Dru Metro 130 XTL G20 User manual

English
Store this document in a safe place
Dieses Dokument bitte sorgfältig aufbewahren
Metro 100 XTL
Installation manual (GB / IE)
959.027.01.GB
G20/25
GB
B*%,QVWDOOLQGG 

2
METRO 100 XTL  INSTALLATION MANUAL
English
Contents
page
Preface 3
1. Introduction 3
2. CE declaration 3
3. SAFETY 4
3.1 General 4
3.2 Regulations 4
3.3 Precautions / safety instructions during installation 4
4. Instructions 4
5. Removing the packaging 4
6. Installation 5
6.1 Regulations 5
6.2 Type of gas 5
6.3 Gas connection 5
6.4 Placing the appliance 5
6.5 Flue gas discharge / combustion air supply system 6
6.6 Placing the chimney breast 10
6.7 Placing the control box 11
6.8 Adjusting the appliance 11
6.9 Placing the wood/pebble set 12
6.10 Panes 13
7. Wireless remote control 14
7.1 Receiver 14
8. Final check 15
8.1 Gastightness 15
8.2 Gas pressure / pre-pressure 15
8.3 Ignition pilot and main burner 15
8.4 Flame image 16
9. Maintenance 17
9.1 Parts 17
10. Delivery 17
11. Malfunctions 18
Appendix 1Parts included with the delivery 21
Appendix 2Technical data 21
Appendix 3 Figures 22
GB
B*%,QVWDOOLQGG 

3
METRO 100 XTL  INSTALLATION MANUAL
English
Preface
DRU, a manufacturer of gas-red heating appliances, develops and produces products that comply with the highest
quality, performance and safety requirements.
This guarantees that the user will be able to enjoy using his product for many years to come.
This appliance has a CE marking, which means that it complies with the essential requirements of the European gas
appliance directive.
Two manuals are supplied with the appliance: the installation manual and the user manual.
As an installer, you must be competent in the eld of atmospheric gas-red heating.
The installation manual will give you the information you need to install the appliance in such a way that it will
operate properly and safely.
This manual discusses the installation of the appliance and the regulations that apply to the installation. In addition,
you will nd technical data for the appliance and information on maintenance, any malfunctions that might occur
and their possible causes.
The gures are included at the back of this booklet (Appendix 3).
Please carefully read and use this installation manual.
The following symbols are used in the manual to indicate important information:
➠
Work to be performed
!Tip Suggestions and recommendations
!Caution You will need these instructions to prevent problems that might occur during installation and/or use.
Caution You need these instructions to prevent re, personal injury or other serious damages.
After delivery, you should give the user manual and this installation manual to the user.
1. Introduction
The Metro 100 XTL is a room-sealed atmospheric gas-red heating appliance.
This version of the Metro 100 XTL is suitable for natural gas. The safe operation of the appliance is guaranteed by the
use of a second thermocouple tted to the main burner.
A room-sealed appliance does not extract the combustion air from the living environment, but from outside. This is
done by means of a combined ue gas discharge system / combustion air supply system. In this concentric system,
the outer pipe functions as the air supply and the inner pipe functions as the ue gas discharge.
This system can be installed through the wall or through the roof.
These appliances are built within a chimney breast. For this, DRU has a number of chimney breasts in its range.
In order to reach a proper heat discharge, the chimney breast must be ventilated. DRU is able to supply various
ventilation elements.
The adjustable height of the appliance can be increased by means of the extension legs that can be ordered from
DRU.
The appliances are supplied with a wireless remote control that works on batteries.
2. CE declaration
We hereby declare that the design and construction of DRU’s atmospheric gas-red heating appliance comply with
the essential requirements of the Gas Appliance Directive.
Product: atmospheric gas-red heating appliance
Type: Metro 100 XTL
Applicable EEC directives: 2009/142/EC
Applied harmonized standards: NEN-EN-613
NEN-EN-613/A1
Internal measures by the company guarantee that appliances produced in series comply with the essential require-
ments of the prevailing EEC directives and the standards derived from them.
This declaration will lose its validity if adjustments are made to the appliance, without prior written permission by DRU.
M.J.M. Gelten
General manager
DRU verwarming B.V.
Postbus 1021, 6920 BA Duiven
Ratio 8, 6921 RW Duiven
www.dru.nl
GB
B*%,QVWDOOLQGG 

4
METRO 100 XTL  INSTALLATION MANUAL
English
3. SAFETY
3.1 General
Caution - Carefully read this chapter on safety, before you start performing installation or maintenance work;
- Please observe the general regulations and the precautions/safety instructions in this manual.
3.2 Regulations
Please install the appliance in accordance with the applicable national, local and constructional (installation) regulations.
3.3 Precautions / safety instructions during installation
Carefully observe the following precautions/safety regulations:
➠
you should only install and maintain the appliance if you are a competent installer in the eld of atmospheric gas-red heating;
➠
do not make any changes to the appliance;
➠
use non combustible and heat-resistant materials for the chimney breast, including the top of the chimney breast, the
material in the chimney breast and the back wall against which the appliance will be placed;
➠
take sucient measures to prevent temperatures of a wall behind the chimney breast becoming too high, including
the materials and/or objects behind the wall;
➠
comply with the minimum required internal measurements of the chimney breast;
➠
ventilate the chimney breast by means of the ventilation holes, which will form a combined passage of at least 200cm2;
➠
only use the ue gas discharge / combustion air supply system supplied by DRU;
➠
mount the appliance using the wall brackets supplied;
➠
do not place the appliance too tightly against the back wall;
➠
make sure the space between the appliance’s legs is kept free;
➠
do not cover the appliance and/or do not wrap it in an insulation blanket or any other material;
➠
make sure that combustible objects and/or materials have a distance from the appliance of at least 500mm;
➠
only ever use the supplied wood/pebble set;
➠
place the wood/pebble set exactly as described;
➠
make sure the pilot burner and the space around it is kept free;
➠
make sure thermocouple 2 and the space around it are kept free;
➠
make sure there is no dirt in gas pipes and connections;
➠
mount a gas tap directly next to the appliance;
➠
check the connections for gastightness before using the appliance;
➠
use heat resistant electrical wiring;
➠
place the electrical wiring in such a way that they are free from the appliance;
➠
replace torn or broken panes;
➠
avoid blocking of the pressure equalization hatch(es) on top of the appliance;
➠
check whether the pressure equalization hatch(es) t well onto the sealing surface, prior to building in the appliance;
➠
do not ignite the appliance until it is fully installed.
4. Instructions
Observe the following items during installation in order to guarantee a proper and safe operation of the appliance:
➠
mount the control box supplied as low as possible;
➠
avoid that the ignition cable runs over the receiver;
➠
avoid that the ignition cable touches or crosses the antenna;
➠
avoid that the ignition cable runs alongside metal parts, in order to prevent weakening of the spark;
➠
properly nish the edges in case of a tight construction;
➠
do not apply plaster on or over the anges;
➠
avoid damaging the pane when removing/placing the glass window;
➠
clean the pane before you use the appliance, in order to prevent dirt from burning in the glass;
➠
make sure that the wires of thermocouple 2 cannot come into contact with hot parts.
5. Removing the packaging
Note the following items when removing the packaging:
➠
Check the appliance for damages during transport.
➠
If necessary, contact DRU Service.
After removing the packaging, you should have the following components:
- Socket spanner; you will nd it in the space between the assembly frame and the combustion chamber;
- Decorative strips; you will nd them in the abovementioned space as well;
- Box containing parts; you will nd it in the combustion chamber.
GB
B*%,QVWDOOLQGG 

5
METRO 100 XTL  INSTALLATION MANUAL
English
➠
Remove the box containing parts from the combustion chamber.
In appendix 1 / table 5 you can see which parts you should have after removing the packaging.
➠
Contact DRU Service if you do not have all the parts after you nished removing the packaging.
➠
Dispose packaging in accordance with local regulations.
6. Installation
Read this manual carefully to ensure a proper and safe operation of the appliance.
!Caution Install the appliance in the order described in this chapter.
6.1 Regulations
➠
Observe the applicable (installation) regulations.
➠
Observe the regulations/instructions in this manual.
6.2 Type of gas
The data plate indicates for which type of gas, gas pressure and for which country this appliance is intended. The
data plate is connected to a chain. It should remain connected to the chain.
Caution Check whether the appliance is suitable for the type of gas and the gas pressure used at the location.
6.3 Gas connection
Place a gas tap in the gas connection, close to the appliance.
Caution - Make sure there is no dirt in gas pipes and connections;
- Prevent twisting the gas tap when connecting the gas pipe.
The following requirements apply to the gas connection:
- use a gas pipe with the correct dimensions, so that no pressure loss can occur;
- the gas tap should have the CE marking;
- you should always be able to reach the gas tap.
6.4 Placing the appliance
Caution - Make sure that combustible objects and/or materials have a distance from the appliance of at least 500mm;
- Always place the appliance against a wall of non combustible and heat-resistant material;
- Take sucient measures to prevent temperatures of a wall behind the chimney breast becoming too high, including
the materials and/or objects behind the wall;
- Do not make any changes to the appliance.
!Caution - Take the adjustable height of the appliance into account; it depends on the setting of the adjustable feet (see g.1);
- If applicable, the extension legs should be xed by means of self-tapping screws;
- Take the minimum internal construction depth of the appliance into account; Metro 100 XTL: 448 mm (see g. 2.).
!Tip You can determine the construction height of the appliance (X in g. 2) yourself (min. 248 mm).
Place the appliance as follows:
➠
Determine the location of the appliance.
➠
Determine the construction height of the appliance.
➠
Provide a gas connection at the location. For details, see section 6.3.
➠
Make a passage for the ue gas discharge/combustion air supply system with the following diameters. For details, see
section 6.5.
- Ø160 mm for a wall terminal through non combustible material;
- Ø 250 mm for a wall terminal through combustible material;
- Ø160 mm for a roof terminal through non combustible material;
- Ø 250 mm for a roof terminal through combustible material.
GB
B*%,QVWDOOLQGG 

6
METRO 100 XTL  INSTALLATION MANUAL
English
For adjusting the C Prole in relation to the construction frame, proceed as follows:
➠
Loosen the M5 nuts by one stroke. (See gure 3) Slide the prole to the required distance in relation to the construction
frame (15-30mm). Then retighten the nuts.
➠
Place the appliance on its destined location.
The gas control is mounted under the appliance, at the burner plate. It should be disconnected and placed in the
control box at a later stage. For placing the gas control in the control box, see section 6.7.
Follow the procedure described below:
➠
Disconnect the pipes from the gas control (exible gas pipe, aluminium pilot-ame pipe and thermocouple 1).
!Caution The red wire of thermocouple 2 must remain connected to the gas control.
➠
Disconnect the gas control from the burner plate by unscrewing the self-tapping screw.
➠
Carefully unwind the red and black wires of thermocouple 2.
➠
Lay the gas control together with the wires of thermocouple 2 in the direction of the control box.
Caution - Make sure there is no dirt in gas pipes and connections;
- Avoid kinks in the pipes.
➠
Roll out the pipes in the direction of the control box.
➠
Roll out the ignition cable in the direction of the control box.
!Caution The data plate should remain connected to the chain.
➠
Place the chain with the data plate in the direction of the control box.
➠
Set the height of the appliance using the adjustable feet and
➠
Make the appliance level at the same time.
Caution - Do not place the appliance too tightly against the back wall; this is guaranteed by dimensions of the construction
frame;
- Make sure the space between the appliance’s legs is kept free;
- Do not cover the appliance and/or do not wrap it in an insulation blanket or any other material.
➠
Attach the appliance to the wall, using the supplied key bolts (4). See appendix 3 gure 4.
➠
Use the hook to connect the threaded rods to the corners of the construction frame. See gure 5 and 6.
!Caution Adjust the threaded rod in such a way with the tensioning nut that you have sucient setting space.
➠
Determine the height of the eye nut against the wall.
➠
Attach the eye to the wall using the supplied key bolt.
➠
Use hook to connect the threaded rod to the tensioning nut. Connect the other hook to the threaded rod using the
connection nut.
➠
Connect the hook to the eye nut against the wall.
➠
Adjust everything, using the tensioning nut.
6.5 Flue gas discharge / combustion air supply system
6.5.1 General
The appliance is of the C11/C31 type.
The appliance is connected to a combined ue gas discharge/combustion air supply system, hereafter referred to
as the concentric system.
The passage to the outside can be made with a wall terminal (see section 6.5.2) or a roof terminal (see section 6.5.3).
If necessary, you can also use an existing chimney (see section 6.5.4).
Caution - Only use the concentric system supplied by DRU (Ø100 / Ø150mm). This system has been tested together with the ap-
pliance. DRU cannot guarantee a proper and safe operation of other systems and does not accept any liability for this;
- For connecting to an existing chimney you should only use the chimney kit supplied by DRU.
The concentric system is constructed from (the connection stump of) the appliance.
If structural circumstances require that the concentric system is placed rst, the appliance can later be connected
with a telescopic pipe piece.
GB
B*%,QVWDOOLQGG 

7
METRO 100 XTL  INSTALLATION MANUAL
English
6.5.2 Application with wall terminal
6.5.2.1 Construction of concentric system with wall terminal
The concentric system with wall terminal has to comply with the following conditions:
- First, a concentric pipe of at least 0.5 meters should be connected vertically to the appliance;
- The total vertical pipe length may have a maximum of 4 meters;
- A 90° bend is connected to the other end of the vertical part;
- When using 0.5 meter of vertical pipe length, the total horizontal pipe length can have a maximum of 2 meters
(excluding wall terminal, see g. 7a);
- When using a minimum of 1 meter up to a maximum of 4 meters of vertical pipe length, the total horizontal pipe
length can have a maximum of 3 meters (excluding wall terminal, see g. 7b and 7c).
Depending on the construction of the concentric system, the appliance must receive further settings; see Table 1 for
determining the conditions and section 6.8, Adjusting the appliance, for the method.
Table 1: Conditions for the adjustment of the appliance with a wall terminal
G20/25
Total number of
meters vertical
pipe length
Total number of
meters horizontal
pipe length (excluding
wall terminal)
See gure Air inlet guide Bae Distance of
restriction
in mm
0,5 0 - 2 5a NO NO OPEN
1 - 4 >0 - 3 5b NO NO OPEN
1 - 4 0* 5c YES, 13mm OPENING NO OPEN
* factory setting
6.5.2.2 Placing concentric system with wall terminal
Caution - Maintain a distance of at least 50mm between the outside of the concentric system and the walls and/or the ceiling.
If the system is built in (for instance) a cove, it should be made with non combustible material all around it.
- Use heat-resistant insulation material when passing through combustible material;
- The rosette (mounting inner plate) of the wall terminal is too small to seal the Ø250mm opening when passing
through combustible material. That is why you should rst apply a suciently large heat-resistant intermediate
plate to the wall. Then, the rosette is mounted on the intermediate plate.
!Caution Some heat-resistant insulation materials contain volatile components that will spread an unpleasant smell for a pro-
longed time; these are not suitable.
Place the concentric system as follows:
➠
Build the system up from (the connection stump of) the appliance.
➠
Connect the concentric pipe pieces and the bend.
➠
On each connection, apply a clip binding with silicon sealing ring.
➠
Use a self-tapping screw to x the clip binding to the pipe on locations that cannot be reached after installation.
➠
Apply sucient clamps, so that the weight of the pipes does not rest on the appliance.
➠
Determine the remaining length of the wall terminal;
➠
Make sure the wall terminal has the right dimensions.
!Caution - Make sure that the right insertion length is maintained;
- Place the wall terminal with the groove/folded seam at the top;
- Make sure the horizontal concentric pipe pieces are sloping towards the wall terminal, in order to prevent rain water
from entering.
➠
Mount the rosette (mounting inner plate); if necessary, on a heat resistant intermediate plate when passing through
combustible material.
➠
Attach the wall terminal from the outside with four screws in their respective holes.
GB
B*%,QVWDOOLQGG 

8
METRO 100 XTL  INSTALLATION MANUAL
English
6.5.3 Application with roof terminal
6.5.3.1 Construction of concentric system with roof terminal
The concentric system with roof terminal has to comply with the following conditions:
- The construction of the chosen system has to be allowed. (See the procedure described below);
- First, a concentric pipe of at least 1meter should be connected vertically to the appliance.
Depending on the construction of the concentric system, the appliance is set by placing the bae and/or adjusting
the air inlet guide.
In the following procedure you can see how the allowability of a concentric system can be determined and which
settings are needed.
➠
Determine the following data:
1) The number of bends required (no distinction is made between 45° and 90° bends);
2) The total number of meters of horizontal pipe length;
3) The total number of meters of vertical and/or sloping pipe length (roof terminal excluded).
With these data and Table2 you will be able to determine whether the concentric system is allowed.
In Table3 you can see which setting the appliance requires.
Follow the procedure described below:
➠
In the rst 2 columns of Table2, look for the number of bends required and the total horizontal pipe length.
➠
In the 3rd column of Table2, look for the total vertical and/or sloping pipe length.
If you end up in a box with the letter A, B, C, or D, the concentric system chosen by you is allowed.
➠
Use Table 3 to determine which conditions apply for the bae and/or the air inlet guide (for setting, see section 6.8).
Examples
To clarify, we will give 2 examples to determine the allowability of a concentric system and the conditions for setting
the appliance.
In Table 2 the route to be followed is indicated by arrows. The result is indicated by a box with a red border.
Example 1
1) 2 bends
2) 3 meters horizontal
3) 8 meters vertical/sloping
→ Construction of this concentric system is allowed.
→ Situation B applies for the adjustment of the appliance.
Example 2
1) 3 bends
2) 4 meters horizontal
3) 9 meters vertical/sloping
→ Construction of this concentric system is not allowed.
GB
B*%,QVWDOOLQGG 

9
METRO 100 XTL  INSTALLATION MANUAL
English
Table 2: Determination of the permissibility of a concentric system with a roof terminal
G20/25 Total number of
meters horizontal
pipe length
Total number of meters vertical and/or sloping pipe length
1234567
↓8↓910 11 12
no bends 0 B B B CCCCCDDDD
2 bends 0 A A B B B CCCCCDD
1 AABBBCCCCC
2 AABBBCCC
→3 AABBBC
4AABB
5
3 bends 0 A A A B B B CCCCCD
1 AAABBBCCCC
2 AAABBBCC
3 AAABBB
→4 AAAB
5
4 bends 0 AAAABBBCCCCC
1 AAAABBBCCC
2 AAAABBBC
3 AAAABB
4 AAAA
5
5 bends -
■= situation is not allowed
Table 3: Conditions for the adjustment of the appliance with a roof terminal
G20/25
Situation Air inlet guide Bae Distance of restriction in mm
A NO NO OPEN
B YES, ADJUSTED TO 13MM YES 55
C YES, ADJUSTED TO 9MM YES 45
D YES, ADJUSTED TO 9MM YES 40
6.5.3.2 Placing concentric system with roof terminal
The roof terminal can end in a sloping and a at roof.
The roof terminal can be supplied with an adhesive plate for a at roof or with a universally adjustable tile for a
sloping roof.
Caution - Maintain a distance of at least 50mm between the outside of the concentric system and the walls and/or the ceiling.
If the system is built in (for instance) a cove, it should be made with non combustible material all around it;
- Use heat-resistant insulation material when passing through combustible material.
!Caution Some heat-resistant insulation materials contain volatile components that will spread an unpleasant smell for a pro-
longed time; these are not suitable.
GB
B*%,QVWDOOLQGG 

10
METRO 100 XTL  INSTALLATION MANUAL
English
Place the concentric system as follows:
➠
Build the system up from (the connection stump of) the appliance.
➠
Connect the concentric pipe pieces and, if necessary, the bends.
➠
On each connection, apply a clip binding with silicon sealing ring.
➠
Use a self-tapping screw to x the clip binding to the pipe on locations that cannot be reached after installation.
➠
Apply sucient clamps, so that the weight of the pipes does not rest on the appliance.
➠
Determine the remaining length of the roof terminal.
➠
Make sure the roof terminal has the right dimensions.
!Caution Make sure that the right insertion length is maintained.
➠
Connect the roof terminal to the concentric pipes.
!Caution - Make sure that the universal tile ts well with the surrounding tiles;
- Make sure that the adhesive plate ts well onto the at roof.
6.5.4 Connection of existing chimney
It is possible to connect the appliance to an existing channel.
A exible SS pipe is placed in the chimney for discharging ue gases. The surrounding space is used to supply com-
bustion air.
The following requirements apply when connecting to an existing chimney:
- only allowed when used in combination with the special DRU chimney kit. The installation manual is also supplied;
- the dimensions should be at least 150 x 150 mm;
- the vertical length has a maximum of 12meters;
- the horizontal length has a maximum of 3meters;
- the existing chimney has to be clean;
- the existing chimney has to be tight.
If the appliance is installed into an existing chimney by means of a chimney kit, there may be a slight loss in heat
output.
For setting the appliance, the same conditions/instructions apply as for the concentric system described above.
6.6 Placing the chimney breast
The appliance is designed to be mounted tightly in a new chimney breast.
In order to provide proper heat discharge, there should be sucient space around the appliance.
The chimney breast should be ventilated suciently by means of ventilation holes.
This appliance is only suitable for construction using a chimney breast from promatec or other non combustible and
heat-resistant material. (Thickness 15-30 mm)
Caution - Use non combustible and heat-resistant materials for the chimney breast, including the top of the chimney breast,
the material in the chimney breast and the back wall of the chimney breast;
- The ventilation holes - which should be mounted as high as possible - should have a combined passage of at least
200 cm2.
!Caution When placing the chimney breast, you should take the following into account:
(see g. 2)
- the narrow anges of the appliance’s mounting frame;
- the location of the control box: it should be placed with a distance of 850 mm to the left or to the right of the appli-
ance - as low as possible;
- the measurements of the control box; see Placing the Control Box section 6.7;
- the location of the ventilation holes;
- the measurements of the panes, so that they can be placed/removed after placing the chimney breast;
- the protection of the gas control and the pipes against cement and plaster.
!Tip - You should preferably apply the ventilation holes on both sides of the chimney breast. You can use DRU ventilation
elements.
GB
B*%,QVWDOOLQGG 

11
METRO 100 XTL  INSTALLATION MANUAL
English
➠
Check whether the concentric system is placed correctly.
➠
Check the xture of the clip binding with self-tapping screws on places that cannot be reached later on.
➠
Maintain sucient space around the appliance in the chimney breast, so the heat can escape:
- minimum height: ca. 200 mm (g. 8).
➠
Do not apply plaster on or over the anges, because:
- the heat of the appliance could cause cracks;
- it will no longer be possible to remove/place the panes.
➠
When using plaster nishing, the chimney breast should dry for at least 6 weeks before it is taken into operation, in
order to prevent cracks.
6.7 Placing the control box
The control box is placed as low as possible in the chimney breast.
!Caution - Take the position of the appliance’s legs into account. The shaded parts in g. 2 show the locations where the control
box can be mounted;
- The bottom of the control box may not be placed higher in the appliance, than the burner bed.
A number of components are placed in the control box, such as data plate, gas control, receiver belonging to the
remote control.
Proceed as follows, when placing the control box; see g.9 for details:
➠
Make an opening in the chimney breast of 285 x 194 mm (h x w).
➠
Place the inner frame (1); unscrew bolts (5) for this.
!Tip - When the chimney breast is made of bricks, the inner frame can be built with bricks at the same time;
- When using a dierent material, you can glue the inner frame or x it with four ush screws.
➠
Mount the gas control to the brackets of the inner frame (2).
➠
Reconnect the pipes to the gas control.
Caution - Avoid kinks in the pipes;
- Place the aluminium pilot burner pipe free from the oor and / or the wall;
- Tighten the exible gas pipe and the pilot burner pipe until they are gastight.
➠
If applicable, connect the wires of thermocouple 1 to the gas control; see g 10.
Caution - First tighten the thermocouple by hand and;
- then tighten it a quarter turn using a suitable spanner.
➠
If necessary, blow clean the gas pipe.
➠
Connect the gas pipe to the gas tap.
➠
Bleed the gas pipe.
➠
Place the receiver (3); for connections, see section 7.1.
➠
Place the data plate (6).
➠
Fix the outer frame with door (4) to the inner frame using 2 socket cap screws.
!Tip You can place the outer frame in such a way, that the door turns to the left or to the right.
6.8 Adjusting the appliance
The appliance has to be set in such a way that it works correctly in combination with the concentric system.
For that purpose, a bae is placed and/or the air inlet guide is removed. The conditions for using a wall terminal are
described in section 6.5.2.1, and for using a roof terminal in section 6.5.3.1.
GB
B*%,QVWDOOLQGG 

12
METRO 100 XTL  INSTALLATION MANUAL
English
6.8.1 Bae (R)
The bae (R) is supplied separately; see g. 11a.
This is mounted as follows (see g. 11b):
➠
Unscrew the 8 self-tapping screws (S) from the middle plate (T).
➠
Remove this plate.
➠
Place the bae.
➠
Use the template supplied to set the distance of the restriction (see g. 12) as follows:
- A distance of 40 mm means that the bae is closed to a maximum level;
- A distance of 45-55 mm is set by means of the template.
➠
Fix the bae by using the socket cap screw (U).
➠
Place back the middle plate.
6.8.2 Air inlet guide (L)
The air inlet guide is at the back, below the combustion chamber. In order to reach it, you must remove the
vermiculite tray.
Ex works, the air inlet guide is mounted with an opening of 13mm.
If table 2 (page 10) indicates that the air inlet guide must be removed, please proceed as follows.
➠
irst remove the vermiculite tray.
➠
Unscrew the self-tapping screws (indicated in gure 13) and remove the air inlet guide. Screw the self-tapping screws
back in the appliance!
If the opening should be made smaller to 9mm, you must screw the supplied air inlet cover plate onto the air inlet
guide. (see gure 14)
Tip If the self-tapping screws are dicult to reach, it is possible to remove the burner from the appliance by unscrewing
the self-tapping screws (5x) indicated. (See gure 15)
6.9 Placing the wood/pebble set
The appliance is supplied with a wood set or a pebble set.
The vermiculite that is used to ll the burner tray is black when using the wood set and has a natural colour when
using the pebble set.
The gures do not always show the correct colours.
Caution Strictly observe the following instructions to prevent unsafe situations:
- only ever use the supplied wood/pebble set;
- place the wood/pebble set exactly as described;
- make sure the pilot burner and the space around it are kept free from objects (see g.16a and g.16b);
- make sure that thermocouple 2 and the space around it are kept free from objects (see g. 17a and g. 17b);
- make sure that the slot between the burner tray and the tray surrounding the burner is kept free from objects;
- make sure there is no vermiculite’s ne dust on the burner.
6.9.1 Wood set
The wood set consists of black vermiculite (see g.18), chips (see g.19) and a number of branches.
➠
Fill the burner tray with vermiculite; equally spread the vermiculite; see g.20.
!Caution - You can inuence the ame image by moving the vermiculite, yet
- the burner deck has to remain covered with vermiculite in order to prevent that the life expectancy of the burner is
reduced.
➠
Fill the tray surrounding the burner with chips; equally spread the chips; see g. 22.
➠
Identify branches A up to H by using g.21a.
!Tip Use the burn stains on the branches for identication.
➠
Place branches A up to D around the (main) burner (see g.21b and g.22):
- First place branch B symmetrically in relation to the pilot burner;
- Proceed with branches A, C and D.
➠
Then place branches E up to H that are lying over the burner (see g.21c).
GB
B*%,QVWDOOLQGG 

13
METRO 100 XTL  INSTALLATION MANUAL
English
Caution The branches should not completely cover the burner opening (see g.21d and g.22), because:
- the main burner will not ignite properly; which could result in unsafe situations;
- the appliance will become lthy more quickly, as a result of soot;
- the ame image may be aected.
6.9.2 Pebble set
The pebble set consists of natural colour vermiculite; (see g.18) and white carrara stones.
➠
Fill the burner tray with vermiculite; equally spread the vermiculite; see g.23a.
!Caution - You can inuence the ame image by moving the vermiculite, yet
- the burner deck has to remain covered with vermiculite in order to prevent that the life expectancy of the burner is
reduced.
➠
Fill the burner tray and the tray surrounding the burner with carrara stones.
➠
Equally spread the carrara stones in one layer; see g.23a and g.23b.
Caution Incorrect placement of the stones, e.g. on top of each other, could have the following consequences:
- the main burner will not ignite properly, which could result in unsafe situations;
- the ame image is aected.
6.10 Panes
!Caution - Avoid damaging the panes during removal/placing;
- Avoid/remove ngerprints on the panes, as they will burn into the glass.
- Always remove the side glass pane rst.
6.10.1 Removing the side pane
At the top and bottom of the side glass pane you will nd springy window strips. First remove the lock bolts from
these strips. Take the window strip by the handles and position it in relation to the upper or lower brackets. (parking
position) See gure 24.
Tilt the top of the glass pane towards you and grab the glass pane at both sides. Lift the glass pane and tilt its bottom
out of the appliance and remove it.
When mounting the side glass pane, you must proceed in reverse order.
!Caution: When mounting the side glass pane, you must carefully place the springy window strips in front of the glass pane
again, in order to avoid damaging the glass pane.
6.10.2 Front pane
After placing the wood/pebble set you can place the front pane as described below.
!Caution - The DRU logo should be at the bottom right corner;
- The self-tapping screws must not be over-tightened, since otherwise they could break or strip the thread: tight=tight;
- Make sure that the front pane ts well onto the side panes.
6.10.2.1 Side panes
The side panes should be removed in case of torn or broken panes.
6.10.2.1 Removing the front pane
When removing the front pane, you should follow the next steps, see g. 25:
➠
Remove the vertical decorative strips by pulling them o at the top rst; turning them over parallel to the pane and
then loosening them at the bottom.
➠
Remove the U-shape horizontal strip by gripping it with 2 hands in the slot and lifting it out.
➠
Unscrew the 6 self-tapping screws of the lower glass strip with 2 turns, using the socket spanner supplied.
!Caution Do not remove the self-tapping screws: leave them in place in the lower glass strip.
➠
Unscrew the 6 self-tapping screws from the upper glass strip, by using the socket spanner supplied.
➠
Remove the upper glass strip.
➠
Slide the glass pane to the side for approx. 20 mm.
➠
Slightly tilt the top of the pane towards you.
➠
Grab the pane at both sides.
➠
Lift up the pane and tilt the bottom of the pane towards you.
➠
Remove the pane.
GB
B*%,QVWDOOLQGG 

14
METRO 100 XTL  INSTALLATION MANUAL
English
6.10.2.2 Placing the front pane
Placing the front pane will take place in reverse order of the removal procedure described above.
!Caution - The DRU logo should be at the bottom right corner;
- The self-tapping screws must not be over-tightened, since otherwise they could break or strip the thread: tight=tight;
- Make sure that the front pane ts well onto the side panes.
!Caution The self-tapping screws must not be over-tightened, since otherwise they could break or strip the thread: tight=tight.
6.10.2.3 Removing the rear glass pane
Loosen the self-tapping screws of the vertical window strip by 2 strokes. Do not remove the strip! The remainder of
the procedure is equal to that of the front glass pane.
7. Wireless remote control
The appliance is supplied with a wireless remote control.
Ignition, controlling the ame height and switching o are performed by a remote control that operates a receiver
in the control box.
User Manual, chapter 4, Wireless Remote Control, describes the operation of the appliance including the way the
remote control works.
Caution Do not ignite the appliance until it is fully installed.
Below, we will describe how the receiver is connected.
7.1 Receiver
The receiver should be connected to the appliance, before the batteries are installed.
Follow the procedure below (see g. 26):
➠
Fit the connection cable’s brown plug to the receiver (see g. 26, arrow F).
➠
Connect the white plug to the gas control.
!Tip The plugs have dierent sizes that correspond with the connectors.
➠
Connect the cables of thermocouple 1 to the receiver; (see g. 26, arrows B).
!Tip - The size of the eye corresponds with the size of the screw;
- The colours of eye and screw also correspond.
➠
Connect the black wire with the white plug of thermocouple 2 to the receiver (see g. 26, arrow E).
!Caution Make sure that the wires of thermocouple 2 cannot come into contact with hot parts
➠
Connect the ignition cable to the receiver; (see g.26, arrow A)
➠
Connect power:
a) When using batteries, see section 7.1.1 below;
b)When using an adapter:
- connect it to the receiver; (see g.26, arrow C);
- insert the plug into the wall socket.
➠
Place the receiver (V) in the control box, as indicated on g.27.
➠
Bend the antenna out of the clips; see g.26, arrow D.
➠
Set the antenna straight.
!Caution - Do not place the antenna (N) too close to the ignition cable and/or metal parts (for the correct position, see g.27);
- Do not place the ignition cable over and/or along metal parts: this will weaken the spark;
- Do not lay the ignition cable over the receiver: this could damage the receiver;
- Avoid dust on or in the receiver: cover it when performing work.
GB
B*%,QVWDOOLQGG 

15
METRO 100 XTL  INSTALLATION MANUAL
English
7.1.1 Placing / replacing the batteries
Follow the procedure below when placing the batteries:
➠
Open the door of the control box.
➠
Pick up the receiver.
➠
Slide the cover o.
➠
Place or remove the 4 penlite (AA type) batteries.
!Caution - Avoid a short circuit between the batteries and metal objects/parts;
- Observe the “+” and“-” poles of the batteries and the holder;
- Use alkaline batteries.
➠
Slide back the cover.
➠
Place back the receiver.
!Caution Batteries are regarded as “small chemical waste” and may therefore not be disposed with the household rubbish.
8. Final check
In order to check whether the appliance is working properly and safely, you must perform the following checks
before the appliance is used.
8.1 Gastightness
Caution All connections must be gastight.
!Caution The gas control can be subjected to a maximum pressure of 50 mbar.
➠
Check the connections for gastightness.
8.2 Gas pressure / pre-pressure
The burner pressure is set at the factory; see data plate. It is not necessary to check the burner pressure.
Caution The pre-pressure in house installations should be checked, as they can vary.
➠
Check the pre-pressure; see g. 28 for the measuring nipple on the gas control.
➠
Contact the gas company if the pre-pressure is not correct.
8.3 Ignition pilot and main burner
For igniting the pilot and main burners, see the User Manual, chapter 4, section 4.2, Remote Control.
Caution - During the ignition process, you are not allowed to operate control button B on the gas control manually;
- Always wait 5 minutes after the pilot burner has gone out, before you re-ignite the appliance.
- Do not turn the pilot burner lower by using the settings on the gas control.
8.3.1 Pilot burner
➠
Check the ignition of the pilot burner:
- the pilot burner should start at the rst attempt.
If the pilot burner does not ignite:
➠
check if the ignition sparks:
a) If not, the ignition cable is probably not lying free from metal parts;
b)If it does, there is probably still air in the pipe.
➠
Bleed the pipe and/or
➠
Lay the ignition cable free from metal parts.
Caution: The pilot burner pipe must be protected against possible corrosion inuences, e.g. moisture, falling cement, dirt falling
down from a chimney, etc. The pilot burner pipe must be permanently kept free from the ground and the walls of the
room in which the appliance is built.
GB
B*%,QVWDOOLQGG 

16
METRO 100 XTL  INSTALLATION MANUAL
English
8.3.2 Main burner
Caution The burner should ignite smoothly and should not pop as a result of delayed ignition.
➠
Check the function of the main burner from the standby (pilot burner) position:
- after opening the gas valve, the main burner should burn within a few seconds.
!Tip When the gas valve is opened, the motor will run; this is audible.
1) If the main burner does not burn:
➠
Check if button A on the gas control is in the position ON;
➠
Check if the space surrounding the pilot burner is free from objects;
➠
Check the placement of the wood/pebble set.
➠
If necessary, correct the above mentioned faults.
➠
Test the main burner 5x for a good operation.
2) If main burner ignites, but goes out again after approx. 22 seconds, please:
➠
Check the wiring of thermocouple 2 for:
- Loose wiring;
- Wrongly connected wiring;
- Short-circuit;
- Broken wire.
➠
Check if thermocouple 2 is dirty.
➠
Check if thermocouple 2 is positioned correctly in the ame; see g. 29.
➠
Check if thermocouple 2 is defective; see chapter 11, table 4 under J7.
➠
Check if the receiver is defective; see chapter 11, table 4 under J8.
➠
If necessary, correct the above mentioned faults.
➠
Test the main burner 5x for a good operation.
8.4 Flame image
The ame image can only really be assessed when the appliance has been burning for several hours. Volatile compo-
nents from paint, materials, etc., which evaporate in the rst hours, will aect the ame image.
!Caution If the chimney breast is made of stone-like materials or has a plaster nish, this may only take place 6 weeks after pla-
cing the chimney breast, in order to prevent shrinkage cracks.
➠
Check whether the ame image is acceptable.
If the ame image is not acceptable, this can be due to:
- the evaporation of volatile substances;
- incorrect placement of the wood/pebble set;
- incorrect settings of the appliance.
➠
If necessary, improve the placement of the wood/pebble set.
➠
If necessary, improve the settings of the appliance; for this, see section 6.8.
GB
B*%,QVWDOOLQGG 

17
METRO 100 XTL  INSTALLATION MANUAL
English
9. Maintenance
Once a year the appliance should be checked, cleaned and, if necessary, repaired by a competent installer in the eld
of atmospheric gas-red heating.
Check at least whether the appliance is working properly and safely.
Caution - Close the gas tap when performing maintenance work;
- Check the gastightness after repair;
- After replacing thermocouple 1 you should rst tighten the swivel by hand and then give it another quarter turn
with a suitable spanner;
- Do not turn the pilot burner lower by using the settings on the gas control.
➠
If required, clean the following components:
- the pilot burner;
- the space surrounding the pilot burner;
- the panes.
!Caution - Remove/place the panes as described in section 6.10;
- Remove the deposit on the inside of the panes with a damp cloth or a non-abrasive detergent such as copper polish;
- Avoid/remove ngerprints on the panes, as they will burn into the glass;
- Replace a broken and/or cracked pane as described in section 6.10.
Caution If necessary, place back the wood/pebble set correctly; for this, see section 6.9.
➠
Inspect the ue gas discharge / combustion air supply system.
Caution You must always perform a nal check.
➠
Perform a check as described in chapter 8.
9.1 Parts
Parts that must be replaced, can be obtained from your supplier.
10. Delivery
You must explain to the user how he should operate the appliance. You should instruct her/him for instance on
using the appliance for the rst time, the operation of the remote control, annual maintenance.
Caution - Tell the user to close the gas tap immediately in case of malfunctions/bad performance and contact the installer in
order to prevent dangerous situations;
- Indicate the location of the gas tap;
- Point out the precautions in the user manual concerning unintended ignition by other remote controls such as car
keys and garage door openers.
➠
Instruct the user about the appliance and the remote control.
➠
When the appliance is started for the rst time, point out that
- in order to avoid cracks in a chimney breast made of stone-like materials or nished with plaster, it should dry for at
least 6 weeks prior to putting the appliance into operation
- when the appliance is stoked up for the rst time, volatile components evaporate from paint, materials, etc.;
- when evaporating, the appliance should preferably be set at the highest level;
- the room should be well ventilated.
➠
Give the user manual and installation manual to the user (the installation manual should be kept near the appliance).
GB
B*%,QVWDOOLQGG 

18
METRO 100 XTL  INSTALLATION MANUAL
English
11. Malfunctions
In the following table you will nd an overview of malfunctions that might occur, the possible causes and the
remedies.
Table 4: Diagnosis of malfunctions
Problem Possible cause Remedy
A. No transmission
(motor will not run)
1. The (new) communication
code between receiver and
remote control must still be
conrmed.
2. Empty batteries.
3. Receiver is damaged.
4. Remote control is damaged.
5. Motor cable at valve/receiver is
broken.
6. Bent pins of the 8-wire con-
nector.
7. If the receiver is surrounded by
metal, this could decrease the
transmission range.
1. Hold down the reset button of the receiver,
until you hear 2 sound signals; see g.30.
Let go of the reset button after the second,
longer sound signal and press button
(small ame) or button (large ame) on the
remote control within 20sec., until you hear
an extra long sound signal conrming that
the new code has been set.
2. Replace batteries.
!Caution Avoid short circuit between the batteries
and metal parts of the appliance.
3. Replace the receiver and conrm the code
(remedy 1).
4. Replace the remote control and conrm the
code (remedy 1).
5. Replace the motor cable.
6. Make sure that the pins of the 8-wire connec-
tor are straight.
7. Change the position of the antenna.
B. No ignition (spark) 1. Button A in position MAN.
2. Ignition cable runs over and/or
alongside metal parts.
3. Ignition pen corroded.
4. 60-second delay before the full
restart is not yet nished.
1. Switch button A on the gas control to ON, see
g 27.
2 Do not place the ignition cable (S) over and/or
along metal parts. This will weaken the spark;
see g.27.
If necessary, replace the ignition cable.
3. Replace the ignition pen.
4. Wait until the delay time has passed.
C. No sound signal 1. Receiver is damaged.
2. 60-second delay before the full
restart is not yet nished.
1. Replace the receiver and conrm the code
(remedy 1 at A)
2. Wait until the delay time has passed.
D. One continuous sound
signal of 5 sec.
(Possible 7 short beeps
prior to the 5 sec.
sound signal)
1. Loose wiring between receiver
and gas control.
2. Receiver is damaged.
3. Bent pins of the 8-wire con-
nector.
4. Damaged magnetic valve.
5. Thermocouple 2 still too hot.
1. Connect the wiring properly.
2. Replace the receiver and conrm the code
(remedy 1 at A)
3. Make sure that the pins of the 8-wire connec-
tor are straight.
4. Replace the gas control.
5. Wait until the thermocouple has cooled down
suciently
GB
B*%,QVWDOOLQGG 

19
METRO 100 XTL  INSTALLATION MANUAL
English
Table 4: Diagnosis of malfunctions
Problem Possible cause Remedy
E. No pilot burner ame 1. Air in the pilot burner pipe.
2. Wires of thermocouple 1 have
been cross-connected.
3. No spark at the pilot burner.
4. Injector is blocked up.
1. Flush the pipe or start the ignition process
several times.
2. Check the polarity of the thermocouple wiring.
Connect the thermocouple wiring properly, if
necessary.
3.1 Check if the ignition cable (S) is lying free from
metal parts; see g.27.
If necessary, move it away from the metal
parts.
3.2 If necessary, replace the ignition cable.
3.3 If necessary, replace the ignition pen.
4.1 Clean the injector.
4.2 If necessary, replace the injector.
F. Electronics keep spar-
king while the pilot
burner is ignited
1. Receiver is damaged. 1. Replace the receiver and conrm the code
(remedy 1 at A)
G. Pilot burner is burning,
but magnetic valve clo-
ses after ca. 10 seconds
or when the appliance
gets hot
1. Thermocouple 1 does not
function.
2. Batteries (almost) empty.
1.1 Measure the voltage, using a digital multime-
ter, set to mV range, by connecting the cables
to the cable shoe. The cable shoe is located on
the outside, directly next to the magnet nut at
the rear of the gas control; see g.31.
The voltage should be at least 5mV within 20
seconds.
It may not be lower when the appliance is
warm.
If the voltage is too low:
- the thermocouple should be placed better in
the ame or
- the thermocouple should be replaced.
1.2 Check the size of the pilot burner ame.
Correct a ame that is too small.
1.3 Check the wiring of the thermocouple to the
receiver.
If necessary, replace the wiring.
2. Replace the receiver’s batteries.
!Caution Avoid short circuit between the batteries
and metal parts of the appliance.
H. There are short sound
signals, but no sparks
and no sound / clicks
can be heard of the
magnet opening the
valve
1. Batteries (almost) empty. 1. Replace the receiver’s batteries.
!Caution Avoid short circuit between the batteries
and metal parts of the appliance.
I. Pilot burner is burning,
but there is no gas ow
to the main burner
1. Button A in position MAN.
2. Appliance in the pilot ame
position.
3. Pre-pressure of the gas is too
low.
4. Damaged magnetic valve.
1. Turn button A on the gas control to ON; see
g 27.
2. Increase the ame height by pressing button
(large ame) on the remote control.
3. Check pre-pressure.
If necessary, contact gas company.
4. Replace the gas control.
GB
B*%,QVWDOOLQGG 

20
METRO 100 XTL  INSTALLATION MANUAL
English
Table 4: Diagnosis of malfunctions
Problem Possible cause Remedy
J. Main burner ignites,
but goes out again af-
ter approx. 22 seconds.
1. Wiring of thermocouple 2 is
loose.
2. Wires of thermocouple 2 have
been cross-connected.
3. Short-circuit in the wiring of
thermocouple 2.
4. Broken wire in the wiring of
thermocouple 2.
5. Thermocouple 2 is dirty.
6. Thermocouple 2 is not posi-
tioned correctly in the ame
(see g. 29)
7. Thermocouple 2 is defective.
8. Receiver is defective.
1. Connect the wiring properly.
2. Connect the wiring properly.
3. Replace wiring.
4. Replace wiring.
5. Clean the thermocouple.
6. Position the thermocouple correctly in the
ame.
7. Check the voltage across thermocouple 2 just
before the main burner goes out.
If the voltage is lower than 1.8 mV, replace
thermocouple 2.
8. Check the voltage across thermocouple 2 just
before the main burner goes out.
If the voltage is higher than 1.8 mV, replace
the receiver.
GB
B*%,QVWDOOLQGG 
