Dual XDVDN8190 Operating instructions

XDVDN8190
INSTALLATION/OWNER'S MANUAL
DVD Multimedia Receiver with Internal GPS Navigation
and T Touch Screen Display
DVD
VI DEO rM
DD/oOLBYI
DIGITAL disc
DIGITAL AUDID lJplu
•
· ~. 0· ilvRtlas ,-
,
I Bluetooth®
~
umm
Safety Notes:
The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is asafety feature
to prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the
parking brake is engaged. It is illegal
in most states for the driver to view video while the vehicle is in motion.

XDVDN8190 PREPARATION ..
Table of Contents Page
Warning Statement. .......................................... .. 3
Safety Information/Precautions ................................. .. 4
Preparation/MountinglWiring ...................................
.. 5-7
Remote Control Overview . . . . . . . . .. 8
Control Locations -Monitor Closed. ............................... .. 9-11
Control Locations -Monitor Open 12
Control Locations - Remote ................................... .. 13-14
General Operation ............................................ .. 15-17
General Setup Menu. .......................................... .. 18-20
Setting the Clock. ......................................... .. 21
Anti-theft Code ............................................. .. 22
Screen Setup. .......................................... .. 23-26
ASP Configuration. ......................................... .. 27-28
AMlFM Tuner Operation. ...................................... .. 29-32
Warning Statement 33
DVD Operation .............................................. .. 34-42
DVD Setup .................................................. .. 43-49
CD Operation ................................................ .. 50-54
MP3IWMA Operation. ......................................... .. 55-58
SO Card. .................................................... .. 59-62
JPEG Operation 63-64
Media Compatibility Information 65-66
iPod Operation. .............................................. .. 67-72
Bluetooth Operation 73-76
Navigation Operation. .......................................... .. 77-83
Rear-Zone Audio Operation. . . .. . . . . . . . . .. . . .. . . . .. . . .. . . .. . . . .. .. 84
Warranty ................................................... .. 85
Specifications. ............................................. .. 86
Troubleshooting. ............................................... .. 87-89
2

.. XDVDN8190 PREPARATION
FA
WARNING A
Upon installation of this Monitor/DVD player ("'uniO into a vehicle, the driver of the vehicle
must not operate this unit by watching videos or playing video games while driving.
Failure to follow this instruction could lead to driver distraction which could result in
serious injury or
death to the vehicle's occupants orpersons outside the vehicle and/or
property
damage.
Several states prohibit the installation of monitors/DVD players if the screen is visible from
the driver's seat. If you reside in ajurisdiction which has enacted such alaw, this unit
must not be installed so that the screen is visible from the driver's seat. When installing
this unit in the front console/dashboard, the unit must be positioned so that it is facing the
front passenger seat only. Failure to follow this instruction could lead to driver distraction
which could result in serious injuryor death to the vehicle's occupants or persons outside
the vehicle and/or property damage.
This unit is designed so that it may be operated only when the vehicle is in "Park" and the
parking brake is fully engaged. To this end, this unit includes aparking brake lock-out
feature which prohibits the unit from operating if the vehicle is not in "Park" and/orthe
parking brake is not fully engaged. When installing this unit. the installer must connect
the parking brake detect wire ("'Yellow-Blue Lead1 to the parking brake mechanism in
order to make the parking brake lock-out feature operable. DO NOT simply ground the
parking brake detect wire to ametal portion of the vehicle. Failure to properly install
the parking brake lock-out feature could lead to driver distraction which could result in
serious injury or death to the driver's occupants orpersons outside the vehicle and/or
property damage.
Once the parking brake lock-out feature is installed, the owner/user must not attempt to
disruptlneutraUze the parking brake lock-out feature by (a) partially engaging the parking
brake and/or (b) purchasing/using any device orunit designed to send necessary brake
signals to the unit. Failure to follow these instructions could lead to driver distraction
which could result in serious injury or death to the driver's occupants or persons outside
the vehicle and/or property damage.
When operating this unit. keep the unit'svolume level low enough so that the vehicle's
occupants can heartraffic-related sounds such as poUce and emergency vehicles.
Failure to follow this instruction could lead to driver distraction which could result in
serious injuryor death to the vehicle's occupants or persons outside the vehicle and/or
property damage.
3

XDVDN8190 OPERATION ..
A Safety Information
Please read all instructions carefully before attempting to install or operate.
Due to its technical nature. it is highly recommended that your DUAL XDVDN8190 is installed by aprofessional
installer or an authorized dealer. This product is only for use in vehicles with 12VDC negative ground only.
Safety Notes:
The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is asafety feature to
prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the parking
brake is engaged. It is illegal in most states for the driver to view video while the vehicle is in motion.
To prevent damage orinjury:
1. Make sure to ground the unit securely to the vehicle chassis ground.
2. Do not remove the top or bottom covers of the unit.
3. Do not install the unit in a spot exposed to direct sunlight or excessive heat or the possibility of water splashing.
4. Do not subject the unit to excessive shock.
5. When replacing a fuse. only use a new one with the prescribed rating. Using a fuse with the wrong rating may
cause the unit to malfunction.
6. To prevent short circuits when replacing a fuse. disconnect the wiring harness first.
7. Use only the provided hardware and wire harness.
8. You cannot view video while the vehicle is moving. Find a safe place to park and engage the parking brake.
9. If you experience problems during installation. consult your nearest DUAL dealer.
1 O.lf the unit malfunctions. reset the unit as described on page 10 first. If the problem still persists. consult your
nearest DUAL dealer or call tech assistance @ 1-866-382-5476.
11.To clean the monitor. wipe only with adry silicone cloth or soft cloth. Do not use astiff cloth. or volatile solvents
such as paint thinner and alcohol. They can scratch the surface of the panel and/or remove the printing.
12.When the temperature of the unit falls (as in winter). the liquid crystal inside the screen will become darker
than usual. Normal brightness will return after using the monitor for awhile.
Additional
Notes:
1. When extending the ignition. battery or ground cables. make sure to use automotive-grade cables or other
cables with an area of 0.75mm (AWG 18) or more to prevent voltage drops.
2. Do not touch the liquid crystal fluid if the LCD is damaged or broken. The liquid crystal fluid may be hazardous
to your health or fatal. If the liquid crystal fluid from the LCD contacts your body or clothing. wash it off with soap
immediately.
This device complies with part 15 of the FCC rules and regulations.
Operation is subject to the following two conditions:
1) This device may not cause harmful interference. and
2) This device must accept any interference received. including interference that may cause undesired operation.
4

• XDVDN8190 INSTALLATION
Preparation
Please read entire manual before installation.
Before You Start
•Disconnect negative battery terminal. Consult aqualified technician for instructions.
•Avoid installing the unit where it would be subject to high temperatures. such as from direct sunlight. or where it
would be subject to dust. dirt or excessive vibration.
Getting Started
•Slide the unit out of the mounting sleeve.
•Install mounting sleeve into opening. bending tabs to secure.
•Connect wiring harness and antenna as shown on pages 6-7. Consult aqualified technician if you are unsure.
•Certain vehicles may require an installation kit and/or wiring harness adapter (sold separately).
•Test for correct operation and slide unit into mounting sleeve.
•Attach unit to mounting sleeve using supplied #1 Phillips screws.
•Snap
trim ring into place.
•Mount the
iplug™ adapter to any smooth clean surface using the supplied double-sided tape or Phillips head
screws.
HEX BOLT
..
.. ..
0°
0°
MOUNTING STRAP 0°0
0
~
o
o
~
MOUNTING SLEEVE
o
1-' -------~·I
Mounting sleeve opening dimensions
7-3/16" x2-1/16" (183 mm x 53 mm)
5
TYPICAL FRONT-LOAD DIN MOUNTING METHOD

XDVDN8190 INSTALLATION
Expanded Wiring Diagram - Inputs/Outputs
o
I
OP~l
MONITOR
--r-
Ground
REVERSE
LAMP; (
YELLOWIBLUE
REDACC
VIDEO OUT YELLOW
- ~
~l
~
0:1
GROUND BLACK
POWER ANTENNA BLUE
FUSE BATIERY +YELLOW
20A .
FRONT R
AMP REMOTE
REAR R
REAR L
BLUElWHITE
WHITE/BLACK
{~ GRAY
GRAY/BLACK
VIOLET
{! VIOLET/BLACK
GREEN
{~ GREEN/BLACK
-{ ~ WHITE FRONT L
FMAM
ANTENNA
oNAVIGATION ANTENNA
Ground
GPS Antenna Installation
Determine asuitable location for mounting the GPS antenna. For optimum reception. the antenna should be
mounted in the center of the vehicle roof with a minimum of 6" from any window. The antenna can also be
mounted to the rear trunk lid at least 4" from the rear window.
Do not install the antenna in alocation where it may obstruct the field of view to the skyline such as on the front
dashboard
or rear deck tray. Clean the mounting location thoroughly before attaching the antenna. The antenna
uses apowerful magnet and requires
no adhesive to apply.
Do not slide the antenna during positioning as damage to the painted surface can occur.
Once the antenna is mounted. carefully plan the cable route to the XDVDN8190.
Notes:
Do not install the GPS antenna inside the vehicle -as this will reduce reception significantly.
The antenna must
be mounted on ametallic surface for best performance.
Be careful not to pinch or twist the antenna cable.
Use a
grommet when running wires through any metal openings.
6

XDVD 8 90 INSTALLATION
Wiring Diagram - Option~l AN Connections
iPod
D
@
Game Console
~ I~_----IIOO
00
Front Amplifier
Overhead Monitor
Rear View
Camera
Headrest Monitor
~ -----\:~o Sub Amplifier
Rear Amplifier
Center Channel Amplifier
Wiring Notes:
Subwoofer output
The SUBWOOFER audio output (Blue RCA) is active in all audio modes and must be connected to an external
amplifier.
Center output
The CENTER audio output (Gray RCA) is only active in DVD 5.1 (6-channel) audio modes and must be connected to
an external amplifier.
Rear view camera
A rear view camera (not included) can be used with the CAMERA input.
Need help?
Call our Technical Service Hotline. [phone].
7

XDVD 8190 OPERATION
To first use the IR Remote control.
you must first pull the battery
insulation tape out
To insert or replace the battery:
IR Remote Preparation
Notes:
• Remove the battery if the remote will
not be used for a month or longer
• Remove and dispose of battery properly
'-..... ~:'/~
~ PULL
Remove the battery holder
Remove the battery from the battery
holder
PullOut
IIOOf
..rr!
.. (1)
VOl.'
VOl-
lifO
~~CH
.,
sa
k'C
ESC
A- PIC
~
OK
•
T,nE
""
ROOT
CJ
~
~ 44
~
•
Install the new battery
Make sure to keep the (+) side up
Insert the battery holder
K0 1111 t..1 tlf •
s'Je ') u's up
Push In
l.lw
CAUTION!!!
• Do not store battery with metalUc
objects or materials
8

XDVDN8190 OPERATION
Control Locations - Monitor Closed
CD Band
WAuto Store/Preset Scan
G) Secondary LCD
(j) Disc-In Indicator
®Display
WOpen/Close Monitor
(j) Eject
(j) Rotary Encoder/Enter
CV Reset
Secondary LCD Information 2
@ SO Card Slot
@Bluetooth Hands-Free Microphone
@Play/Pause/Scan
@ChanneUChapterlTrack Up/Fast Forward
@ChanneL/ChapterlTrack Down/Fast Reverse
@Mute
@Mode/Rear-Zone Audio On/Off
®Infrared Sensor
@PowerNoLume
34
··i·· J•• :: :•• :: ••••: , •• :::: .-f •••• : :: i··· :...: LOUD
ID iii
.. · .. .. ... ··· .. . ..
· .. . .
·. .. .
· ... ... .. ..
NOTE: Secondary LCD onLy functions when TFT monitor is closed.
9
1) LOC
2)ST
3) TIMEITRACK/CHAPTER
4) LOUD
LOCAL indicator. icon will be off when DISTANCE (OX) is seLected
STEREO radio station indicator
DispLays
TRACK time. TUNING frequency. MP3 103 info & CLOCK information.
LOUDNESS seLection indicator

XDVDN8190 OPERATION •
Control Functions - Monitor Closed
Band
AS/PS
(Auto Store/Preset Scan)
Secondary
LCD
Display
Press BAND to increment from
FM1. FM2. FM3. AM ~ FM1.
Press AS/PS momentarily to start station PRESET SCAN function.
Press AS/PS for 2seconds
to start AUTO STORE station preset function in
current BAND.
Additional
LCD for system information while monitor is closed.
When the monitor is closed. press
DISP to toggle display between
information available for the current mode. including clock. frequency and
track information.
When the monitor is open. press
DISP to toggle display between the current
mode and the navigation map. The navigation
SO card must be inserted to
use this feature.
Disc-In Indicator
Red =Disc inserted. Blue = No disc.
Open Monitor Press OPEN to open or close the monitor. Be careful not to not touch
or obstruct the monitor movement during the open/close sequence. or
permanent damage could occur.
Eject Press
~ once to eject disc.
Rotary Encoder/Enter Rotate clockwise/counter-clockwise
to select desired item. and press once
to ENTER.
Reset To resolve abnormal operation or if the unit is inoperable. press the
RESET button located on the front bottom-right corner of the unit. The unit
will reset the main processor (but not the default settings).
Note: Use the tip of a
pen to access the reset button. To restore the factory
default settings. refer to page
19.
SO Card Slot Insert SO card to access Navigation software. MP3. WMA or JPEG files. The
card will click into place when properly inserted. To remove card. press in on
the card. then release to eject.
Microphone
Use microphone for Bluetooth operation.
Play/Pause/Scan
In tuner mode. press SCAN to scan all strong stations in the current band.
In disc mode. press once for PAUSE. and "PAUSE" will appear in the display.
Press again to resume
PLAY.
ChanneVChapterlTrack Up
Fast Forward
ChanneVChapterlTrack Down
Fast Reverse
Press to select the next channeUchapter/track for playback.
Press and hold
to manual tune up or fast forward.
Press to select the previous channeUchapter/track for playback.
Press and hold to manual tune down or fast reverse.
10

• XDVDN8190 OPERATION
Control Functions - Monitor Closed
Mute IPress MUTE to silence audio output. "MUTE" will appear in the display. Press
MUTE again to restore audio at previous volume level.
11
Mode
Infrared Sensor
Power
Volume
Caution
Press MODE to select between the unit's available modes, including Tuner.
DVD (which includes CD and MP3IWMA playback), iPod. Camera. SD.
Navigation and Auxiliary inputs. Each time the MODE button is pressed the
next mode is chosen. Modes of operation are indicated
on the OSD. Hold the
MODE button for 3seconds to toggle the Rear-Zone audio feature on and off.
Direct the remote control towards the infrared sensor
to remotely control
numerous functions of the unit.
Press
PWR momentarily to turn the unit on. Press PWR for more than 3
seconds to turn the unit off.
When the monitor is in the open position, the left side rotary controls the
volume. which is visible as a
number from 0to 40. to the right of the volume
icon
.. ») displayed on the screen. When the icon is not displayed. turn the
rotary to display the volume level. Turning the rotary while the volume
is
muted will cancel the mute function.
Note:
To program the default volume level (only up to level 20) when the unit
is turned
on: turn the rotary to the desired level. then push and hold the rotary
for 3seconds to program the current volume level.
Monitor
OPEN Notes:
•The angle
can also be manually selected via the screen setup menu.
•The color of the
LCD monitorvaries between viewing angles. Select the angle
with the most optimum view for your location.
•The last position of the monitor can be saved in memory. When 'TFT Auto
Open" is selected in the General Setup Menu, the monitor will return to its
last position automatically the next time the unit is turned on.
•
Due to its highly technological design, the XDVDN8190 faceplate is NOT
removable. Do not attempt to remove the faceplate.
•Upon installation.
do not attempt to move the monitor by hand. Use the
ANGLE
Ji./T and OPEN buttons on the front panel or the remote control.
•
The unit will stop if it encounters any obstacles during the open/close
sequence. Ifthis occurs, remove the obstacle and press
OPEN again to
resume the monitor open/close sequence.

XDVDN8190 OPERATION
Co trol Locations and Functions - Monitor Open
CD
Band
CD
AS/PS
CD
Navigation
CD
Close Monitor
CD
Info/Picture
CD
Screen Angle Up
CD
Screen Angle Down
Band
AS/PS
(Auto Store/Preset Scan)
Navi
Close Monitor
Info/Picture
Screen Angle Up
Screen Angle Down
Press BAND to increment from FM1. FM2. FM3. AM ~ FM1.
Press AS/PS momentarily to start station PRESET SCAN function.
Press
AS/PS for 2seconds to start AUTO STORE station preset function in current
BAND.
When the monitor is open. press NAVI to toggle display between the current mode
and the navigation map.
The navigation SO card must be inserted to use this feature.
Press
CLOSE to open or close the monitor. Be careful not to not touch or obstruct the
monitor movement during the open/close sequence.
or permanent damage could
occur.
Press
to display DVD disc information in DVD mode. Holding this button for 3seconds
brings up the Brightness setting. which can
be adjusted by pressing the ANGLE A/T
buttons. turning the rotary encoder or by pressing the .... or ~ buttons on the main
remote control.
Note: The Brightness can not be adjusted in Bluetooth mode.
Press to adjust the angle of the screen upwards.
Press
to adjust the angle of the screen downwards.
12

XDVD 8190 OPERATION
Control Locations - Remote
CD
Mode @Info @Root
WMute ®Search @Repeat
CV
Open/Close @Key #0 @ChapterfTrack/Seek Tune Down
CD
Power @Band/Stop @ChapterfTrack/Seek Tune Up
CD
Key #1
@Audio Select @Fast Reverse/Manual Tune Down
CD
Key #2
@Escape @Fast Forward/Manual Tune Up
(j) Key
#3
@4-Way -
Up
®Zoom
(i) Volume
Up
@Menu @Audio
CD
Key #4
@Picture @Angle/Music mode (iPod only)
@Key
#5
@4-Way -Left @Sub-TitleNideo mode (iPod only)
@Key
#6
@OK/Play/Pause
@Volume Down ®4-Way -Right
@Key #7 @RepeatA-B
@Key
#8
@TItle Menu/JPEG thumbnail view/CD Scan
@Key #9 @4-Way -Down
•The remote control uses one 3volt Lithium CR2025 battery. For best performance. replace only with CR2025 or equivalent.
13

XDVDN8190 OPERATION.
Control Fundions - Remote
Mode Press once to incrementallyselect desired source.
Mute Press once to MUTE audio; press again to return audio.
Open/Close Press once to open monitor; press again to close the monitor.
Power Press
once to turn the unit on. press again to turn unit off.
Keys 0-9 Direct access chapter/track/preset station for current BAND.
Volume Up Increase VOLUME.
Volume Down Decrease VOLUME.
Info Displays DVD information.
Search Search function
in the DVD mode.
Band/Stop Press to increment BAND or to STOP while in DVD/MP3 mode.
Audio Select Enter
AUDIO Setup mode.
Escape Exit current menu.
4-Way-Up/Down/Left/Right Navigating system
and DVD/SD/JPEG menus.
Menu Enter the MAIN system menu.
BRIGHTNESS parameter setting for TFT.
OK Starts/pauses playback or confirms settings.
Repeat A-B Repeat playback from time frame A to time frame B.
Title Menu Enters the title menu on DVD; activates thumbnail view for JPEG.
Root Menu Enters the main menu of the DVD.
Repeat Repeats playback of current chapter/track orfolder.
ChapterfTrack
Down Selects the previous chapter/track for playback.
ChapterfTrack
Up Selects the next chapter/track for playback.
Fast Reverse Fast reverses the disc/SD/iPod content.
Fast Forward Fast forwards the disc/SD/iPod content.
Zoom Zooming in/out on an image from DVD disc or JPEG.
Audio Change the audio language for DVD disc playback.
Angle Selects between different angles (when available) for ascene/Selects
iPod
Music mode/Rotates JPG clockwise.
Sub-Title Language selection for subtitle/Selects
iPod Video mode.
14

XDVDN8 9 OPERATION
General Operation
Power On/Off
Mute
Mode
Optional Mode Selection
Volume
Audio Adjustment
(from front panel)
Press
PWR to turn the unit on. Hold for 3seconds to turn the unit off.
Press
MUTE to silence the audio; .-r will appear in the OSD (On Screen Display).
Press
MUTE again to cancel.
Press
MODE to select between Tuner. Disc. iPod. Bluetooth. Camera. SO.
Navigation and Auxiliary inputs. Modes of operation are indicated in the OSD
(On Screen Display). iPod. and SO card (optional) must be connected/inserted to
appear in the MODE selection string.
Press the top left corner of the screen
to display the OSD menu bar. Press
Tuner. Disc. iPod. Bluetooth. Camera.
SO. Navigation or Auxiliary in the MAIN
menu page
to select the desired source.
Adjust VOLUME using rotary encoder or the
VOL +/- buttons (00-40).
Press volume knob momentarily to enter the Audio Adjustment menu. Press
volume knob momentarily to advance
to desired parameter to be changed.
Turn volume knob
(j or Uto adjust to desired level. Press volume knob to
advance to next selection
or press and hold to exit.
2-Channel Audio Settings
.. __ mm1o ~
IiiiiI U User ~
_ 00.,1111,1111111111111
.. 001111111111111111111(1}
iiiiIII 00.,1111111111111" J 0fJ
(i1iIJ 00.,1111111111111111 rm
.. tIIlllllllllllllllllrH
_ rD Off r;
6-Channel Audio Settings
Item
A djustable Range
Master Volume 00 to 40
Front left Channel Volume ·10 to +10
Front Right Channel Volume
·10 to +10
Rear left Channel Volume -10 to +10
Rear Right Channel Volume
·10to +10
Center Channel Volume ·1010 +10
Subwoofer Volume
-1010+10
Note: 6-Channel audio is only
adjustable when "Full
6CH"
mode is selected. Refer to page
47 for more details.
15
Audio Adjustment
(from remote) Press the SEL button. Press the
.. or Tbuttons on the remote to select an
item to
be adjusted. Press .... or" to adjust the desired setting. Press the ESC
button on the remote control to exit the audio control menu.
Note: The Bass and Treble levels are only adjustable when
EQ is set to "User"
mode. The Loud function compensates for deficiencies in sound ranges at low
levels. When the Loud function is
on. LOUD is displayed in the 050.

DVDN8190 OPERATION
General Operation
INFO/PIC Press INFO momentarily to display DVD disc information.
Monitor Brightness Press and hold
PIC for 3seconds to change monitor BRIGHTNESS.
Turn volume knob 0or t> to adjust to desired level
(0 minimum120 maximum: lOis default).
CVBS Screen Controls While in iPod Video playback. Aux or Camera mode:
Press and hold
PIC for 3seconds to access PICTURE MENU.
Press PIC momentarily to step to next selection:
Sharpness Turn volume knob 0or
t> to adjust the sharpness.
(0 minimum/+20 maximum).
Color Turn volume knob 0
or t> to adjust the color.
(0 minimum/+20 maximum).
Contrast Turn volume knob 0
or t> to adjust the contrast.
(0 minimum/+20 maximum).
Brightness Turn volume knob 0
or t> to adjust the brightness.
(0 minimum/+20 maximum).
Tint Turn volume knob 0
or t> to adjust the tint.
(0 minimum/+20 maximum).
Note: Adjustments
to Sharpness. Color. Contrast. Brightness. or Tint are only
possible while
in either iPod video playback. Aux or Camera mode. Avideo
signal must
be present for adjusting the CVBS screen controls.
16

D D 19 OPERATION
General Operation - Main Menu
Main Menu Access There are two methods to access the MAIN menu:
•Press MENU button
on the remote control.
•Touch the upper left corner
of the touch screen.
17
Touch Access Buttons
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
12)
13)
14)
15)
16)
Rapid Dial Rotary Encoder
Touch to access AM/FM TUNER mode.
Touch to access NAVIGATION mode (Navigation
SD card must be inserted).
Touch to access
CD/DVD mode (CD/DVD must be inserted).
Touch
to access CAMERA mode. if optional camera isn't connected. "No Signal
Detected"
will be displayed.
Touch
to access BLUETOOTH mode (BLUETOOTH must be activated first). Refer
to page 73 for more details.
Touch to
RETURN to previous screen.
Touch to access iPod mode (optional iPod
must be connected to activate).
Touch
to enter STANDBY mode. Touch the screen again (or any button) to
resume normal operation.
Note: VOLUME level
can be controlled in STANDBY mode.
Touch
to access AUXILIARY AN INPUT mode.
Touch
to access SD mode (optional SD card must be inserted).
Touch to access
SCREEN SETUP menu.
Touch
to access GENERAL SETUP menu.
Touch
to access ASP Config menu.
Touch
to access CD/DVD SETUP menu. (CD/DVD must be inserted to function).
Touch
to access REAR ZONE menu.
Touch
to access MAIN menu.
The rotary encoder
on the right side can also control touch screen functions from
the main menu.
•Select desired function rotating clockwise
or counter-clockwise.
•Press to confirm/ENTER.

DVDN8190 OPERATION
GENERAL Setup - Menu
General Setup Menu •Press GENERAL icon to access the GENERAL setup mode.
•Select desired parameter you wish to change.
•Page
will return back to previous screen after 15 seconds of inactivity or
by pressing the RETURN button.
GENERAL Setup Menu
matrix -page 1
"til-
::,,. ....
:~> .. .,;.:'.
:,ro, :'
::"yE
1',:'~·i.t}i;E:W·':':'·:(")i-f' :("~
Et',,-·· :'''cj,
",<t·
>,
,:X~,·' ;~"'\<!
,.",~
A,
,:-
'.'.';.
·,i
':,,:
USA
S-Amerl
Radio USA S-Amer2 Set
to appropriate setting for your country
Europe
Clock adjust
AM
00:00 See adjusting the clock on page 21 for more details
Clock Mode 12Hr 12Hr
PM 6:00
24Hr
18:00
Camera Image Normal Normal Normal Image
Reverse
Mirror camera input image 180 degrees
Auto System
will auto detect NTSC or PAL
Video Format Auto
NTSC
For NTSC compatibility
PAL For PAL compatibility
On
TFT panel will automatically open when IGN is turned on
TFT Auto Open Off Off
TFT panel will not auto open when IGN is turned on
Manual
TFT will only open/close when OPEN button is pressed
18

XDVDN8190 OPERATION
GE ERAL Setup - Menu
General Setup Menu •Press GENERAL icon to access the GENERAL setup mode.
•Press
PAGE icon in the lower right comer.
•Select desired parameteryou wish to change.
•Page
will return back to previous screen after 15 seconds of inactivity or
by pressing the RETURN button.
GENERAL Setup Menu
matrix -page 2
_~~~~::' '~'I!. ~~~~~:._::' .. :~~, \~ ~:~'l: ".}",.~,:;~,~~:;~~. ~:t;.· , ~ ~'~'." ?-'. ·ty~:~ :~
P~~l¥::.:: :-Tt _. I.. q • .
~'~: .?~~ '~; .£~ ,~~ ?i.} _ :/~:~,'. \~,:';;f;li
c'
, ..
"
-,
Bluetooth Off Off Turns offthe Bluetooth functionality
On Enables Bluetooth functionality
Anti-theft
Code
0000
----
Must enter password to turn anti-theft on or off
Anti-theft active Off
On
System will require apassword if main battery power is
removed
for more then 40 seconds
Off
No password will be required if power is removed
Load Factory
Yes
Are you Load all factory parameters to their original settlings,
defaults sure? Notes: This
will not reset the anti-theft password.
Yes/Cancel Default anti-theft password is
0000.
19

XDVDN8190 OPERATION
GENERAL Setup - Adjusting Radio Frequency
Adjusting Radio Frequency
Step 1Touch top left corner of screen.
Step 2Touch GENERAL icon.
Step 3Touch USA.
Step 4Touch the setting for your region.
Step 5Touch RETURN to exit.
20
