Dreamline Visions User manual

Visions Tub Door & QWALL-TUB Kit
Tub Door AND SHOWER BACKWALLS KIT INSTALLATION
INSTRUCTIONS
IMPORTANT
DreamLineTM reserves the right to alter, modify or redesign products at any time
without prior notice. For the latest up-to-date technical drawings, manuals or any
other details please refer to the support.BathAuthority.com web page.
STEP 1: Install Shower Backwalls
Shower Backwalls Installation Instructions
STEP 2: Install Shower Door
Shower Door Installation Instructions
Please read these instructions carefully before installing. If you have any questions regarding
installation, please call our technical support specialists Monday through Friday 9:00 AM –5:00
PM EST at Phone: [phone], Fax:[phone] or e-mail our technical support
group at [email protected].
For more information on DreamLine Shower Kit please visit www.BathAuthority.com

Rev 1.6 1
VISION
SHOWER DOOR &TUB DOOR INSTALLATION INSTRUCTIONS
IMPORTANT
DreamLineTM reserves the right to alter, modify or redesign products at any time without
prior notice. For the latest up-to-date technical drawings, manuals or any other details
please refer to the support.BathAuthority.com web page.
Please carefully read the instructions before installing. If you have any questions
regarding installation, please call our technical support specialists Monday through Friday
9:00 AM – 5:00 PM EST at 1-866-731-8378, ext. 3 or e-mail our technical support group at
[e-mail].
For more information on DreamLineTM Shower Doors & Tub Doors please visit www.BathAuthority.com

Rev 1.6 2
Preparation
1. After opening all boxes and packages, read this introduction carefully. Check that all of the
needed parts are included in the package, by marking all the components on the “Detailed
Diagram of Shower Door Components”. Examine boxes and packages for shipping damage. If
the unit has been damaged, has a finishing defect, or has missing parts, please contact our
customer support department within 3 business days of the delivery date. Please note that
DreamLine TM will not replace any damaged products or missing parts free of charge
after 3 business days or if the product has been installed. Feel free to contact DreamLineTM
if you have any questions.
2. Please note that you should consult your local building codes with questions on
installation compliance standards. Building and plumbing codes may vary by location,
and DreamLine is not responsible for code compliance standards for your project.
3. Install all of the required plumbing and drainage before securing the shower. Have a competent
and licensed (if required by local code) plumber or tradesman do and/or approve your
plumbing installation.
4. Please insure that prior to the installation the installation surface is leveled and solid and will be
able to support the total weight of the unit. Also make sure the walls are at right angles. While
some adjustment in leveling of the door is possible, irregular installation surface level or
improper angle of side walls will result in serious problems for your installation. Please, note
that some adjustments and drilling might be necessary during the installation process.
Note: If glass has silk, print or molded designs, please make sure that clear side faces inside
the shower
Tools Required
Caulk Tape
Measure Pencil Screwdriver
Phillips
Level Gun
Caulk Drill
Electric Hammer Miter saw or Hacksaw
Drill bit Drill bit
(Ø=5/16") (Ø=1/8")

Rev 1.6 3
Detailed Diagram of Shower Door Components
123
4
5
6
8
9
10
11
12
13
14
15
16
17
7
Packing List
01 Glass profile 2pcs 10 Round head screw ST4.2×30 8pcs
02 Wall profile 2pcs 11 Round head screw ST4.2x25 8pcs
03 Guide rail 2pcs 12 Round head screw ST4.2x10 4pcs
04 Glass door 2pcs 13 Flat head screw ST4.2x15 4pcs
05 Stationary glass 2pcs 14 Decorative cover 4pcs
06 Handle 2pairs 15 Wall anchor 8pcs
07 Magnetic strip 1pair 16 Glass holder 4pcs
08 Anti-water strip 4pcs 17 Wheel assembly 4pairs
09 Single side strip 2pcs
NOTE: Unpack your unit carefully and inspect it. Lay it out and identify all parts using parts
diagram and part list in your manual as a reference. Before discarding the carton, check for
small hardware bags that tend to fall to the bottom of the box. If any parts are damaged or
missing, please contact DreamLineTM for replacement.

Rev 1.6 4
Shower Door Installation
1. Measure the distance between two
walls. This distance is marked as “W”.
See Fig. 1 for details.
Fig. 1
2. Your Guide rails (03) have been
precut for the installation between
the walls with a distance of: 60”
If W=60”, then it is unnecessary to
cut the Guide rails and you can
continue to Step 3.
If W<60”,then you will need to cut
the Guide rails from both ends.
The length to cut off will be L:
L=
See Fig. 2 & Fig. 3 for details.
Fig. 2
L
LL
W
60”−W
2

Rev 1.6 5
Fig. 3
3. If the Guide rails (03) have been cut, you will need to
reinstall the roller stoppers on each Guide rail on both
sides where it has been cut.
Remove existing stopper. Mark the drilling hole with a
distance of 2” from the cut off edge of the Guide rail.
Drill the new hole using Ø 1/8” drill bit; then fasten the
stopper with screw.
ATTENTION:
Do not drill Guide rail throughout, only the first layer.
See Fig. 4 for details
Fig. 4
1
2
Ø1/8”
2”

Rev 1.6 6
4. Fasten the bottom Guide rail (03) to the Glass profiles (01)
with the Round head screws ST4.2x25 (11).
See Fig. 5 for details.
Fig. 5
5. Slide the Stationary glasses (05) fully into the groove of
the Glass profiles (01), and then fasten it by the Glass
holders (16) to the bottom Guide rail (03).
See Fig. 6 for details.
Fig. 6
2
1
3

Rev 1.6 7
6. Slightly tap the Single side strips (09) in between the
Stationary glasses (05) and the Glass profiles (01) using
wooden shim or other piece of wood. The strips should be
inserted from the sides that will face inside the shower.
ATTENTION:
Do not use the screwdriver or other metal objects; you can
scratch or damage the glass and aluminum.
7. Repeat Step #4 and Step #5 to fasten the upper Guide rail
(03) to the Glass profiles and secure the Stationary glasses
by the Glass holders (16).
See Fig. 7 for details.
Fig. 7
8. Slide the Wall profiles (02) all the way onto the Glass profiles
(01) on both sides. Make sure the flanges of the Wall profiles
faces inside the shower.
See Fig. 8 for details.
Fig. 8

Rev 1.6 8
9. Move the finished frame to the designated
position on the shower base, the bathtub or the
threshold (depending on your installation); push it
against the walls. If your top and bottom wall
opening measurements are different or if the
walls are out-of-plumb, make adjustment by
slightly pulling the Wall profiles (02) out of the
Glass Profiles (01).
Use the level to adjust the frame in the vertical
position
See Fig. 9 for details.
Fig. 9
10. Using help to hold this assembly in the right
position, mark the drill holes on the wall through
the holes on the flange of the Wall Profiles (02).
11. Gently set the assembled unit aside; drill the holes
using Ø 5/16” drill bit and insert the Wall anchors
(15).
Apply silicone caulk along the Wall profiles and
around the holes on the wall. Also apply silicone
under the bottom Guide rail (03). Place the whole
shower assembly back into the designated position
and secure it to the walls using the Round head
screws ST4.2×30 (10).
See Fig. 10 for details.
Fig. 10
Ø5/16”
2
1
3
4
5
6

Rev 1.6 9
NOTE: Glass Door (04) comes with
preinstalled Wheel assemblies (17). If not,
please refer to (Fig. 11) for detailed
installation.
12. Fasten the top and the bottom Wheel
assemblies (17) to the Glass door (04). The
top wheels can adjust the door level with the
adjustable bolt and lock nut. The bottom wheel
has a press button to fix the wheel on to the
bottom Guide rail (03).
Note:
The lock nut of the upper wheel and the press
button of the bottom wheel should be
pointing up.
See Fig. 11 for details.
Fig. 11
13. Slide the top door wheels into the
top Guide rail (03). Push the
bottom wheels into the bottom
Guide rail by pressing down the
button on the Wheel assembly.
Use the Phillips screwdriver #2 (do
not use power screwdriver) to
adjust upper wheels, make sure
they move smoothly and the door
closes tight.
See Fig. 12 for details.
Fig. 12
2
1
3
4
5
6
2
1 3
4

Rev 1.6 10
14. Install the Handles (06) to the Glass doors (04).
Press the anti-water strips (08) on the vertical edges of the
Stationary glasses (05) and both vertical edges of the Glass
doors.
Press the Magnetic strips (07) on the vertical edges of both
Glass doors for tight closing.
See Fig. 13 for details.
Fig. 13
15. Do the final adjustments of the assembled unit in the Wall
profiles (02).
Drill the holes in the Glass profile (01) through predrilled holes
in the Wall Profile using Ø 1/8” drill bit.
ATTENTION:
Do not drill the profile throughout, only the first layer of
the wall profile.
Secure the Wall profile to the Glass profile using the Round
head screws ST4.2×10 (12).
Cover the exposed screw heads with the Decorative covers
(14).
See Fig. 14 for details.
Fig. 14
2
1
3
Ø1/8”
2
1
3

Rev 1.6 11
16. Apply the sealant along the profiles and guide rails;
on the seams between the bottom guide rail and
the profiles as well as along the shower base or
threshold.
See Fig. 15 for details.
Fig. 15
Product Maintenance
To insure long lasting life for your acrylic back walls, wipe them off after each use with a soft cloth. To
clean the acrylic back walls use non-abrasive sprays or cream based cleaners. Never use abrasive
cleansers, metal brushes or scrapers that could scratch or dull the surface.
To insure long lasting life for your glass shower products, wipe them off after each use with a soft cloth.
Rinse and wipe of the glass using either soft cloth or squeegee to prevent soap buildup. Never use
abrasive cleaners and cleaning products that contain scoring agent because this may scratch the surface.
Never use bristle brushes or abrasive sponges.
To assure a long lasting finish wipe off the metal parts after each use with a soft cloth. Do not use
abrasive cleaners or cleaning products containing ammonia, bleach or acid. If accidentally used, rinse the
surface as soon as possible to prevent finish peeling or corrosion. After cleaning the shiny finishes, rinse
thoroughly and wipe dry with soft cloth. Clean stainless steel surfaces at least once a week. When
applying stainless steel cleaner or polish, work with (not across) the grain. Never use abrasive sponge or
cloth, steel wool or wired brushes.
Caulk

QWALL TUB
TUB ACRYLIC BACK WALL INSTALLATION INSTRUCTIONS
IMPORTANT
DreamLineTM reserves the right to alter, modify or redesign products at any time
without prior notice. For the latest up-to-date technical drawings, manuals or any
other details please refer to the support.BathAuthority.com web page.
Please carefully read the instructions before installing. If you have any questions
regarding installation, please call our technical support specialists Monday through
Friday 9:00 AM – 5:00 PM EST at 1-866-731-8378, ext. 3 or e-mail our technical support
group at [email protected].
Rev 1.1 1
For more information on DreamLineTM Tub Back Wall please visit www.BathAuthority.com

Preparation
1. After opening all boxes and packages, read this introduction carefully. Check that all of
the needed parts are included in the package, by marking all the components on the
“Detailed Diagram of Tub Back Wall Components”. Examine boxes and packages for
shipping damage. If the unit has been damaged, has a finishing defect, or has missing
parts, please contact our customer support department within 3 business days of the
delivery date. Please note that DreamLine TM will not replace any damaged products or
missing parts free of charge after 3 business days or if the product has been
installed. Feel free to contact DreamLineTM if you have any questions.
2. Please note that you should consult your local building codes with questions on
installation compliance standards. Building and plumbing codes may vary by
location, and DreamLine is not responsible for code compliance standards for your
project.
3. This acrylic wall system is specially designed to be installed over any solid surface. If you
are installing the acrylic walls over the existing tiles, remove all loose tiles before the
installation. If you are installing over the existing painted walls, take all loose paint off.
Please, note that some cutting and drilling might be necessary during the installation
process.
4. Make sure to turn off the water supply, remove faucet, handles or any fixture trims
protruding from the wall. Clean the surface removing soap film and dirt from all wall
surfaces using regular household detergent, then wipe it dry.
Tools Required
Caulk Tape
Measure Pencil
Screwdriver
Phillips
(Ø 5/16")
Drill bit
Level Gun
Caulk Drill
Electric Hammer
Knife T-Square
Rev 1.1 2

Detailed Diagram of Tub Back Wall Components
12
4
3
7
5
8
9
10
6
Packing List
01 Side panel 2pcs 06 Wall anchor 21pcs
02 Back panel 2pcs 07 Countersunk screw ST4.2×30 21pcs
03 Decorative edge molding 2pcs 08 Decorative cover 15pcs
04 Corner cover 2pcs 09 Glass shelf 2pcs
05 Wall cover 1pc 10 Shelf bracket 6pcs
Rev 1.1 3
NOTE: Unpack your unit carefully and inspect it. Lay it out and identify all parts using the
detailed diagram and packing list in your manual as a reference. Before discarding the carton,
check for small hardware bags that tend to fall to the bottom of the box. If any parts are
damaged or missing, please contact DreamLineTM for replacement.

Back Panel Installation Instruction
1. Measure the distance of the back wall
of the tub (corner to corner)
The distance is “W”
See Fig. 1 for details.
Fig. 1
2. Divide the W measurement by 2
(W/2). Place a mark on the back wall
and draw a vertical line from top to
bottom.
See Fig. 2 for details.
Fig. 2
Rev 1.1 4
W
W/2
W/2

3. Measure the side walls from the
corner to the front point where the
Side panel (01) is going to end.
This distance is “D”.
See Fig. 3 for details.
Fig. 3
4. Verify on which side of your tub
wall the fixtures will be installed.
Place a mark on the side wall (NB:
not the side panel!) with a
distance of 1” (one inch) from the
corner and draw a vertical line from
top to bottom.
Take the exact measurements:
•from the fixture to the line:
(A, B, C)
•from the fixture to the bottom:
(E, F).
See Fig. 4 and Fig. 5 for details.
Fig. 4
Rev 1.1 5
D
D
CB
F
E
A
1
”
Trim line
D
D - 1”

Fig. 5
5. Attach the Center cover (05)
vertically at the center point
along the line and mark the
drilling holes through the
predrilled holes on the Center
cover.
Drill the holes using Ø5/16” drill
bit and insert the Wall Anchors
(06).
See Fig. 6 and Fig. 7 for details.
Fig. 6
Rev 1.1 6
Ø5/16”
1
2
3
4

Fig. 7
6. Attach the Corner cover (04)
to the corner of the wall and
mark the drilling holes
through the predrilled holes
on the Corner cover.
Drill the holes using Ø5/16”
drill bit and insert the Wall
Anchors (06).
See Fig. 8 and Fig. 9 for
details
Fig. 8
Rev 1.1 7
1
2
3
4
Ø5/16”

Fig. 9
7. Determine the position of both Back
panels (02).
NOTE:
a) Narrow side of the Back panel
cannot be trimmed and should
face the center of the Back wall.
b) Wide side of the Back panel can
be trimmed to the size of the wall
and should face the corner.
Place a mark on the wide side of the
Back panel with a distance of
(W/2 – 1”) from the center edge of
the Back panel to the wide side of
the Back panel and draw a straight
line from top to bottom.
See Fig. 10 for details.
Fig. 10
Rev 1.1 8
W/2-1”
W/2-1”
b
b
a
