DROPSA SMART2 Operating instructions

1
SMART 2
Oil Lubrication Electro-Pump
SW ver. 1.10
User and
Maintenance Manual
Warranty information
TABLE OF CONTENTS
1. INTRODUCTION
2. GENERAL DESCRIPTION
3. PRODUCT-MACHINE IDENTIFICATION
4. TECHNICAL SPECIFICATIONS
5. MACHINE COMPONENTS
6. UNPACKING AND INSTALLING THE MACHINE
7. INSTRUCTIONS FOR USE
8. TROUBLESHOOTING
9. MAINTENANCE PROCEDURE
10. DISPOSAL
11. ORDERING INFORMATION
12. DIMENSIONS
13. HANDLING AND TRANSPORTATION
14. OPERATING HAZARDS
15. PRECAUTIONS
16. WARRANTY INFORMATION
17. DECLARATION OF COMPLIANCE WITH STANDARDS
18. DROPSA LOCATIONS
Manual drafted in compliance with C2084IE– WK 54/04
EC Directive 98/37, Annex I, paragraph 1.7.4
http://www.dropsa.com
Manufacturer DropsA SpA
Product SMART2
Year 2004
Certification
DRAFT

2
1. INTRODUCTION
This User and Maintenance Manual refers to SMART2 - Oil Lubrication Electro-Pump.
You can find additional copies and newer revisions of this document from our website http://www.dropsa.com.
Alternatively contact one of our Sales Offices.
This manual contains important information on health and safety issues for the personnel. It is recommended
to attentively read this manual and carefully keep it in good condition so that it is always available to personnel
requiring to consult it.
2. GENERAL DESCRIPTION
Oil lubrication pump SMART2 has been designed for industry machine tools.The electric gear-pump was
designed to work with Single Line Injectors and Valves 33.
SMART2 is available in two versions:
- Manual SMART2, manually controlled via the PLC of the machine tool;
- Automatic SMART2, automatically controlled via built-in VIP2004 controller.
2.1 LUBRICATION CONTROL SYSTEM - PRINCIPLES OF OPERATION
AUTOMATIC SMART 2 operates on the principle of intermittent lubrication which involves the following
three steps:
 Prelube
 Lube (lube – wait)
 Standby
2.1.1 PRELUBE
This step is made up of a set of cycles (max 999 cycles) during which the lubrication system runs a series of
lubrication cycles (lubrication will be described in paragraph 2.1.2) necessary to vent air from the pump and
check lubrication functions.
Prelube takes place:
- on POWER-ON;
- on RESET;
- Any time new parameters are set.
When prelube is set to “0”, Intermittent Lubrication will only consist in the lube – standby/standby - lube
phases (see START mode).
2.1.2 LUBE
This step is made up of a set of cycles (max 999 cycles) during which lubrication is carried out. Each cycle
consists of two sub-cycles (lube and wait) and involves the monitoring of timers and/or inputs:
- during lube, system delivers lubricant to the lubrication points;
- during wait, a timer defines the wait time between two or more lube cycles or before the beginning of
the standby phase (in case only 1 lube cycle was set).
There are three types of lube:
 TIMER: Lubricant delivery is simply regulated by a timer;
 PS: Lubricant delivery is carried out only if the system is in pressure;
 SEP: Lubricant delivery is carried out only the system detects three changes in the position of the
mechanical piston.
2.1.3 STANDBY
During this step lubrication system is idle until the next lubrication cycle. There are three ways to regulate
standby:
 TIMER: a timer regulate system idling;
 PULSE: a pulse counter regulate system idling;
 BOTH: both a timer and a pulse counter regulate system idling. The type of standby will depend on
which of these two events will start first.

3
3. PRODUCT-MACHINE IDENTIFICATION
Machine identification yellow label is located on the front side of the reservoir and contains product serial
number, input voltage and details of the operating parameters.
4. TECHNICAL SPECIFICATIONS
4.1 General technical specifications
Lubricant Mineral Oil
Lubricant Viscosity 68 ÷ 320 cSt (320 ÷ 1480 SUS)
Working Temperature +5°C ÷ + 60°C (+41°F ÷ +140°F)
Storage Temperature - 20°C ÷ + 60°C (-4°F ÷ +140°F)
Working Humidity 90% max
Mechanical Protection Grade IP-55
Sound Pressure Level <70 dB (A)
4.2 Electric gear pump
Voltage 110V/50Hz 110V/60Hz 220V/50Hz
Power absorption 162W 155 W 150W
Nominal current 1.48A 0.69A
Pump flowrate 180 cm³/min
(10.98 cu.in.)/min
220 cm³/min
(13.42 cu.in.)/min
180 cm³/min
(10.98 cu.in.)/min
Maximum Pressure 30 bar (411psi)
Reservoir Capacity 3 litres (0.66 gals)
By-pass Calibration 25 bar (367.5 psi)
Pressure-Switch calibration 18 bar (264.6 psi)
Insulation Class B
Rotation direction clockwise
Revolutions/min 2900 3500 2900
Max working time in continuous 2 minutes
MIN STANDBY time 5 times MIN setup time
NOTE: pump output is energized.
4.3 Battery backup (DATE and TIME)
CPU real time clock is powered by a lithium battery for Date and Time backup in the event of powerfailure.
Voltage 3.7V
Current consumption 100mA
Capacitance 800 mA/h
Temperature -50°C÷+70°C (-58°F÷+158°F)
Lifetime 5 years
5. MACHINE COMPONENTS
The following main components are assembled to the baseplate:
 A reservoir, made of transparent plastic material;
 An electric gear-pump, with high performance and minimum power consumption;
 A SAMBA level sensor, which indicates lubricant minimum level via a N.O. electric contact
(reservoir empty). To reverse N.O. to N.C., please contact Dropsa Eng. Dept.;
 A manometer;
 A N.O. Pressure-switch , which detects system in pressure;
 A PCB user interface.

4
5.1 MANUAL SMART2
The electronic board, located under the cover of manual SMART2, allows pressure-switch and electric level
contact management both indipendent and serial.
On the front panel there are:
 Push-button for manual control, “MANUAL”;
 LED indicator for “PUMP ON”.
5.1 AUTOMATIC SMART2
VIP2004 Controller, located under the cover of automatic SMART2, allows pump total autonomy both in cycle
times, alarms or checks.
On the front panel there are:
 LCD display 16x2 types;
 Push-buttons: three for control/management and one RESET button.

5
6. UNPACKING AND INSTALLING THE PUMP
6.1 UNPACKING
Once a suitable location has been found to install the unit, remove the pump from package. Check the unit has
not been damaged during transportation or storage. No particular disposal procedures are necessary as
package materials are no dangerous for health or environment. However, package should be disposed of in
accordance with regulations that may be in force in your area or state.
6.2 INSTALLING THE PUMP
 In order to facilitate any maintenance intervention, to avoid unnatural posture for personnel during
machine operation or the possibility of sustaining impacts, install the machine in a comfortable and
easy-to-reach location.
 Allow sufficient space for the installation, leaving minimum 100 mm (3.9 in.) around the unit.
 Do not install the unit in aggressive or explosive/inflammable environments or on vibrating surfaces.
 To install the pump, use only the supplied bracket provided with two holes for Ø6 mm (Ø 0.2 in.)
screws (see Dimensions, ch. 12).
6.3 HYDRAULIC CONNECTION
Connect SMART2 to the system via the hydraulic connection located on the baseplate, on the right side of the
pump: standard thread ¼ BSP.
6.4 ELECTRIC WIRING
6.4.1 ELECTRIC DIAGRAM
Here follows the general electric diagram for both automatic and manual SMART2:
NOTICE: Pressure can be monitored by a micro-switch or a NPN/PNP proximity sensor.
6.4.2 USER CONNECTIONS
The following picture shows PCB user interface, where the user has to connect power supply and external
outputs for the correct functioning of both automatic and manual SMART2. For details about connections,
please refer to special paragraphs. (PCB serigraphy only refers to automatic SMART2).
PCB user connections
only refers to automatic
SMART2
M1
M2

6
6.4.2.1 CONNECTIONS FOR MANUAL SMART2
Here follows user connections for power supply (terminal M1), pressure-switch and electric level contact
(independent or serial), and the manual push-button (terminal M2). Furthermore, it is also shown how to
change the type of connection (indipendent or serial) for the pressure-switch and electric level contact, by
acting on the jumper located on the electronic board of manual SMART2.
6.4.2.2 CONNECTIONS FOR AUTOMATIC SMART2
Here follows user connections for power supply (terminal M1), external alarm and proximity sensor or micro-
switch (terminal M2).

7
6.4.3 POWER-SUPPLY SWITCH, VARIABLE RESISTOR AND BATTERY
6.4.3.1 POWER SUPPLY SWITCH
⇒ For 220V switch rightwards.
⇒ For 110V switch leftwards.
6.4.3.2 VARIABLE RESISTOR
It allows to regulate display brightness.
6.4.3.3 BATTERY ACTIVATION
The controller is provided with a three-pin-jumper to activate battery backup of Date and Time when the
equipment is powered off.
To short-circuit the board and activate the battery, insert the bridge only into two pins (see above
picture).
WARNING:
- Each time the bridge is removed or powerfailure occurs, Date and Time are reset. It is
recommended to setup Date and Time each time the bridge is removed and then put back in
place.
- In order to make a complete reset of the machine, remove the bridge and switch-off the
machine.
6.4.4 PRECAUTIONS TO BE TAKEN DURING CONNECTING PROCEDURE
⇒ Prior to any operation, verify the voltage of the machine on the product label.
⇒ In order to prevent dangers of electric shocks due to direct or indirect contact with the
energized parts, electrical power supply line must be protected by a suitable magneto-
thermal circuit breaker with an intervention threshold of 0.03 Ampere and 1 second
minimum operating time. Circuit breaker power must be ≤10 kA and nominal power In =6
A.
BATTERY
JUMPER
At the end of all connecting operations, make sure that pipes and wires are safe from
impacts and carefully fixed.
VARIABLE
RESISTOR
POWER SUPPLY
SWITCH

8
7. INSTRUCTIONS FOR USE
7.1 Manual SMART2
When the unit is equipped with the manual system, located on the frontal side panel you find the PUMP-ON
indicator which is on when the pump is operating. Remote control is via external timer or PLC.
Warning: Manual control device cannot be used through a direct control but must be operated through
a deck or an electronic circuit with a max power absorption of 400mA.
7.2 Automatic SMART2
When the unit is equipped with an automatic control, all the pump functions and checks are carried out
through the built-in VIP2004 controller, alarms and external signals included. Timers are also controlled by the
system. For details about machine operation, please refer to par. 7.4.
7.3 Machine operations
7.3.1 Prior to machine start-up
 Verify the unit is undamaged.
 Check that hydraulic and electric connections have been carefully carried out.
 Refill the reservoir with compatible lubricant.
 Verify the voltage: MAX 220VAC.
RESERVOIR REFILL
Use ONLY compatible lubricant and refill the reservoir by means of the oil refill plug provided with a filter. Do
not pour lubricant directly into the reservoir without using this oil refill plug.
7.3.2 Machine start-up
In order to avoid damage to the machine, the unit must start operating at a minimum working temperature of
+5°C (+41°F).
 Switch ON the unit.
 Verify unit start-up.
 Verify piping are air-bubble-free.
 Adjust pressure.
 Set-up machine parameters.
 Verify machine correct operation: pump must carry out lubrication correctly and according
to parameters setup.
AIR VENTING
Pump well-functioning is not affected by presence of air in the system. However, it is advisable to vent air by
starting the pump until lubricant comes out air-bubbles-free. (It is recommended to avoid pump operation
when lubricant is below the minimum level).
PRESSURE REGULATION
Pressure can be verified via manometer. It is possible to regulate pressure by acting on the screw located on
the frontal side of the baseplate.
⇒ To increase pressure: turn the screw clockwise.
⇒ To decrease pressure: turn the screw anticlockwise.
In case of doubts as to correct machine functionin
g
, it is recommended to contac
t
our Eng. Dept. to request testing procedures.

9
7.4 SMART2 with built-in VIP2004 controller operation
7.4.1 Typical working session
Notice: prelube is always carried out according to prelube cycles set-up: if prelube cycles = ‘0’, no
prelube is run and the system will start operating either in standby or lube according to the pre-set
start mode.
7.4.2 Typical system start-up
LUBE X 2 TIMER
00m05s STOP
STANDBY 01m00s
setu
p
-> start
PRELUBE X 3 TIMER
00m05s STOP
PRELUBE will be carried out only when prelube cycles are set
(PRELUBE ≠0).
Whether prelube has been completely carried out (PRELUBE ≠0) or no
prelube was set (PRELUBE = 0), LUBE or STANDBY will start (see
start mode
)
.
www.DROPSA.com
SMART2 rel. 1.10
Jan 01-01-2004 0:00
setu
p
-> start
During standby, you can also see date and time when the function is
enabled (see setup).
STANDBY 99 I
setu
p
-> start
PRELUBE
CYCLES?
YES
PRELUBE
NO
LUBE
YES
STANDBY
LUBE
CYCLES
?
WAIT
NO

10
7.4.3 Setup session
Press YES to enter SETUP.
Press NO to
g
o back to STANDBY or
A
LARM
(
if activated
)
.
Press SET to enter LUBE Time setup; use “-“ and “+” to change the value and
SAVE to save the new setting. Push NEXT to go to the next setup.
To modify STANDBY Time,when this function is controlled by a timer.
This parameter can be set only if
STANDBY type
is
timer
or
both
.
To modify STANDBY pulse when this function is controlled by a pulse register.
This parameter can be set only if STANDBY type is pulse or both.
Press YES to enter the EXTENDED MENU.
Press NO to re-initialize the machine.
Press SET to enter STANDBY Type setup;use “-“ and “+” to select Timer
–
Pulse - Both and SAVE to save the new setting. Push NEXT to go to the next
setu
p
.
To select LUBE Type: Timer – PS - SEP.
ONLY for PS: To modify DELAY Time for pump-OFF.
To modify LUBE Cycle.
To modify WAIT Time between two or more lube cycles.
Note: this parameter is displayed only if Lube or Prelube > 1
To select START mode system: START IN LUBRIC. / START IN STANDBY.
To modify PRELUBE Cycle.
To select the type of alarm electric contact: Norm. Close/ Norm.Open.
To set the day (DATE).
To set the month (DATE).
To set the year (DATE).
To set the hour (TIME).
To set the minutes
(
TIME
)
.
SET UP?
YES NO
LUBE Time 00m05s
SET NEXT
STANDBY 01m00s
SET NEXT
STANDBY 99i
SET NEXT
EXTENDED MENU?
YES NO
STANDBY TIMER
SET NEXT
LUBE Type TIMER
SET NEXT
DELAY Time 00m10s
SET NEXT
LUBE Cycles 2
SET NEXT
WAIT Time 00m10s
SET NEXT
START IN LUBRIC.
SET NEXT
PRELUBE 0
SET NEXT
A
LARM Norm.Open
SET NEXT
Day 1
SET NEXT
Month 1
SET NEXT
Year 2004
SET NEXT
Hour 0
SET NEXT
Minute 0
SET NEXT
BACK TO STANDBY OR
A
LARM
(
IF ACTIVATED
)
MACHINE
RE-INITIALIZATION
Date & Time Enabled
SET NEXT To enable/disable Date and Time function

11
7.4.4 Operative parameters
Parameter Description Operative range Dropsa setting
Timer* A timer defines lube duration 00m01s ÷ 4m59s
PS
Lube starts when system is in
pressure (Pressure is
monitored by a pressure-
switch)
LUBE Type
SEP
A proximity sensor detects
the changes of position of the
piston: after three changes a
lube cycle is completed
10s ÷ 99 min. 00m:10s
Timer* A timer defines standby
duration (system idle) 01m00s ÷ 999h59m59s 06m:00s
Pulse A pulse register defines
standby duration (system idle) 1i ÷ 9,999,999i 100i
STANDBY
Type
Both
Standby duration (system
idle) is defined by both
standby timers (timer and
pulse), whichever occurs first
See Standby
Timer and pulse
06m:00s
100i
DELAY TIME
(FOR PS ONLY)
A timer defines the duration of
PUMP ON (time lag for pump
OFF) once the system goes in
pressure
01s ÷ 99 min. 00m:02s
LUBE Cycles Number of lube cycles to be
carried out by the system 01÷ 999 1
PRELUBE cycles
Number of prelube cycles,
which will be carried out
before the lube cycles
1÷ 999 0
WAIT Time
A timer defines the duration
of a pause time between each
lube process.
ONLY for ‘LUBE type: SEP’:
Set 00m00s for continuous
service
01s ÷ 16m39s 00m:05s
START IN LUBRIC.
START MODE It allows to choose how to
start the working session START IN STANDBY START IN LUBRIC.
Norm. Open
Alarm It allows to choose the type of
alarm electric contact Norm. Close Norm. Close
Date & Time It allows to enable/disable
Date & time display and setup Enabled/Disabled Enabled
Day It allows to set the day 1-31 1
Month It allows to set the month 1-12 1
Year It allows to set the year 2000÷2099 2004
Hour It allows to set the hour 0-23 0
Minute It allows to set the minutes 00-59 00
*Default setting: Lube type: Timer; Standby Type: Timer; Date & Time: Enabled
NOTICE: When Date and Time are enabled, in order to avoid controller malfunctioning, it is
recommended to set day, month and year in accordance with the calendar.
7.5 I-R communication
Controller VIP2004 is provided with an I-R port for infra-red communication via special I-R device and Dropsa
software to be installed on your PC. This innovative system will allow you to remotely manage (1÷1.5 m – 39 ÷
60 in.-) two important operations:
- Lube status reading-> reading of the machine data on your PC: lube parameters, date, time and
logs;
- Machine programming -> setup of the machine data from your PC: lube parameters, date and time.
The I-R communication system (Dropsa software included) is furnishable by Dropsa on demand.

12
8. TROUBLESHOOTING
The following diagnostic table indicates the main anomalies which may be encountered, the probable causes
and possible solutions. If you cannot solve the problem, do not attempt to disassemble the unit, but
contact the Engineering Department of DROPSA S.p.A.
8.1 PUMP DIAGNOSTICS (MANUAL AND AUTOMATIC SMART2)
ANOMALY PROBABLE CAUSE SOLUTION
Pump does not deliver
lubricant.
Pump does not deliver the
fixed amount of lubricant
• Pump draws off air
because the reservoir
is empty.
→ Refill the reservoir and vent air
from the system.
• Loosened inner
fittings.
→ Retighten all the fittings.
Be sure there are no
Leakages.
• Wear of the pump. → Replace the pump.
Pump delivers oil at an
improper pressure
• Wrong calibration of
the by-pass valve.
→ Install a manometer to adjust
by-pass at the proper
pressure.
The system stays in
pressure at the end of the
lube cycle
• Vent valve damaged
or dirty.
→ Inspect and clean the valve.
Replace it, if necessary.
8.2 VIP2004 CONTROLLER ALARMS (AUTOMATIC SMART2)
When an alarm occurs, an external signal is ON. The display will show one of the following alarms for two
seconds:
ALARM 01 - TIMER FAULT Internal process error during lube by timer.
ALARM 02 - PX VENT FAILED At the beginning of lube by PS: it was detected
that the system has not vented air.
ALARM 04 PS - PRESSURE ALARM During lube by PS, it was detected that the
system never goes in pressure.
ALARM 06 PS - PRESSURE LOSS During lube by PS, even though the pump is
operating, the system loses pressure.
ALARM 08 PS - GENERAL FAULT Internal process error during lube by PS.
ALARM 09 SEP - CYCLE TIMEOUT During lube by SEP: the sensor cannot detect
one or all the changes of position of the piston.
ALARM 10 SEP - GENERAL FAULT Internal process error during lube by SEP.
ALARM 11 - LOW LEVEL The Samba Level Sensor detected low level.
Refill the reservoir.
8.3 RESTART/RESET the system
Once one of the above alarm status occurs, another display will be shown:
For example:
There are two ways to restore machine operating:
⇒ By pressing setup (left push-button), the system will enter the setup session to modify, at any rate,
parameters and re-start the machine.
⇒ By pressing reset for two seconds (right push-button or RESET button), the system will be reset and
the machine will be re-initialized and will operate according to the last saved data setup.
WARNING: This unit can be opened and repaired by Dropsa personnel only
ALARM 11
setup reset

13
9. MAINTENANCE PROCEDURE
SMART2 has been designed and manufactured to require the minimum maintenance. Anyway, it is
recommended :
 To keep the unit clean and periodically to check pipe joints to readily detect possible leaks.
PERIODICAL MAINTENANCE
Inspection Number of
work cycles Maintenance Procedure
Lubrication 1.000 -
Cleanliness of refill filter 4.000 Replace the refill filter, if necessary
Cleanliness of reservoir 6.000 Clean the bottom of the reservoir in case of impurities
10. DISPOSAL
During maintenance or disposal of the machine care should be taken to properly dispose of environmentally
sensitive items. Refer to local regulations in force in your area.
When disposing of this unit, it is important to ensure that the identification label and all the other relative
documents are also destroyed.
11. ORDERING INFORMATION
11.1 MANUAL SMART2
11.2 AUTOMATIC SMART2
PART N° DESCRIPTION
3600240 SMART2 ELECTRO-PUMP 110V/50 Hz
3600241 SMART2 ELECTRO-PUMP 110V/60 Hz
3600242 SMART2 ELECTRO-PUMP 220V/50 Hz
PART N° DESCRIPTION
3600210 SMART2 ELECTRO-PUMP 110V/50 Hz
3600211 SMART2 ELECTRO-PUMP 110V/60 Hz
3600212 SMART2 ELECTRO-PUMP 220V/50 Hz
The machine does not require any special tool for check or maintenance tasks. However, it
is recommended the use only of appropriate and in good conditions tooling, protective
devices (gloves) and clothing (626/94 and DPR 547/55) to avoid injury to persons o
r
damage to machine parts.
WARNING: It is recommended the use of impurity-free lubricant
WARNING:Prior to any maintenance, be sure that the power and the hydraulic supplies
are off and there is no residual pressure in the main/branch pipe.

14
11.3 SPARE PARTS
PART N° DESCRIPTION
3132725 Control kit for automatic SMART2
3132726 Control kit for manual SMART2
3600903 Motor unit for SMART2 110V/50Hz (automatic and manual)
3600904 Motor unit for SMART2 110V/60Hz (automatic and manual)
3600905 Motor unit for SMART2 220V/50Hz (automatic and manual)
6770033 Transparent reservoir 3 litres (0.66 gals)
3292053 Manometer 60 bar (882 psi) 1/8” cone
6770070 Refilling Cap (for oil)
3130101 Refilling filter
3291048 Pressure-switch 18 bar (264.6 psi)
1655582 MIN level
12. DIMENSIONS
Weight: 4.00 Kg (8.8 lbs)

15
13. HANDLING AND TRANSPORTATION
Prior to shipping, the equipment is carefully packed in cardboard package. During transportation and storage,
always maintain the pump the right way up as indicated on the box. On receipt check that package has not
been damaged. Then, storage the machine in a dry location.
⇒ Due to machine contained weight and size, it is not necessary the use of material handling
equipment. Anyway, we recommend to lift the equipment observing the right way up shown on
the cardboard package.
14. OPERATING HAZARDS
Power supply
Any type of intervention must not be carried out before unplugging the machine from power supply. Make
sure that no one can start it up again during the intervention. All the installed electric and electronic equipment,
reservoirs and basic components must be grounded.
Flammability
The lubricant generally used in lubrication systems is not normally flammable. However, it is advised to avoid
contact with extremely hot substances or naked flames.
Pressure
Prior to any intervention, check the absence of residual pressure in any branch of the lubricant circuit as it may
cause oil sprays when disassembling components or fittings.
Noise
Pump does not produce excessive noise, less than 70 dB(A).
15. PRECAUTIONS
No particular operating hazards characterize the machine, except for the following precautions:
♦ Operator’s contact with the lubricant in case of piping breaking/opening or during
refill/maintenance. -> Protection against direct and indirect contact with the fluid must be provided
by the user: the operator must be provided with suitable individual protective clothing and devices
(tit VIII – 626).
♦ Use of incompatible lubricant. Main unauthorized fluids:
⇓
Fluids Dangers
Lubricants containing abrasive components Premature wear of pump
Lubricants containing silicon Pump failure
Petrol – solvents – inflammable liquids Fire – explosion –seal damage
Corrosive products Pump damage - danger to persons
Water Pump oxidization
Food Products Contamination of the product
WARNING: It is necessar
y
to carefull
y
read about the instructions and the risks involved in
the use of lubrication machines. The operator must know the machin
e
functioning through the User and Maintenance Manual.

16
16. WARRANTY INFORMATION
All products manufactured and marketed by Dropsa are warranted to be free of defects in material or
workmanship for a period of at least 12 months from date of delivery. Extended warranty coverage applies as
follows:
Complete system installation by Dropsa: 24 Months
All other components: 12 months from date of installation; if installed 6 months or more after ship date,
warranty shall be maximum of 18 months from ship date.
If a fault develops, notify us giving a complete description of the alleged malfunction. Include the part
number(s), test record number where available (format xxxxxx-xxxxxx), date of delivery and installation and
operating conditions of subject product(s). We will subsequently review this information and, at our option,
supply you with either servicing data or shipping instruction and returned materials authorization (RMA) which
will have instructions on how to prepare the product for return. Upon prepaid receipt of subject product to an
authorized Dropsa Sales & Service location, we will then either repair or replace such product(s), at out option,
and if determined to be a warranted defect, we will perform such necessary product repairs or replace such
product(s) at our expense.
Dropsa reserves to right to charge an administration fee if the product(s) returned are found to be not
defective.
This limited warranty does not cover any products, damages or injuries resulting from misuse, neglect, normal
expected wear, chemically caused corrosion, improper installation or operation contrary to factory
recommendation. Nor does it cover equipment that has been modified, tampered with or altered without
authorization.
Consumables and perishable products are excluded from this or any other warranty.
No other extended liabilities are states or implied and this warranty in no event covers incidental or
consequential damages, injuries or costs resulting from any such defective product(s).
The use of Dropsa product(s) implies the acceptance of our warranty conditions. Modifications to our standard
warranty must be in made in writing and approved by Dropsa.

17
17. DECLARATION OF COMPLIANCE WITH CE STANDARDS
Manufacturer :
DROPSA SpA
Company
Via Croce, 1 – 20090 Vimodrone (MI)
Address
0039-02-250791
Telephone
Certifies that:
The machine: SMART 2 PUMP SW ver. 1.00
∗ Has been manufactured in conformance with the EUROPEAN COMMUNITY DIRECTIVE relating
to machines (98/37/EC) + 91/368/EEC, low voltage (BT 73/23/EEC).
∗ Has been manufactured in conformance with the following technical harmonised standards and
specification
EN 292/1, EN 292/2, EN 50081-2, EN 50082-2, EIC EN 60204-1, EN 1050.
Technical Director ing. Walter Divisi
Product Manager Name
DROPSA SpA - Vimodrone (Mi) - Italy
Company
July 04
Signature Date
DRAFT

18
18.DROPSA LOCATIONS
Dropsa USA Inc.
50679 Wing Drive
Utica, Michigan 48315 - USA
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Dropsa France
23, Av. des. Morillons
Z.I. des Doucettes
91140 - Garges Les Gonesse
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Dropsa (UK) Ltd
Unit 6, Egham Business Village,
Egham,Surrey,TW20 8RB
Tel: [phone] - 431177
Fax: [phone] - 438598
E-mail: [email protected]
Dropsa do Brazil
Rua Sobralia 171 Santo Amaro
Sao Paulo, Brazil
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Dropsa S.p.A.
Via B. Croce,1
20090 Vimodrone (MI) Italy
Tel: (+39) 02 - 250.79.1
Fax: (+39) 02 - 250.79.767
E-mail: [email protected] (Export)
E-mail: [email protected] (National)
Polydrop S.A.
Av. Fabregada 26 - Pje Est.2
08907 L'Hospitalet de LLobregat
Barcelona, Spain
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Dropsa Gmbh
Volmerswerther Strasse 80
40221 Dusseldorf 1, Deutschland
Tel: [phone]
Fax:[phone]
E-mail: [email protected]
Dropsa Australia Pty.
C20/148 Old Pittwater Road
Brookvale NSW 2100
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Web site: http://www.dropsa.com - E-mail: [email protected]
