BASIC OPERATION GUIDE
Tablet Mount Cradle
INTRODUCTION
Thank you for acquiring the latest addion to DT Research’s line of tablet accessories – the
Tablet Mount Cradle (ACC-008-32). Featuring compact, robust design, this cradle provides
secure placement and charging of the DT370 and DT380 series tablets whether mounted
in vehicles or on the wall. This innovave cradle provides connecon ports and promotes
ergonomic, efficient access and management of DT Research tablets.
Package Contents
• One (1) Tablet Wall Mount Cradle
• One (1) VESA Conversion Bracket
• Two (2) Keys
• Four (4) Silver Bushes for wall mounng
• Four (4) Black Nuts for VESA mounng
• Eight (8) M4 Screws
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
Copyright © 2019, DT Research, Inc. All Rights Reserved. BOG 061219 WMCENG
Releasing the Tablet from the Cradle
1. Unlock the Cradle with the key, then slide the latch on the bo�om of the Cradle to
loosen the Top Clasp.
2. Using two hands, hold the Tablet on both sides, pull the tablet up to remove the Tablet
from the Cradle.
Before
Wall/ Vehicle Mount Cradle
Dimensions (H x W x D) 198mm x 139mm x 46mm
Weight 1.41lbs/ 640g
Temperature Operaon: 0°C – 40°C; Storage: -20°C – 60°C
Humidity 0% – 90% non-condensing
I/O Ports
Ethernet RJ45 connector for Ethernet x 1
USB 2.0 4
DC-in 1


USB PortsEthernet PortDC-in Jack Latch
Top Clasp
Keyhole
OPERATION

The Tablet Mount Cradle supports VESA standard mounng opons (75 mm x 75 mm) so it can
be easily a�ached onto a wall, in a vehicle, and on a VESA arm.
2 3
 
1. Use the key to unlock, and slide the latch on the bo�om of the Cradle to loosen the Top
Clasp.
2. Insert the bo�om part of the Tablet into the cradle first with the connector parts
correctly lined up.
3. When the bo�om of the Tablet is in place, push the Tablet against the back and into the
Cradle.
4. Push down on the Top Clasp, so the top poron of the cradle slides down and locks into
the locked-down posion.
5. Lock the Cradle with the key.
NOTE: If using a 100 x 100 VESA stand or arm, the VESA Conversion Bracket is
needed. Please place the VESA Conversion Bracket on the back side of the Cradle,
and apply the four M4 screws.
1
3
2
4
5
NOTE: For proper operation, make sure all necessary connections are in place
before powering on the DT Research Tablet.
