DSPPA DA3350 User manual

Public Address System
Digital Power Amplifier
DA3350
DA3450
DA3650
TEMPPROTCLIP70V SIGNAL
-6
-3
-9
-15
-27
-24
-21
-18
0dB
-12
VOLUME
∞
DA3650
电源
POWER
User’s Manual
Welcome to DSPPA Public Address System! Please read the Instructions carefully before operating this device.
Guangzhou DSPPA Audio CO., Ltd
http://www.DSPPA.com
http://www.dsppatech.com

About the Instructions
The Instructions is used at the date when the DA3350/DA3450/DA3650 digital power amplifier is
developed. It contains system introduction, operation attentions, system connection instructions,
product instructions and other contents of the DA3350/DA3450/DA3650 digital power amplifier. The
user shall read the Instructions carefully and operate the device following the indications in the
Instructions before the installation and operation of the device.
Any symbol marked on the rear panel of this machine must be noted. The operations must be
performed according to the instructions of these symbols.
Please keep the Instructions for future reference!
DA—V1.1
Facture 2018-9-19

WARNING
Be sure to observe the following cautions to prevent the damage to the users and others, and the
damage to the equipment or property!
This symbol means a “prohibition”. This symbol means a “must”.
Check the damage condition of power cord.
Do not pulling the power cord to unplug the plug,
unplug the plug directly; otherwise it may cause
electric shock, short circuit or fire.
Do not block the air vent during the operation.
All air vents must be unblocked to avoid the
overheating.
Do not expose the device to dust, vibration,
extreme cold and hot environment.
Do not place heavy objects on the device. Do not
impose an excessive force when operating the
switch, buttons or connecting the external audio
equipment.
Avoid any foreign matter (paper, metal, etc.)
from entering the device through gap or opening.
In such a case, please power off this device
immediately.
Do not attempt to detach the internal parts of this
device or remold it by any way.
Please unplug the power plug immediately to
avoid the electric shock, fire or other accident and
professionals shall be invited for maintenance of
the device in case of any sudden sound
interruption, any abnormal smell or smoke during
the running of the machine.
Smell of Scorching
Be sure to unplug the AC power cord or turn off
the wall outlet to achieve zero energy consumption
when this device will not be operated for a long time.

* * Digital power amplifier
CONTENTS
1. PRODUCT DESCRIPTION..........................................................................................................................................1
1.1 BRIEF INTRODUCTION....................................................................................................................................................1
1.2 PERFORMANCE.............................................................................................................................................................. 1
2. APPEARANCE DESCRIPTION.................................................................................................................................. 1
2.1 DESCRIPTION OF FRONT PANEL.................................................................................................................................... 1
2.2 DESCRIPTION OF BACK PANEL.......................................................................................................................................2
3. CONNECTION INSTRUCTIONS............................................................................................................................... 3
3.1 SYSTEM CONNECTION DIAGRAM.................................................................................................................................. 3
3.2 INPUT AND OUTPUT CONNECTION............................................................................................................................... 3
3.2.1 INPUT CONNECTION..................................................................................................................................................3
3.2.2 OUTPUT CONNECTION.............................................................................................................................................. 3
SAFETY PRECAUTIONS.................................................................................................................................................4
PACKING LIST................................................................................................................................................................. 6
SPECIFICATIONS............................................................................................................................................................ 6

* * Digital power amplifier
1
1. Product Description
1.1 Brief introduction
DA3350/DA3450/DA3650 is a series of digital power amplifier with newly designed appearance and high powers
for selection. The machine is nice and neat, and is suitable for factories, schools, hospitals, shops and many other
commercial applications.
1.2 Performance
Highly efficient switching power supply.
Highly efficient CLASS D amplifier.
100V, 70V constant voltage output (common output end), support 100V/70V output real-time switching.
With perfect and reliable DC output protection, short circuit protection and overheating protection, which
improves the safety performance of the machine.
5 unit LED indicator for status display.
6.35mm socket and XLR socket can easily realize looping connection.
Output short circuit protection and can recover automatically.
A series of high power amplifiers are available.
2. Appearance Description
2.1 Description of front panel
TEMPPROTCLIP
70V SIGNAL
-6
-3
-9
-15
-27
-24
-21
-18
0dB
-12
VOLUME
∞
DA3650
电源
POWER
12345678
1. AC power switch (with light indication)
2. 70V output indicator
3. Signal indicator (output level)
4. Top cutting indicator (to avoid severe top cutting, please reduce the gain appropriately)
5. Protection indicator (DC or short circuit protection)
6. Temperature indicator (over temperature indicator)
7. Volume control knob
8. Ventilation and cooling window

* * Digital power amplifier
2
2.2 Description of back panel
广州市迪士普音响科技有限公司
Guangzhou DSPPA Audio Co.,Ltd.
~220V/50Hz/900W
FA
纯后级广播功放
F8AL250VF A
FUSE TYPE / 保险丝规格
SER.
NO.
DA3350.3450.3 650 SERIES
PROFESSIONAL AMPLIFIER
70V/100V
INPUT LINK
2
3
1 1
3
2
COM 100V/70V
AUDIO OUTPUTS
10
4
1 2 3
56789
信
号
地地
信
号
请勿打开,以免触电
警告
1. Fan
2. Output common terminal
3. 70V /100V output
4. 220V AC fuse
5. 70V /100V output switch
6. XLR input port
7. 6.35mm input port
8. 6.35mm looping socket
9. XLR looping socket
10. 220V AC power line

* * Digital power amplifier
3
3. Connection Instructions
3.1 System connection diagram
广州市迪士普音响科技有限公司
Guangzhou DSPPA Audio Co.,Ltd.
~220V/50Hz/900W
FA
纯后级广播功放
F8AL250VF A
FUSE TYPE / 保险丝规格
SER.
NO.
DA3350.3450.3650 SE RIES
PROFESSIONAL AMPLIFIER
70V/100V
INPUT LINK
2
3
1 1
3
2
COM 100V/70V
AUDIO OUTPUTS
信
号
地地
信
号
Pre-amp.
MP9811P
Another Amp.
MP series
or or
请勿打开,以免触电
警告
3.2 Input and output connection
3.2.1 Input connection
All inputs shall be connected to the XLR socket (figure 1 and 2) or
6.35mm socket on the back panel of the machine.
3.2.2 Output connection
The output terminal is on the back panel. Black for common end, red
for hot end.
100V and 70V share the same terminal output, which can be switched
by the output switch. At this time, each speaker should be equipped
with the corresponding 100V/70V line transformer, and the total
power of the speaker should be less than the rated output power of
the power amplifier.
Note: the two "hot ends" should not be connected with each other at any time.

* * Digital power amplifier
4
Safety Precautions
1．Precautions for Safe Operation
Do not plug the power cord into the power grid before the system line is not connected.
Be sure that the input voltage of the device is exactly the same as the voltage required for this device.
Otherwise it may burn the device.
Do not open the case without authorization in order to avoid the risk of electric shock because there is a
dangerous voltage in the device.
Please unplug the power cord from the socket for the sake of safety when the device will not be used because
the device is not completely disconnected from the power grid when the device is powered off.
Do not put the device in a super-cooling or superheating place.
Be sure there is a well-ventilated operating environment to avoid the heat and excessive temperature from
damaging the device during the operation.
Please unplug the power plug in rainy or wet days or without operation for a long time.
Be sure to unplug the power plug to ensure the complete disconnection from the power grid before detaching
or re-install any parts of the device, disconnecting or re-connecting any electrical plugs of the device or
performing any connection.
Do not open the case to repair the device without authorization in case of any fault in order to avoid the
accident or aggravate the damage of the device.
Do not put any corrosive chemicals on or near the device.
2．Precautions for After-Sale Services
The Company will provide the free warranty services of three years (including replacement of parts free of
charge) for any quality problem occurred since the date of purchase if the user installed and operated the
device as required and it is within the range of normal operation.
For any warranty, the user must provide the warranty card, user’s self-deposit stub invoice and sales invoice
as the voucher.
Any of the following circumstances is not included in the range of free warranty:
1. Damage of product resulted from the incorrect installation, operation or handling;
2. Damage of product resulted from any abnormal condition, for example, excessive power voltage or
environment humidity, etc.
3. Damage of product resulted from any natural disasters or other accidents;
4. The serial number of the products on the shell is converted, altered or removed;
5. The product was once repaired or modified by others rather than the authorized personnel of the Company;
Please keep the Instructions and Warranty Card properly;
For any question or attentions not covered in the Instructions, please feel free to contact our dealer or visit
our website at: http://www.DSPPA.com, http://www.dsppatech.com.

* * Digital power amplifier
5
In case of any fault during the warranty period, please feel free to contact our service personnel or dealers for
maintenance treatment. The Company will not bear any responsibility of free warranty for any damage
resulted from the unauthorized demolition of the users themselves or the repair of others rather than the
technical staff of the company.

* * Digital power amplifier
6
Packing List
No.
List
Quantity
1
Digital power amplifier
1 pc
2
User’s manual
1 pc
3
Certificate
1 pc
4
Warranty
1 pc
5
Charter washer
4 pcs
6
White 5 x 19 semi countersunk head cross machine wire
4 pcs
7
1500MM/6.3 RCA
1 pc
8
6.3mm to RCA plug
1 pc
Specifications
Item
DA3350
DA3450
DA3650
RMS
450W
550W
750W
Min. source electromagnetic force
≤1000mV
SNR
≥80dB
Frequency response
80Hz~16kHz (±3dB)
Total harmonic distortion
≤1% （1kHz, normal condition）
Indicator light
“70V” , "signal", "top cutting", "protection", "over temperature"
Protection
Over temperature, DC, short circuit
Power supply
AC220V/50Hz
Rated power
550W
650W
900W
Package size (L×W×H mm)
555455185
Machine size (L×W×H mm)
48338088
Gross weight (Kg)
8.9
8.9
8.9
Net weight (Kg)
7.7
7.7
7.7
Technical specifications are subject to change without prior notice.

* * Digital power amplifier
7
Guangzhou DSPPA Audio Co., Ltd
Cautions
Please unplug the power cord plug from the socket for the sake of safety when the device will not be used
because the device is not completely disconnected from the power grid when the power switch of the device is
in OFF state.
The device cannot be subject to water droplets or splashes and any items like vases filled with water cannot be
placed on this device.
Do not open the cover of the machine to prevent the electric shock. If necessary, it shall be repaired by the
professional with the professional certificate.
The terminal marked with a symbol in the device indicates that it is dangerous and charged. The
connecting operation of these terminals shall be performed by the trained staff.
The device is connected with the power grid via the power cord plug, so, the connection between the device
and the power grid can be cut off by unplugging the power cord plug in case of any fault or danger. Therefore,
the power outlet is required to be mounted at a place where the plug of the power cords can be easily
unplugged or plugged.
