Drew & Cole EP1165 User manual

/Speed
Heating
Humidifier
Heater & Humidifier
Fan User’s Manual
Heater & Humidifier Fan Manual.indd 1 05/05/2020 12:11

2SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY
Quick Start Guide
Preparing
Thermal safety cutout
1 Metre
3 Feet
/Speed
Heating
Humidifier
/Speed
Heating
Humidifier
Ensure there is a
minimum of 1 metre (3
feet) of clear space all
around the fan.
IMPORTANT: Ensure that no
items can block the air intake
on the back of your fan.
IMPORTANT: Ensure that
the power cable is not a trip
hazard.
Filling the water tank
Pull the water tank lid
upwards.
Fill the tank using the
water jug provided with
demineralize or filtered
water.
Close the water tank lid and
push down to ensure it is
fully closed.
Your fan is fitted with an internal thermal safety switch. This will stop the fan from
operating if the internal temperature exceeds the normal operating temperature. If this
happens refer to the ‘Thermal Safety Cutout’ on page 9.
IMPORTANT: Please read the Important Safeguards before using your appliance.
Heater & Humidifier Fan Manual.indd 2 05/05/2020 12:11

3
SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY
Controls
Hand warmer
Slot the plug into a
mains socket and switch
the power on at the
socket if required.
When you plug the fan
in you will hear a ‘beep’
and the /Speed icon
will flash.
Press the /Speed
button to turn your fan
on.
Place the hand warmer on
the front of the fan.
The hand warmer is held in
place with magnets.
Turn the fan to high speed,
and the heater on. Leave the
hand warmer attached for a
minimum of 10 minutes.
Turn the fan off. Wait for 2
minutes. Grip the sides of
the hand warmer and pull it
off the front of the fan.
Heating Humidifier
/Speed
Heating
Humidifier
/Speed
/Speed button
Press and hold for 1.5 seconds: Unit will bleep and turn on to low speed fan,
white icon on.
Press and hold for a further 1.5 seconds: Unit will bleep then a double bleep
and switch to high speed fan, Blue icon on.
Press and hold for a further 1.5 seconds: Unit will bleep and turn back to low
speed fan, white icon on.
Press to turn unit off.
Heating button
IMPORTANT: The fan must be on to use this function.
Press once: Turn heater ON, white icon.
Press again: Turn heater OFF, icon not illuminated.
Humidifier button
IMPORTANT: The water tank must be filled to use this function.
Press once: Turn humidifier ON, white icon.
Press again: Turn humidifier OFF, icon not illuminated.
Heating
/Speed
Humidifier
Heater & Humidifier Fan Manual.indd 3 05/05/2020 12:11

4SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY
Index
Important safeguards 05
What water to use? 09
Thermal safety cutout 09
Box contents 10
Parts of your fan 10
Preparing your fan 11
Filling the water tank 12
Using your fan 13
Using the hand warmer 15
Descaling your water tank 16
Storing & cleaning your fan 17
Troubleshooting 18
Specification 18
Topic
Heater & Humidifier Fan Manual.indd 4 05/05/2020 12:11

5
SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY
• Read all instructions
before using this
product.
• When using any
electrical appliance,
basic safety precautions
should always be
followed including the
following:
• Check that the voltage
of the main circuit
corresponds with the
rating of the appliance
before operating.
• Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT leave the
appliance unattended
while it is operating.
• Close supervision is
necessary when any
appliance is used by or
near children or pets.
• This appliance can
be used by children
aged from 8 years and
above and persons
with reduced physical,
sensory or mental
capabilities or lack
of experience and
knowledge if they have
been given supervision
or instruction concerning
use of the appliance in a
safe way and understand
the hazards involved.
• Children shall not play
with the appliance.
• Children of less than 3
years should be kept
away unless continuously
supervised.
• Cleaning and user
maintenance shall not
be made by children
without supervision.
• Children aged from 3
When using electrical appliances, basic safety precautions should always be
followed including the following:
Important Safeguards
Heater & Humidifier Fan Manual.indd 5 05/05/2020 12:11

SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY
6
Important Safeguards (cont...)
years and less than 8
years shall only switch
on/off the appliance
provided that it has
been placed or installed
in its intended normal
operating position and
they have been given
supervision or instruction
concerning use of the
appliance in a safe
way and understand
the hazards involved.
Children aged from 3
years and less than 8
years shall not plug in,
regulate and clean the
appliance or perform
user maintenance.
• Switch off at the wall
socket then remove the
plug from the socket
when not in use or
before cleaning.
• If the supply cord is
damaged, it must
be replaced by the
manufacturer, its service
agent or similarly
qualified persons in
order to avoid a hazard.
• If the supply cord or
appliance is damaged,
stop using the
appliance immediately
and seek advice from
the manufacturer or
its service agent or
a similarly qualified
person.
• CAUTION: In order to
avoid a hazard due to
inadvertent resetting
of the thermal cut-out,
this appliance must not
be supplied through
an external switching
device, such as a timer,
or connected to a circuit
that is regularly switched
on and off by the utility.
• DO NOT let the cord
hang over the edge of a
table or counter or let it
come into contact with
any hot surfaces.
• The use of accessory
attachments is not
Heater & Humidifier Fan Manual.indd 6 05/05/2020 12:11

SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY 7
Important Safeguards (cont...)
recommended by the
appliance manufacturer,
apart from those
supplied with this
product.
• DO NOT pull the plug
out by the cord as this
may damage the plug
and/or the cable.
• DO NOT use this
product for anything
other than its intended
use.
• This appliance is for
household use only.
• DO NOT carry the
appliance by the power
cord.
• DO NOT use the
appliance outdoors.
• Use the appliance in a
well ventilated area.
• DO NOT use the
appliance near explosive
and combustible gas.
Avoid long-term direct
solar radiation.
• DO NOT locate the item
directly below the socket
outlet and outdoor.
• DO NOT use the same
socket with other items.
• After adding water to the
water tank, DO NOT tilt
or knock the appliance.
If you wish to move the
appliance, please push
it slowly from the side in
order to avoid spilling.
• DO NOT cover the wind
outlet.
• DO NOT use the
appliance near water.
• Caution: DO NOT
operate the appliance
with wet hands.
• CAUTION: Some parts
of this product can
become very hot and
cause burns. Particular
attention has to be given
where children and
vulnerable people are
present.
• In the unlikely event
the appliance develops
a fault, stop using
it immediately and
Heater & Humidifier Fan Manual.indd 7 05/05/2020 12:11

seek advice from the
Customer Support Team.
• WARNING: In order to
avoid overheating, do
not cover the heater.
• The heater must not be
located immediately
below a socket outlet.
• Do not use this heater
in the immediate
surroundings of a bath,
a shower or a swimming
pool.
• WARNING: This heater
is not equipped with a
device to control the
room temperature. Do
not use this heater in
small rooms when they
are occupied by persons
not capable of leaving
the room on their
own, unless constant
supervision is provided.
• Care should be
taken when using the
appliance due to the
emission of hot water
vapour. Unplug the
appliance during filling
and cleaning.
• Ifyourequireany
more information or
assistance, please
contact our Customer
Services Team - their
opening hours are as
follows:
8:00am - 7:30pm
(Monday - Friday)
8:00am - 1:00pm
(Saturdays and Sunday)
You can contact them
between these hours on:
0344 800 0631 (UK
customers)
0412 132 998 (Irish
customers)
Alternatively you can
send them an email
on CustomerCare@
highstreettv.com
SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY
8
Important Safeguards (cont...)
Heater & Humidifier Fan Manual.indd 8 05/05/2020 12:11

SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY 9
What water to use?
• For the best results and to prolong the life of your appliance, we recommend
that you use demineralised, distilled or filtered water. This will prevent the
build up of limescale inside your fan.
• You can use tap water, but you will have to regularly descale your fan
following the instructions given on pages 16.
Thermal safety switch
Your fan is fitted with an internal thermal safety switch. This will stop the fan from
operating if the internal temperature exceeds the normal operating temperature.
IF YOUR HEATER SHUTS DOWN
• Turn the fan off by removing the plug from the mains socket.
• Leave the fan to cool for approximately 10 minutes or until the fan feels cool.
• Plug the fan back into the mains socket and turn on as usual.
The product and its packaging have been manufactured from valuable materials that can be
recycled. Recycling reduces the amount of refuse and helps to preserve the environment.
Dispose of the packaging at a recycling point that sorts materials by type. Make use of the local
facilities provided for collecting paper, cardboard and light weight packaging.
Appliances marked with this symbol must not be disposed of along with normal household
waste!
You are legally obliged to dispose of old appliances separately from household waste.
Information about collection points where old appliances can be disposed of free of
charge is available from your local authorities.
Heater & Humidifier Fan Manual.indd 9 05/05/2020 12:11

SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY
10
Box Contents
/Speed
Heating
Humidifier
Heater & humidifier fan
Hand
warmer
Water jug
User
manual
Parts of Your Fan
/Speed
Heating
Humidifier
Fan speed
Heater On/Off
Wind/Heat
outlet
Mist nozzle
Power cable
Tank lid Handle
Humidifier
On/Off
Heater & Humidifier Fan Manual.indd 10 05/05/2020 12:11

SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY 11
Preparing Your Fan
Place your fan in the room you wish to
use it in with a minimum of 1 metre (3
feet) of clear space all around it.
IMPORTANT: Ensure that the power
cable is positioned so that it does not
present a trip hazard on the floor or
can be snagged and accidently pulled
off a raised surface.
IMPORTANT: Ensure that no items can
block the air intake on the back of your
fan, such as curtains, fabric covers or
furniture.
1 Metre
3 Feet
/Speed
Heating
Humidifier
/Speed
Heating
Humidifier
Heater & Humidifier Fan Manual.indd 11 05/05/2020 12:11

SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY
12
Filling The Water Tank
Pull the water tank lid upwards.
Fill the tank with water using the
water jug provided ensuring you use
demineralize or filtered water.
Tank capacity: 130ml. To prevent over
filling and spillage we recommend
filling to 120ml using the measuring
jug provided.
IMPORTANT: Never place scent or
other chemicals in the water tank as
they could damage the fan.
Close the water tank lid and push
down to ensure it is fully closed.
Heater & Humidifier Fan Manual.indd 12 05/05/2020 12:11

SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY 13
Slot the plug into a mains socket and
press the power switch on the socket
to the on position if required.
When you plug the fan in you will hear
a ‘beep’ and the /Speed icon will
flash white.
Using the fan function
Press the /Speed button to:
Press and hold for 1.5 seconds: Unit
will bleep and turn on to low speed
fan, white icon on.
Press and hold for a further 1.5
seconds: Unit will bleep then a double
bleep and switch to high speed fan,
Blue icon on
Press and hold for a further 1.5 sec-
onds: Unit will bleep and turn back to
low speed fan, white icon on.
Press to turn unit off
/Speed
Heating
Humidifier
Heating Humidifier/Speed
Using Your Fan
IMPORTANT: Your fan is fitted with an internal thermal safety switch to
prevent your fan from overheating. If this is tripped your fan will shutdown
and cannot be used. See page 9 for what to do if this happens to your fan.
Your fan also has an automatic shut off function if it is accidently tipped over.
If this happens simply stand it back up correctly and it will reset. Simply start
again the required functions.
Please ensure your fan is always placed on a level and stable surface,
otherwise it will not switch on.
Heater & Humidifier Fan Manual.indd 13 05/05/2020 12:11

SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY
14
Using Your Fan (cont...)
Using the heating function
Whilst the fan is running at low or high
speed, press the Heating button to
turn the heater on or off.
ON: White icon.
OFF: Icon not illuminated.
IMPORTANT: The fan must be turned
on to use this function.
Using the humidifier function
Ensure the water tank is full before
using this feature.
Whilst the fan is running at low or high
speed, press the Humidifier button to
switch the humidifier on or off.
ON: White icon.
OFF: Icon not illuminated.
Turning the fan off
Switch the heater or humidifier off by
pressing the required button.
Press the /Speed button until the
icon flashes.
IMPORTANT: The fan will continue to
run for approximately 10 seconds to
cool the unit down.
After the fan has stopped, you can
remove the plug from the mains socket
to completely turn the fan off.
Heating Humidifier/Speed
Heating Humidifier/Speed
Heater & Humidifier Fan Manual.indd 14 05/05/2020 12:11

SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY 15
Using The Hand Warmer
Place the hand warmer on the front of
the fan.
The hand warmer is held in place with
magnets.
Turn the fan to high speed, then turn
the heater function on.
Leave the hand warmer attached to the
front of the fan for a minimum of 10
minutes.
Note: The longer you leave the hand
warmer attached to the front of the
fan, the longer it will stay warm.
When the hand warmer is attached to
the front of the fan the fan output will
be less powerful.
Turn the heater function off then turn
the fan off. Wait for 2 minutes.
Grip the sides of the hand warmer and
pull it off the front of the fan.
Your hand warmer is now ready for use.
Cleaning the hand warmer: Wipe
clean only with a damp cloth.
Heater & Humidifier Fan Manual.indd 15 05/05/2020 12:11

SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY
16
Descaling Your Water Tank
Fill the water tank with 50% lemon
juice and 50% water.
Plug your fan in and turn the power on
if required.
Press the Humidifier button and run
until the tank is empty.
Repeat the process again but only
fill the water tank with water and NO
lemon juice.
Heating Humidifier/Speed
Heater & Humidifier Fan Manual.indd 16 05/05/2020 12:11

SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY 17
Storing & Cleaning Your Fan
Emptying the water tank
If you are not going to use the fan for
an extended period, empty the water
tank.
Open the tank lid and pour any
remaining water out.
Cleaning your fan
We recommend that the fan is cleaned
at least once a month and always
before storing.
Turn the fan off and remove the plug
from the mains socket. Allow to cool
before cleaning. Wipe the surface of
the fan with a dry cloth
Heater & Humidifier Fan Manual.indd 17 05/05/2020 12:11

SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY
18
Troubleshooting
Specification
Heater On/Off EP1165
Wattage
Voltage
400W
220 - 240V
Hertz 50 - 60Hz
If your fan is not working check the following:
• Be sure to it is plugged in and the power switched on.
• Check for any obstructions. If you find an obstruction, turn the fan off and
unplug it. Leave the fan to cool down for at least 10 minutes. Carefully
remove the obstruction. Plug the fan back into the power socket and press
the /Speed button to restart your fan.
• If you are still have the same problem, remove the plug from the mains
socket and have the appliance serviced by an authorised service personnel
only.
Heater & Humidifier Fan Manual.indd 18 05/05/2020 12:11

SAVE THESE INSTRUCTIONS- FOR HOUSEHOLD USE ONLY 19
Notes
Heater & Humidifier Fan Manual.indd 19 05/05/2020 12:11

Distributed by:
HSTV Corby
PO Box 7903
CORBY
NN17 9HY
Model number: EP1165
V6-05/20
Please recycle our product and
packaging where facilities exist.
Check with your Local Authority
or retailer for recycling in your
country.
Heater & Humidifier Fan Manual.indd 20 05/05/2020 12:11
