Dual Sirus XM 2013 User manual

Built-inBluetooth Wireless Technology
Top of the line Dual receivers have built-in Bluetooth,
allowingthe user toconveniently andsafely integrate
their smartphones and other devices into the car’s audio
system.The technology supports the three most popular
proles: HFP, A2DP and AVRCP.
Technology 1
Multimedia 5
CD Receivers 8
Combo Packs 11
Ampliers 12
Speakers 13
Accessories 16
Product Comparisons 18
Easy to use Connectivity and Device Integration for ...
Hands-free Calling (HFP)
Allows phone calls via the car’s audio
systemusingmost Bluetoothenabled
cell phones, including the iPhone
and other smartphones. Answer a
call, redial, or manage call waiting
– all while keeping your hands on the
wheel and eyes on the road.
Audio Streaming andPlayer
Control (A2DP and AVRCP)
Allows for wireless audio streaming
from a mobile phone or a media
player tothecar’sreceiver.Control
your media player directly from
the receiver’s front panel while
also enjoying quality sound from
your car’s speakers.

CD Playback Mode
Most Dual CD receivers allow playback of
MP3/WMA data CDs in addition to traditional
CDs and CD-R/RWs. Know what is playing at a
glance with ID3 tag display of artist and track
information.
Dual is one of the rst manufacturers to oer SiriusXM-Ready
receivers, allowing the user to easily expand their in-car
entertainment by adding satellite radio. The universal adapter
allows the SiriusXM Connect Vehicle Tuner Kit to be plugged
directly into the receiver. (Sold separately, SiriusXM subscription
required).
TECHNOLOGY
... Enhanced In-Car Entertainment and Safer Driving Habits.
Multi-Format Audio Support
Dual receivers are compatible with today’s most popular digital audio
formats: MP3 andWMA. Most Dual receivers support all these formats,
allowingtheusertobringtheirentiremusiccollectiontothecarvia
CD, USB drive, SD card or media player.
SD Card Playback Mode
Many Dual audio receivers feature an SD
card input, allowing the user to access their
music library (up to 32GB of MP3 or WMA
les) via an SD/SDHC card. The SD card
inputs are conveniently located on the front
panel or behind the faceplate of the receiver.
USB Playback Mode
Most Dual audio receivers feature USB
inputs, allowing the users to access their
music library (up to 16GB of MP3 orWMA
les) via a USB ash drive.The USB inputs are
conveniently located on the front panel of
the receivers.

TECHNOLOGY
Direct USB Control for iPod®/iPhone®
Plug in your iPod or iPhone via the USB input and
control it directly from the receiver’s front panel.
Browse the music library, change songs and adjust
volume – all safely, within arm’s reach, while enjoying
high-quality sound from the car speakers.The
connected device will also charge, so it is ready to go
when you are.
Custom Colors
Withover32,000colorvariations,ourCustomColors
feature allows the user to match the receiver’s LCD and
buttonilluminationtothevehicle’sinteriorlighting;or
even create a color that ts the mood!
3”QVGA Full-Color LCD
These large, multi-line digital LCDs (320 x 240) feature stunning, full-color
background graphics. The scrolling display shows album art, artist and song
information.

In-Dash Control for Pandora
Enjoy personalized Internet radio in your car, directly from the
receiver. Give tracks “thumbs up” or “thumbs down,” bookmark
a song for purchase and switch between your personalized
radio stations. The receiver conveniently displays full track
data. The Pandora control feature is compatible with iPhone
devices connected to the receiver via USB and with Android
and Blackberry devices connected via Bluetooth. Pandora app
required (free download from the iTunes App Store).
TECHNOLOGY
UltraMotion Display
Dual is the rst manufacturer to introduce tablet-like, multi-
touchdisplayfunctionalityinautomobilemultimediareceivers.
The UltraMotion Display allows you to swipe, ick, drag and drop
objects, and to rearrange the menu icons for a custom layout.
The stunning, 3D-like menu graphics are also interactive.The
technologyispoweredbyDual’s3Dgraphicsenginefeaturing
an ARM Cortex ™ A8 single core 1GHz CPU.
High-Performance Speakers
The DLS 4-way, high-performance speaker series feature a
balanceddomemidrangeforenhancedclarity,aninjection-
molded polypropylene woofer cone for accurate bass response,
a rubber surround to withstand heat and moisture, dual Piezo
tweetersfor extendedhigh-frequencyresponseandalow-prole
basket design for installation exibility.
Portable Device Mount
The adjustable Portable Device Mount provides added value
for today’s connected consumer. As consumers increasingly
use their smartphones for navigation and music streaming,
device integration into the head unit is not only a matter of
convenience, but also safety. The Portable Device Mount adjusts
to t most smartphones, iPhone and iPod devices.
Steering WheelControl-Ready
Replace the factory-installed head unit without losing the
convenience of controlling the receiver directly from the steering
wheel. (Third party adapter required).

MULTIMEDIA
5
This 2.0 DIN multimedia receiver features a large 6.2” digital, high-resolution display. Direct control for iPod/iPhone devices is
available through the connector on the back (cable included). The built-in Bluetooth Wireless Technology supports hands-free
calling, audio streaming and player control. The receiver also features a rear USB input, front panel microSD card and 3.5mm A/V
inputs to connect other media devices. Two dedicated video outputs on the back allow for the connection of additional monitors.
The receiver is back-up camera ready.
XDVD1262BT DVD Multimedia Receiver with Built-In Bluetooth®
This new receiver features a 6.2” high-denition digital LCD with multi-touch technology and interactive, 3D-like menu graphics.
The display allows you to swipe, ick, drag and drop objects, and to rearrange the icons for customized menu.
Direct control for iPod/iPhone devices, including control for Pandora Internet radio is available through the USB input on the front.
The receiver features two A/V inputs - a 3.5mm auxiliary input on the front and RCA inputs on the back. An SD card slot behind the
semi-detachable faceplate supports 1080p playback. The receiver is Bluetooth-ready.
A dedicated RCA video output on the back allows for the connection of an additional monitor. The receiver is also steering wheel
control-ready and back-up camera-ready.
DXV3D DVD Multimedia Receiver with UltraMotion Display
1.15 MEGAPIXEL
1.15 MEGAPIXEL
READY
Multi-Touch
Display

MULTIMEDIA
6
This 1.0 DIN multimedia receiver features a large 7” digital, high-
resolution display. Direct control for most iPod and iPhone devices is
available through the connector on the back (cable included). Other
features include a front panel USB input, SD card and 3.5mm A/V
inputs to connect other portable media devices. Two dedicated video
outputs on the back allow for the connection of additional monitors.
The receiver is back-up camera ready.
XDVD1170 DVD Multimedia Receiver
This 1.0 DIN multimedia receiver features a large 7” digital, high-resolution display. Direct control for most iPod and iPhone devices is
available through the connector on the back (cable included). The built-in Bluetooth Wireless Technology supports hands-free calling,
audio streaming and player control. Other features include a front panel USB input, SD card and 3.5mm A/V inputs to connect other
portable media devices. Two dedicated video outputs on the back allow for the connection of additional monitors. The receiver is back-
up camera ready.
XDVD1170BT DVD Multimedia Receiver with Built-in Bluetooth
1.15 MEGAPIXEL
1.15 MEGAPIXEL
This 2.0 DIN multimedia receiver features a large 6.2” digital, high-
resolution display. Direct control for most iPod and iPhone devices is
available through the connector on the back (cable included). Other
features include a rear USB input, front panel microSD card and 3.5mm
A/V inputs to connect other portable media devices. Two dedicated
video outputs on the back allow for the connection of additional
monitors. The receiver is back-up camera ready.
XDVD1262 DVD Multimedia Receiver
1.15 MEGAPIXEL

7
MULTIMEDIA
This 1.0 DIN multimedia receiver boasts a large 7” digital, LED
backlit, high-resolution (1.15 Megapixels) display. Direct USB
control for iPod and iPhone devices is available through the USB
input on the back. The input also supports video playback (IPV40
cable required). The front panel features SD card and 3.5mm A/V
inputs to connect other portable media devices. Two dedicated
video outputs on the back allow for the connection of additional
monitors. The receiver is back-up camera ready.
XDVD3101 DVD Multimedia Receiver
1.15 MEGAPIXEL
This 2.0 DIN multimedia receiver boasts a 6.2” digital, LED backlit, high-resolution (1.15
Megapixels) display. Direct USB control for iPod and iPhone devices is available through
the USB input on the back. The input also supports video playback (IPV40 cable required).
The front panel features SD card and 3.5mm auxiliary inputs to connect other portable
media devices. Two dedicated video outputs on the back allow the connection of
additional monitors. The receiver is back-up camera ready.
XDVD3201 DVD Multimedia Receiver
NEW!
NEW!
1.15 MEGAPIXEL

8
CD RECEIVERS
This new receiver features a large, 3” QVGA TFT multi-line, full-color LCD (320 x 240) with stunning, 3D-like background graphics. The
scrolling display shows album art and artist/song information. Direct control for iPod/iPhone devices, including control for Pandora
Internet radio is available through the USB input on the front. The Pandora control feature allows you to give tracks “thumbs up”
or “thumbs down,” bookmark a song for purchase and switch between your personalized radio stations. The receiver conveniently
displays full track data. The receiver is also steering wheel control-ready.
XDMA761 CD Receiver with 3”QVGA LCD
XDMA550BT Bluetooth® CD Receiver
This versatile CD receiver features a high-contrast LCD that is easy to read in the dark as well as in full sunlight.The built-in Bluetooth allows
for hands-free calling, audio streaming and control of connected devices, including control of Internet radio apps on Apple, Android and
Blackberry phones. Direct control for iPod/iPhone is available through the USB input on the front.The USB input charges your device and
allows playback of MP3/WMA les from ash drives.There are two auxiliary inputs – a 3.5mm jack on the front and RCA-type on the back.
XDMA450 CD Receiver
Featuring a high-contrast LCD, direct USB control for iPod/
iPhone devices, two auxiliary inputs - 3.5mm on the front
and RCA-type on the back, and two preamp outputs (F+R/S
selectable).
XD250 CD Receiver
Featuring a front panel USB charge port, and a 3.5mm auxiliary
input to connect portable media devices.
Charge Only

CD RECEIVERS
9
XDMA6630 CD Receiver
The built-in Bluetooth technology in this versatile CD receiver
allows for hands-free calling, audio streaming and control of
connected devices, including control of Internet radio apps on
Apple, Android and Blackberry phones. Direct control for iPod/
iPhone is available through the USB input on the front, which also
charges your device and allows playback of MP3/WMA les from
ash drives. A 3.5mm auxiliary input is located on the front.
Shown with the included Portable Device Mount.
XDMA6510 CD Receiver
Featuring direct USB control for iPod and iPhone devices,
and an adjustable Portable Device Mount to securely
hold electronics safely within the driver’s reach.
XDMA6540 CD Receiver
This full-featured CD receiver boasts a full-graphic LCD
with thousands of custom color variations. The built-in
Bluetooth allows for hands-free calling, audio streaming
and control of connected devices, including control of
Internet radio apps on Apple, Android and Blackberry
phones. Direct control for iPod/iPhone is available
through the USB input on the front. The receiver is
SiriusXM-Ready, and includes a Portable Device Mount
which securely holds electronics in place.
Shown with the included Portable Device Mount.
XDMA6438 CD Receiver
Featuring direct USB control for iPod and iPhone devices.
XD1228 CD Receiver
Featuring a front panel USB charge port, and a 3.5mm
auxiliary input to connect portable media devices.
Charge Only

CD RECEIVERS
10
XDMA5280 CD Receiver
Featuring direct USB control for iPod and iPhone devices,
and an adjustable Portable Device Mount to securely hold
electronics safely within the driver’s reach.
XDMA6370 CD Receiver
Featuring direct USB control for iPod and iPhone, plus a front
panel 3.5mm auxiliary input and an SD card input behind the
faceplate.
X2DMA400 CD Receiver
Featuring direct USB control for iPod and iPhone, plus front
panel SD card and 3.5mm auxiliary inputs. The universal
adapter allows the SiriusXM Connect Vehicle Tuner Kit to be
plugged directly into the receiver (Sold Seperately).
Shown with the included Portable Device Mount.
XDM6351 CD Receiver
Featuring front panel USB and 3.5mm auxiliary inputs to
connect portable media devices.
XR4115 Digital Media Receiver
Featuring front panel USB, SD card, and 3.5mm auxiliary
inputs to connect mobile devices.

11
CP6500 CD Receiver with Speakers
This combo pack includes the XDMA6438 CD Receiver and a
pair of 6.5” 2-way speakers. The receiver features direct USB
control for iPod/iPhone devices and front panel USB and
3.5mm auxiliary inputs.
CP5250 CD Receiver with Speakers
This combo pack includes the XD5250 CD Receiver and a pair
of 6.5”2-way speakers. The receiver features a front panel USB
charge port and a 3.5mm auxiliary input to connect portable
media devices.
Charge Only
COMBO PACKS

12
AMPLIFIERS
Featuring performance-matched output transistors for
maximum power transfer and black anodized extruded
aluminum heat sinks for dissipating the heat. Direct-wire
inputs eliminate the need for extra terminals while ensuring
a more positive connection through increased wire contact.
In addition, thermal overload and low-impedance circuits
provide protection for even the most demanding applications.
AMPLIFIERS
XPR510D 1500 Watt Digital Mono Amplier
XPR540 1200 Watt 4/3/2 Channel Amplier
Featuring variable high-pass and low-pass crossovers with a
12dB/octave crossover slope and a 0, 6 or 12dB bass boost. For
installation exibility, it also includes high-level and low-level inputs
- accommodating connection to OEM and aftermarket head units.
XPR520 600 Watt 2/1 Channel Amplier
Featuring simultaneous stereo and bridged operation, allowing
the connection of both full-range speakers and a subwoofer to
the amplier.
DPA250 250 Watt 2/1 Channel Amplier
Featuring simultaneous stereo and bridged operation, allowing
the connection of both full-range speakers and a subwoofer to the
amplier.
Remote Bass Control (included)

13
SPEAKERS
Featuring a balanced dome midrange for enhanced vocal clarity,
injection-molded polypropylene woofer cones for accurate bass
response, rubber surrounds to withstand heat and moisture, dual
Piezo tweeters for extended high-frequency response and a low-
prole basket design for installation exibility.
DLS6940 400 Watt 6”x 9”4-Way Speakers
DLS6540 320 Watt 6.5”4-Way Speakers
Featuring a balanced dome midrange for enhanced vocal clarity
and an injection-molded woofer cone for accurate bass response.
DLS6840 300 Watt 6”x 8”4-Way Speakers
Featuring a balanced dome midrange for enhanced vocal clarity and
injection-molded woofer cone for accurate bass response.
Fits both 5”x 7” and 6” x 8” speaker openings.
DLS5240 250 Watt 5.25”4-Way Speakers
Featuring a balanced dome midrange for enhanced vocal
clarity and an injection-molded woofer cone for accurate
bass response.
DLS4640 200 Watt 4”x 6”4-Way Speakers
Featuring a balanced dome midrange for enhanced vocal
clarity and an injection-molded woofer cone for accurate
bass response.

SPEAKERS
14
DLS4040 200 Watt 4”4-Way Speakers
Featuring a balanced dome midrange for enhanced vocal clarity and
an injection-molded woofer cone for accurate bass response.
SUBS / ENCLOSURES
DLS12 12”Subwoofer
• 1000 Watts peak power
• 250 Watts RMS
• Works with sealed or vented enclosures
• 12” Low-Q optimized driver with 38 oz. magnet
• Brushed nickel injection-molded cone
• Heavy-gauge stamped steel basket
• Treated foam surround
• Vented 2” voice coil
ALB12 12”8PPGFSJOBO"NQMJGJFE&ODMPTVSF
• 300 Watts peak power
• 60 Watts RMS
• MOSFET powered
• Frequency response: 20Hz – 200Hz
• Variable low-pass crossover: 40Hz – 200Hz
• 30oz. Magnet

BAK1500 10”Low-Prole
Underseat Amplied Subwoofer
• 1500 Watts peak power
• MOSFET powered
• Frequency response: 20Hz - 160hZ
• Remote level control (included)
• Dimensions: 2.9” (H) x 10.5” (W) x 14.9” (D)
SUBS/ENCLOSURES
15
BP1204 Bandpass Enclosure
• 1100 Watts peak power
• 600 Watts RMS
• Dual 12” low-q optimized drivers with 45 oz. magnets
• Brushed aluminum injection-molded cones
• Treated foam surrounds
• 4 ohm nominal impedance
• Dual acrylic viewing windows
• Blue illumiNITE™ LED illumination
• Mirrored 3-chamber design
• Carpeted enclosure with embroidered logo
• Dimensions (30” x 14.4” x 14.4”)
SBX100 10”Subwoofer
in a Vented Enclosure
• 175 Watts RMS
• 500 Watts Peak
• Black polypropylene cone
• Rubber surround
• Sensitivity: 88dB
• Frequency response: 25Hz - 500Hz
• Dimensions: Depth: 5.91” - Top:9.84”
Height: 12.8”- Width: 16.54”
SBX101 10”Subwoofer
in a Ported Enclosure
• 175 Watts RMS
• 500 Watts Peak
• Aluminum woofer cone
• Rubber surround
• Sensitivity: 87dV
• Frequency response: 25Hz - 500Hz
• Dimensions: Depth:6.5” - Top:11.2”
Height:12.8”- Width:17.7”
Remote Level
Control (included)

ACCESSORIES
16
IP35 Audio Interface Adapter IP45 Audio/Video Interface Adapter
IPV40 Video Playback
Cable for iPod and iPhone Devices
• Includes 3.5mm to 3.5mm cable
• Universal connection for all portable digital media players
• Multiple mounting options for easy front-of-dash access
The Dual IP45 allows you to listen to and view content from any
portable device (equipped with standard RCA outputs) through
your multimedia car stereo. Multiple mounting options and a
cosmetic rubber boot allow for easy, inconspicuous installation.
The IPV40 cable connects iPod/iPhone devices to select 2012 and
up multimedia receivers with a USB input and dedicated video
input. This 40” cable includes a standard Apple 30 pin connector
on one end and splits to a full size USB with an RCA video output
connector on the other end. It provides a high-quality digital
audio connection, full playback control and charging of your
iPod or iPhone. In addition, the IPV40 allows video to be dis-
played when the vehicle is parked.
BTM100 Bluetooth® Module
• Supports HSP, HFP, A2DP, AVRCP proles
• Integrated noise cancelling microphone
• Sun visor mounting clip
• Answer and place calls using front panel controls
• Communicates with most Bluetooth enabled phones
• Last number redial
• View last 5 received/dialed/missed calls

PRODUCT COMPARISONS
17

PRODUCT COMPARISONS
18

www.dualav.com
407.936.0129
© 2013 Dual Electronics Corporation, 250 International Pkwy, Heathrow, FL 32746.
Specications are subject to change without notice. All trademarks are the property of their respective owners.
LIT001_Dual_2013
