Dual XDMA7650 Operating instructions

INSTALLATION/OWNER'S MANUAL
AM/FM/CD/MP3/WMA Receiver with USB,
Control for iPod® and 2-Step Motorized Face
XDMA7650

2
TYPICAL FRONT-LOAD DIN MOUNTING METHOD
REMOVAL KEYS
MOUNTING SLEEVE
XDMA7650 INSTALLATION
Preparation
Please read entire manual before installation.
Before You Start
•Disconnectnegativebatteryterminal.Consultaqualifiedtechnicianforinstructions.
•Avoidinstallingtheunitwhereitwouldbesubjecttohightemperatures,suchasfrom
directsunlight,orwhereitwouldbesubjecttodust,dirtorexcessivevibration.
Getting Started
•Removetrimringfromunit,
•Remove2transitscrewslocatedontopoftheunit.
•Insertthesuppliedkeysintotheslotsasshown,andslidetheunitoutofthemounting
sleeve.
•Installmountingsleeveintoopening,bendingtabstosecure.
•Connectwiringharnessandantenna.Consultaqualifiedtechnicianifyouareunsure.
•Certainvehiclesmayrequireaninstallationkitand/orwiring
harnessadapter(soldseparately).
•Testforcorrectoperationandslideinto
mountingsleevetosecure.
•Snaptrimringintoplace.

3
FUSE
Whenreplacingthefuse,
makesurenewfuseisthe
correcttypeandamperage.
Usinganincorrectfuse
coulddamagetheradio.
TheXDMA7650usesone
10ampATMfuselocated
besidethewiringconnector.
XDMA7650 INSTALLATION
Wiring Diagram
BLUE
Subwoofer Preamp Output
BLACK
Front Preamp Output
Steering Wheel Interface Input
PAC SWI-PS required
Antenna Connector

4
XDMA7650 OPERATION
Control Locations - Receiver
2 31 4
11
12
131415
20
Audio/Menu
Select/Power
Mute
Loud
Preset1/Repeat
Preset2/Random
Preset3/Intro
Eject
USBInput
AuxiliaryInput
1
2
3
4
5
6
7
8
9
Open
Preset6/FolderUp
Preset5/FolderDown
Preset4/Play/Pause
Tune/TrackUp
Tune/TrackDown
Source
Display
Reset
Band/Escape
13
14
15
16
17
18
11
12
10
75 6 8 9
16
10
19
17
19
20
18

5
XDMA7650 OPERATION
Control Locations - Remote
1 2
4
3
19
17
18
20
21
16
5
6
7
8
9
13
15 14
10
12
11
Loudness
Open
Mute
Display
EQ
Preset5/FolderDown
Preset4/Play/Pause
Preset1/Repeat
Band/Escape
Tune/TrackDown
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Source
VolumeUp
Audio/Menu
Select/Power
Tune/TrackUp
VolumeDown
Scan/PS
Preset2/Random
Preset3/Intro
Preset6/FolderUp
Local
20
21

6
XDMA7650 OPERATION
Press oranyotherbutton(exceptEJECTorOPEN)toturn
theuniton.Pressandhold for3secondstoturntheunit
off.
Press SOURCEtoselectbetweenAM/FM,CDplayer,USB,
operationofiPodandauxiliaryinput.Modesofoperationare
showninthedisplay.
NOTE:CD,USBandoperationofiPodmodeswillnotappear
unlessaCDisinsertedorUSB/iPoddevicesareconnected.
Inserta3.5mmconnectorintothefrontpanelAUXport.
Connecttheotherendofthe3.5mmconnectortothe
headphoneoutputofanaudiodevice,MP3player,etc.Press
SOURCEtoselectAUXmode.
Thesteeringwheelinterfaceinputlocatedonthebackof
theheadunitallowsconnectiontothePacific Accessory
Corporation (PAC) SWI-PSinterfacemodule(sold
separately).Visitwww.pac-audio.comfordetails.
Toconfiguresteeringwheelcontrols,followtheinstructions
providedwiththePAC SWI-PSinterfacemodule.After
installingtheinterfacemodule,insertthemodule's3.5mm
jackintotheportonthebackoftheheadunit.
Adjustvolumeusingvolumeknob(00-46).
Press DISPLAYtoselectbetweenclockanddifferenttypesof
information,suchasradiofrequency,CDtrack/elapsedtime
orMP3/WMAsonginformation.
Press RESETuponinitialinstallationorifabnormal
operationoccurs.Resetbuttonislocatedonthefrontpanel.
Withtheuniton,pressandholdDISPLAYuntiltheclock
beginstoflash,thenrelease.PressTUNE
nn
toadjustthe
hoursandTUNE
ll
toadjusttheminutes.PressDISPLAY
momentarilytosavetheselectedtime.
Theclockwilldisplay12-hourAM/PMtimeinUSAfrequency
spacingmode(PM10:00).InEuropeanfrequencyspacing
mode,theclockwilldisplay24-hourtime(22:00).
Power On/Off
Source
Auxiliary Input
Steering Wheel Interface
Input
Volume
Display
Reset
Set the Clock
12/24-hour Clock
General Operation

7
XDMA7650 OPERATION
General Operation - Setup Menu
Setup Menu PressandholdAUDIO/MENUformorethan3secondsto
accessthesetupmenu.PressAUDIO/MENUmomentarily
toselectbetweenthemenufunctionsandrotatethevolume
knob left/righttoadjustoractivatethedesiredfunction.
Menu Function Options Action
Auto Station
Store AUTOSTORE Press SELECTtoseekandsave6strongstationsinthe
currentband.(Tuner mode only)
Local/Distance
Tuning
LOCALOFF Activatesdistancetuning(inTunermodeonly).
LOCALON Activateslocaltuningforstrongstationreceptiononly.
Tuner
Frequency
Spacing
FREQUSA ProgramstheunittoUSAtunerspacing.
(200kHzforFMand10kHzforAM).(Tuner mode only)
FREQEUR ProgramstheunittoEuropeantunerspacing.
(50kHzforFMand9kHzforAM).(Tuner mode only)
Clock
Display
CLOCKOFF Programsunittonotdisplaytheclockwhenthepoweris
off.
CLOCKON Programsunittodisplaytheclockwhenthepowerisoff.
Auxiliary
Input
AUX-INON Enablesthefrontpanel3.5mmauxiliaryinput.
AUX-INOFF Disablestheauxiliaryinput.
Subwoofer
RCA output
SUBWFRON ActivatesthesubwooferRCAoutput.Subwoofercontrol
willbeavailableintheaudiomenu.
SUBWFROFF DisablesthesubwooferRCAoutput.
Beep
Confirmation
BEEPOFF Disablestheconfirmationbeep.
BEEPON Enablestheconfirmationbeep.
Programmable
Turn On Volume PRO-VOL# Programsunittoalwaysturnonataspecificvolume
(defaultisOFF).Anyvolumelevel1-46canbeselected.
Power on
Message
MESSAGEOFF Disablespoweronmessage.(example:GOODMORNING)
MESSAGEON Enablespoweronmessagetobedisplayed.
Scrolling
Option
SCROLL15
SEC
Programsunittoscrollinformationonceevery15
seconds(default).
SCROLLONCE Programsunittoscrollonce,thenshowfirst10
charactersondisplay.
SCROLLON Programsunittoscrollcontinuously.
SCROLLOFF Programsunittoshowthefirst10charactersonthe
display.
Illumination
Dimmer
DIMMERHIGH Programsunittothebrightestilluminationlevel.
DIMMERMED Programsunittothemiddleilluminationlevel.
DIMMERLOW Programsunittothedimmestilluminationlevel.
Demonstration
Mode
DEMOOFF Disablesthedemonstrationmode.
DEMOON Enablesthedemonstrationmessage.

8
XDMA7650 OPERATION
Press AUDIOmomentarilytoselectbetweenBass,Treble,
Balance,Fader,EQ,SubwooferandSourceVolumeLevel.
Press AUDIO until BASSappearsthenrotatevolumeknob
left/righttoadjust(-6minimum/+6maximum).
Press AUDIO until TREBLEappearsthenrotatevolumeknob
left/righttoadjust(-6minimum/+6maximum).
Press AUDIO until BALappearsthenrotatevolumeknob
left/righttoadjust(BALLEFT12-BALRIGHT12).
BALEVENrepresentsequalbalance
Press AUDIO until FADERappearsthenrotatevolumeknob
left/righttoadjust(FADERFRONT12-FADERREAR12).
FADEVENrepresentsequalfader
Press AUDIOuntilEQappears.Rotatethevolumeknobleft/
righttoselectbetweenFLAT(default),POP,JAZZ,CLASSIC,
BEAT,ROCKandUSERequalizationcurves.PressSELECT
toconfirm.AnymanualadjustmenttotheBassorTreble
settingsareautomaticallysavedasUSER.
Press AUDIO until SUBappearsthenrotatevolumeknob
left/righttoadjust(0minimum/+12maximum).
* Note: Subwooferoptionwillnotappearifdisabledinthe
setupmenu.Refertopage7fordetails.
Thesourcevolumelevelcontrolallowsagainadjustment
foreachaudiosource:AM,FM,CD,AUX,USBandoperation
ofiPod.Setthesourcevolumelevelforeachmode,
dependingontherelativevolumeofeachaudiosource.
Tosetthesourcevolumelevel,pressAUDIOuntilSRC
LEVELappears.Afteronesecond,thecurrentmodewill
appearonthedisplay.Turnthevolumeknobtoadjust
theaudiolevelofthecurrentsource(-6minimum/+6
maximum).
Note: Onlythecurrentmodewillbeavailablefor
adjustment.Toadjustanothermodeofoperation,press
SOURCEuntilthedesiredmodeisselected,thensetthe
sourcevolumelevelforthatmode.
Audio
Bass
Treble
Balance
Fader
EQ
Subwoofer
Source Volume Level
General Operation
BASS TREBLE BALANCE FADER EQ SUBWOOFER* SOURCE LEVEL

9
XDMA7650 OPERATION
Seek Tuning
Manual Tuning
Band
Storing and Recalling
Station Presets
Press TUNE
nn
or TUNE
ll
formorethanonesecond
toseektothenextstrongstation.
Press TUNE
nn
or TUNE
ll
momentarilytochange
radiofrequencyupordownonestepatatime.Pressand
holdtoadvancequickly.
Press BANDtoselectbetweenFM1,FM2,FM3,AM1and
AM2bands.
Upto18FMstationsand12AMstationscanbestored.To
storeastation,selectthedesiredbandandstation.Press
andholdthedesiredpresetbutton(1-6)formorethan
2seconds.Whenstored,thepresetnumberwillappearin
thedisplay.Thestationcanberecalledanytimebypressing
thecorrespondingpresetbutton.
AM/FM Tuner Operation

10
XDMA7650 OPERATION
Insert CD
Eject CD
Track Select
Fast Forward and Reverse
Pause
Intro
Repeat
Random
CD-R/CD-RW Compatibility
Press EJECTtoaccesstheCDslot.Withthelabelfacing
up,insertastandardsizeCDintotheCDslot.TheCDwill
automaticallybeginplayback.
Press EJECTtoejecttheCD.Theunitwillchangeto
previousmodeofoperation.Ifthediscisnotremoved
within10seconds,theunitwillreloadthedisc.Theunit
doesnothavetobeturnedontoejectCD.
Press TRACK
ll
toskiptothebeginningofthenext
track.PressTRACK
nn
toreturntothebeginningofthe
currenttrack.PressingTRACK
nn
againskipstothe
beginningoftheprevioustrack.
PressandholdTRACK
ll
or TRACK
nn
tofastforward
orreverseatrack.
Press
l
/ II totemporarilystopCDplayback.
Press
l
/ II againtoresumeplayback.
Press INT toentertheIntromenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-CancelstheINT function.
•ALL-Playsthefirst10secondsofeachtrack.
Press RPT toentertheRepeatmenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-PlaysalltracksonCD.
•TRACK-Continuouslyrepeatsselectedtrack.
Press RDM toentertheRandommenu,thenturnthe
volumeknobtoselectoneofthefollowingoptions:
•OFF-CancelstheRDM function.
•ALL-Playsalltracksinrandomorder.
SomeCD-RsandCD-RWsmaybeincompatiblewiththis
unit,dependingonmediatypeandrecordingmethod.In
addition,thefollowingCDsmaybeincompatiblewiththis
unit:
CDsexposedtoextremetemperaturesordirectsunlight
forextendedperiodsoftime,CDsrecordedinwhicha
recordingsessionfailedorare-recordingwasattempted
and,orencryptedorcopy-protectedCDswhichdonot
conformtotheaudioCD-DAredbookrecordingstandard.
CD Player Operation

11
XDMA7650 OPERATION
CD Player Operation - MP3/WMA Files
Playing an MP3/WMA Disc
Displaying Information
Title Icon
Artist Icon
Folder Icon
File Icon
Character Support
WhenanMP3/WMAencodeddiscisfirstinserted,
“READING”willappearinthedisplay.Dependingonthe
numberoffilesandfolders,thismaytakeseveralseconds.
Press DISPLAYtoselectbetweentitle(default),artist,file
name,foldername,tracknumber,andclock/elapsedtime.
“NOID3TAG”willbedisplayediftheMP3filecontainsno
ID3taginformation.
“UNKNOWN”willbedisplayediftheWMAfilecontainsno
WMAtaginformation.
“ROOT”willbedisplayedifthedirectorynameofaroot
folder is not labeled.
Thisiconwillilluminatewhenthesongtitleisdisplayed.
Thisiconwillilluminatewhentheartistnameisdisplayed.
Thisiconwillilluminatewhenthedirectorynameis
displayed.
Thisiconwillilluminatewhenthefilenameisdisplayed.
Maximumcharacterdisplayinformation
•Trackname–32charactermaximum
•Directoryname–32charactermaximum
•*Songtitle–30charactermaximum
•*Artistname–30charactermaximum
*SongtitleandArtistNamewillonlybedisplayedifincluded
withtheMP3/WMAfile.
WhenreferringtoMP3/WMAplayback,thefollowingterms
aresynonymous:
•Filenameandtrackname
•Foldernameanddirectoryname

12
XDMA7650 OPERATION
CD Player Operation - MP3/WMA Files
Folder/File Search Mode
Step 1
Step 2
Step 3
Step 4
MP3/WMACDmodefeaturesafileandfoldersearchmode.
Thissearchallowsnavigatingthroughfolderstofinda
specificMP3orWMAfileforplayback.
Press SELECT."MP3CDSEARCH"willappear,thena
listofthefilesinthecurrentlyselecteddirectorywillbe
accessible.
Turn the volume knob.Thelistofsubfoldersandfilesinthe
currentfolderwillcycle.Turningthevolumeknobleftwill
cycletothebeginningofthefolder/filelist.Anysubfolders
willbelistedatthebeginningofthelist,followedbyany
files.
willilluminatewhenafolderishighlighted.
willilluminatewhenafileishighlighted.
Navigate to the desired folder and file.
•Togouponefolderlevel,pressESConce.
•Toviewthecontentsofahighlightedfolder,press
SELECT.
Note:the"FOLDERUP"optionmayalsobeselectedto
navigateuponefolderlevel.
Press SELECTtobeginplayingtheselectedMP3/WMAfile.
Note: Press ESCfromtherootdirectorytoexitsearchmode.

13
XDMA7650 OPERATION
CD Player Operation - MP3/WMA Files
Folder Access
Repeat
Random
Intro
Presstoselectthepreviousfolder.
Presstoselectthenextfolder.
*FolderaccessisonlyavailableonMP3/WMAdiscsrecorded
withmorethanonefolder.
Press RPT toentertheRepeatmenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-PlaysalltracksonCD.
•TRACK-Continuouslyrepeatsselectedtrack.
•FOLDER-Continuouslyrepeatsallfilesinselectedfolder.
Press RDM toentertheRandommenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-CancelstheRDM function.
•ALL-Playsalltracksinrandomorder.
•FOLDER-Playsalltracksinfolderinrandomorder.
Note:Randommodeisretainedinmemorywhenselecting
betweenothermodesandwhentheunitisturnedon/off.
Press INT toentertheIntromenu,thenturnthevolume knob
toselectoneofthefollowingoptions:
•OFF-CancelstheINT function.
•ALL-Playsfirst10secondsofeachtrack.
•FOLDER-Playsfirst10secondsofeachtrackinfolder.
Note:Folderrepeat,randomandintrooptionsonlyfunction
onMP3/WMAdiscsrecordedwithmorethanonefolder.

14
XDMA7650 OPERATION
CD Player Operation - MP3/WMA Files
Thefollowingtypesofdiscs/filesarecompatible:
•CD-ROM(ISO),CD-R,CD-RW
•CD-DA
•MP3data
•WMAdata
Thefollowingtypesofdiscs/filesarenotcompatible:
•WMAfilesthatareprotectedbyDRM(DigitalRights 
 Management).
•WMAlosslessformat
•DiscsrecordedwithTrackAtOnceorpacketwriting
•MP3PROformat
•MP3playlists
•WAVformat
MP3/WMAplaybacksequenceisbasedonrecordedorder
offilesandbeginsintherootfolderofthedisc.Anyempty
foldersorfoldersthatdonotincludeMP3/WMAfilesare
skipped.Thisunitmaynotplayfilesintheordertheywere
recordedin.Refertoyourrecordingsoftware’suser’smanual
for more information.
•ISO9660level1
•ISO9660level2
•YellowBookMODE1
•YellowBookMODE2FORM1
•Multisession
•Maximumfoldersandfiles-256
•Maximumfolderlevels-8
•MPEG-1/2/2.5AudioLayer-3
ISO9660standards:
•Maximumnestedfolderdepthis8(includingtherootfolder).
•Validcharactersforfolder/filenamesarelettersA-Z
 (allcaps),numbers0-9,and“_”(underscore).Some
 charactersmaynotbedisplayedcorrectly,dependingon
 thecharactertype.
•ThisdevicecanplaybackdiscsinJoliet,Romeo,andother
 standardsthatconformtoISO9660.MP3/WMAwritteninthe
 formatsotherthantheabovemaynotplayand/ortheirfile
 namesorfoldernamesmaynotbedisplayedproperly.
Media Compatibility
Playback Order
Compatible Recording
Formats

15
XDMA7650 OPERATION
CD Player Operation - MP3/WMA Files
AninternalbufferprovidesESP(ElectronicSkipProtection)to
virtuallyeliminateskipping.
Whenplayingadiscrecordedwithregularaudiofiles
(CD-DAor.WAV)andMP3/WMAfiles,theunitwillplaythe
MP3/WMAfilesonly.
OnlyMP3fileswithfilenameextension(.mp3)canbeplayed.
OnlyWMAfileswithfilenameextension(.wma)canbeplayed.
Donotattempttoplaydiscswhichcontainnon-MP3/WMA
fileswiththeMP3/WMAextension.
8kHz~48kHz
32kHz~48kHz
32kbps~320kbpsconstant
Variable bit rates
32kbps~192kbpsconstant
Variable bit rates
Note:
Somefilesmaynotplayorbedisplayedcorrectly,
dependingonsamplingratesandbitrates.
ID3tagsVersion1.0to2.0.
ThismodelwillnotdisplayID3Version2.0orgreatertags.
Forbestresults,usethefollowingsettingswhenburningan
MP3disc:
128kbpsorhigherconstantbitrate
44.1kHzorhighersamplingfrequency
Forbestresults,usethefollowingsettingswhenburninga
WMAdisc:
64kbpsorhigherconstantbitrate
32kHzorhighersamplingfrequency
Additional MP3/WMA
Information
Sampling Frequency Rates
MP3
WMA
Transfer Bit rates
MP3
WMA
MP3 Tag Display
Recommended Settings

16
XDMA7650 OPERATION
USB Operation - MP3/WMA Files
PlayMP3/WMAfilesfrommostmassstoragedevicesby
connectingthemtotheXDMA7650'sUSBport.
WhenaUSBdeviceisfirstconnected,“READING”will
appearinthedisplayandplaybackwillbeginmomentarily.
Dependingonthenumberoffilesandfolders,itmaytake
severalsecondsforthedevicetobeginplaying.Ifnovalid
MP3/WMAfilesaredetected,“NOFILE”willbedisplayed
andthelastmodewillberesumed.
Press TRACK
ll
toskiptothebeginningofthenext
track.PressTRACK
nn
toreturntothebeginningofthe
currenttrack.PressingTRACK
nn
againskipstothe
beginningoftheprevioustrack.
PressandholdTRACK
ll
or TRACK
nn
to fast
forwardorreverseatrack.
Press
l
/ II totemporarilystopUSBplayback.
Press
l
/ II againtoresumeplayback.
Press SELECTtoentertheUSBfile/foldersearchmode.
"USBSEARCH"willbedisplayed.Alistofallthefolders
fromtheUSBdevicewillbedisplayed.
Note:Anyfileslocatedintherootdirectorywillbelocatedin
thefoldernamed"ROOT".PressSELECTtoviewthefileson
therootfolder.
Turnthevolume knobtocyclethroughallthefoldersonthe
deviceandpressSELECTtochoosethedesiredfolder.The
listoffilesintheselectedfolderwillbedisplayed.Turnthe
volume knobtocyclethroughthelistoffiles.
Oncethedesiredsongisdisplayed,pressSELECTtobegin
playbackofthedesiredsong.
PressingESCwhenviewingthecontentsofafolderwill
returntothelistoffoldersontheUSBdevice.PressESC
againtoexitthesearchmenu.
Note:DuetodifferencesinUSBdevicetransferspeeds,itis
recommendedtolimiteachfoldertolessthan30songs.
Connecting a USB Device
(sold separately)
Playing Music
Track Select
Fast Forward and
Reverse
Pause
File Search
Step 1
Step 2
Step 3

17
XDMA7650 OPERATION
USB Operation - MP3/WMA Files
Whenafileisaccessed,theclockandelapsedtimewillbe
displayed.PressDISPLAYmomentarilytoselectbeween
artist,songtitle,filename,foldername,tracknumberand
clock/elapsedtime.
"NOTITLE"willbedisplayedifnosongtitleinformationis
available.
"NOARTIST"willbedisplayedifnoartistinformationis
available.
Thisiconwillilluminatewhenthesongtitleisdisplayed.
Thisiconwillilluminatewhentheartistnameisdisplayed.
Thisiconwillilluminatewhenthefoldernameisdisplayed.
Thisiconwillilluminatewhenthefilenameisdisplayed.
Press toselectthepreviousfolder.
Press toselectthenextfolder.
Note:FolderaccessisonlyavailableonUSBdeviceswith
morethanonefolder.
Press RPT toentertheRepeatmenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-PlaysalltracksonUSBdevice.
•TRACK-Continuouslyrepeatsselectedtrack.
•FOLDER-Continuouslyrepeatsallfilesinselectedfolder.
Press RDM toentertheRandommenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-CancelstheRDM function.
•ALL-Playsalltracksinrandomorder.
•FOLDER-Playsalltracksinfolderinrandomorder.
Note:Randommodeisretainedinmemorywhenselecting
betweenothermodesandwhentheunitisturnedon/off.
Press INT toentertheIntromenu,thenturnthevolume knob
toselectoneofthefollowingoptions:
•OFF-CancelstheINT function.
•ALL-Playsfirst10secondsofeachtrack.
•FOLDER-Playsfirst10secondsofeachtrackinfolder.
Displaying Information
Song Title Icon
Artist Icon
Folder Icon
File Icon
Folder Access
Repeat
Random
Intro

18
XDMA7650 OPERATION
USB Operation - MP3/WMA Files
Maximumcharacterdisplayinformation
•Trackname–32charactermaximum
•Directoryname–32charactermaximum
•*Songtitle–30charactermaximum
•*Artistname–30charactermaximum
*Songtitleandartistnamewillonlybedisplayedifincluded
withtheMP3/WMAfile.
Thefollowingtypesoffilesarecompatible:
•MP3data
•WMAdata
Thefollowingtypesoffilesarenotcompatible:
•WMAfilesthatareprotectedbyDRM(DigitalRights 
 Management).
•WMAlosslessformat
•MP3PROformat
•MP3playlists
•WAVformat
MP3/WMAplaybacksequenceisbasedonorderthefiles
arecopiedtotheUSBdeviceandbeginsintherootfolder.
AnyemptyfoldersorfoldersthatdonotincludeMP3/WMA
filesareskipped.Dependingonyoursoftware,theplayback
ordermayvary.
•Maximumnumberoffiles:48896
•Maximumnumberoffolders:127plustherootdirectory
•Maximumnumberoffilesineachfolderandroot:382
•Maximumnumberoffolderlevels(subfolders):8
(7levelsplustheroot)
Note:Ifthenumberoffiles/foldersexceedsthemaximum
outlinedabove,theadditionalfiles/folderswillbeignored.
Note: Devicesthatexceedthemaximumnumberoffilesor
foldersmaynotfunctionproperly.
DuetothedifferencesofUSBdevices,somedevicesmay
notbecompatible.USBdevicesmustbe‘massstorage
class’andformattedtotheFATorFAT32filesystemin
ordertoensurecompatibility.
Character Support
Media Compatibility
Playback Order
Playback Capacity
USB Device Compatibility

19
XDMA7650 OPERATION
USB Operation - MP3/WMA Files
OnlyMP3fileswithfilenameextension(.mp3)canbeplayed.
OnlyWMAfileswithfilenameextension(.wma)canbeplayed.
Donotattempttoplaynon-MP3/WMAfileswiththeMP3/WMA
extension.
8kHz~48kHz
32kHz~48kHz
32kbps~320kbpsconstant
Variable bit rates
32kbps~192kbpsconstant
Variable bit rates
Note:Somefilesmaynotplayorbedisplayedcorrectly,
dependingonsamplingratesandbitrates.
ID3tagsVersion1.0to2.0
Note:IfaninvalidID3tagversionisdetected,"NOSUPPORT"
willscrollonthedisplay.
Additional MP3/WMA
Information
Sampling Frequency Rates
MP3
WMA
Transfer Bit rates
MP3
WMA
MP3 Tag Display

20
XDMA7650 OPERATION
Operation of iPod
TheXDMA7650featuresadirectUSBcontrolsystemfor
iPod.ToplaymusicfromaniPoddevice,connecttheUSB
cable(includedwithyouriPoddevice)totheXDMA7650's
USBport.Onceconnected,READINGwillappearinthe
display.Playbackwillbeginautomatically.Ifasongis
playingontheiPoddevicebeforeitisconnected,itwill
continuetoplay.
Press DISPLAYtoselectbetweenartist,songtitle,album,
elapsedtime,clockandtracknumber.
Connect an iPod Device
(Not Included)
Displaying Information
SearchItem MenuNavigation
Playlist Menu Playlists Songs
Artist Menu Artists Albums Songs
Album Menu Albums Songs
Song Menu Songs
Audiobooks Menu Audiobooks
Podcast Menu Podcasts
Seethebelowtableforalistofthesearchmenunavigationoptions.
Search Menu Functions
(step 1)
(step 2)
(step 3)
Press SELECToncetoenterthesearchmode.
Turnthevolumeknobtoselectbetweenplaylist,artist,
album,song, audiobook and podcast. Press SELECTtoselect
thedesiredsearchtype.
NavigatetothedesiredsongandpressSELECTtobegin
playbackofthatsong.Usethetablebelowforreference
whennavigatingthroughthemenuoptions.
Note: Press ESCtoaccessthepreviouslevel(uponelevel).
PressingESC fromthesearchmainmenuwillexitthe
search.
Search Mode
