following internet address:
https://fw.draytek.com.tw/Vigor2135/Document/CE/
Manufacturer: DrayTek Corp.
Address: No.26, Fushing Rd., Hukou, Hsinchu Industrial Park, Hsinchu 303, Taiwan
Product: Vigor2135 Wireless Series
Frequency Information for Europe area:
2.4GHz WLAN For ac model, 2400MHz - 2483MHz, max. TX power: 19.79dBm *1
For ax model, 2400MHz - 2483MHz, max. TX power: 19.81dBm *1
5GHz WLAN For ac model,
5150MHz - 5350MHz, max. TX power: 22.74dBm *2
5470MHz - 5725MHz, max. TX power: 29.88dBm *2
For ax model,
5150MHz - 5350MHz, max. TX power: 22.70dBm *2
5470MHz - 5725MHz, max. TX power: 29.47dBm *2
Requirements in AT/BE/BG/CZ/DZ/DK/EE/FR/DE/IS/IE/IT/EL/ES/
CY/LV/LI/LT/LU/HU/MT/NL/NO/PL/PT/RO/SI/SK/TR/FI/SE/CH/HR.
5150MHz~5350MHz is for indoor use only.
(*1: for 2.4GHz WLAN model; *2: for 5GHz WLAN model)
This product is designed for 2.4GHz /5GHz WLAN network throughout the EC region.
Declaration of Conformity
Hereby, DrayTek Corporation declares that the radio equipment type Vigor2135 series router is in
compliance with Regulation SI 2017 No. 1206.
Manufacturer: DrayTek Corp.
Address: No. 26, Fushing Rd., Hukou, Hsinchu Industrial Park, Hsinchu 303, Taiwan
Product: Vigor2135 Wireless Series
Importer: CMS Distribution Ltd: Bohola Road, Kiltimagh, Co Mayo, Ireland
Frequency Information for UK area:
2.4GHz WLAN For ac model, 2400MHz - 2483MHz, max. TX power: 19.79dBm *1
For ax model, 2400MHz - 2483MHz, max. TX power: 19.81dBm *1
5GHz WLAN For ac model,
5150MHz - 5350MHz, max. TX power: 22.74dBm *2
5470MHz - 5725MHz, max. TX power: 29.88dBm
For ax model,
5150MHz - 5350MHz, max. TX power: 22.70dBm *2
5470MHz - 5725MHz, max. TX power: 29.47dBm
Requirements in UK. 5150MHz~5350MHz is for indoor use only.
(*1: for 2.4GHz WLAN model; *2: for 5GHz WLAN model)
This product is designed for 2.4GHz /5GHz WLAN network use in the UK & Ireland.

v
External Power Supply ErP Information
*The external power supply used for each product will be model dependent.
1 2 3 4 5 6 7 8 9
A Manufacturer CWT CWT CWT CWT CWT APD APD APD APD
B Address No. 222, Sec.
2, Nankan Rd.,
Lujhu
Township,
Taoyuan
County 338,
Taiwan
No. 222, Sec.
2, Nankan Rd.,
Lujhu
Township,
Taoyuan
County 338,
Taiwan
No. 222, Sec.
2, Nankan Rd.,
Lujhu
Township,
Taoyuan
County 338,
Taiwan
No. 222, Sec.
2, Nankan Rd.,
Lujhu
Township,
Taoyuan
County 338,
Taiwan
No. 222, Sec.
2, Nankan Rd.,
Lujhu
Township,
Taoyuan
County 338,
Taiwan
No.5, Lane 83,
Lung-Sou St.,
Taoyuan City
330, Taiwan
No.5, Lane 83,
Lung-Sou St.,
Taoyuan City
330, Taiwan
No.5, Lane 83,
Lung-Sou St.,
Taoyuan City
330, Taiwan
No.5, Lane 83,
Lung-Sou St.,
Taoyuan City
330, Taiwan
2ABB012F UK 2ABB018F UK 2ABL024F UK 2ABL030F UK 2ABN036F UK WA-12M12FG WB-18D12FG WA-24Q12FG WA-36A12FG C Model identifier 2ABB012F EU 2ABB018F EU 2ABL024F EU
2ABL030F EU 2ABN036F EU WA-12M12FK WB-18D12FK WA-24Q12FK WA-36A12FK
D Input voltage 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V
Input AC frequency 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60HzE Output voltage DC 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V
F Output current 1.0A 1.5A 2.0A 2.5A 3.0A 1.0A 1.5A 2.0A 3.0A
G Output power 12.0W 18.0W 24.0W 30.0W 36.0W 12.0W 18.0W 24.0W 36.0W
H Average active
efficiency 84.9% 86.2% 87.6% 87.8% 89.8% 83.7% 85.4% 88.6% 88.2%
I Efficiency at low load
10% 73.6% 78.0% 81.3% 83.3% 83.7% 74.5% 80.5% 86.4% 85.4%
J No-load power
consumption 0.07W 0.07W 0.07W 0.07W 0.07W 0.07W 0.10W 0.07W 0.10W
For more update, please visit www.draytek.com.

vi
Regulatory Information
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device may accept any interference received, including interference that may cause
undesired operation.
RF Exposure Warning
This equipment must be installed and operated in accordance with provided instructions and the
antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20
cm from all persons and must not be co-located or operating in conjunction with any other antenna or
transmitter. End-users and installers must be provided with antenna installation instructions and
transmitter operating conditions for satisfying RF exposure compliance.
Company name ABP International Inc.
Address 13988 Diplomat Drive Suite 180 Dallas TX 75234
ZIP Code 75234 E-mail [email protected]m
USA Local
Representative Contact Person Mr. Henry N Castillo
Tel. [phone]
Caution
Any changes or modifications not expressly approved by the grantee of this device could void the
user's authority to operate the equipment.
The antenna/transmitter should be kept at least 20 cm away from human body.

vii
T
Ta ab bl le e o of f C Co on nt te en nt ts s
1. Package Content .................................................................................................. 1
2. Panel Explanation................................................................................................. 2
2.1 Vigor2135ac, Vigor2135Vac, Vigor2135FVac............................................................................ 2
2.2 Vigor2135ax............................................................................................................................... 5
3. Hardware Installation ........................................................................................... 7
3.1 Network Connection for ac series.............................................................................................. 7
3.2 Network Connection for ax series.............................................................................................. 8
3.3 Wall-Mounted Installation for ac series...................................................................................... 9
3.4 Wall-Mounted Installation for ax series ....................................................................................10
4. Software Configuration.......................................................................................11
5. Customer Service............................................................................................... 17

1
1
1. . P Pa ac ck ka ag ge e C Co on nt te en nt t
Take a look at the package content. If there is anything missed or damaged,
please contact DrayTek or dealer immediately.
Vigor2135ac series Vigor2135ax
RJ-45 Cat-5 Ethernet Cable Antenna (for Vigor2135ac series)
& Quick Start Guide
The type of the power adapter depends on the country that the router will be
installed. * The maximum power consumption is 18 Watts.
UK-type Power Adapter EU-type Power Adapter
USA/Taiwan-type Power Adapter AU/NZ-type Power Adapter
Note
Remove the protective film from the router before use to
ensure ventilation.

2
2
2. . P Pa an ne el l E Ex xp pl la an na at ti io on n
2
2. .1 1 V Vi ig go or r2 21 13 35 5a ac c, , V Vi ig go or r2 21 13 35 5V Va ac c, , V Vi ig go or r2 21 13 35 5F FV Va ac c
LED Status Explanation
Blinking The router is powered on and running normally.
Blinking
(quickly) When both ACT and WLAN LEDs blink quickly, it
means the WPS function is enabled and active. The
system is waiting for a wireless station of
connection.
(Activity)
Off The router is powered off.
On Internet connection is ready.
Blinking The data is transmitting.
WAN Off Internet connection is not ready.
On The phone connected to this port is off-hook.
Off The phone connected to this port is on-hook.
1, 2
(for “V” model) Blinking A phone call comes.
On Wireless access point is ready.
Blinking Ethernet packets are transmitting over wireless LAN.
Blinking
(quickly) When both ACT and WLAN LEDs blink quickly, it
means the WPS function is enabled and active. The
system is waiting for a wireless station of
connection.
~
WLAN
Off The WLAN function is inactive.
On The LAN port is connected.
Blinking The data is transmitting.
~
LAN1/2/3/4 Off The LAN port is disconnected.
On A USB device is connected and active.
USB Blinking The data is transmitting.

3
C
Co on nn ne ec ct to or rs s
Interface Description
Wireless LAN
ON/OFF/WPS WLAN On - Press the button and release it within 2 seconds. When the wireless function is ready, the green LED will be on.
WLAN Off - Press the button and release it within 2 seconds to turn
off the WLAN function. When the wireless function is not ready, the
LED will be off.
WPS - When WPS function is enabled by web user interface, press
this button for morethan 2 seconds to wait for client’s device making
network connection through WPS.
Factory Reset Restore the default settings.
Usage: Turn on the router (ACT LED is blinking). Press the hole and
keep for more than 5 seconds. When you see the ACT LED begins to
blink rapidly than usual, release the button. Then the router will
restart with the factory default configuration.
USB1~USB2 Connector for a USB device (USB Modem or printer).
P4~P1 Connectors for local networked devices.

4
WAN
Connector for remote networked devices (by Ethernet cable).
WAN (FVac)
Connector for fiber connection for accessing the Internet.
Phone2/Phone1
(for “V” model) Connector of analog phone for VoIP communication.
ON/OFF Power switch.
PWR Connector for a power adapter.

5
2
2. .2 2 V Vi ig go or r2 21 13 35 5a ax x
LED Status Explanation
Off The system is not ready or is failed.
Blinking The system is ready and can work normally.
ACT Blinking with WLAN WPS is enabled and waiting for the response
from the wireless client.
On Internet connection is ready.
Blinking The data is transmitting.
WAN Off Internet connection is not ready.
Off Wireless function is not ready.
On Wireless function is ready.
Blinking Data is transmitting (sending/receiving).
WLAN Blinking with WLAN WPS is enabled and waiting for the response
from the wireless client.
On A USB device is connected and active.
USB Blinking The data is transmitting.

6
Interface Description
WLAN
ON/OFF
WPS
Wireless band will be switched /changed
according to the button pressed and released.
For example,
2.4G (On) and 5G (On) – in default.
2.4G (Off) and 5G (On) – pressed and
released the button once.
2.4G (On) and 5G (Off) – pressed and
released the button twice.
2.4G (Off) and 5G (Off) – pressed and
released the button three times.
WPS - When WPS function is enabled by web
user interface, press this button for more than 2
seconds. The router will wait for any wireless
client connecting to it through WPS.
Power switch.
PWR: Connecter for a power adapter.
LAN P4-P1
Connectors for local networked devices.
Left LED on - The port is connected.
Left LED off - The port is disconnected.
Left LED Blinking - The data is transmitting.
Right LED on -The port is connected with
1000Mbps.
Right LED off - The port is connected with
10/100 Mbps.
WAN
Connector for accessing the Internet.
Left LED on - The port is connected.
Left LED off - The port is disconnected.
Left LED Blinking - The data is transmitting.
Right LED on -The port is connected with
1000Mbps.
Right LED off - The port is connected with
10/100 Mbps.
USB
Connector for USB devices (for 3G/4G USB
Modem or printer).
Factory
Reset
Restore the default settings. Usage: Turn on the
router. Press the button and keep for more than
10 seconds. Then the router will restart with the
factory default configuration.

7
3
3. . H Ha ar rd dw wa ar re e I In ns st ta al ll la at ti io on n
This section will guide you to install the router through hardware connection and
configure the router’s settings through web browser.
3
3. .1 1 N Ne et tw wo or rk k C Co on nn ne ec ct ti io on n f fo or r a ac c s se er ri ie es s
Before starting to configure the router, you have to connect your devices
correctly. Here we take Vigor2135ac as an example.
1. Connect the cable Modem/DSL Modem/Media Converter to any WAN port of
router with Ethernet cable (RJ-45).
2. Connect one port of 4-port switch to your computer with a RJ-45 cable. This
device allows you to connect 4 PCs directly.
3. Connect one end of the power cord to the power port of this device.
Connect the other end to the wall outlet of electricity.
4. Connect detachable antennas to the router. Power on the router.
5. Check the ACT and WAN, LAN LEDs to assure network connection.
(For the detailed information of LED status, please refer to section 2. Panel
Explanation)

8
3
3. .2 2 N Ne et tw wo or rk k C Co on nn ne ec ct ti io on n f fo or r a ax x s se er ri ie es s
1. Connect the cable Modem/DSL Modem/Media Converter to any WAN port of
router with Ethernet cable (RJ-45).
2. Connect one port of 4-port switch to your computer with a RJ-45 cable. This
device allows you to connect 4 PCs directly.
3. Connect one end of the power cord to the power port of this device.
Connect the other end to the wall outlet of electricity.
4. Power on the router.
5. Check the ACT and WAN LEDs to assure network connection.

9
3
3. .3 3 W Wa al ll l- -M Mo ou un nt te ed d I In ns st ta al ll la at ti io on n f fo or r a ac c s se er ri ie es s
Vigor2135 series has keyhole type mounting slots on the underside.
1. Drill two holes on the wall. The distance between the holes shall be 168mm.
2. Fit screws into the wall using the appropriate type of wall plug.
3. With the screws installed, the router can be slotted into place.
Note
The recommended drill diameter shall be 6.5mm (1/4”).
4. When you finished about procedure, the router has been mounted on the
wall firmly.

10
3
3. .4 4 W Wa al ll l- -M Mo ou un nt te ed d I In ns st ta al ll la at ti io on n f fo or r a ax x s se er ri ie es s
Vigor router has keyhole type mounting slots on the underside.
1. Drill two holes on the wall. The distance between the holes shall be
100.75mm. The recommended drill diameter shall be 6.5mm (1/4”).
2. Fit screws into the wall using the appropriate type of screw plug.
3. Hang the Vigor router directly onto the screws.

11
4
4. . S So of ft tw wa ar re e C Co on nf fi ig gu ur ra at ti io on n
To access Internet, please finish basic configuration after completing the
hardware installation.
The Quick Start Wizard is designed for you to easily set up your router for
Internet access. You can directly access the Quick Start Wizard via Web
Configurator.
1. Make sure your PC connects to the router correctly.
Note You may either simply set up your computer to get IP dynamically
from the router or set up the IP address of the computer to be the
same subnet as the default IP address of Vigor router
192.168.1.1. For the detailed information, please refer to the
section - Trouble Shooting in the User’s Guide.
2. Open a web browser on your PC and type http://192.168.1.1. A pop-up
window will open to ask for username and password. Please type
“admin/admin” as the Username/Password and click Login.

12
3. Now, the Main Screen will pop up. Click Wizards>>Quick Start Wizard.
Note The home page will change slightly in accordance with the router
you have.
4. Enter the login password on the field of New Password and retype it on the
field of Confirm Password. Then click Next to continue.

13
5. On the next page as shown below, please select the WAN interface that you
use and click Next. If Ethernet interface is used, please choose WAN1; if 3G
USB modem is used, please choose WAN3. Then click Next for next step.
6. On the next page as shown below, please select the appropriate protocol
according to the information from your ISP. For example, you should
select PPPoE mode if the ISP provides you PPPoE interface. Then click Next
for next step.
