Dual XDM6810 Operating instructions

INSTALLATION/OWNERS MANUAL
AM/FM/CD/MP3 Receiver with Detach Face
XDM6810

2
XDM6810 INSTALLATION
Preparation
TYPICAL MOUNTING METHOD
RESET
BUTTON
SECURITY
LED
KEYS
Please read entire manual before installation.
Before You Start
•Disconnect negative battery terminal. (consult a qualified technician for instructions)
•Avoid installing the unit where it would be subject to high temperatures, such as from
direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting Started
•Remove 2 transit screws located
on top of the unit.
•Insert the supplied keys into the
slots as shown, and slide the unit
out of the mounting sleeve.
•Install mounting sleeve into
opening, bending tabs to secure.
•Connect wiring harness and
antenna. (consult a qualified
technician if you are unsure)
•Certain vehicles may require an
installation kit and/or wiring
harness adapter (sold separately).
•Test for correct operation and slide
into mounting sleeve to secure.
•Snap trim ring into place.

3
XDM6810 INSTALLATION
Wiring Diagram
FUSE
When replacing a fuse,
make sure new fuse is the
correct type and amperage.
Using an incorrect fuse
could damage the radio.
The XDM6810 uses one
10 amp ATM fuse located
beside the wiring connector.

4
XDM6810 OPERATION
Control Locations
Release
Power
Volume
Local/Distance
Auto Store/Preset Scan/Select
Tuner Scan
Band/Enter
Eject
EQ
Display/0
Tune/Track Up/9
1
2
3
4
5
6
7
8
9
10
11
Tune/Track Down/8
Mode/7
Preset 6/Folder Up
Preset 5/Folder Down
Preset 4/Shuffle
Preset 3/Repeat
Preset 2/Scan
Preset 1/Pause
Audio
Loudness
Mute
12
13
14
15
16
17
18
19
20
21
22
2122 20 19 18 17 16 15 14 13 12 11
1 2 34 5 678 9 10
The XDM6810 allows playback of your favorite MP3 files recorded on CD-R and CD-RW
discs. Its powerful on-board DSP processor decodes the compressed audio while main-
taining near-CD sound quality. An internal buffer provides up to 100 seconds of ESP
(Electronic Skip Protection) (@128kbps/44.1kHz) and allows alphanumeric or direct track
search - even while a song is currently playing!

5
XDM6810 OPERATION
General Operation
Press RELEASE and pull away from the left side to remove.
To re-install, insert right side of faceplate first then push
left side to secure.
*For semi-permanent faceplate installation, remove trim ring and install
supplied Phillips head #1 screw through left side of mounting frame into face-
plate.
Press POWER or any other button (except eject) to turn the
unit on. Inserting a disc will turn the unit on automatically.
Press POWER to turn the unit off.
Press MODE to select between tuner, CD player and auxiliary
input. Modes of operation are indicated in the display.
Press LOUD to activate and deactivate the loudness contour
curve. Activating this feature will enhance the bass and
treble frequencies when listening to music at low volumes.
Adjust volume using rotary encoder (00-100).
Press AUDIO for 2 seconds, then use the rotary encoder to
select between BEEP ALL, BEEP OFF or BEEP 2ND.
Press MUTE to silence the audio. Press any button to cancel.
Press EQ to select between FLAT, CLASSICS, POP, ROCK and
DSP OFF (default) equalization curves. FLAT indicates no
audio enhancement. Any adjustment to the Bass or Treble
settings automatically cancels the current EQ curve.
Press DISP to select between clock and radio frequency
(tuner mode) or CD track/elapsed time (CD player mode).
With the unit on, press DISP to display the clock, then
release. Press and hold DISP until the clock begins to flash,
then release. Press TUNE
nn
to adjust the hours and
TUNE
ll
to adjust the minutes. Press DISP momentarily
to save the selected time.
The clock will display 12-hour AM/PM time in U.S. frequency
spacing mode (PM 10’00). In European frequency spacing
mode, the clock will display 24-hour time (22’00).
Faceplate Removal
Power On/Off
Mode
Loudness
Volume
Confirmation Beep
Mute
Preset EQ Curves
Display
Set the Clock
12/24-hour Clock

6
XDM6810 OPERATION
General Operation
Press and hold for more than 2 seconds to RESET the unit
upon initial installation, when selecting between
US/European frequency spacing or if abnormal operation
occurs. The rest button is located behind the faceplate.
Press AUDIO to select between Volume (default), Bass,
Treble, Balance & Fader.
Press AUDIO until BAS appears
Rotate encoder left/right to adjust
(+10 maximum / -10 minimum)
Press AUDIO until TRB appears
Rotate encoder left/right to adjust
(+10 maximum / -10 minimum)
Press AUDIO until BAL appears
Rotate encoder left/right to adjust
(BAL 10L/BAL 10R) L=R represents equal balance.
Press AUDIO until FAD appears
Rotate encoder left/right to adjust
(FAD 10F/FAD 10R) F=R represents equal fader.
Reset
Audio
Bass
Treble
Balance
Fader

Press TUNE
nn
or TUNE
ll
momentarily to seek the
next strong station.
Press TUNE
nn
or TUNE
ll
for more than 2 seconds,
then release. "MANUAL" will momentarily appear in the
display. Press TUNE
nn
or TUNE
ll
momentarily to
move radio frequency up or down one step at a time. Press
and hold to advance quickly. If tuning is not adjusted for 5
seconds, the unit will return to seek tuning mode (default).
"AUTO" will momentarily appear in the display.
Press SCAN to preview strong stations on the current band,
pausing for 5 seconds at each. Press SCAN again to cancel.
Press LOC to activate local tuning for strong station recep-
tion only. Press LOC again to cancel and resume Distance
tuning (default).
Press BAND to select between FM1, FM2, FM3 and AM
bands.
A switch on the bottom of the chassis selects between
US/European FREQUENCY SPACING. After changing the
switch position, press RESET to activate the change.
Up to 18 FM stations and 6 AM stations can be stored. To
store a station, select the desired band and station. Press
and hold the desired preset button for more than 2 seconds.
When stored, the preset number will appear in the display.
The station can be recalled anytime by pressing the
corresponding preset button.
Press AS/PS for more than 2 seconds to automatically store
the six strongest stations in the current band. Automatic
Local/Distance is activated during the initial band scan.
Press AS/PS for less than 2 seconds to scan presets 1-6 on
the current band, pausing for 5 seconds at each. Press
AS/PS again to cancel.
7
XDM6810 OPERATION
Tuner Operation
Seek Tuning
Manual Tuning
Scan Tuning
Local/Distance
Band
Frequency Spacing
Storing and Recalling
Station Presets
Automatically Store
Stations
Preset Scan

With the label facing up, insert a standard size CD into the
CD slot. The CD will automatically begin playback.
Press the EJECT button to stop and eject the CD. The unit will
change to previous mode of operation (tuner or auxiliary
input). If the disc is not removed within 10 seconds, the unit
will reload the disc.
Press TRACK
ll
to skip to the beginning of the next track.
Press TRACK
nn
to return to the beginning of the current
track. Pressing TRACK
nn
again skips to the beginning of
the previous track.
Press and hold TRACK
nn
or TRACK
ll
to fast forward
or reverse a track.
Press
l
/ II to temporarily stop CD playback.
Press
l
/ II again to resume playback.
Press SCN to play the first 10 seconds of each track. S-SCN
will appear in the display along with the current track num-
ber. Press SCN again to cancel.
Press RPT to continuously repeat selected track. S-RPT will
appear in the display along with the current track number.
Press RPT again to cancel.
Press SHF to play all tracks in random order. S-SHF will
appear in the display along with the current track number.
Press SHF again to cancel.
8
XDM6810 OPERATION
CD/MP3 Player Operation
Insert CD
Eject CD
Track Select
Fast Forward and Reverse
Pause
Scan
Repeat
Shuffle

Playing an MP3 Disc
MP3 Icon
Folder Icon
ID3 Tag Display
Display Information
When an MP3 encoded disc is first inserted, READING CD
ROM will appear in the display. Depending on the number of
files and folders, this may take several seconds.
The icon will illuminate anytime a valid MP3 encoded
disc is inserted.
The icon will flash in folder navigate modes.
The icon will illuminate anytime a folder is selected in
the folder search and folder navigate modes.
Press DISP to select between Filename (default), Clock,
Track Name, Artist Name, Album name, Year & Comment.
*Track Name, Artist Name, Album name, Year and
Comment (ID3 information) will only be displayed if included
with the MP3 file.
Maximum character display information
• Filename – 28 character maximum
• Folder name – 16 character maximum
• Track name – 27 character maximum
• Artist name – 27 character maximum
• Album name – 27 character maximum
• Year – 4 character maximum
• Comment – 27 character maximum
9
XDM6810 OPERATION
CD/MP3 Player Operation

10
XDM6810 OPERATION
Press SELECT to select between the following MP3 Modes:
• Direct Numeric Track Select
• Alphanumeric Track or Folder Search
• Root Folder Navigate
• Current Folder Navigate
Press SELECT one time, "MP3 T*" will flash in the display.
Use the buttons in the above table (3 keystroke maximum
input), or the rotary encoder to enter the desired track
number.
Press ENTER to confirm the selected track number or, wait
for the input cycle to time out (approximately 4 seconds).
CD/MP3 Player Operation
MP3 Direct Select, Search
and Navigate Modes
Direct Numeric Track
Select
Step 2
MP3 Button Function Table
Button Function
SELECT MP3 Direct Select, Search and Navigate Modes
ENTER Enter/Confirm
Preset 1 A, B, C, 1
Preset 2 D, E, F, 2
Preset 3 G, H, I, 3
Preset 4 J, K, L, 4
Preset 5 M, N, O, 5
Preset 6 P, Q, R, 6
MODE S, T, U, 7
Track Down V, W, X, 8
Track Up Y, Z, [Space], 9
DISP _, -, +, 0
AUDIO Character Shift
Rotary Encoder Character Select (A, B, C ~ 8, 9, 0)
Refer to the following button function table when selecting, searching or
navigating MP3 files and folders:
