Dual XC4100 Operating instructions

INSTALLATION/OWNERS MANUAL
AM/FM/CASSETTE Receiver
XC4100

KEYS
XC4100 INSTALLATION
Preparati n
Please read entire manual before installation.
Bef re Y u Start
• Disconnect negative battery terminal.
(consult a qualified technician for instructions)
• Avoid installing the unit where it would be subject to high temperatures,
such as from direct sunlight, or where it would be subject to dust, dirt or
excessive vibration.
Getting Started
•Insert the supplied keys into the slots as shown, and slide the unit out of the
mounting sleeve.
•DIN mounting procedure:
Install mounting sleeve into dash opening, bending tabs to secure.
•2-Shaft mounting procedure:
Remove knobs, faceplate and DIN mounting adapters from unit.
Install unit into kit or dash opening from behind. Adjust rear shaft nuts to
correct depth. Install faceplate and knobs.
•Certain vehicles may require an installation kit and/or wiring harness
adapter (sold separately).
2

KNOBS
SHAFT NUTS
MOUNTING SLEEVE
DIN ADAPTERS
DASH OPENING
OR INSTALLATION KIT
KNOBS
SHAFT NUTS
XC4100 INSTALLATION
Installati n
3
Typical 2-Shaft Mounting
Typical DIN Mounting

Rem te Turn-On
C nnect t amplifier r p wer
antenna. Insulate wire if n t used.
RCA Cable
(s ld separately)
Antenna
C nnect r
BLUE
Rear Preamp Output
C nnect t amplifier RCA Input
GREY
Gr und
C nnect t vehicle
chassis gr und.
BLACK
Access ry
C nnect t existing igniti n
circuit r switched 12 v lt s urce.
RED
Right
Gray/Black (-)
Gray (+)
Left
White/Black (-)
White (+)
AMP
3 AMP
AGC Fuse
.5 AMP
AGC Fuse
XC4100 INSTALLATION
Wiring
Diagram
4
FUSES When replacing fuses, make sure new
fuse is the correct type and amperage. Using an
incorrect fuse could damage radio. The XC4100 uses
one 3 amp AGC fuse (Ignition) and one .5 amp AGC
fuse (Remote turn-on) located in-line.

XC4100 OPERATION
C ntr l L cati ns
5
Power/Volume
Band
Stereo Indicator
FM Indicator
Mono/Stereo
Tuning
Balance
Bass Boost
Auxiliary Input
Eject/Fast Forward
8910
1
1
2
38
4
5
6
9
10
7
2 5 6
3 4 7
General Operati n
Turn POWER knob clockwise to turn the unit on. Turn
POWER knob counter-clockwise until a click is heard to
turn the unit off.
Insert a cassette to begin playback.
Turn POWER knob clockwise or eject cassette to begin
or resume tuner operation.
Insert a standard 3.5 mm (line or headphone output) plug into
the auxilary input to listen to a portable CD or MP3 player.
P wer On/Off
Cassette M de
Tuner M de
Auxilary M de

XC4100 OPERATION
6
General Operati n (c ntinued)
Press BASS to activate and deactivate bass boost
curve. Activating this feature will enhance the bass
frequencies when listening to music at low volumes.
Adjust volume by turning VOL knob clockwise or
counter-clockwise.
Adjust balance by turning BAL knob clockwise or
counter-clockwise.
Bass B st
V lume
Balance
Cassette Player Operati n
Insert a standard audio cassette into the cassette slot.
The cassette will automatically begin playback.
Press the EJECT button all the way in to stop and eject
the cassette. The unit will change to tuner mode.
Press the EJECT button half way in to fast forward.
Press EJECT again to resume playback.
Insert Cassette
Eject
Fast F rward
Tuner Operati n
Turn TUNE knob to select desired station.
Press MO/ST during FM tuner operation to select
mono or stereo reception of the broadcast signal. The
FM stereo LED indicator iluminates during FM stereo
reception.
Press BAND to select between FM and AM bands. The
FM LED indicator illuminates when FM is selected.
Tuning
FM M n /Stere
Band

XC4100 WARRANTY
7
Limited One-Year Warranty
This warranty gives you specific legal rights. You
may also have other rights which vary from
state to state.
Namsung America Inc. warrants this product to
the original purchaser to be free from defects in
material and workmanship, under normal
conditions, for a period of one year from the
date of the original purchase.
Namsung America agrees, at our option, during
the warranty period, to repair any defect in
material or workmanship or to furnish an equal
new or renewed product in exchange without
charges, subject to verification of the defect or
malfunction and proof of the date of purchase.
During the One-Year Warranty Period: For One
Year from the date of purchase, your product
will be replaced with a new, renewed or
comparable product (whichever is deemed
necessary) if it becomes defective or
inoperative. This is done without charge to you.
Replacement products are warranted for the
balance of the original warranty period.
Wh is c vered? This warranty is extended to
the original retail purchaser for products
purchased and used in the U.S.A., in the 48
contiguous states ONLY.
What is c vered? This warranty covers all
defects in material and workmanship in this
product. The following are not covered:
installation/removal costs, damage resulting
from accident, misuse, abuse, neglect, product
modification, improper installation, incorrect
line voltage, unauthorized repair or failure to
follow instructions supplied with the product, or
damage occurring during return shipment of the
product.
What t d ? If the product requires warranty
service, you must prepay the initial shipping
charges. DUAL will pay the return shipping
charges if the product is returned to an address
within the USA.
Namsung America Inc.
Attn: Returns Center
21318 64th Ave. South
Kent, WA 98032 U.S.A.
Toll Free: 1-866-626-7863
Exclusion of Certain Damages: This warranty is
exclusive and in lieu of any and all other
warranties, expressed or implied, including
without limitation the implied warranties of
merchantability and fitness for a particular
purpose and any obligation, liability, right, claim
or remedy in contract or tort, whether or not
arising from the company’s negligence, actual
or imputed. No person or representative is
authorized to assume for the company any
other liability in connection with the sale of this
product. In no event shall the company be liable
for indirect, incidental or consequential
damages.

Namsung America Inc.
21318 64th Ave. South
Kent, WA 98032
Toll Free: 1-866-626-7863
©2003 Namsung America, Inc.
EVOK0403-V01
Specificati ns
Signal-to-noise: >40dB
Frequency response: 60Hz-6.3kHz, ±3dB
Tuning range: 87.5MHz-107.9MHz
Frequency response: 30Hz-13kHz, ±3dB
Tuning range: 530kHz-170kHz
Frequency response: 80Hz-2kHz, ±3dB
Total system power: 30 Watts Peak
Power output: 15Wx2 @ 14.4 VDC
Power supply: 11-16 VDC, negative gr und
Speaker output impedance: 4 hms
Fuses: 3 amp fast bl w AGC, .5 amp fast bl w AGC
Dimensions: 7.5" x 7" x 2.38" (191 x 178 x 60 mm)
Specifications subject to change without notice
Cassette Player
FM Tuner
AM Tuner
General
