Dual XHD6430 Operating instructions

INSTALLATION/OWNER'S MANUAL
CD Receiver with Detachable Face
XHD6430
READY

2
TYPICAL FRONT-LOAD DIN MOUNTING METHOD
Please read entire manual before installation.
Before You Start
•Disconnectnegativebatteryterminal.Consultaqualifiedtechnicianforinstructions.
•Avoidinstallingtheunitwhereitwouldbesubjecttohightemperatures,suchasfrom
directsunlight,orwhereitwouldbesubjecttodust,dirtorexcessivevibration.
Getting Started
•Removetrimringfromunit,
•Remove2transitscrewslocated
ontopoftheunit.
•Insertthesuppliedkeysintothe
slotsasshown,andslidetheunit
outofthemountingsleeve.
•Installmountingsleeveinto
opening,bendingtabstosecure.
•Connectwiringharnessand
antenna.Consultaqualified
technicianifyouareunsure.
•Certainvehiclesmayrequirean
installationkitand/orwiring
harnessadapter(soldseparately).
•Testforcorrectoperationandslide
intomountingsleevetosecure.
•Snaptrimringintoplace.
XHD6430 INSTALLATION
Preparation
KEYS
HEX BOLT
MOUNTING SLEEVE
PLAIN WASHER
HEX NUT
MOUNTING STRAP

3
FUSE
Whenreplacingthefuse,
makesurenewfuseisthe
correcttypeandamperage.
Usinganincorrectfuse
coulddamagetheradio.
TheXHD6430usesone
10ampATMfuselocated
besidethewiringconnector.
XHD6430 INSTALLATION
Wiring Diagram
Antenna
Connector
Steering Wheel Interface Input
(PAC SWI-PS required)
FRONT R/SUB
L-CH
R-CH
REMOTE IN
BLACK 8-pin Female Mini-DIN
BTM60 Connection (included)
REAR/SUB
(selectable)
RCA Preamp Output
Connections
FRONT

4
TheXHD6430allowsplaybackofyourfavoriteMP3andWMAfilesrecordedonCD-R
andCD-RWdiscs.Itspowerfulon-boardDSPprocessordecodesthecompressed
audiowhilemaintainingnear-CDsoundquality.AninternalSRAMbufferprovidesESP
(ElectronicSkipProtection)tovirtuallyeliminateskippingandallowsalphanumericor
directtracksearch-evenwhileasongiscurrentlyplaying!
XHD6430 OPERATION
Control Locations - Receiver
Release
Talk
Mode
Power( )/Select
Display
Preset1/Repeat
Preset3/Intro
Preset2/Random
Preset4/Play/Pause
Eject
USBPort
1
2
3
4
5
6
7
8
9
10
12 AuxiliaryInput
Preset6/FolderUp
Preset5/FolderDown
Tune/TrackUp
Tune/TrackDown
Band/ESC
Audio/Menu
Scan/HDSeek
Tag
Mute/EndCall
13
14
15
16
17
18
19
20
21
21
12456 7 8
12
9
3
20 19 18 17 16
11
10
11
131415

5
Control Locations - Remote
Key9
Mute/EndCall
Key0/Display
Talk
Key8/Tag
Key7
Preset4/Play/Pause
Preset1/Repeat
Band/ESC/Key*
Tune/TrackDown
1
2
3
4
5
6
7
8
9
10
12
13
14
15
16
17
18
19
20
Mode
Power( )/Select
VolumeUp
Audio/Menu
Tune/TrackUp
VolumeDown
Scan/HDSeek/Key#
Preset3/Intro
Preset2/Random
Preset6/FolderUp
Preset5/FolderDown
2 3
6
5
8
7
10
19
12
13
17
18
9
20
15
16
21
XHD6430 OPERATION
1 4
14
11
21
11

6
General Operation
XHD6430 OPERATION
Faceplate Removal
Semi-Permanent
Faceplate Installation
Power On/Off
Mode
Auxiliary Input
Steering Wheel Interface
Input
Volume
Mute
Reset
Display
Set the Clock
Press RELEASEandpullawayfromtheleftsidetoremove.
Tore-install,insertrightsideoffaceplatefirstthenpush
leftsidetosecure.
Removetrimringandinstallsupplied#1x7/32”Phillips
headscrewthroughleftsideofmountingframeintofaceplate.
Press oranyotherbutton(excepteject)toturntheuniton.
Insertingadiscwillturntheunitonautomatically.Pressand
hold toturntheunitoff.
Press MODEtoselectbetweenAM/FM,CDplayer,operation
of iPod®,USB,auxiliaryinputandBluetoothmodes.Modesof
operationareindicatedinthedisplay.
Note:CDmodewillnotappearunlessaCDisinserted.USB
modewillnotappearunlessaUSBdeviceisconnected.
OperationofiPodmodewillnotappearunlessaniPoddevice
isconnected.Bluetoothmodewillnotappearunlessthe
BTM60Bluetoothmoduleisconnected.
Insert3.5mmplugtoconnectyourportableaudiodevice.
Thesteeringwheelinterfaceinputlocatedonthebackofthe
headunitallowsconnectiontothePAC (Pacific Accessory
Corporation) SWI-PSinterfacemodule(soldseparately).Visit
www.pac-audio.comfordetails.
Toconfiguresteeringwheelcontrols,followtheinstructions
providedwiththePAC SWI-PSinterfacemodule.After
installingtheinterfacemodule,insertthemodule's3.5mm
jackintotheportonthebackoftheheadunit.
Adjustvolumeusingvolumeknob(00-46).
Press tosilencetheaudio.“MUTE”willflashinthe
display.Press againtocancel.
Press to RESETtheunituponinitialinstallationorif
abnormaloperationoccurs.Theresetbuttonislocated
behindthefaceplate.
Press DISPtoselectbetweenclockanddifferenttypesof
information,suchasradiofrequency,CDtrackorMP3/USB
songinformation.
Withtheuniton,pressandholdDISPuntiltheclockbegins
toflash,thenrelease.PressTUNE
nn
toadjustthe
hoursandTUNE
ll
toadjusttheminutes.PressDISP
momentarilytosavetheselectedtime.

7
XHD6430 OPERATION
General Operation
Setup Menu
Menu Function Options Action
Auto Station
Store AUTOSTORE Press SELECTtoseekandsave6strongstationsinthecurrentband.
(Tuner mode only)
Delete Tags DELETETAGS Press SELECTtopermanentlydeletealliTunestagscurrentlysavedin
theunit.(Tuner mode only)
Tuning Mode
TUNERDIGITAL Programstheunittotunetodigitalandanalogradiostations.(Tuner
mode only)
TUNERANALOG Programstheunittotunetoanalogradiostationsonly.(Tuner mode
only)
Loudness
Curve
LOUDOFF Disablestheloudnessfunction.
LOUDON Enablestheloudnessfunction.Activatingthisfeaturewillenhancethe
bassandtreblefrequencieswhenlisteningtomusicatlowvolumes.
Clock
Display
CLOCKOFF Programsunittonotdisplaytheclockwhenthepowerisoff.
CLOCKON Programsunittodisplaytheclockwhenthepowerisoff.
Auxiliary
Input
AUXON Enablesthefrontpanel3.5mmauxiliaryinput.
AUXOFF Disablestheauxiliaryinput.
Rear/Sub
RCA output
R/SSUB ProgramstheRear/SubRCApreampoutputtosubwoofer.
R/SREAR ProgramstheRear/SubRCApreampoutputtorear.
Beep Confirmation BEEPOFF Disablestheconfirmationbeep.
BEEPON Enablestheconfirmationbeep.
Local/Distance
Tuning
LOCALOFF Activatesstandarddistancetuning.
LOCALON Activateslocaltuningforstrongstationsonly.
Programmable
Turn On Volume PRO-VOL# Programsunittoturnonataspecificvolume
(defaultisOFF).
Power on Message MESSAGEOFF Disablespoweronmessage.
MESSAGEON Enablespoweronmessagetobedisplayed.
Scrolling
Option
SCROLLONCE Programsunittoscrollonce,thenshowthefirst10charactersonthe
display.
SCROLLON Programsunittoscrollcontinuously.
SCROLLOFF Programsunittoshowthefirst10charactersonthedisplay.
Illumination
Dimmer
DIMMERHIGH Programsunittothebrightestilluminationlevel.
DIMMERMEDIUM Programsunittothemiddleilluminationlevel.
DIMMERLOW Programsunittothedimmestilluminationlevel.
Demonstration
Mode
DEMOOFF Disablesthedemonstrationmode.
DEMOON Enablesthedemonstrationmessage.
PressandholdAUDIO/MENUformorethan3secondstoaccessthe
setupmenu,thenpressAUDIO/MENUtocyclethroughmenuoptions.
Whendesiredoptionappearsinthedisplay,rotatethevolume knob
left/righttoadjustoractivatethedesiredfunction.PressESCtoexit
themenuatanytime.
Setup Menu

8
XHD6430 OPERATION
Press ESCtoexitanymenuadjustmentmode.
Press AUDIO/MENUmomentarilytoselectbetweenBass,
Treble,Balance,Fader,EQ,Subwoofer*andSourceVolume
Level.
Press AUDIO/MENU until BASSappears,thenrotate
thevolume knobleft/righttoadjust(-6minimum/+6
maximum).
Press AUDIO/MENU until TREBLEappears,thenrotate
thevolume knob left/righttoadjust(-6minimum/+6
maximum).
Note:BassandTreblesettingsaresavedastheUSEREQ
setting.
Note: BassandTreblesettingsareretainedforeachmode
individually.
Press AUDIO/MENU until BALANCEappears,thenrotatethe
volume knobleft/righttoadjust(BALL12toBALR12).L=R
representsequalbalance.
Press AUDIO/MENU until FADERappears,thenrotatethe
volume knobleft/righttoadjust(FADERF12toFADERR12).
F=Rrepresentsequalfader.
Press AUDIO/MENU until EQappears.Rotatethevolume
knobleft/righttoselectbetweenFLAT(default),POP,JAZZ,
CLASSIC,BEAT,ROCKandUSERequalizationcurves.Press
SELECTtoconfirm.AnymanualadjustmenttotheBassor
TreblesettingsareautomaticallysavedasUSER.
Press AUDIO/MENU until SUB-Wappears,thenrotatethe
volume knobleft/righttoadjust(0-12).Adjustinglevelsto0
turnsthesubwooferoff.
Thesourcevolumelevelcontrolallowsagainadjustmentfor
eachaudiosource:AM,FM,CD,AUX,USB,operationofiPod
andBluetooth.Setthesourcevolumelevelforeachmode,
dependingontherelativevolumeofeachaudiosource.
Tosetthesourcevolumelevel,pressAUDIO/MENU until
SOURCELEVELappears.Afteronesecond,thecurrent
modewillappearonthedisplay.Turnthevolume knob to
adjusttheaudiolevelofthecurrentsource(-6minimum/+6
maximum).
Note: Onlythecurrentmodewillbeavailableforadjustment.
Toadjustanothermodeofoperation,pressMODEuntilthe
desiredmodeisselected,thensetthesourcevolumelevel
forthatmode.
Escape
Audio
Bass
Treble
Balance
Fader
EQ
Subwoofer
Source Volume Level
General Operation
BASS TREBLE BALANCE FADER EQ SUBWOOFER* SOURCE LEVEL

9
XHD6430 OPERATION
Analog and Digital Tuning
Seek Tuning
Manual Tuning
Scan Tuning
Band
Storing and Recalling
Station Presets
Thefollowingtuningfunctionswillaccessbothanalogand
digitalstations.RefertotheHD SEEK mode sectiononpage
10forinstructionsontuningtoonlydigitalstations.
Press TUNE
nn
or TUNE
ll
formorethanonesecond
toseekthenextstrongstation.
WhenanHDRadiostationisselected,anHDRadiologowill
begintoflashonthedisplay.Inaboutfiveseconds,HDor
HD1willilluminateaftertheradiofrequency.
•If"HD"appears,theradiostationisbroadcastingahigher
 qualitysound.Noadditionalstationsareavailable.
•If"HD1"appears,additionalmulticastchannels(HD2
 and/orHD3)areavailable.PressTUNE
ll
to tune to
 otheravailablemulticastchannels.
Press TUNE
nn
or TUNE
ll
momentarilytomoveradio
frequencyupordownonestepatatime.Pressandholdto
advancequickly.
Press SCANmomentarilytopreviewstrongstationsonthe
currentband,pausingforfivesecondsateach.PressSCAN
againtocancel.
Press BANDtoselectbetweenFM1,FM2,FM3,AM1and
AM2bands.Uptosixpresetscanbeprogrammedforeach
band.
Upto18FMstationsand12AMstationscanbestored.
includingHDRadiostationsandmulticastchannels.To
storeastation,selectthedesiredbandandstation.Press
andholdthedesiredpresetbutton(1-6)formorethantwo
seconds.Whenstored,thepresetnumberwillappearin
thedisplay.Thestationcanberecalledbypressingthe
correspondingpresetbutton.
HD Radio™ AM/FM Tuner Operation

10
XHD6430 OPERATION
Display
HD Seek Mode
Whentheunitistunedtoananalog station,pressDISP to
togglethedisplaybetweenthefollowingoptions:
WhentheunitistunedtoanHD Radio station,pressDISP to
togglethedisplaybetweenthefollowingoptions:
Wheninformationisunavailable,"NODATA"appearsinthe
display.
PressandholdHD SEEKfor2secondstoactivatedigital-
onlytuningmode.TheHD SEEKiconwillappearonthe
display,indicatingthattheunitwillskipoveranalogstations
andtunetoHDRadiostationsonly.Followtheinstructions
onpage9toaccessseek,manualandscantuning.
• Storing and Recalling Station Presets
 HDRadiomulticaststations(HD2andHD3)canalso
 bestoredaspresets.Whenapresetmulticaststation
 isrecalled,"LINKING"appearsinthedisplayuntilthe
 downloadprocessiscomplete(approximately5seconds).
Note:IftheHDRadiosignalonthepresetisunavailable,
 theunitrevertstothepreviousanalogordigitalstation.
•Automatically Store Only HD Radio Stations
 WhileinHDSEEKmode,pressandholdAUDIO/MENU to
enterthesetupmenu.ChoosetheAUTOSTOREmenu
 optionandpressSELECTtobeginautomaticallystoring
 thefirst6HDRadiostationstopresets1-6.
Note:SinceallHDRadiostationsthatblendtodigitalare
considered'strong'stations,theAutoStationStorefeature
willstorethefirst6HDRadiostations,beginningfromthe
lowestfrequency.Multicastchannels(HD2and/orHD3)are
notautomaticallystoredwiththisfeature,butcanbestored
byholdingthedesiredpresetnumber(1-6)for3seconds.
HD Radio™ AM/FM Tuner Operation
(LINE 1) FREQUENCY
FREQUENCY
STATION NAME
PROGRAM TYPE
ARTIST
SONG TITLE CLOCK (LINE 2) BAND/PRESET
(LINE 1) FREQUENCYFREQUENCY
CLOCKBAND/PRESET
(LINE 2)

11
XHD6430 OPERATION
TheiTunesTaggingfeatureoftheXHD6430allowstheuser
to"Tag"songsthatareplayingonHDRadio™stationsand
enablesthemtobepurchasedlaterthroughiTunes®.With
thetouchofabuttontheunitwillrememberthetitleand
artistsonginformation,andthentransferthatinformation
toyouriPoddevicethenexttimeyouconnectittothe
XHD6430.Anewlistcalled"Tagged"willappeariniTunes,
givingyoutheoptiontopurchaseeachsong.
Tune to an HD Radio station.TheHDlogointhedisplay
mustremainsolid-indicatingthatadigitalstationistuned.
Ifthesonghasvalidartistandsongtitleinformation,the
TAGbuttonwillturnred.
Press the TAG button.TAGGINGSONGwillappear,followed
bySONGTAGGED,confirmingthesonginformationhas
beensavedtointernalmemory.Thesonginformationwill
besavedinmemoryuntilaniPoddeviceispluggedin.Up
to64Tagscanbesavedbeforetheymustbetransferredor
deleted.
Plug in an iPod device.AlltheTagscurrentlyinmemory
willbeautomaticallytransferred,deletingtheTagsfromthe
headunit'smemory.Seepage23forconnectiondetails.
IfaniPoddeviceispluggedinwhenasongistagged,the
TagwillbeimmediatelytransferredtotheiPoddevice(see
page12forcompatibilitywithiPoddevices).
AftertheTagtransfertotheiPoddeviceiscomplete,
theXHD6430willdisplaythenumberoftagsthatwere
successfullytransferred.
Sync with iTunes.Alistnamed"Tagged"willappearonthe
leftintheiTunessoftware.Clickonthe"Tagged"listtoview
allthesongsthathavebeentaggedandclickthe"view"
buttonforpurchaseinformation.
Note: SomeiPoddevicesmayrequireyoutoselect'transfer
purchases'inthecontextmenufromthenameofyouriPod
devicetotransferTagstoiTunes.
Managing Tags
ToviewthecurrentnumberofsavedTagsinmemory,press
andholdTAGfor3seconds.Thecurrentnumberofsaved
Tagswillappearalongwiththetotal(64).
Todeleteallthesavedtagswithouttransferringthemtoan
iPoddevice,changetotunermode,thenpressAUDIO/MENU
for3secondstoenterthesetupmenu.PressAUDIO/MENU
oncemoreuntilDELETETAGSappears,thenpressSELECT.
Aconfirmationmessagewillappear.
Note:TagsaremanagedfromtheiTunessoftware.
Overview
Tagging Music
Step 1
Step 2
Step 3
Step 4
Viewing Tags in Memory
Deleting All Tags
iTunes® Tagging

12
XHD6430 OPERATION
iTunes® Tagging
Device Compatibility
with iTunes Tagging
Compatiblewith
•*iPhone3GS
•*iPhone3G
•*iPhone
•*iPodtouch(2ndgeneration)
•iPodnano(4thgeneration)
•iPodclassic
•*iPodtouch(1stgeneration)
•iPodnano(3rdgeneration)
DisplayedMessage Description
CHECK iPod VER
ThereisacompatibilityissuewiththeiPoddevicethatis
connected.CheckthelistofcompatibleiPoddevicesbelow.
IftheattachediPoddeviceiscompatible,updatethefirmwareto
thelatestversionusingiTunes®.
SENDING TAGS TagsarebeingsenttotheiPoddevice.Thisprocesscantake
severalminutesdependingonthenumberofTagsbeingsent.
iPod FULL ThereisnotenoughspaceontheconnectediPoddeviceto
transfertheiTunesTags.FreeupspaceusingiTunes.
TRANSFER FAILED
Connectionerror.EnsuretheiPoddeviceispoweredonand
reconnecttheiPoddeviceuntilaTAGSSENTconfirmationis
displayed.
ALREADY TAGGED
Thesamesonghasalreadybeentaggedfromthesameradio
station,andiscurrentlysavedinmemory.Thesamesongcannot
betaggedtwice-unlessthesongistaggedonadifferentradio
station,theTagsaresenttoaniPoddeviceorthetagsareerased.
MEMORY FULL
CONNECT iPod
TheinternalmemoryoftheXHD6430willhold 64 Tags.AniPod
devicemustbeconnectedtotransfertheTags,ortheTagsmust
bedeletedbeforemoresongscanbetagged.
NO TAG INFO
Thereisnotsufficientinformation(artistortitle)totagthesong.
SomeHDRadio™stationsorcertainsongsmaynotfullysupport
iTunesTagging.
TAGGING FAILED TherewasanerrorsavingtheTaginformationtotheinternal
memory.Pressthe TAGbuttonagain.
NO TAGS STORED
Therearenotagssavedintheinternalmemory.TheDELETE
TAGSfunctioncanonlydeleteTagsthataresavedintheinternal
memory.
Troubleshooting
*SomeiPoddevicesmayrequireyoutoselect'transferpurchases'inthecontextmenufromthename
ofyouriPoddevicetotransferTagstoiTunes.
Gotowww.apple.com/itunesforthelatestversionoftheiTunessoftware.

13
XHD6430 OPERATION
Insert CD
Eject CD
Track Select
Fast Forward and Reverse
Pause
Repeat
Random
Intro
CD-R/CD-RW Compatibility
Withthelabelfacingup,insertastandardsizeCDintothe
CDslot.TheCDwillautomaticallybeginplayback.
Press EJECTtoejecttheCD.Theunitwillchangeto
previousmodeofoperation(AM/FM,AUX,USB,operation
ofiPodorBluetooth).Ifthediscisnotremovedwithin10
seconds,theunitwillreloadthedisc.Theunitdoesnothave
tobeturnedontoejectCD.
Press TRACK
ll
toskiptothebeginningofthenext
track.PressTRACK
nn
toreturntothebeginningofthe
currenttrack.PressingTRACK
nn
againskipstothe
beginningoftheprevioustrack.
PressandholdTRACK
ll
or TRACK
nn
tofastforward
orreverseatrack.
Press
l
/ II totemporarilystopCDplayback.
Press
l
/ II againtoresumeplayback.
Press RPT toentertheRepeatmenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-Playsalltracksondisc.
•TRACK-Continuouslyrepeatsselectedtrack.
Press RDM toentertheRandommenu,thenturnthe
volume knobtoselectoneofthefollowingoptions:
•OFF-CancelstheRDM function.
•ALL-Playsalltracksinrandomorder.
Note:Randommodeisretainedinmemorywhenselecting
betweenothermodesandwhentheunitisturnedon/off.
Press INT toentertheIntromenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-CancelstheINT function.
•ALL-Playsthefirst10secondsofeachtrack.
SomeCD-RsandCD-RWsmaybeincompatiblewiththis
unit,dependingonmediatypeandrecordingmethod.
Inaddition,thefollowingCDsmaybeincompatiblewith
thisunit:CDsexposedtoextremetemperaturesordirect
sunlightforextendedperiodsoftime,CDsrecordedin
whicharecordingsessionfailedorare-recordingwas
attemptedandencryptedorcopy-protectedCDsthatdonot
conformtotheaudioCD-DAredbookrecordingstandard.
CD Player Operation

14
CD Player Operation - MP3/WMA Files
Playing an MP3/WMA Disc
Displaying Information
Title Icon
Artist Icon
Folder Icon
File Icon
Character Support
WhenanMP3/WMAencodeddiscisfirstinserted,
“CDPLAY”willappearinthedisplay.Dependingonthe
numberoffilesandfolders,thismaytakeseveralseconds.
Press DISPtoselectbetweenthefollowing:
“NOID3TAG”willbedisplayediftheMP3filecontainsno
ID3taginformation.
“UNKNOWN”willbedisplayediftheWMAfilecontainsno
WMAtaginformation.
“ROOT”willbedisplayedifthedirectorynameofaroot
folder is not labeled.
Thisiconwillilluminatewhenthesongtitleisdisplayed.
Thisiconwillilluminatewhentheartistnameisdisplayed.
Thisiconwillilluminatewhenthefoldernameisdisplayed.
Thisiconwillilluminatewhenthefilenameisdisplayed.
Maximumcharacterdisplayinformation
•Trackname–32charactermaximum
•Directoryname–32charactermaximum
•*Songtitle–30charactermaximum
•*Artistname–30charactermaximum
*SongtitleandArtistNamewillonlybedisplayedif
includedwiththeMP3/WMAfile.
XHD6430 OPERATION
(LINE 1) FILE NAME ELAPSED TIME
CLOCK
TRACK NUMBER
TOTAL TRACKS
ARTIST
SONG TITLE
FOLDER NAME
(LINE 2)

15
XHD6430 OPERATION
CD Player Operation - MP3/WMA Files
Folder/File Search Mode
Folder/File Navigation
Navigating Note
Press SELECTtoenterthefolder/filesearchmode.Thehead
unitwillreadtheCD,andalistoffoldersandfilesfromthe
CDwillbedisplayed.Thesearchwillalwaysbeginfromthe
currentdirectory.
Whensearchingthecontentsofafolderorsubfolder,press
ESCtonavigateuponefolderlevel.
Turnthevolume knobtocyclethroughthelistoffoldersand
files.
Folderswillbedisplayedfirst,followedbyanyfiles.
•Whenafoldernameisbeingdisplayed, will
illuminate.
•Whenafilenameisbeingdisplayed, willilluminate.
Whenafoldernameisbeingdisplayed,pressSELECT to
changedirectoriesandbegindisplayingthecontentsofthat
folder.
Whensearchingthecontentsofafolderorsubfolder,select
"FOLDERUP"atthetopofthefile/folderlistorpressESC to
gouponefolderlevel.
Press ESCfromtherootdirectorytoexitsearchmode.
Afternavigatingtodesiredfile,thetracknamewillbe
displayedbydefault.PressDISPmomentarilytocycle
throughotherdisplayoptions.
FOLDER 1 FOLDER 2 Etc . . .
FILE 1 FILE 2

16
CD Player Operation - MP3/WMA Files
XHD6430 OPERATION
Folder Access
Repeat
Random
Intro
Press toselectthepreviousfolder.
Press toselectthenextfolder.
Note: FolderaccessisonlyavailableonMP3/WMAdiscs
recordedwithmorethanonefolder.
Press RPT toentertheRepeatmenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-PlaysalltracksonCD.
•TRACK-Continuouslyrepeatsselectedtrack.
•FOLDER-Continuouslyrepeatsallfilesinselectedfolder.
Press RDM toentertheRandommenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-CancelstheRDM function.
•ALL-Playsalltracksinrandomorder.
•FOLDER-Playsalltracksinfolderinrandomorder.
Note:Randommodeisretainedinmemorywhenselecting
betweenAM/FM,CD,AUXandUSBmodesandwhentheunit
isturnedon/off.
Press INT toentertheIntromenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-CancelstheINT function.
•ALL-Playsfirst10secondsofeachtrack.
•FOLDER-Playsfirst10secondsofeachtrackinfolder.
Note:Folderrepeat,randomandintrooptionsonlyfunction
onMP3/WMAdiscsrecordedwithmorethanonefolder.

17
XHD6430 OPERATION
CD Player Operation - MP3/WMA Files
Thefollowingtypesofdiscs/filesarecompatible:
•CD-ROM(ISO),CD-R,CD-RW
•CD-DA
•MP3data
•WMAdata
Thefollowingtypesofdiscs/filesarenotcompatible:
•WMAfilesthatareprotectedbyDRM(DigitalRights 
 Management).
•WMAlosslessformat
•DiscsrecordedwithTrackAtOnceorpacketwriting
•MP3PROformat
•MP3playlists
•WAVformat
MP3/WMAplaybacksequenceisbasedonrecordedorder
offilesandbeginsintherootfolderofthedisc.Anyempty
foldersorfoldersthatdonotincludeMP3/WMAfilesare
skipped.Thisunitmaynotplayfilesintheordertheywere
recordedin.Refertoyourrecordingsoftware’suser’s
manual for more information.
•ISO9660level1
•ISO9660level2
•YellowBookMODE1
•YellowBookMODE2FORM1
•Multisession
•Maximumfoldersandfiles-256
•Maximumfolderlevels-8
•MPEG-1/2/2.5AudioLayer-3
ISO9660standards:
•Maximumnestedfolderdepthis8(includingtheroot
folder).
•Validcharactersforfolder/filenamesarelettersA-Z
 (allcaps),numbers0-9,and“_”(underscore).Some
 charactersmaynotbedisplayedcorrectly,dependingon
 thecharactertype.
•ThisdevicecanplaybackdiscsinJoliet,Romeo,andother
 standardsthatconformtoISO9660.MP3/WMAwritteninthe
 formatsotherthantheabovemaynotplayand/ortheirfile
 namesorfoldernamesmaynotbedisplayedproperly.
Media Compatibility
Playback Order
Compatible Recording
Formats

18
CD Player Operation - MP3/WMA Files
XHD6430 OPERATION
AninternalbufferprovidesESP(ElectronicSkipProtection)
tovirtuallyeliminateskipping.
Whenplayingadiscrecordedwithregularaudiofiles
(CD-DAor.WAV)andMP3/WMAfiles,theunitwillplaythe
MP3/WMAfilesonly.
OnlyMP3fileswithfilenameextension(.mp3)canbeplayed.
OnlyWMAfileswithfilenameextension(.wma)canbe
played.
Donotattempttoplaydiscswhichcontainnon-MP3/WMA
fileswiththeMP3/WMAextension.
8kHz~48kHz
32kHz~48kHz
32kbps~320kbpsconstant
Variable bit rates
32kbps~192kbpsconstant
Variable bit rates
Note:
Somefilesmaynotplayorbedisplayedcorrectly,
dependingonsamplingratesandbitrates.
ID3tagsVersion1.0to2.0
Forbestresults,usethefollowingsettingswhenburning
anMP3disc:
•128kbpsorhigherconstantbitrate
•44.1kHzorhighersamplingfrequency
Forbestresults,usethefollowingsettingswhenburninga
WMAdisc:
•64kbpsorhigherconstantbitrate
•32kHzorhighersamplingfrequency
Additional MP3/WMA
Information
Sampling Frequency
Rates
MP3
WMA
Transfer Bit rates
MP3
WMA
MP3 Tag Display
Recommended Settings

19
XHD6430 OPERATION
PlayMP3/WMAfilesfrommostmassstoragedevicesby
connectingthemtotheXHD6430'sUSBport.
WhenaUSBdeviceisfirstconnected,“READING”will
appearinthedisplayandplaybackwillbeginmomentarily.
Dependingonthenumberoffilesandfolders,itmaytake
severalsecondsforthedevicetobeginplaying.Ifnovalid
MP3/WMAfilesaredetected,“NOFILE”willbedisplayed
andthelastmodewillberesumed.
Press TRACK
ll
toskiptothebeginningofthenext
track.PressTRACK
nn
toreturntothebeginningofthe
currenttrack.PressingTRACK
nn
againskipstothe
beginningoftheprevioustrack.
PressandholdTRACK
ll
or TRACK
nn
to fast
forwardorreverseatrack.
Press
l
/ II totemporarilystopUSBplayback.
Press
l
/ II againtoresumeplayback.
Press SELECTtoentertheUSBfile/foldersearchmode.
"USBSEARCH"willbedisplayed.Alistofallthefolders
fromtheUSBdevicewillbedisplayed.
Note:Anyfileslocatedintherootdirectorywillbelocatedin
thefoldernamed"ROOT".PressSELECTtoviewthefileson
therootfolder.
Turnthevolume knobtocyclethroughallthefoldersonthe
deviceandpressSELECTtochoosethedesiredfolder.The
listoffilesintheselectedfolderwillbedisplayed.Turnthe
volume knobtocyclethroughthelistoffiles.
Oncethedesiredsongisdisplayed,pressSELECTtobegin
playbackofthedesiredsong.
PressingESCwhenviewingthecontentsofafolderwill
returntothelistoffoldersontheUSBdevice.PressESC
againtoexitthesearchmenu.
Connecting a USB Device
(sold separately)
Playing Music
Track Select
Fast Forward and Reverse
Pause
File Search
Step 1
Step 2
Step 3
USB Operation - MP3/WMA Files

20
Whenafileisaccessed,theclockandelapsedtimewill
bedisplayed.PressDISPmomentarilytoselectfilename
(default),songtitle,artist,tracknumberorclock&elapsed
time.
"NOTITLE"willbedisplayedifnosongtitleinformationis
available.
"NOARTIST"willbedisplayedifnoartistinformationis
available.
Thisiconwillilluminatewhenthesongtitleisdisplayed.
Thisiconwillilluminatewhentheartistnameisdisplayed.
Thisiconwillilluminatewhenthefoldernameisdisplayed.
Thisiconwillilluminatewhenthefilenameisdisplayed.
Press toselectthepreviousfolder.
Press toselectthenextfolder.
Note:FolderaccessisonlyavailableonUSBdeviceswith
morethanonefolder.
Press RPT toentertheRepeatmenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-PlaysalltracksonUSBdevice.
•TRACK-Continuouslyrepeatsselectedtrack.
•FOLDER-Continuouslyrepeatsallfilesinselectedfolder.
Press RDM toentertheRandommenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-CancelstheRDM function.
•ALL-Playsalltracksinrandomorder.
•FOLDER-Playsalltracksinfolderinrandomorder.
Note:Randommodeisretainedinmemorywhenselecting
betweentuner,CD,AUXandUSBmodesandwhentheunitis
turnedon/off.
Press INT toentertheIntromenu,thenturnthevolume knob
toselectoneofthefollowingoptions:
•OFF-CancelstheINT function.
•ALL-Playsfirst10secondsofeachtrack.
•FOLDER-Playsfirst10secondsofeachtrackinfolder.
USB Operation - MP3/WMA Files
XHD6430 OPERATION
(LINE 1) FILE NAME ELAPSED TIME
CLOCK
TRACK NUMBER
TOTAL TRACKS
ARTIST
SONG TITLE
FOLDER NAME
(LINE 2)
Displaying Information
Title Icon
Artist Icon
Folder Icon
File Icon
Folder Access
Repeat
Random
Intro
