Dreame RAW4 User manual

Water Hookup Kit for Auto Refilling and Draining
The illustrations in this manual are for reference only.
Please refer to the actual product.
Installation Guide

SCAN THE QR CODE
TO GET THE
STEP-BY-STEP INSTRUCTIONS
Get the
Installation Video

001
027
105
053
131
157
209
261
Installation Guide
EN
Installationsanleitung
DE
Asennusopas
FI
Installationsvejledning
DK
Guide d'installation
FR
Guida all'installazione
IT
Installasjonsveiledning
NO
Guia de Instalação
PT
079Guía de instalación
ES
183Installatiehandleiding
NL
235Instrukcja montażu
PL
287Installationsmanual
SV
313Kurulum Kılavuzu
TR

1
EN Safety Information
Usage Restrictions
WARNING
· This product should not be used by children younger than 8 years old nor persons with physical, sensory,
intellectual deficiencies, or limited experience or knowledge without the supervision of a parent or guardian
to ensure safe operation and to avoid any risks. Cleaning and maintenance shall not be performed by children
without supervision.
· The input terminals of the water hookup kit can only be connected to the designated DC power supply output
terminals of the base station.
· Use only with compatible base station. This product is for floor cleaning in a home environment only. Do not use
it outdoors, on non-floor surfaces, or in a commercial or industrial setting.
· The water hookup kit should be connected to the water source using the new pipe assembly included in the
package. Do not reuse old pipe assembly.
· Before disassembling or installing the water hookup kit and its accessories, make sure that both the water
hookup kit and the base station are not connected to the power supply.
To avoid electric shock, re or injury caused by improper use of the appliance, please read the user
manual carefully before using the appliance and keep it for future reference.

2
EN
Safety Information
Usage Restrictions
· Add only water and the official cleaning solution, no other cleaning solutions (such as alcohol, disinfectant,
etc.) are allowed to be added. Keep the cleaning solution out of reach of children.
· Children shall not play with the water hookup kit or its accessories. Please keep the disassembled package
properly and do not allow children to touch or swallow it.
· Please do not disassemble, repair or modify the water hookup kit, if anything, please contact the after-sales
service team.
· Please do not use unofficial or damaged solenoid valve wire, otherwise it may lead to smoke, heat, fire and
other dangerous situations. If the solenoid valve wire is damaged, please stop using it immediately and
contact the after-sales service team in time.
· When the water hookup kit needs to be transported, please empty the water hookup kit and it is recommended
to use the original packaging.
· Please use the water hookup kit in accordance with the instructions in the manual, any loss and injury caused
by improper use shall be borne by the user.
· Pre-delivery inspection may leave residual water, please rest assured that it is safe to use.

3
EN
Used Water Tank Clean Water Tank
Product Overview
3-Way Diverter
Valve（G3/8）
Packing List
3/8" Elbow (thick)
Ⓐ Ⓑ Ⓕ
Ⓓ ⒺⒸ
Ⓖ Ⓗ
Fixing Base
1/4" Elbow (thin)
Clean Water Pipe
Adapter Assembly
Used Water Pipe
Adapter Assembly
×2

4
EN
Product Overview
3/8" Used
Water Pipe (thick)
1/4" White Clean
Water Pipe (thin) Spiral Cable Wrap Wire Organizer
1/4" Blue Clean
Water Pipe (thin)
Controller Assembly
(Solenoid Valve Connector)
Packing List
ⓁⒿ ⓀⒾ
Ⓜ Ⓝ Ⓞ Ⓟ Ⓠ
3/8" Connection
Locking Clip (big)
1/4" Connection
Locking Clip (small) Pipe Fixing Clip
×7 ×7

5
EN
Water PipeUsed Water Filter Clean Water Filter
Clean Water Tank & Used Water Tank
Float Ball
Clean Water Tank Ⓑ
Clean Water Tank Ⓑ
Used Water Tank Ⓐ
Used Water Tank Ⓐ
Sealing Cover
Carrying Handle
Cleaning Solution Adding Inlet
Sealing Cover
Release Clips
Cleaning Solution
Bottle Installation Slot
Product Overview

6
EN
Completed Installation
Note:
The illustrations in this manual are for reference only. Please refer to the actual installation situation.
1/4" Elbow
(thin) Ⓕ
3/8" Elbow
(thick) Ⓖ
Spiral Cable
Wrap Ⓟ
1/4" White
Clean Water
Pipe (thin) Ⓝ
Clean Water Pipe Adapter Assembly Ⓓ
Used Water Pipe Adapter Assembly Ⓔ
Solenoid Valve Connector Ⓘ
3-Way Diverter Valve Ⓗ
1/4" Blue Clean
Water Pipe (thin) Ⓞ
Angle Valve/
Water Source
3/8" Used Water Pipe
(thick) Ⓜ
Pipe Fixing Clip Ⓛ
Controller Assembly Ⓘ
Floor Drain
3/8" Elbow (thick) Ⓖ
1/4" White Clean
Water Pipe (thin) Ⓝ
Product Overview

7
EN
Location Requirements
Installation Precautions
·The size of the 3-way diverter valve in the package is G3/8. If the size does
not match, please purchase a suitable adapter separately.
·Use a water pressure gauge to measure the water pressure and confirm
that it is between 0.14 MPa and 1 MPa.
·Close the main water valve in your home before installation and make sure
all the water in the pipes has been drained.
·Do not connect the water hookup kit to a hot water source.
·Before installation, please unplug the base station and make sure the base
station is not connected to the power supply.
·Installation location needs to avoid direct sunlight and water.
·The location is recommended to be close to the water source and floor
drain.
·It is recommended that the distance between the base station and the
socket be within 1.5 m.
·Remove any objects that are closer than 1.5 m from the front and 5 cm from
either side of the base station.
·There should be no threshold higher than 2 cm near the installation area.
(If the threshold height is 2-3.5 cm, the official threshold ramp needs to be
purchased separately)
·Place the base station in a location with a good 2.4 GHz Wi-Fi signal.
Installation Instruction

8
EN
Installation Instruction
Monkey WrenchTape MeasureScrewdriver
Flat Screwdriver
Knife
Necessary Tools (not supplied)
Te󶀅on Tape Angle Valve
≥ 12 cm

9
EN
Cove of
Storage Bin
1. Open the upper cover, take out the clean water tank, used water tank
and the cover of storage bin.
2. Remove the 2 󶀄xing screws by a screwdriver and take out the storage bin.
3. Pull out plug a1 and a2, store the parts properly.
4. Place the Fixing Base Ⓒ at the bottom.
Installation Instruction
❶Install the Fixing Base
a2
a1
Step ❶-❷
Fixing Base Ⓒ

10
EN
5. Align the storage bin with the internal structure, install it slowly downward
and make sure its top side is 󶀅ush with the internal structure.
7. Place the Floor Cleaner into the slot of cleaning solution.
6. Tighten the 2 󶀄xing screws by a screwdriver. 8. Reinstall the cover of storage bin.
Installation Instruction

11
EN
Push the Ⓐand Ⓑdownward into place and ensure that they are well
attached.
Installation Instruction
❷ Install the Clean/Used Water Tank ❸ Assemble the Clean/Used Water
Pipe Adapter Assembly
1. Open the back cover on the base station with a
󶀅athead screwdriver. Store the cover properly.
Step ❸
Clean Water Tank Ⓑ Used Water Tank Ⓐ

12
EN
Installation Instruction
Note:
Ensure that the water hookup kit is well attached and cannot be removed
from the base station to avoid the risk of water leakage.
3. Wiping water on the O-ring helps to install Ⓓ and Ⓔ.
2. Tighten the 2 󶀄xing screws by a screwdriver to 󶀄x the water hookup kit to
the base station.
4. Install the Ⓓ and Ⓔuntil they click into place.
Note:
·Make sure the Ⓓand Ⓔare installed securely in place and cannot be pulled out.
·The round button on the parts is the release button, do not press it during
installation.
Used Water Pipe
Adapter AssemblyⒺ
Clean Water Pipe
Adapter Assembly Ⓓ
Click

13
EN
Note:
In order to keep the pipes tidy, use a knife to cut out the appropriate length
of the water pipes before installation.
For other installation methods, please
refer to the following gures:
① Fixed to the Wall Drain
Note:
This part needs to be purchased separately.
② 3-Way Floor Drain Joint
How to Disassemble a Water Pipe
Used Water Pipe
Adapter Assembly Ⓔ
Snap Ring
3/8" Used Water
Pipe (thick) Ⓜ
Floor Drain
Hold the snap ring and pull out the
water pipe forcefully.
Installation Instruction
❹Connect the Used Water Pipe
3/8" Used Water
Pipe (thick) Ⓜ3/8" Elbow
(thick) Ⓖ
3/8" Elbow
(thick) Ⓖ
Step❹-❺

14
EN
❺ Connect the Clean Water Pipe and Controller Assembly
Installation Instruction
1/4" White Clean
Water Pipe (thin) Ⓝ
1/4" Elbow
(thin) Ⓕ
Clean Water Pipe
Adapter Assembly Ⓓ
1/4" Blue Clean Water
Pipe (thin) Ⓞ
3-Way Diverter Valve Ⓗ
Controller Assembly
(Solenoid Valve Connector) Ⓘ
Controller Assembly
(Solenoid Valve Connector) Ⓘ
1/4" White Clean
Water Pipe (thin) Ⓝ

15
EN
Option 1- Water Source with Male Thread Fitting
Completed Installation
Option 1
-With Male Thread Fitting
Option 2
-With Female Thread Fitting
Installation Instruction
❻ Install the 3-way Diverter Valve
Note:
·Close the main water valve in your home before installation and make
sure all the water in the pipes has been drained.
·Check whether the sealing ring is in place before installation. If not, all
the butted male thread fittings need to be firmly wrapped with Teflon
tape 6-9 turns in the direction of screwing to prevent leakage.
·It is recommended to install an angle valve at the water source before
installing the 3-way diverter valve.
·Use a monkey wrench to install if necessary.
Step ❻
Adapter
(purchase separately
if necessary)
3-Way Diverter
Valve Ⓗ
（ G3/8）
Blue Clean Water Pipe
（from controller
assembly）Ⓞ
Angle Valve/
Water Source
（not supplied）

16
EN
Installation Instruction
Option 2 - Water Source with Female Thread Fitting
Angle Valve/Water Source
（not supplied）
Adapter
(purchase separately
if necessary)
Adapter
(purchase separately
if necessary)
Faucet/Plug3-Way Diverter
Valve Ⓗ
（ G3/8）
Blue Clean Water Pipe
（from controller assembly）Ⓞ

17
EN
Install the 1/4" connection locking clip Ⓙ in position ① - ⑥ .
Install the 3/8" connection locking clip Ⓚ in position ⑦ - ⑪.
⑥
④
⑤
⑦
⑧
⑨
⑩
⑪
②
①
Note: Before installation, make sure the water pipe is fully inserted and cannot be pulled out.
③
Installation Instruction
❼Install the Connection Locking Clip
Step ❼-❽
