DT168
ENGLISH
BASIC OPERATION GUIDE
DT168
Embedded Controller/
System
Note: The actual package contents may vary depending on the configuraon acquired.
ENGLISH 4
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131 hp://www.dtresearch.com
Copyright © 2012, DT Research, Inc. All Rights Reserved. DT Research is a registered trademark of DT Research, Inc.
INTRODUCTION
Thank you for acquiring the latest addion to DT Research’s line of Embedded Controller/ System
devices—the WebDT 168, featuring a compact and robust design powered by the AMD Geode™
processor and providing effecve soluons for a broad range of compung needs. The WebDT 168
supports major embedded operang systems as well as Windows XP. The user is offered a choice
of soware soluons on a plaorm characterized by the following:
High-integraon and energy-efficient processor technology•
Robust, fanless construcon for reliable operaon•
Cost-effecve compung in compact and versale packaging•
Package Contents
DT168
AC/DC Power Adapter
Base/Stand
Basic Operaon Guide
2
3
2
3
4
11
BOG030512DT168ENG
SPECIFICATIONS
System
Processor AMD Geode™ LX 800
GPU Integrated in the CPU
Memory (RAM) 128MB or 512MB
Storage 64MB to 1GB Flash; 160GB HDD
Operang Systems Microso® Windows® CE, Windows® XP Embedded, or
Windows® XP Pro for Embedded Systems
Display Resoluon Up to 1280 x 1024
Network Interface 10/ 100MB BaseT LAN; Wi-Fi 802.11a/b/g (oponal)
Expansion Mini PCI
Input/Output Ports
1 VGA port; 12V DC-in jack; 2 Audio jacks (Microphone-in
Headphone-Out jacks); 4 USB 2.0 ports; 2 Serial/ COM ports;
1 Parallel port; RJ45 connector for Ethernet;
Wi-Fi dipole antenna (oponal)
Power
AC/DC Adapter Input: 100 – 240V AC; Output: 12V DC
Mechanical
Enclosure Aluminum chassis; ABS plascs end-caps
Dimensions (H x W x D) 1.8 x 5.7 x 5.1 in/ 46 x 144 x 130 mm
Weight 1.45 lbs/ 660 g
Environmental
Regulatory FCC Class B, CE, C-Tick, UL, RoHS compliant
Temperature Operaon: 0°C - 40°C; Storage: -20°C - 60°C
Humidity 0% - 90% non-condensing
* Specificaons subject to change without noce.

DT168
ENGLISH 23ENGLISH
THE DT168
Powering ON and OFF
The Power Buon is located in the front of the DT168. The Power Buon may be configured to
funcon differently depending on the power opons of the operang system. In general, to turn the
DT168 on, push and release the Power Buon on the front bezel. The adjacent power LED will be lit
(blue) and the corresponding interface will be displayed on the display monitor.
To turn offthe device, again depending on soware operang system, push and release the Power
Buon or use a soware shutdown interface. In the event of system lockup, the Power Buon may
be used to perform a reset on the device. To do that, push and hold the Power Buon for at least 4
seconds. The system will shut down and all unsaved work may be lost. Pushing on the Power Buon
again will restart the device.
Device Ports
The DT168 features a comprehensive set of I/O ports while preserving the compact size of the
enclosure. The VGA, Network (10/100 BaseT Ethernet), and Power ports are supplemented by a set
of two (2) Serial, one (1) Parallel, four (4) USB 2.0 and Audio ports.
Memory and Storage
The DT168 may be available in memory configuraons ranging from 64MB of flash memory to 4GB
of flash. Depending on base soware configuraon, the user may use up the internal flash memory
of the WebDT 168 for the user’s installed soware and storage. The user may also supplement
storage space with USB-based peripherals such as flash disks, disk drives, etc. RAM capacity ranges
from 128MB to 1GB.
VESA Mounng Bracket Installaon Guide for DT168
It is quite simple to mount the DT168 to VESA adapters or LCD monitors using the external
mounng bracket.
OPTIONS
The DT168 is designed to work with a range of custom and off-the-shelf opons to enhance its
applicability for various deployments.
USB-to-Serial and USB-to-PS/2 adapters•
Bracket and Cable for Internal Hard Disk Drive (HDD) Mounng•
IInternal (mini-PCI) and External (USB) wireless LAN (WLAN) adapters•
Short VGA cable for connecon to mounted display•
External bracket for mounng the DT168 to VESA adapters and LCD monitors (see mounng•
process above)
Precauons
Always exercise care when operang and handling the DT168.•
Never disassemble any poron of the enclosure. It will void any product warranty on the DT168.•
Do not use any AC/DC adapter other than the one provided with the device or acquired from the•
manufacturer or its partners.
In the unlikely event that smoke, abnormal noise, or strange odor is present, immediately power•
down the DT168 and disconnect all power sources. Please report the problem to your device
provider immediately.
Rear ViewFront View
ABC D FE G
G H I
A E H
B D F I
C
G
USB ports
Power Indicator
Power buon
Audio jacks
Parallel Port
Serial Ports
VGA
Ethernet port
USB ports
