DSPPA MAG808C User manual

Package List
No.
List
Number
1
MAG808C equipment
1
2
Manual
1
3
Certificate
1
3
Warranty card
1
4
1500MM/Cat-5 cable
1
5
Gooseneck Microphone
1
Guangzhou DSPPAAudio Co., Ltd.
Public Address System
Remote Control Panel MAG808C
Manual
Welcome to use DSPPA Public Address System! Please read the Instructions carefully before
operating this device.
Guangzhou DSPPAAudio CO., Ltd
http://www.DSPPA.com
http://www.dsppatech.com
Note
This device can not withstand water droplets or water splashes and can not place items
such as vases filled with water on the equipment.
Do not open the machine to avoid electric shock. If necessary, open it by a professional
staff.
This device is connected with power supply through the power plug. When the equipment
fails, or is dangerous, unplug the power supply and disconnect the device from the power
grid. Therefore, it is necessary to place the power socket to a place where it’s convenient
to unplug the power supply.

1. Digital display
2. Sound source selection button +
Press this key to change the audio source of the current linked zone.
3. Source selection button -
Press this key to change the audio source of the current linked zone.
4. Volume control button +
Press this button to increase the volume of the zone.
5. Volume control button -
Press this button to decrease the volume of the zone.
6. Output level indicator
The level of the audio output is displayed.
7. Previous song button
When playing MP3 songs, press this button to switch to "previous song";
8. MP3 volume adjustment knob
Adjust the MP3 volume: clockwise rotation is for increasing the volume; counterclockwise rotation
for volume attenuation.
9. Play / pause button
When playing MP3 songs, press this button to "Play / Pause".
10. “Next” button
When playing MP3 songs, press this button to switch to "next song";
11. LINE volume adjustment knob
Adjust the volume of LINE: turn clockwise to raise the volume and counterclockwise rotation to
decrease volume.
12.MIC volume adjustment knob
Adjust the volume level of the MIC: turn clockwise to raise the volume and counterclockwise
rotation to decrease volume.
13. Microphone MIC input interface
14.LINE input port
15. USB interface
Insert the flash drive here to provide programs such as built-in MP3
Appearance Description
1.1 Features
+ 24V DC power supply;
Network port balanced output audio;
Level indication;
Partition source control;
Partition volume control;
Digital display;
MP3 player and separate volume control knob;
One way LINE input and separate volume control knob;
One way MIC input and separate volume control knob.
1.2 Panel Description

1.3 Address Instruction
In the case of plug-in, press the INPUT- and VOLUNE + keys several times, the Ax
will appear on the LED(x on behalf of 1 ~ 8), that is, the current address. Such as: A1
for current address 1, the panel to be connected to the host WP1 port; A2 to A8 and
so on. If you want to modify the current address, press the INPUT- or INPUT + keys
to change the address and press the VOLUME- key to confirm the modification.
Specification
This specification is subject to change without notice.
Model
MAG808C
Power
DC 24V
MIC input sensitivity
10±2mV
LINE input sensitivity
300±50mV
USB input sensitivity
-10dB
MIC frequency response
100Hz～15kHz（±3dB）
AUX frequency response
20Hz～20kHz（±3dB）
Noise
<0.5mV
Distortion
<0.5% 1KHz
Rated supply
DC 24V
The output level of the network port
(balanced)
2000±100 mV
Equipment size (L×W×H)
145mm×80mm×47mm
Packing Size (L×W×H)
310mm×180mm×95mm (1PS)
Net weight
0.4Kg
Gross weight
0.7Kg (1PS)
