DSPPA MP7806 User manual

MP7806 2 Zones All-in-one Amplifier with
MP3/Tuner/CD/CD/DVD
Model
MP7806
Rated output
60W
Output method
4-16Ω balanced output, 70V & 100V fixed-voltage outputs
Input
MIC1, 2, 3 & 4: 600Ω, 2.5mV-500mV, balanced
AUX: 10kΩ, 250mV(±50mV), unbalanced
Frequency response
MIC: 100Hz-15kHz (±3dB) AUX: 40Hz-20kHz (±3dB)
Harmonic distortion
< 0.5% (1kHz, 1/3 rated power)
Line S/N (4Ω output)
70dB
Microphone S/N (4Ω output)
70dB
Protection
AC fuse, DC output protection, and overload protection
Power consumption
120W
Outer Packing Size (mm)
(L×W×H)520×500×235
Unit Size (mm)
(L×W×H)430×400×132
Gross weight
15.5kg
Net weight
13kg
70V, 100V & 4-16 Ω, rated power 60W
1 video input,1 aux input,4 Mic XLR input
Equipped USB interface. Able to supports common USB flash disk
Built in DVD player and tuner with remote control.
Bass and treble control.
Features
This series of amplifiers are rated from 60W to 350W. There are 1 video input, 1 aux input, 4 Mic
XLR input. Bass and treble controls and master volume control are provided. A remote chime
trigger could be used to activate the amplifier built-in pre announcement chime tone.Extensive
protection with indicator from short-circuit, overload and high temp.
Description
Specification

Rear Panel
Connection

Packing List
MP78 series product 1 set
Power cord 1 pcs.
AM antenna 1 pcs.
FM antenna 1 pcs.
Audio line 1 pcs.
User’s Manual 1 copy
Warranty Card 1 copy
4-position terminal 2 pcs.
2-position terminal 1 pcs.
