Dreamline TORERO User manual

TORERO Shower Door Installation Instruction
IMPORTANT
Please read carefully the following instructions before installing your shower door. If you
have any questions regarding shower door installation, please call our technical support
specialists Monday through Friday, 9:00AM – 5:00PM EST at 1-866-731-8378 ext. 3 or e-mail
our technical support group at [e-mail]
DreamLineTM reserves the right to alter, modify or redesign
products at any time without prior notice. For the latest up-to-
date technical drawings, manuals or any other details please
refer to the BathAuthority.com web page.
Rev.1.1 1

Rev.1.1 2
reparationP
1. After opening all boxes and packages, read this introduction carefully. Check that all of
, please, install all of the required
.Please note that you should consult your local building codes with questions on
e tub is leveled and solid and will be able to
the needed parts are included in the package, by marking all the components on the
“Detailed Diagram of Tub Door Components”. Examine boxes and packages for shipping
damage. If the unit has been damaged, has a finishing defect, or has missing parts, please
contact our customer support department within 3 business days of the delivery date.
Please note that DreamLine TM will not replace any damaged products or missing
parts free of charge after 3 business days or if the product has been installed. Feel
free to contact DreamLineTM if you have any questions.
2. If this unit is going to be installed in a new construction
plumbing and drainage before installing the shower. Use a competent and licensed (if
required by local code) plumber for all plumbing installation.
3
installation compliance standards. Building and plumbing codes may vary by
location and DreamLine is not responsible for code compliance standards for your
project.
.Please insure that prior to the installation th4
support the total weight of the unit. Also make sure the walls are at right angles. While
some adjustment in leveling of the door is possible, irregular tub level or improper angle
of side walls will result in serious problems for your installation. Please, note that some
adjustments and drilling might be necessary during the installation process.
5. Please, NOTE! This door does not have out-of-plumb adjustment. Make sure your
walls are at right angles.
Tools Required
Hammer
Electric
Drill
Caulk
Gun
Level
Phillips
Screwdriver
Pencil
Measure
Tape
Caulk
Miter saw or Hacksaw
Drill bit
(Ø=5/16")
Drill bit
(Ø=3/16")

Rev.1.1 3
Detailed Diagram of T b Door Componentsu
1
3
2
4
5
6
7
8
9
10
11
12
13
14
15
Packing List
01 Guide rail lat head bolt M4×10 2pcs1pc 09 F
02 Threshold 1pc 10 Roller 2sets
03 Glass door 1pc 11 Guide block 1pc
04 Handle 1pc 12 Guide rail holder 2pcs
05 Wall anchor 4pcs 13 Bumper Strip 2pcs
06 Countersunk screw ST4.2×18 er2pcs 14 Decorative cov 2pcs
07 Round head screw ST4.2×25 2pcs 15 4mm hex wrench 1pc
08 Round head screw ST4.2×35 4pcs
OTE:N Unpack your unit carefully and inspect it. . Lay it out and identify all parts using the
detailed diagram and packing list in your manual as a reference. Before discarding the carton,
check for small hardware bags that tend to fall to the bottom of the box. If any parts are
damaged or missing, please contact DreamLineTM for replacement.

Rev.1.1 4
Tub Door Installation
.Measure the distance between two
See Fig. 1 for details.
Fig. 1
2. The Guide rail (01) and the Threshold
1
walls. This distance is marked as
“W”.
W
(02) have been precut for the installation
between the walls with a distance of 60”.
If W=60”, then it is unnecessary to cut
the Guide rail with the Threshold and
you can continue to Step 3.
If W<60”, then you will need to cut the
r details.
Fig. 2
Guide rail with the Threshold from one
end to the size of the “W”.
See Fig. 2 and Fig. 3 fo
W
W

Rev.1.1 5
Fig. 3
3. If the Threshold (02) has been cut off
ers of the
side of
ee Fig. 4 for details.
Fig. 4
from the end, you will need to drill
another hole, which is 2” away from
the end of the Threshold.
Drill through the two lay
aluminum using the Ø 3/16” drill bit,
and then enlarge the hole on its first
layer with the Ø 5/16” drill bit.
Apply the caulk to the bottom
the Threshold and secure it to the
shower base or the tub with the
Round head screw ST4.2×25mm
(07).
S
3/8”
4
3
5
2″
Φ5/16”
Ø 3/16”
1
2
6
W
W
