Draytek Vigor2300 Setup guide

1
1
1
2
2
2
2
3
4
4
5
6
8
12
13
14
15
15
16
17
17
Chapter 0. Preface
Chapter 1. Getting Started
Chapter 2. Installation & Setup
......................................................................
......................................................................
.............................................................
.............................................................................
............................................
....................................................................
.................................................................................
............................................
........................................................
.............................................................................
...........................................................
....................................
.....................................................................
..................................................
...................................................
...............................................................
..............................................
...................................................................................
0.1 About This Guide
0.2 Copyright Declarations
0.3 Trademarks
0.4 How To Become A Registered Owner
0.5 Safety Instructions
0.6 Warranty
0.7 European Community Declarations
1.1 Introduction
1.2 Unpacking Your Package
1.3 Front Panels , Back Panels & Side Panels.
1.4 Detailed Features
2.1 Typical Connection to Network
2.2 Configure Your Router
2.3 Configure Your Broadband Access
Further Help
A
B
C
. PPPoE Setup
. PPTP Setup
. Static IP User and Dynamic IP(DHCP Client)
.........................................................................
...........................................................................
............................
Table of Contents

Preface
1
0.1 About This Guide
0.2 Copyright Declarations
0.3 Trademarks
0.4 How To Become A Registered Owner
0.5 Safety Instructions
0.6 Warranty
0.7 European Community Declarations
This manual is designed to assist users in using the router. Information
in this document has been carefully checked for accuracy; however, no
guarantee is given as to the correctness of the contents. The information
contained in this document is subject to change without notice. Should
you have any inquiries, please feel free to contact our support via E-mail,
Fax or phone. For latest product info and features, please visit our
website at .
Copyright 2002 DrayTek Corporation. All rights reserved. This
publication contains information that is protected by copyright.
No part may be reproduced, transmitted, transcribed, stored in
a retrieval system, or translated into any language without written
permission from the copyright holders.
0.1 About This Guide
0.2 Copyright Declarations
www.draytek.com.tw

Microsoft is a registered trademark of Microsoft Corp. Windows,
Windows 95, 98, 98SE, Me, NT, XP and 2000 are trademarks of
Microsoft Corp. Other trademarks and registered trademarks of
products referred to in this manual are the properties of their
respective owners.
Web registration is preferred. Please visit our website. Alternatively, fill in
the registration card and mail it to the address found on the reverse side
of the card. Registered owners will receive future product and update
information.
Please read the installation guide thoroughly before you set up the
router.
The router is a complicated electronic unit that may be repaired only
be authorized and qualified personnel. Do not try to open or repair
the router yourself.
Do not place the router in a damp or humid place, e.g. a bathroom.
The router should be used in a sheltered area, within a temperature
range of +5 to +40 Celsius.
Do not expose the router to direct sunlight or other heat sources.
The housing and electronic components may be damaged by direct
sunlight or heat sources.
Keep the package out of reach of children.
When you would like to dispose of the router, please follow the local
regulations on conservation of the environment.
We warrant to the original end user (purchaser) that the routers will
be free from any defects in workmanship or materials for a period of
three (3) years from the date of purchase from the dealer. Please keep
your purchase receipt in a safe place as it serves as proof of date of
purchase.
During the warranty period, and upon proof of purchase, should the
product have indications of failure due to faulty workmanship and/or
0.3 Trademarks
0.4 How To Become A Registered Owner
0.5 Safety Instructions
0.6 Warranty







2

Hereby, DrayTek Corporation declares that the router is in compliance
with the essential requirements and other relevant provisions of R&TTE
Directive 99/5/EC.
0.7 European Community Declarations
materials, we will, at our discretion, repair or replace the defective
products or components, without charge for either parts or labor, to
whatever extent we deem necessary to restore the product to proper
operating condition. Any replacement will consist of a new or re-
manufactured functionally equivalent product of equal value, and will
be offered solely at our discretion. This warranty will not apply if the
product is modified, misused, tampered with, damaged by an act of
God, or subjected to abnormal working conditions.
The warranty does not cover the bundled or licensed software of other
vendors. Defects which do not significantly affect the usability of the
product will not be covered by the warranty.
We reserve the right to revise the manual and online documentation
and to make changes from time to time in the contents hereof without
obligation to notify any person of such revision or changes.
3

Getting Started
4
The Vigor2300 router provides multiple users with efficient and reliable
access over a DSL line, or Cable Modem service to the Internet and
corporate LAN for using E-mail, sharing documents, Web surfing, file
transfers, etc.
The broadband access protocol supports PPPoE, PPTP, Dynamic IP(DHCP)
and Static IP. These protocols comply with worldwide
Ethernet-based DSL/Cable Modem standards.
More than that, it also provides firewall and Virtual Private Networking
(VPN) features to protect your local area network when connecting to
the Internet.
1.1 Introduction
1.2 Unpacking Your Package
1.3 LED Indicators & Back Panels
1.4 Detailed Features
1.1 Introduction

5
Your Vigor2300 router package should contain the items listed below.
If any item is missing or damaged, contact your dealer or DrayTek
Customer Service Department immediately.
1.2 Unpacking Your Package
For Euro / China Users
One Quick Start Guide with warranty
/registration card
One CD-ROM; includes User Manual
in electronic form, released firmware,
and utilities
Quick Start Users Guide
One Ethernet LAN cable (blue) for
connection to a computer or hub
Ethernet LAN Cable (RJ-45 Cable)
One AC/DC power adapter (black),
AC100-240V, input DC5V/2.8A output
for the router be used in EU and China
One AC/DC power adapter (black),
AC100-240V, input DC5V/2.4A output
for the router be used in Ireland and the
UK
One AC/DC power adapter (black),
AC100-240V, input DC5V/2.8A
output for the router be used in the
America and Taiwan
For American / Taiwan Users
For UK Users
CD (Driver)

6
1.3 Front Panels, Back Panels & Side Panels
The front panel provides LED for device status. Refer to the following
table for the meaning of each feature.
Link/Act
Link/Act
Wide Area Network port status. When connected
to the broadband device, the ADSL/Cable
modem, this LED should be on.
Local Area Network port status. A steady LED
indicates a connection between computers on your
LAN. A flickering LED indicates data transmission.
100Mbps
Speed status of the WAN connection.
A steady LED indicates 100Mbps speed.
If the Link light is on and the 100 light is off,
the speed is 10Mbps.
100Mbps
Speed status of the Ethernet connection.
A steady LED indicates 100Mbps speed.
If the Link light is on and the 100 light is off,
the speed is 10Mbps.
VPN connection status. A steady LED indicates
VPN connection is up.
VPN
Printer Printer port status. A steady LED indicates the
printer is connected.
WAN
Ethernet
1-4
Online Online status of the Vigor2300. A steady LED
indicates the Internet access is available
Operation status of the Vigor2300. After start
up, the LED will blink once every two seconds
to indicate proper operation.
System

7
Printer Port
The printer port is located on the right side of the Vigor2300. Use a
printer cable to connect to your printer.
Side Panel
Back Panel
For connection the Vigor2300 to an electrial outlet.
WAN
Power Use this switch to provide power to your Vigor2300.
The RJ-45 Ethernet ports labeled WAN is used to
connect your Vigor2300 to your DSL or cable
modem.
Factory
Reset
DC 5V
Resets the configuration to default settings. Refer
to the Appendix for instructions on how to perform
a factory reset.
The RJ-45 Ethernet ports labeled 1-4 are used to
connect your computers using Ethernet cables to
your Vigor2300.
LAN ports
1-4
4X WAN
3X
2X1X
DC5V Factory
Reset
Power

The Vigor2300 router provides many built-in server and
software features to provide a convenient comprehensive solution
for your SOHO network.
For DSL
users, the router has a built-in PPPoE client for establishing a
connection with the ISP. There is no need to install a further PPPoE
driver on your computers.
Some DSL
modems (e.g. Alcatel modems) only provide a PPTP local connection
for an end user computer. The router has a built-in PPTP client for
establishing a connection for your local network. There is no need to
install a PPTP client driver on your computers.
In most
cable modem environments, the router supports a DHCP client on the
WAN port. They can automatically get IP network settings from a cable
head-end access server.
For most dynamic IP users, the client
can update the WAN IP address to the registered DDNS provider when
the WAN IP has been changed.
For the router, the
client can get network time information from the specfied time server
and provide a time base for call scheduling usage.
WAN Features
Point-to-Point Protocol over Ethernet (PPPoE) Client:
Point-to-Point Tunnelling Protocol (PPTP) Client:
Dynamic Host Configuration Protocol (DHCP) Client:
Dynamic DNS (DDNS) Client:
Simple Network Time Protocol (SNTP) Client:
8
1.4 Detailed Features

Network Features
The server
provides an easy-to-configure function for your local IP network. It can
automatically assign IP network configurations for local PCs, such as IP
address, IP netmask, gateway IP address, and Domain Name server etc.
The DNS proxy maintains a
DNS cache, including a mapping table of domain names and IP
addresses. The proxy also remembers DNS query packets sent through
the router and saves them into its own DNS cache. For enhanced speed,
when a DNS query packet enters the router, the proxy searches its local
DNS cache. If matched, the router sends an answer to the host that sent
the DNS query packet. Only unmatched DNS queries require querying a
WAN Domain Name Server.
Multi-NAT
allows multiple SOHO users to concurrently connect to an Internet
Service Provider (ISP) via a single Internet access account or multiple
statically-assigned IP addresses.
Used in most
LAN-to-LAN applications. The RIP protocol exchanges routing
information between routers.
Dynamic Host Configuration Protocol (DHCP) Server:
Domain Name Server (DNS) Proxy:
Mutiple Network Address Translation (Multi-NAT):
Routing Information Protocol (RIP) Support:
9

10
Security Features
The VPN function enables linking of remote Networks via the Internet
through authenticated and secure tunnels.
RAS provides remote dial-in access
services for home workers, branch offices, or telecommuters. The router
offer 10 dial-in user profiles, including an authentication mechanism
through CHAP/PAP and Calling Line Identification (CLID), secure
callback functions, and 16 Lan-to-Lan Dialer Profiles, etc.
When a dial-in user is coming and the user account is not included in
router database. The client will issue a login request which must include
a shared secret with the RADIUS server. These extended accounts will
keep in the server database.
In addition to the built-in NAT mechanism, the router features
another powerful firewall to protect your local network, or to deny
specified local user's access to unauthorized network services.
VPN (Virtual Private Network) with PPTP/L2TP/IPSec
Encryption:
Remote Access Server (RAS):
Remote Authentication Dial-In User Service (RADIUS) Client:
Firewall:

Management Features
A Web browser is the most common tool used to
surf the Internet. You may use or
browser, to configure the router as easily as surfing a website.
The Telnet User Interface (TUI) is an efficient
method of configuring and managing routers. It utilizes a traditional
command-line user interface and is mainly for advanced configuration,
management, and troubleshooting.
The system manager can remotely manage
the routers through an ISDN remote dial-in, or ISDN or DSL/Cable
WAN interface.
The Flash ROM memory saves the router firmware
and configurations, even after power down.
Using this server and the
software, you may easily upgrade to the
latest firmware whenever enhanced features are added.
Web (HTTP) Server:
Telnet Terminal Server:
Remote Management:
Built-in Flash ROM:
Firmware Upgrade (TFTP) Server:
Microsoft Internet Explorer Netscape's
Firmware Upgrade Utility
11

12
1. Connect the router to the power adapter and an Ethernet cable
between a PC and any one of the four ports switch hub in the router.
2. If the PC is set to obtain IP address automatically(recommended),
reboot the PC and ensure that it has obtained an IP address from the
router(you can use Windows winipcfg.exe or ipconfig.exe to check).
The Vigor2300 router uses web configuration, you can use it very easy.
Please follow the instructions closely, step by step.
Preparation
See ' 2.1 Typical Connection to Network '
Installation & Setup
2
2.1 Typical Connection to Network
2.2 Configure Your Router
2.3 Set Up Your Broadband Access

4c 4c
13
2.1 Typical Connection to Network
With a RJ-45 cable, connect the WAN interface to the external
ADSL/Cable modem.
With a RJ-45 Cable, connect one port of 4-port switch to your
computer.
Connect the power cord to the DC-5V port and to the power
source.
Step
Step
Step
Step
1
2
3
4
ADSL/ Cable
modem
RJ-45
Cable
Power
Adapter co dr3
2
RJ-45
Cable
1
4a
LAN
Internet
a. To turn the unit on by the power switch
After start up, check the system LED. It should blink green.
Check the WAN and Ethernet LED to assure network connections.
b.
c.
4b

14
Open your web (e.g. MSIE or Netscape) and enter IP
into the address bar (http://192.168.1.1). The router will ask for a
username and password. There is none by default, so just press .
Once pass the password prompt, you will now see the router main menu:
When you go into the web, please click on Wireless LAN Setup.
address of the router
OK
2.2 Configure Your Router

15
From the main menu and find "Quick Setup" Section.
Click on Internet Access Setup.
Check Enable to enable the PPPoE client and enter ISP information.
A. PPPoE Setup:
2.3 Configure Your Broadband Access

16
B. PPTP Setup:
Check Enable to enable a PPTP client to establish a tunnel to DSL modem.
PPTP Server IP address: Specifies the IP address of the PPTP-
enabled DSL modem.

17
C. Static IP User and Dynamic IP(DHCP Client):
enableSelect to turn on the broadband access capability
In this application, you receive a fixed public IP address or a public
subnet from your ISP and you should choose an IP address to assign to
the LAN2/WAN interface.
But the most cases, the only setting you need to make is to check Obtain
an IP address automatically.
Please refer to the detailed manual on the supplied DrayTek CD.
If you have further questions, please contact your own DrayTek dealer.
Further Help
