Draytek Vigor2620PVn Series User manual

Vigor2620PVn series
Router
Quick Start Guide
Version: 1.0
Firmware Version: V3.8.9_RC5
(For future update, please visit DrayTek web site)
Date: September 21, 2018

Intellectual Property Rights (IPR) Information
Safety Instructions and Approval
Safety
Instructions
Read the installation guide thoroughly before you set up the router.
The router is a complicated electronic unit that may be repaired only be
authorized and qualified personnel. Do not try to open or repair the
router yourself.
Do not place the router in a damp or humid place, e.g. abathroom.
Do not stack the routers.
The router should be used in a sheltered area, within atemperature
range of +5 to +40 Celsius.
Do not expose the router to direct sunlight or other heat sources. The
housing and electronic components may be damaged by direct sunlightor
heat sources.
Do not deploy the cable for LAN connection outdoor to prevent electronic
shock hazards.
Keep the package out of reach of children.
When you want to dispose of the router, please follow local regulations on
conservation of the environment.
Warranty We warrant to the original end user (purchaser) that the router will be free
from any defects in workmanship or materials for a period of two (2) years
from the date of purchase from the dealer. Please keep your purchase receipt
in a safe place as it serves as proof of date of purchase. During the warranty
period, and upon proof of purchase, should the product have indications of
failure due to faulty workmanship and/or materials, we will, at our discretion,
repair or replace the defective products or components, without charge for
either parts or labor, to whatever extent we deem necessary tore-store the
product to proper operating condition. Any replacement will consist of a new
or re-manufactured functionally equivalent product of equal value, and will
be offered solely at our discretion. This warranty will not apply if theproduct
is modified, misused, tampered with, damaged by an act of God, or subjected
to abnormal working conditions. The warranty does not cover the bundled or
licensed software of other vendors. Defects which do not significantly affect
the usability of the product will not be covered by the warranty. We reserve
the right to revise the manual and online documentation and to make changes
from time to time in the contents hereof without obligation to notify any
person of such revision or changes.
© All rights reserved. This publication contains information that is protected
by copyright. No part may be reproduced, transmitted, transcribed, stored in
a
retrieval system, or translated into any language without written
permission
from the copyright
holders.
The following trademarks are used in this document:
Microsoft is a registered trademark of Microsoft Corp.
Windows, Windows 95, 98, Me, NT, 2000, XP, Vista, 7, 8 and Explorerare
trademarks of Microsoft Corp.
Apple and Mac OS are registered trademarks of Apple Inc.
Other products may be trademarks or registered trademarks oftheir
respective manufacturers.
Copyrights
Trademarks

Hereby, DrayTek Corporation declares that the radio equipment type Vigor2620 is in compliance with
Directive 2014/53/EU.
The full text of the EU Declaration of Conformity is available at the following internet address:
http://www.draytek.com.tw/ftp/Vigor2620/Document/CE/
Manufacturer: DrayTek Corp.
Address: No. 26, Fu Shing Road, HuKou Township, HsinChu Industrial Park, Hsin-Chu County,
Taiwan 303
Product: Vigor2620PVn series
USA Local
Representative
Company name
ABP International Inc.
Address
13988 Diplomat Drive Suite 180 Dallas TX 75234
ZIP Code
75234
E-mail
[e-mail]
Contact Person
Mr. Robert
Messer
Tel.
19728311600
Frequency Information for Europe area:
2.4G WLAN
2412MHz - 2472 MHz, max. TX power: 19.98dBm *1
Requirements in AT/BE/BG/CZ/DZ/DK/EE/FR/DE/IS/IE/IT/EL/ES/
CY/LV/LI/LT/LU/HU/MT/NL/NO/PL/PT/RO/SI/SK/TR/FI/SE/CH/
UK/HR. 5150MHz~5350MHz is for indoor use only.
(*1: for 2.4G WLAN model; )
This product is designed for POTS, DSL and 2.4GHz WLAN network throughout the EC region.
Declaration of Conformity

Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device may accept any interference received, including interference that may cause
undesired operation.
Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
The antenna/transmitter should be kept at least 20 cm away from human body.
DrayTek Vigor2620PVn series VDSL2/ADSL2+ routers are compliant with 47 C.F.R. Part
68.
More update, please visit www.draytek.com.
Frequency Information for FCC:
2.4G WLAN
2412MHz - 2462 MHz,
Regulatory Information

Be a Registered Owner
Web registration is preferred. You can register your Vigor router via http://www.draytek.com.
Firmware & Tools Updates
Due to the continuous evolution of DrayTek technology, all routers will be regularly upgraded.
Please consult the DrayTek web site for more information on newest firmware, tools and
documents. http://www.draytek.com

Table of Contents
1. Introduction............................................................................................................1
2. Package Content ...................................................................................................2
3. Panel Explanation..................................................................................................3
3.1 Vigor2620................................................................................................................................... 3
3.2 Vigor2620n...............................................................................................................................................................5
4. Hardware Installation ............................................................................................7
4.1 Network Connection via DSL..................................................................................................... 8
4.2 Wall-Mounted Installation........................................................................................................... 9
5. Software Configuration.......................................................................................10
5.1 Quick Start Wizard for Network Connection............................................................................. 10
6. Customer Service................................................................................................13

1. Introduction
Vigor2620 series is a VDSL2 router with multi-subnet for secure and efficient
workgroup management. It integrates IP layer QoS, NAT session/bandwidth
management to help users control works well with large bandwidth.
By adopting hardware-based VPN platform and hardware encryption of
AES/DES/3DES, and hardware key hash of SHA-1/MD5, the router increases the
performance of VPN greatly and offers several protocols (such as
IPSec/PPTP/L2TP).
The object-based design used in SPI (Stateful Packet Inspection) firewall allows
users to set firewall policy with ease. CSM (Content Security Management)
provides users control and management in IM (Instant Messenger) and P2P (Peer
to Peer) more efficiency than before. In addition, DoS/DDoS prevention and
URL/Web content filter strengthen the security outside and control inside.

2. Package Content
Take a look at the package content. If there is anything missed or damaged,
please contact DrayTek or dealer immediately.
Vigor Router
RJ-45 to RJ-45 Cable
(Annex B)

RJ-11 to RJ-
45 Cable (Annex B) RJ-11 to RJ-11 Cable (Annex A)
Quick Start Guide
The type of the power adapter depends on the country that the router will be
installed.
UK-type Power Adapter EU-type Power Adapter
USA/Taiwan-type Power Adapter AU/NZ-type Power Adapter

3. Panel Explanation
Vigor2620
LED Status Explanation
Off
The router is powered off.
Blinking
The router is powered on and
running normally.
On
The router is ready to access Internet.
Off
The router is not ready to access Internet.
Blinking
Slowly: The DSL connection is
ready. Quickly:
On
Physical line has been connected.
Blinking
The connection is training.
On
The LAN port is connected.
Blinking
The data is transmitting through the LAN
port.

Interface Description
Factory Reset
Restore the default settings. Usage: Turn on the router
(ACT LED is blinking). Press the hole and keep for more
than 5 seconds. When you see the ACT LED begins to
blink rapidly than usual, release the button. Then the
router will restart with the factory default configuration.
DSL
Connecter for accessing the Internet.
LAN P2-P1
Connecters for local network devices.
ON/OFF Power Switch.
PWR Connecter for a power adapter.

Vigor2620n
LED Status Explanation
Off
The router is powered off.
Blinking
The router is powered on and
running normally.
On
The router is ready to access Internet.
Off
The router is not ready to access Internet.
Blinking
Slowly: The DSL connection is
ready. Quickly:
On
Physical line has been connected.
Blinking
The connection is training.
On
The LAN port is connected.
Blinking
The data is transmitting through the LAN
port.
On
(Green)
Vigor device is ready for sending
wireless signal.
Off
No wireless signal is sent out.
Blinking
(Orange)
Blinks with one second cycle for two
minutes. The WPS function is active.
Blinking
(Green)
The data is transmitting via
wireless connection.

Interface Description
Wireless LAN
ON/OFF/WPS 
Press the button and release it within 2 seconds.
When the wireless function is ready, the green LED
will beon.
Press the button and release it within 2 seconds to
turn off the WLAN function. When the wireless
function is not ready, the LED will be off.
When WPS function is enabled by web user
interface, press this button for more than 2
seconds to wait for
client’s device making network connection through
WPS.
Factory Reset
Restore the default settings. Usage: Turn on the router
(ACT LED is blinking). Press the hole and keep for more
than 5 seconds. When you see the ACT LED begins to
blink rapidly than usual, release the button. Then the
router will restart with the factory default
configuration.
DSL
Connecter for accessing the Internet.
LAN P2-P1
Connecters for local network devices.
ON/OFF Power Switch.
PWR Connecter for a power adapter.

4. Hardware Installation
This section will guide you to install the router through hardware connection and
configure the router’s settings through web browser.
Before starting to configure the router, you have to connect your devices
correctly.

Network Connection via DSL
1. Connect the DSL interface to the external ADSL splitter with an ADSLline
cable.
2. Connect one port of 4-port switch to your computer with a RJ-45 cable. This
device allows you to connect 4 PCs directly.
3. Connect one end of the power cord to the power port of this device.
Connect the other end to the wall outlet of electricity.
4. Power on the router.
5. Check the ACT and ADSL2+, LAN LEDs to assure networkconnections.

4.2 Wall-Mounted Installation
Vigor router has keyhole type mounting slots on the underside.
1. A template is provided on the Vigor router packaging box to enable youto
space the screws correctly on the wall.
2. Place the template on the wall and drill the holes according tothe
recommended instruction.
3. Fit screws into the wall using the appropriate type of wallplug.
Note The recommended drill diameter shall be 6.5mm (1/4”).
4. When you finished about procedure, the router has been mounted onthe
wall firmly.

5. Software Configuration
To access Internet, please finish basic configuration after completing the
hardware installation.
5.1 Quick Start Wizard for Network Connection
The Quick Start Wizard is designed for you to easily set up your router for
Internet access. You can directly access the Quick Start Wizard via Web User
Interface. Make sure your PC connects to the router correctly.
Note You may either simply set up your computer to get IP dynamically from
the router or set up the IP address of the computer to be the same
subnet as the default IP address of Vigor router 192.168.1.1. For the
detailed information, please refer to - Trouble Shooting of the user’s
guide.
Open a web browser on your PC and type http://192.168.1.1. A pop-up window
will open to ask for username and password. Please type “admin/admin” as the
Username/Password and click Login.
Note If you fail to access to the web configuration, please go to “Trouble
Shooting” on User’s Guide for detecting and solving your problem.

Now, the Main Screen will pop up. Click Wizards>>Quick Start Wizard.
Note The home page will change slightly in accordance with the router you
have.
1. If your router can be under an environment with high speed NAT, the
configuration provide here can help you to deploy and use the router quickly.
The first screen of Quick Start Wizard is entering login password. After
typing the password, please click Next.
2. On the next page, please select the WAN interface that you use. IfDSL
interface is used, please choose WAN1;

3. Click Next to go to the following page.

4. Manually enter SIM PIN code and SPM Name provided by your ISP. Thenclick
Next for viewing summary of such connection.
5. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then,
the system status of this protocol will be shown.
6. Now, you can enjoy surfing on the Internet.
6. Customer Service
If the router cannot work correctly after trying many efforts, please contact your
dealer for further help right away. For any questions, please feel free tosend
e-mail to [e-mail].
