Dressler CESAR 1312 User manual

User Manua
l
service@dressler.com
CESAR™
Generator
Model 1312


User Manual
CESAR™ Generator
Model 1312
CESAR 1312 (E)

ii CESAR 1312 (E)
Dressler®HF-Technik GmbH
COPYRIGHT
This manual and the information contained herein is the proprietary property
of Dressler®HF-Technik GmbH.
No part of this manual may be reproduced or copied without the express
written permission of Dressler®HF-Technik GmbH. Any unauthorized use of
this manual or its contents is strictly prohibited. Copyright ©2003
Dressler®HF-Technik GmbH. All Rights Reserved.
DISCLAIMER AND LIMITATION OF LIABILITY
The information contained in this manual is subject to change by
Dressler®HF-Technik GmbH without prior notice. Dressler®HF-
Technik GmbH makes no warranty of any kind whatsoever, either expressed
or implied, with respect to the information contained herein. Dressler®HF-
Technik GmbH shall not be liable in damages, of whatever kind, as a result of
the reliance on or use of the information contained herein.
PRODUCT USAGE STATEMENT
Read this entire manual and all other publications pertaining to the work to be
performed before you install, operate, or maintain this equipment. Practice all plant
and product safety instructions and precautions. Failure to follow instructions can
cause personal injury and/or property damage. If the equipment is used in a manner
not specified by the manufacturer, the protection provided by the equipment may be
impaired. All personnel who work with or who are exposed to this equipment must
take precautions to protect themselves against serious or possibly fatal bodily injury.
Dressler®HF-Technik GmbH provides information on its products and associated
hazards, but it assumes no responsibility for the after-sale operation of the
equipment or the safety practices of the owner or user. This equipment produces or
uses potentially lethal high-voltage, high-current, radio frequency (RF) energy.
NEVER DEFEAT INTERLOCKS OR GROUNDS.

CESAR 1312 (E) iii
CESAR™ 1312 Generator
TRADEMARKS
CUSTOMER FEEDBACK
Dressler®HF-Technik GmbH’s technical writing staff has carefully developed
this manual using research-based document design principles. However,
improvement is ongoing, and the writing staff welcomes and appreciates
customer feedback. Please send any comments on the content, organization,
or format of this user manual to:
To order a manual, please contact the Dressler Customer Service
Department:
®is a registered trademark of Dressler®HF-
Technik GmbH.
CESAR™ is a trademark of Dressler®HF-Technik GmbH.
Internet Explorer® is a registered trademark of the Microsoft
Corporation.
Microsoft®is a registered trademark of the Microsoft Corporation.
Modbus®is a registered trademark of Gould, Inc.
Smith ®The Smith®chart shown is produced under a copyright
license from Analog Instruments Company, New Providence, New
Jersey 07974.
Windows NT®is a registered trademark of the Microsoft Corporation.
Windows®is a registered trademark of the Microsoft Corporation.

iv CESAR 1312 (E)
Dressler®HF-Technik GmbH

CESAR 1312 (E) Table of Contents v
CESAR™ 1312 Generator
Chapter 1. Safety and Product Compliance Guidelines
Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
Interpreting the Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
This Revision of the Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
Understanding Model 1312 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Type Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Danger, Warning, and Caution Boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
Safety Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
Rules for Safe Installation and Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
Interpreting Product Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
Product Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
Product Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
Safety and Compliance Directives and Standards . . . . . . . . . . . . . . . . . . . . .1-5
Electromagnetic Compatibility (EMC) Directives and Standards . . . . . . .1-5
Safety Directives and Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6
Conditions of Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6
Interlocks and Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-7
Chapter 2. Product Overview and Theory
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Theory of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Chapter 3. Specifications
Physical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Physical Specifications Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Cooling Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6
Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6
Chapter 4. Communication Interfaces
Rear View Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Diagnostic Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8
Matching Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8
CESAR Generator User Port Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-10
User Port—25-Pin User Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-10
Table of Contents

vi Table of Contents CESAR 1312 (E)
Dressler®HF-Technik GmbH
User Port Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-11
Satisfying Minimal 25-Pin User Port Requirements . . . . . . . . . . . . . . . . 4-11
25-Pin User Port Cabling Requirements . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Activating the 25-pin User Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-12
25-Pin User Port Pin Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
25-Pin User Port Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . 4-20
25-Pin User Port Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22
User Port—15-Pin User Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28
Satisfying the Interlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-29
15-Pin User Port Cabling Requirements . . . . . . . . . . . . . . . . . . . . . . . . 4-31
15-Pin User Port Pin Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31
15-Pin User Port Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-36
CESAR Generator Host Port Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-42
Host Port—RS-232 With AE Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-43
RS-232 Connector and Pin Descriptions . . . . . . . . . . . . . . . . . . . . . . . . 4-44
RS-232 Transmission Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-44
AE Bus Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-45
Creating an Ideal Communications Transaction . . . . . . . . . . . . . . . . . . 4-48
Host Port—PROFIBUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-50
PROFIBUS Connector and Pin Descriptions . . . . . . . . . . . . . . . . . . . . . 4-51
PROFIBUS Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-51
Host Port—Ethernet (Modbus/TCP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-56
Understanding Modbus/TCP Commands and Register Types . . . . . . . 4-57
Host Port Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-61
Activating Host Port Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-62
Host Port Command Status Response (CSR) Codes . . . . . . . . . . . . . . 4-62
Host Port Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-62
Chapter 5. Installation, Setup, and Operation
Preparing to Install the CESAR Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Spacing Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Installation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Tools Required for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3
Installing the CESAR Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Mounting the CESAR Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3
Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Connecting RF Output Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Connecting Communication Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5
Connecting the CESAR Generator to a System Interlock Loop . . . . . . . . . . . 5-5
Satisfying the Interlock with a 25-pin User Port . . . . . . . . . . . . . . . . . . . . 5-5
Satisfying the Interlock with a 15-pin User Port . . . . . . . . . . . . . . . . . . . . 5-6
Connecting a Matchbox (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Connecting Common Exciter (CEX) Circuitry (Optional) . . . . . . . . . . . . . . . .5-7
Connecting AC Input (Mains) Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Connecting and Setting Ethernet (Modbus/TCP) Communication . . . . . . . . . 5-9

CESAR 1312 (E) Table of Contents vii
CESAR™ 1312 Generator
Connecting for Ethernet Communication . . . . . . . . . . . . . . . . . . . . . . . . .5-9
Setting the IP Configuration for Ethernet Communication . . . . . . . . . . . .5-9
First-Time Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-10
Operating the CESAR Generator for the First Time With the User Port . . . .5-11
Operating the CESAR Generator for the First Time With Host Port . . . . . . .5-13
Operating the CESAR Generator for the First Time Using the Front Panel .5-14
Normal Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-15
Setting Regulation Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-15
Determining the Regulation Mode Setting . . . . . . . . . . . . . . . . . . . . . . .5-15
Setting Forward Power Regulation Mode (PForward) . . . . . . . . . . . . . . .5-16
Setting Load Power Regulation Mode (Preal) . . . . . . . . . . . . . . . . . . . . .5-17
Setting External Power Regulation Mode (DC Bias) . . . . . . . . . . . . . . .5-18
Controlling the Matchbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-20
Determining the Current matchbox Tune Setting . . . . . . . . . . . . . . . . . .5-20
Setting Manual Tune Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-21
Setting Automatic Tune Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-22
Operating the CESAR Generator Using the Front Panel . . . . . . . . . . . . . . . . . . .5-24
Understanding Basic Front Panel Control Elements . . . . . . . . . . . . . . . . . . .5-25
Using the Front Panel Program Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-26
Accessing the Program Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-27
Entering Values in the Program Menu . . . . . . . . . . . . . . . . . . . . . . . . . .5-28
Front Panel Program Menu Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-29
Regulation Mode Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-30
Match Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-31
Setting the Pulse Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-33
Recipe Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-34
Setting Remote Control Override . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-37
Setting Target Lifetime PARAMETERS . . . . . . . . . . . . . . . . . . . . . . . . .5-38
Reflected Power Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-39
Changing the Pulse Input Configuration Settings . . . . . . . . . . . . . . . . .5-39
Changing the Device Configuration Settings . . . . . . . . . . . . . . . . . . . . .5-40
Setting and Using Preset Generator Settings for Different Applications . . . .5-42
Controlling a Variomatch Unit Attached to the Generator . . . . . . . . . . . . . . .5-43
Understanding Additional Operating Functions . . . . . . . . . . . . . . . . . . . . . . . . . .5-44
Using the Pulsing Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-44
Creating Recipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-45
Using the Remote Control Override . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-47
Setting a Target Lifetime . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-47
Changing Reflected Power Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-48
Connecting to an Ethernet-Enabled Unit With a Web Browser . . . . . . . . . . . . . .5-49
Chapter 6. Troubleshooting and Customer Support
Before Contacting Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Checks With the Power Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Checks With the Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2

viii Table of Contents CESAR 1312 (E)
Dressler®HF-Technik GmbH
General Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Matching Network Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
Interlock Not Satisfied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Front Panel Display (LCD) Not Lit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Communication Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4
Capacitor Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Incorrect Input Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Improper Impedance Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-5
Improper RF Connection or Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Improper Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-6
Improper Interface Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Improper Tuning Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7
Checking for and Resolving Errors and Warnings . . . . . . . . . . . . . . . . . . . . .6-7
World Wide Web Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
Returning Units for Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16
Authorized Returns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-17
Warranty Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-17

CESAR 1312 (E) List of Figures ix
CESAR™ 1312 Generator
Fig 2-1 CESAR generator block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Fig 3-1 CESAR Generator unit dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Fig 4-1 Rear view with 15-pin User port and RS-232 port (pn 61300056) . . . . . . . . . .4-2
Fig 4-2 Rear view with 15-pin User port and Ethernet port (pn 61300057) . . . . . . . . . .4-3
Fig 4-3 Rear view with 15-pin User port and PROFIBUS port (pn 61300058) . . . . . . .4-4
Fig 4-4 Rear view with 25-pin User port and RS-232 port (pn 61300059) . . . . . . . . . .4-5
Fig 4-5 Rear view with 25-pin User port and Ethernet port (pn 61300060) . . . . . . . . . .4-6
Fig 4-6 Rear view with 25-pin User port and PROFIBUS port (pn 61300061) . . . . . . .4-7
Fig 4-7 Matching Interface connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8
Fig 4-8 25-pin User Port connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-11
Fig 4-9 REFLECTED POWER MONITOR signal wiring (pins 2 and 15) . . . . . . . . . .4-22
Fig 4-10 RF FORWARD/LOAD POWER MONITOR signal wiring (pins 3 and 16) . .4-22
Fig 4-11 RF POWER ON signal wiring (pins 4 and 17) . . . . . . . . . . . . . . . . . . . . . . .4-23
Fig 4-12 SET POINT signal wiring (pins 5 and 18) . . . . . . . . . . . . . . . . . . . . . . . . . . .4-23
Fig 4-13 RF FORWARD POWER/DC BIAS REGULATION wiring (pins 6 and 19) . .4-24
Fig 4-14 DC BIAS MONITOR signal wiring (pins 7 and 20) . . . . . . . . . . . . . . . . . . . .4-24
Fig 4-15 RF FORWARD/LOAD REGULATION signal wiring (pins 8 and 21) . . . . . . .4-25
Fig 4-16 INTERLOCK LOOP signal wiring (pins 10 and 23) . . . . . . . . . . . . . . . . . . . .4-25
Fig 4-17 +15 VOLT DC signal wiring (pins 13 and 21) . . . . . . . . . . . . . . . . . . . . . . . .4-26
Fig 4-18 SET POINT STATUS signal wiring (pins 14 and 1) . . . . . . . . . . . . . . . . . . .4-26
Fig 4-19 OVERTEMPERATURE signal wiring (pins 22 and 9) . . . . . . . . . . . . . . . . . .4-27
Fig 4-20 INTERLOCK SATISFIED signal wiring (pins 24 and 11) . . . . . . . . . . . . . . .4-27
Fig 4-21 BLANKING/PULSING signal wiring (pins 25 and 19) . . . . . . . . . . . . . . . . . .4-28
Fig 4-22 15-pin User Port connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-28
Fig 4-23 Interlock interface connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-30
Fig 4-24 OPERATING MODE A wiring diagram (pins 1 and 8) . . . . . . . . . . . . . . . . .4-36
Fig 4-25 OPEATING MODE B wiring diagram (pins 2 and 8) . . . . . . . . . . . . . . . . . . .4-36
Fig 4-26 READY STATUS wiring diagram (pins 3 and 8) . . . . . . . . . . . . . . . . . . . . . .4-37
Fig 4-27 ERROR wiring diagram (pins 4 and 8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-37
Fig 4-28 MAXIMUM POWER LEVEL REACHED wiring diagram (pins 5 and 8) . . . .4-38
Fig 4-29 RF ON wiring diagram (pins 6 and 8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-38
Fig 4-30 INTERFACE VOLTAGE wiring diagram (pins 7 and 8) . . . . . . . . . . . . . . . .4-39
Fig 4-31 BLANKING/PULSING MODE wiring diagram (pins 9 and 8) . . . . . . . . . . . .4-39
Fig 4-32 RF POWER ON wiring diagram (pins 10 and 8) . . . . . . . . . . . . . . . . . . . . . .4-40
Fig 4-33 DC BIAS SET POINT wiring diagram (pins 11 and 8) . . . . . . . . . . . . . . . . .4-40
Fig 4-34 RF POWER SET POINT wiring diagram (pins 12 and 8) . . . . . . . . . . . . . . .4-41
Fig 4-35 TEST VOLTAGE FOWARD POWER wiring diagram (pins 13 and 8) . . . . .4-41
Fig 4-36 TEST VOLTAGE REFLECTED POWER wiring diagram (pins 14 and 8) . .4-42
Fig 4-37 TEST VOLTAGE FOR DC BIAS wiring diagram (pins 15 and 8) . . . . . . . . .4-42
Fig 4-38 RS-232 host connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-44
Fig 4-39 Graphic representation of a message packet . . . . . . . . . . . . . . . . . . . . . . . .4-46
Fig 4-40 AE Bus communications transaction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-48
List of Figures

x List of Figures CESAR 1312 (E)
Dressler®HF-Technik GmbH
Fig 4-41 Communications transaction example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-50
Fig 4-42 PROFIBUS port connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-50
Fig 4-43 Ethernet connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-57
Fig 5-1 Output (RF Out) connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Fig 5-2 CEX/Interconnect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Fig 5-3 Input (Mains) connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Fig 5-4 Front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-24
Fig 5-5 Front panel program menu tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-29
Fig 5-6 Front panel program menu tree (continued) . . . . . . . . . . . . . . . . . . . . . . . . . . 5-30

CESAR 1312 (E) List of Tables xi
CESAR™ 1312 Generator
Table 1-1 CESAR 1312 (E) options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Table 1-2 Electromagnetic compatibility (EMC) directives and standards . . . . . . . . . .1-5
Table 1-3 Safety directives and standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6
Table 1-4 CESAR generator limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8
Table 2-1 CESAR generator theory of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Table 3-1 Physical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
Table 3-2 Electrical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Table 3-3 Cooling specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6
Table 3-4 Climatic specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6
Table 3-5 Environmental specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7
Table 4-1 Matching Interface pin descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8
Table 4-2 25-pin User Port pin descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-13
Table 4-3 Interlock interface pin descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-30
Table 4-4 15-pin User Port pin descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-31
Table 4-5 Setting regulation mode with 15-pin User Port pins 1 and 2 . . . . . . . . . . . .4-35
Table 4-6 RS-232 host pin descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-44
Table 4-7 PROFIBUS Host port pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-51
Table 4-8 PROFIBUS status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-52
Table 4-9 Configuration of download bytes (outbytes) . . . . . . . . . . . . . . . . . . . . . . . .4-54
Table 4-10 Configuration of upload packet (inbytes) . . . . . . . . . . . . . . . . . . . . . . . . .4-55
Table 4-11 Upload status bytes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-56
Table 4-12 Packet format for FC23 send . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-58
Table 4-13 Packet format for FC23 response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-60
Table 4-14 Packet format for FC23 exception error . . . . . . . . . . . . . . . . . . . . . . . . . .4-61
Table 4-15 Host port CSR codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-62
Table 4-16 Host port commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-63
Table 5-1 Output connector pin descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4
Table 5-2 Input connector pin description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8
Table 5-3 Overview of CESAR front panel control elements . . . . . . . . . . . . . . . . . . .5-25
Table 5-4 Adjusting Variomatch capacitors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-44
Table 6-1 Error description and resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8
Table 6-2 Warning description and resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-11
Table 6-3 Customer Service contact information . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-14
List of Tables

xii List of Tables CESAR 1312 (E)
Dressler®HF-Technik GmbH

CESAR 1312 (E) Safety and Product Compliance Guidelines 1-1
Chapter
CESAR™ 1312 Generator Chapter
1
Safety and Product Compliance
Guidelines
IMPORTANT SAFETY INFORMATION
To ensure safe installation and operation of the Dressler®HF-Technik GmbH
CESAR generator, read and understand this manual before attempting to
install and operate this unit. At a minimum, read and follow the safety
instructions and practices documented under “Safety Guidelines” on page 1-3.
INTERPRETING THE MANUAL
The following sections provide information to help you interpret this user
manual.
This Revision of the Manual
This revision of the manual provides information associated with software
release 1.16. This version of the software included changes to the error and
warning messages. Please use an appropriate revision of this manual for
earlier versions of the software. If you do not have the appropriate manual,
contact Customer Support (see “Customer Support” on page 6-14).
Note: The unit reports the software revision level with host port command 198
(see Table 4-16 on page 4-63).

1-2 Safety and Product Compliance Guidelines CESAR 1312 (E)
Dressler®HF-Technik GmbH
Understanding Model 1312 Options
The Model 1312 has several different unit options, each with a unique part
number and unique combination of communication interfaces. The following
table lists the option part numbers and corresponding interfaces. See also
“Rear View Drawings” on page 4-2. For specific interface information, see
“Communication Interfaces” on page 4-1.
Note: To determine which option you have, find the serial tag affixed to the
unit; the part number is on the serial tag.
Type Conventions
Please note the following type conventions:
• Pin and signal names appear in capitalized italics (RF POWER ON).
• New terms appear in italicized text.
• Unit labels (switches, indicators, and so on) appear in boldface text
(Mains).
• Commands (1) and command names (regulation select) appear in
boldface, lowercase text.
Table 1-1. CESAR 1312 (E) options
Model Part
Number User Port Options Host Port Options
25-pin
User Port 15-pin
User Port RS-232 Ethernet PROFIBUS
61300056 X X
61300057 X X
61300058 X X
61300059 X X
61300060 X X
61300061 X X

CESAR 1312 (E) Safety and Product Compliance Guidelines 1-3
CESAR™ 1312 Generator
Danger, Warning, and Caution Boxes
This symbol represents important notes concerning potential harm to people,
this unit, or associated equipment. Dressler®HF-Technik GmbH includes this
symbol in Danger, Warning, and Caution boxes to identify specific levels of
hazard seriousness.
SAFETY GUIDELINES
Review the following information before attempting to install and operate this
unit.
Rules for Safe Installation and Operation
Please note the following:
• Do not attempt to install or operate this equipment without proper training.
• There are no user-serviceable parts inside the CESAR generator. Refer
servicing to trained service personnel (see “Customer Support” on
page 6-14).
• Ensure that this unit is properly grounded (see also “Grounding” on
page 5-4).
DANGER indicates an imminently hazardous situation that, if not
avoided, will result in death or serious injury. DANGER is limited to the
most extreme situations.
WARNING indicates a potentially hazardous situation that, if not avoided,
could result in death or serious injury, and/or property damage.
CAUTION indicates a potentially hazardous situation that, if not avoided,
could result in minor or moderate injury, and/or damage to property.
CAUTION is also used for property-damage-only accidents.

1-4 Safety and Product Compliance Guidelines CESAR 1312 (E)
Dressler®HF-Technik GmbH
• Ensure that all cables are properly connected (see also “CESAR
Generator User Port Options” on page 4-10 and “CESAR Generator Host
Port Options” on page 4-42).
• Verify that input line voltage and current capacity are within specifications
before turning on the power supplies (see “Electrical Specifications” on
page 3-4).
• Use proper electrostatic discharge (ESD) precautions.
• Always be careful around this equipment.
Interpreting Product Labels
The following labels may appear on the unit:
Capacitor discharge
warning
CE label
Hazardous voltage
Nouser-serviceable parts
inside unit

CESAR 1312 (E) Safety and Product Compliance Guidelines 1-5
CESAR™ 1312 Generator
PRODUCT COMPLIANCE
The following sections include information about unit compliance and
certification, including the conditions of use required to be in compliance with
the standards and directives.
Product Certification
Certain options of this product are certified by:
• CE marking, self addressed by Dressler Compliance Engineering
• EMC measurements, verified by Competent Body Product Services
For more information, refer to the letter of conformance (US) or declaration of
conformity (EU) accompanying the product.
Safety and Compliance Directives and Standards
Certain options of this unit have been tested for and comply with the following
electromagnetic compatibility (EMC) and safety directives and standards.
Note: This device must be installed and used only in compliance with the
directives and standards listed in addition to VDE 0113, EN 60204 (IEC
60204), and applicable requirements.
ELECTROMAGNETIC COMPATIBILITY (EMC) DIRECTIVES
AND STANDARDS
Table 1-2. Electromagnetic compatibility (EMC) directives and standards
Directive Description
89/336/EEC EC Council directive on the approximation of the laws of
the Member States relating to electromagnetic
compatibility (EMC Directive)
47 CFR
Part 18 Code of Federal Regulations—Limits and methods of
measurement of radio interference characteristics of
industrial, scientific, and medical equipment
EN 55011 Limits and methods of measurement of radio disturbance
characteristics of industrial, scientific, medical (ISM) radio
frequency equipment (Class A, Group 2) (CISPR 11)
EN 61000-6-2 Electromagnetic Compatibility (generic immunity
standard— industrial)

1-6 Safety and Product Compliance Guidelines CESAR 1312 (E)
Dressler®HF-Technik GmbH
SAFETY DIRECTIVES AND STANDARDS
Conditions of Use
To comply with the stated directives and standards, you must meet the
following conditions of use:
• Before making any other connection to this device, connect the auxiliary
Protective Earth ground terminal to a local earth ground with a copper wire
thatissized accordingtotheapplicablerequirements(see“Specifications”
on page 3-1).
• Install and operate this device in an overvoltage category II installation
only.
• Install and operate this device only in a pollution degree 2 or better
environment, which means an indoor location such as a computer room,
office, or factory floor where only nonconductive pollution occurs during
operation. Occasionally, condensation causes temporary conductivity
when the device is not operating.
• Install this device so that it is fully enclosed by a rack or other enclosure.
The rack or enclosure must be metal and either reinforced or of sufficient
thickness to resist the following tests:
4A steady force of 445 N, applied through a steel hemisphere 12.7 mm
in diameter
4An impact of 7 J applied by dropping or swinging a 0.53 kg, 50 mm
diameter steel sphere
Table 1-3. Safety directives and standards
Directive Description
73/23/EEC EC Council directive on the harmonization of the laws of
the Member States relating to electrical equipment
designed for use within certain voltage limits (LVD - Low
Voltage Directive)
EN 61010-1 Safety requirements for electrical equipment for
measurement, control, and laboratory use
RISK OF DEATH OR BODILY INJURY. Disconnect and lockout/tagout all
sources of input power before working on this unit or anything
connected to it.
Table of contents
Other Dressler Inverter manuals
Popular Inverter manuals by other brands

Vector
Vector Industrial Series VEC023 Owner's manual & warranty information

Generac Power Systems
Generac Power Systems PWRcell XVT076A03 installation manual

EBARA
EBARA E-SPD MT 2200 Instruction and maintenance manual

Puredrive
Puredrive Hybrid Series Installer's guide

Huawe
Huawe SUN2000-33KTL Quick installation guide

Dass
Dass DSP-123K5-OD Operation and installation manual
