DRIVELONG SE2000i User manual














OWNER'S MANUAL
SE2000iE
Smart Inverter
GENERATOR
SE2000i
VER2.6-20220112

CONTENT
1. SAFETY INFORMATION ..........................................................................- 6 -
1.1 OPERATOR ATTENTION ...............................................................- 6 -
1.2 EXHAUST FUMES HAZARDS .......................................................- 7 -
1.3 ELECTRIC SHOCK HAZARDS ......................................................- 8 -
1.4 FIRE AND BURN HAZARDS ..........................................................- 9 -
1.5 CONNECTION NOTES................................................................. - 11 -
2. IMPORTANT LABEL LOCATIONS.......................................................... - 11 -
3. UNIT DESCRIPTION ..............................................................................- 14 -
3.1 COMPONENTS IDENTIFICATION ...............................................- 14 -
3.2 CONTROL PANEL ........................................................................- 16 -
4. PREPARATION .......................................................................................- 17 -
4.1 ENGINE OIL..................................................................................- 17 -
4.2 FUEL .............................................................................................- 19 -
5. STARTING THE ENGINE .......................................................................- 20 -
5.1 CHECK ENGINE OIL ....................................................................- 21 -
5.2 CHECK FUEL................................................................................- 22 -
5.3 OPEN THE FUEL CAP VENT LEVER ..........................................- 23 -
5.4 OPEN THE FUEL TAP ..................................................................- 24 -
5.5 THE ENGINE SWITCH & ECO SWITCH .....................................- 25 -
5.6 USE CHOKE .................................................................................- 26 -
5.7 START THE ENGINE....................................................................- 27 -
5.8 CLOSE CHOKE ............................................................................- 30 -
6. AC OPERATION......................................................................................- 31 -
6.1 USE THE GENERATOR: ..............................................................- 32 -
6.2 SHUT DOWN THE GENERATOR: ...............................................- 34 -
7. DC OPERATION .....................................................................................- 36 -
7.1 CONNECTING THE BATTERY CHARGING CABLE: ..................- 37 -
7.2 DISCONNECTING THE BATTERY CHARGING CABLE: ............- 38 -
8. AC PARALLEL OPERATION ......................................................................- 39 -
8.1 START AC PARALLEL ..................................................................- 39 -
8.2 STOP AC PARALLEL....................................................................- 41 -

‐2‐
9. SPECIAL REQUIREMENTS ...................................................................- 41 -
10. MAINTENANCE ....................................................................................- 43 -
10.1 ENGINE OIL CHANGE ...............................................................- 45 -
10.2 AIR CLEANER SERVICE............................................................- 47 -
10.3 SPARK PLUG SERVICE.............................................................- 48 -
10.4 SPARK ARRESTER MAINTENANCE.........................................- 50 -
10.5 CLEANING FUEL TANK FILTER ................................................- 52 -
11. TRANSPORTATION AND STORAGE...................................................- 53 -
11.1 DRAIN THE FUEL FROM THE CARBURETOR.........................- 53 -
11.2 DRAIN THE FUEL FROM FUEL TANK .......................................- 55 -
11.3 DRAIN THE FUEL FROM THE CARBURETOR AGAIN.............- 55 -
11.4 ENGINE.......................................................................................- 56 -
12. TROUBLE SHOOTING .........................................................................- 57 -
13. SPECIFICATIONS.................................................................................- 63 -
14. WIRING DIAGRAM ...............................................................................- 65 -
15. ENVIRONMENT CORRECTION ..........................................................- 67 -

















‐3‐


Read this manual carefully before operating this generator. This
manual should stay with this generator if it is sold.



























The engine exhaust fumes from this product
contains poisonous carbon monoxide（CO）to
cause loss of consciousness and may lead to
death.

‐4‐

Exhaust contains poisonous carbon monoxide (CO) gas that can
build up to dangerous levels in closed areas.
Breathing CO can cause unconsciousness or death.
Never run the generator in a closed or even partially closed area
where people may be present.


The generator is a potential source of electrical shock if misused.
Do not expose the generator to moisture, rain or snow. Do not let
the generator get wet, and do not operate it with wet hands.

Keep this owner’s manual handy, so you can refer to it at any
t im e. We reserve the right to modify this product or manual at any
time without any notice.
PLEASE READ AND UNDERSTAND THIS MANUAL COMPLETELY
BEFORE OPERATING THE GENERATOR.
This manual will provide you with a good basic understanding of
the operation and maintenance of this machine.
We continually seek advancements in product design and quality.
Therefore, while this manual is the newest, there may be slight
difference between your generator and this manual.




‐5‐

INTRODUCTION
Congratulations on your selection of a marvelous generator.We are
certain you will be pleased with your purchase one of the greatest
portable generators on the market.
This manual will provide you with a good basic understanding of
the operation and maintenance of this machine, please read it
carefully.
These signal words mean:








This manual is filled with important safety information －please
read it carefully.
If you have any questions, please consult an authorized dealer.








You WILL be KILLED or SERIOUSLY HURT if you
don’t follow instructions.
You CAN be KILLED or SERIOUSLY HURT if you
don’t follow instructions.
You CAN be HURT if you don’t follow instructions.

‐6‐
1. SAFETY INFORMATION
1.1 OPERATOR ATTENTION
Read and understand this manual before operating the
generator.
Place the generator in a place where pedestrians, children and
pets are not likely to touch.Do not let children operate the
generator without supervision. Protect children by keeping
them at a safe distance from the generating set.
Turn OFF the Fuel Tap before tilting the generator.
The generator is allowed to be
tilted down, but ONLY lay on
the Drawbar Side, and only
after stopping the engine. If lay
down on otherside, OIL may
leak and damage the engine or
your property. Also FUEL may
leak and cause FIRE or an
EXPLOSION.

‐7‐
DO NOT remove any cover of the generator case when the
engine is running. If not, inverter, alternator or other electric
parts may be damaged because of bad cooling.
1.2 EXHAUST FUMES HAZARDS


Exhaust fumes contains poisonous carbon monoxide（CO）,
a colorless and odorless gas. Breathing CO can cause loss of
consciousness and may lead to death.
Never run your generator inside a garage or house, even if
door or window is open. Operate the generator in a well-
ventilated area.

‐8‐
1.3 ELECTRIC SHOCK HAZARDS

Never operate the engine in rain, snow or wet locations.
Never touch the machine with wet hands.
Ground unit to avoid electrical hazards.
Electrical equipment (including lines and plug connections)
should not be defective.
The generating set must not be connected to other power
sources, such as the power company supply mains. In special
cases where stand-by connection to existing electrical
systems is intended, it shall only be performed by a qualified
electrician who has to consider the differences between
operating equipment using the public electrical supply network
and operating the generating set. In accordance with this part
of ISO 8528 the differences shall be stated in the instruction
manual.
When using extension lines or mobile distribution networks the

‐9‐
total length of lines for a cross section of 1.5 mm2should not
exceed 60 m; for a cross section of 2.5 mm2this should not
exceed 100 m.
1.4 FIRE AND BURN HAZARDS
 


Gasoline is extremely flammable and explosive under certain
conditions. Do not smoke or allow flames or sparks where the
generator is refueled or where gasoline is stored. Refuel in a
well-ventilated area with the engine stopped and cooled.
Fuel is combustible and easily ignited. Do not refuel during
operation. Do not refuel while smoking or near naked flames.
Do not spill fuel.
Check FUEL LEAKAGE before each use. DO NOT use the

‐10‐
generator if the generator is leaking fuel.
The generator is allowed to be tilted down, but ONLY lay down
on the Drawbar Side. If lay down on other side, OIL may leak
and damage the engine or your property. Also FUEL may leak
and cause FIRE or an EXPLOSION.
The muffler becomes very hot during operation and remains
hot for a while after stopping the engine. Be careful not to
touch the muffler while it is hot.
Some parts of the internal combustion engine are hot and may
cause burns. Pay attention to the warnings on the generating
set.
Avoid placing any flammable materials near the exhaust outlet
during operation.
Keep the generator at least 1 m (3 ft) from buildings or other
equipment, or the generator may overheat.
Let the engine cool before storing the generator indoors.
Engine exhaust gases are toxic. Do not operate the generating
set in unventilated rooms. When installed in ventilated rooms,
additional requirements for fire and explosion protection shall
be observed.

‐11‐
1.5 CONNECTION NOTES

Do not connect to a building electrical system unless an
isolation switch has been installed by a qualified electrician.
Avoid connecting the generator in parallel with any other
generator.


2. IMPORTANT LABEL LOCATIONS
Please read the following labels carefully before operating this
generator.

‐12‐




①②
 


3
1
2
5
4
6
7

‐13‐
③④
 


⑤⑥
 
○
7


‐14‐
3. UNIT DESCRIPTION
3.1 COMPONENTS IDENTIFICATION
(1). Control Panel: Location of generator controls and output
receptacles.
1
2
3
4
8
5
6
7
12 10
11
13
9
18
18
16
15 14 17
7

‐15‐
(2). Fuel Cap: Access to fuel tank for filling.
(3). Fuel Cap Vent Lever: Control valve between atmosphere and fuel
tank.
(4). Carrying Handle: Lift the generator by this handle only.
(5). Starter Grip: Pull starter grip for starting engine.
(6). Choke Knob: Cold engine starting aid.
(7). Wheels: Move the generator by the wheels.
(8). Draw Bar Handle: Pull the handle to drag this generator on the
ground.
(9). Maintenance Cover: Allows access to air filter, carburetor and
engine oil cap etc.
(10). Spark Plug Maintenance Cover: Allows access to engine spark
plug.
(11). Oil Maintenance Cover: Allows access to fill the engine oil.
(12). Fuel Gauge: Check fuel level in fuel tank.
(13). Muffler: Lowers engine exhaust noise.
(14). Air Filter: Clean air for engine.
(15). Carburetor: Supply the fuel-air mixture to engine.
(16). Spark Plug: Ignites the fuel-air mixture when the engine piston
reaches the top of the cylinder.
(17). Oil Cap: Access to fill or drain engine oil.
(18). Air Intake Slats: Allow for cooling air to enter the housing.

‐16‐
3.2 CONTROL PANEL
(1). Fuel Tap: Controls fuel supply to the carburetor.
(2). AC Receptacles: AC Output receptacles for connecting AC devices.
(3). 12V DC Receptacle: Connection for re-charging 12V batteries
while the generator is in operation. The receptacle can also supply
power for some 12V electrical appliances.
(4). 12V DC Circuit Breaker: Overload protection for the 12V DC
receptacle.
(5). USB Plug: USB Output receptacles for connecting 5VDC devices.
(6). Parallel Terminal: AC Parallel operation outlets for the same two
generators.
(7). Ground (Earth) Terminal: Grounding point for the generator.
(8). Engine Switch: This switch turns ON or OFF engine ignition
28
9
1
7
12
13
14
16
15
4
6
3
10
11
5

‐17‐
system.
(9). ECO Switch: Turning on this switch can slows the engine speed
when the load is reduced to save fuel, lessen noise and engine wear.
(10). Reset Button: This switch can be used to recover output of the
generator under the condition of overload protection, and unnecessary
to restart engine overall.
(11). Start Button (optional): This switch can be used to start the engine
equipped with electric starter (optional equipment).
(12). READY LED (green): READY LED light comes ON when the
generator is operating normally. It indicates that the generator is
producing electrical power at the receptacles.
(13). OVERLOAD LED (red): If the generator is overloaded, or if there
is a short circuit at AC receptacles, the overload LED light (red) will go
ON, and current to the connected appliance(s) will shut off in a few
seconds.
(14). LOW OIL LEVEL LED (yellow): Lights up when oil level is below
safe operating level, and the engine shuts down automatically. Unless
you refill with oil, the engine will not start again.
(15). POWER LED (optional): Lights up when the Gen-mate unit
(optional equipment) inside the generator is operating normally.
(16). Wi-Fi LED (optional): The light comes ON and flash slowly when
the generator with Gen-mate unit (optional equipment) is connected to
the Gen-mate APP in Smartphone by Wi-Fi.
4. PREPARATION
4.1 ENGINE OIL
NOTE
The engine has been shipped from our factory without oil. Put
oil before starting.
Recommended engine oil: 4-stroke engine oil, SAE 10W-30 or

‐18‐
10W-40, API SE/SF/SG/SH/SJ or higher.
Engine oil quantity: 0.35L.

 
Add Engine Oil:
(1). Open the Oil Maintenance Cover 1, and remove the Oil
Cap/Dipstick 2.
(2). Fill the specified amount of the recommended engine oil by the Oil
Funnel 4(Refer to the section 10.1 of this manual), and then install and
tighten the Oil Cap/Dipstick 2.
NOTE
Make certain the generator is on a flat, level surface.
Keep the engine oil level between LOWER LIMIT and UPPER
LIMIT. Too much or too little oil will shorten the service life of
the engine.
The engine is equipped with a low oil sensor that will prevent
the engine from running. If the oil level falls below a critical
threshold, the engine will stop automatically.
1
2
2
UPPER LIMIT
LOWER LIMIT
Loosen
0.35L

‐19‐
When the engine shuts down automatically by the low oil
protection, the LOW OIL LEVEL LED (yellow) will come on,
and unless you refill with oil, the engine will not start again.
4.2 FUEL
Gasoline is extremely flammable and explosive under certain
conditions. Do not smoke or allow flames or sparks where the
generator is refueled or where gasoline is stored.
Refuel in a well-ventilated area with the engine stopped.
DONOT fill above the Red Level
, otherwise it may overflow
when the fuel warms up and expands.
Check FUEL LEAKAGE before each use. DO NOT use the
generator if the generator is leaking fuel.
Immediately wipe off spilled fuel with a clean, dry, soft cloth,
since fuel may deteriorate painted surfaces or plastic parts.
Add Fuel:
(1). Remove the Fuel Cap 1 and fill the fuel into the tank up to the Red
Level 2.
(2). The fuel level in the fuel tank can be checked through the Fuel
Gauge 3.
1
2
3
Loosen
